USER GUIDE
198L CHEST FREEZER
(KAM198CHWZA)

2
CONTENTS
Safety and warnings ................... 03 - 04
Product overview...................................05
Installation/First time use...........06 - 07
Operation....................................... 08 - 09
Cleaning & maintenance............... 10 - 11
Troubleshooting...................................... 12
Specifications.......................................... 13
THIS USER GUIDE COVERS THE FOLLOWING MODELS
Kogan 198L Chest Freezer – White (KAM198CHWZA)

3
Thank you for buying this Kogan product. Please read all safety instructions before using
your fridge or freezer.
• This appliance is only intended for use within a domestic environment only.
• If the supply cord is damaged, it must be replaced by Kogan.com or an authorised service
agent on Kogan.com’s behalf.
• Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
• The appliance must be unplugged aer use and before carrying out user maintenance on
the appliance.
• WARNING: Keep ventilation openings in the appliance enclosure or in the built-in structure
clear of obstruction.
• WARNING: Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
• WARNING: Do not damage the refrigerant circuit.
• WARNING: Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
• WARNING: When positioning the appliance, ensure the power cord is not trapped or
damaged.
• WARNING: Do not locate multiple portable socket-outlets or portable power supplies at
the rear of the appliance.
• Do not use extension cords or ungrounded, （two prong（ adapters.
• Refrigerant and cyclopentane foaming material used for the appliance are flammable.
Therefore, when the appliance is scrapped, it shall be kept away from any fire source and
be recovered by a special recovering company with corresponding qualification other than
be disposed by combustion, so as to prevent damage to the environment or any other
harm.
Children:
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that they do not play with the appliance.
Unpacking:
• During transportation, protective packaging was used to protect the appliance against any
damage. Aer unpacking, please dispose of all elements of packaging in a way that will
not cause damage to the environment.
• CAUTION: During unpacking, the packaging materials (polythene bags, polystyrene
pieces, etc.) should be kept out of reach of children.
SAFETY AND WARNINGS
WARNING: RISK OF FIRE / FLAMMABLE MATERIALS

4
Disposing:
• Old appliances should not simply be disposed of with normal household waste, but should
be delivered to a collection and recycling centre for electric and electronic equipment. A
symbol shown on the product, the instruction manual or the packaging shows that it is
suitable for recycling.
• Materials used inside the appliance are recyclable and are labelled with information
concerning this. By recycling materials or other parts from used devices you are making a
significant contribution to the protection of our environment.
• Risk of child entrapment. Before you throw away your old refrigerator or freezer:
• Take o the doors.
• Leave the shelves in place so that children may not easily climb inside.
• Information on appropriate disposal centres for used devices can be provided by your local
authority
SAFETY AND WARNINGS (cont’d)

5
PRODUCT OVERVIEW

6
INSTALLATION / FIRST TIME USE
SELECTING A SUITABLE LOCATION
When selecting a position for your unit, ensure the floor is flat and firm, and
the room is well ventilated. Avoid placing your unit near a heat source (ie,
oven, radiator, or hot water system). Avoid direct sunlight as it may increase
the electrical consumption. Extreme cold temperatures may also cause the
unit to not perform correctly. This unit is not designed for use in a garage or
outdoors. Do not drape the unit with any covering.
POWER SOURCE AND GROUNDING
It’s recommended to use the vertical freezer on its own dedicated power
outlet for both convenience and safety. The power outlet must be
grounded.
Important! If the supply cord is damaged, it must be replaced by
Kogan.com or an authorised service agent on Kogan.com’s behalf. Cease
use and ensure the appliance is completely disconnected from the power
supply.
• Before using the freezer, remove all packaging materials, including
bottom cushions and foam pads and tapes inside the freezer, tear off
the protective film on the door and the freezer body.
• Keep away from heat and avoid direct sunlight. Do not place the
freezer in moist or watery places to prevent rust or reduction of
insulating effect.
• The freezer should be placed in a well-ventilated indoor place; the
ground shall be flat and sturdy.
• The top space of the freezer shall be greater than 70cm and the
distances from both sides and backside shall be more than 20cm to
facilitate heat dissipation.
Cleaning before use
Wipe the inside of the unit with a weak solution of bicarbonate soda,
then rinse with warm water using a wrung-out cloth or sponge. Wash
the shelves and drawers in warm soapy water and dry completely
before replacing in the unit. Clean the exterior of the unit with a damp
cloth. Further cleaning instructions can be found on page 8.
Before first use
Allow the freezer to sit for half an hour before connecting to power when
it is firstly started. The freezer shall run for 2 to 3 hours before loading
fresh or frozen foods; the freezer shall run for more than 4 hours in

7
summer in advance considering that the ambient temperature is high.
Energy saving tips
• The appliance should be located in the coolest area of the room, away
from heat producing appliances or heating ducts and out of the direct
sunlight.
• Let hot foods cool to room temperature before placing in the
appliance. Overloading the appliance forces the compressor to run
longer. Foods that freeze too slowly may lose quality or spoil.
• Be sure to wrap foods properly and wipe containers dry before placing
them in the appliance. This cuts down on frost build-up inside the
appliance.
• Appliance storage bin should not be lined with aluminium foil, wax
paper or paper towelling. Liners interfere with cold air circulation,
making the appliance less efficient.
• Organise and label food to reduce door openings and extended
searches. Remove as many items as needed at once and close the
door as soon as possible.

8
OPERATION
Display control
When powering on the freezer, the display window will light fully for 3
seconds, then it enters into normal display, the default set temperature
is -18°C. If no errors happen, the display panel shows set temperature or
mode, if it has error, error code will be displayed on control panel.
Locking and unlocking
• Locking: Long press temperature adjusting key and quick freeze key
for 3s at the same time, it enters into lock status and display window
flashes for several seconds, then enters into normal display state.
• Unlocking: Long press temperature adjusting key and quick freeze
key 3s at the same time, it exits lock status and temperature can be
adjusted.
The following key operations shall be conducted under unlocking state. If
the operation is conducted under locking state, display quickly flashes for
3s as a tip of invalid operation.
Conversion of Fahrenheit and Celsius
Under unlocking state, Fahrenheit and Celsius shall be converted
through long pressing temperature adjusting key for 3s.
Temperature setting
In the mode of freezer, press the temperature adjusting key to
change the set temperature, the set temperature will drop by 1°C/°F
for each press. When the display panel shows -24°C/-11°F, pressing
the temperature adjusting key again will convert the freezer into
refrigerator and the display panel will show 1°C/34°F. In the mode of
refrigerator, the set temperature will increase by 1°C for each press of
adjusting key .
Temperature adjustment mode in Centigrade is as follows:
Temperature adjustment in Fahrenheit is as follows:

9
Quick freeze mode
• Press the quick freeze key to enter quick freeze mode; the indicator
light will confirm selection.
• To exit quick freeze mode, press the quick freeze key once more.
• When continuous running time reaches 24h under quick freeze mode;
quick freeze mode will automatically exit.
• If set to Celsius, “-24” will appear in the display screen and compressor
will continuously run. With Fahrenheit, “-11” will appear in the display
screen and compressor will continuously run.
High temperature alarm
• The alarm indicator light will occur if the freezer reaches high
temperature.
Power off memory
• In case of power failure, the previous settings will be memorised til
power on.
Fault indication
• The following warning appearing on the display window indicate
corresponding fault in the freezer. Though the freezer may still
function with the following fault, the user shall contact a maintenance
specialist for maintenance, so as to ensure normal use of the freezer.
Code Description
E2 Failure of temperature sensor

10
CLEANING AND MAINTENANCE
WARNING! To avoid an electric shock, always unplug your freezer
before cleaning.
Defrosting
• For the most efficient operation and minimum energy consumption,
defrost the freezer when the frost on the freezer walls is excessive or
5mm thick. To minimize disruption, choose a time when the stock of
frozen food is low.
• Important! Do not use boiling water because it may damage the
plastic parts. In addition, never use a sharp or metallic instrument
to remove frost as it may damage the cooling coils and will void the
warranty. We recommend using the plastic scraper.
• Remove the frozen food from the freezer and place it in a cooler to
protect the food.
• Unplug the freezer. The Power Supply light should be off (green light
out).
• During defrosting, the ice melts in the cabinet and drains out through
the bottom front.
• Place a shallow pan outside the front base to capture the defrost
water. Check the pan occasionally so the water does not overflow.
• Clean the interior of the freezer and wipe any residual ice or water from
the cabinet.
• Reset the thermostat to desired setting.
• Switch on the temperature control to the highest setting for two hours
before using, and then adjust to normal level.
• Return food to the freezer.
TIP
Defrosting usually takes a few hours. Leaving the door open will help
speed the process.
Pouring warm water (not boiling) on the ice/frost will help speed
melting. If you must use a scraper- please use caution - it is very easy
to damage the freezer compartment and void your warranty.

11
Cleaning the inner cabinet
• Caution: Before using any cleaning products, please read and follow
the manufacturer’s instructions and warnings to avoid any damage to
your Freezer or personal injury.
• Upon installation of your new appliance, it is recommended that it be
cleaned thoroughly.
• Wash the inside with a damp warm cloth containing a water and
baking soda solution. The solution should be about 2 tablespoons of
baking soda to 2L of water.
• Wash the storage basket with a mild detergent solution.
• Be sure to keep the door seal clean to keep the unit running efficiently.
• The outside of the freezer should be cleaned with mild detergent and
warm water.
• Dry the interior and exterior with a soft cloth.
• The condenser coils should be carefully vacuumed when they are dusty
or dirty.
• It is recommended that the unit be cleaned each time it is defrosted to
help keep the unit odour free and running efficiently.
• Clean your door gasket seals every 3 months using the same warm
water solution described above.
Stop using
• Power failure: Foods can be preserved for a couple of hours even in
summer in case of power failure; it is recommended to reduce the
frequency of opening door and do not put fresh foods into the freezer.
• Long-time non-use: Please unplug the freezer if left unused for a long
time for cleaning. Keep the door open to avoid the bad odour.
• Moving: Do not turn upside or vibrate the freezer, the carrying angle
cannot be greater than 45°C. Do not hold the door and hinge when
moving this unit.
CAUTION
Continuous operation is recommended when the freezer is started.
For best performance, do not stop the freezer under normal
circumstance so as not to affect the freezer’s service life.

12
BASIC TROUBLESHOOTING
Freezer isn’t operating
• Check that the freezer is plugged in and
connected to power.
• Low voltage.
• Ensure temperature control knob is set
correctly.
• Check that a fuse hasn’t blown or circuit
tripped.
Freezer is making strange odour
• Odourous foods should be closely
wrapped and sealed in containers.
• Check for any possibly rotten food.
• Ensure that the interior is clean. Refer to
cleaning instructions.
Freezer compressor is continuously
running
• It is normal for the freezer compressor to
operate for longer periods of time when
the ambient temperature is higher (ie.
Summer).
• Do not put too much food in the freezer
at one time.
• Do not put warm/hot foods into the
freezer.
• Try to minimise the frequency of the door
opening.
Illuminating light does not work
• Check that the freezer is plugged in and
connected to power.
• Ensure the light is not damaged.
The freezer door cannot be properly
closed
• Ensure that food isn’t preventing the door
from closing.
• Ensure that the freezer is completely
level and feet adjusted to touch the floor.
• Ensure the freezer door gaskets/seals are
clean.
Loud noises
• Ensure the floor is flat and the placement
of freezer is stable.
• Check that the freezer accessories are
properly placed.
Buzzing during operation
• Refrigerants circulating in the refrigerant
lines will produce eruption of sound and
a grunt, which is normal and does not
affect the cooling effect.
• Buzz will be generated by running
compressor specially when starting up or
shutting down.
• The solenoid valve or electric switch
valve will clatter which is a normal
phenomenon and does not affect the
operation.
Transient difficulty in door opening
• After refrigeration, there will be pressure
difference between the inside and
outside of the freezer that results in
transient difficulty in door opening. This is
a normal physical phenomenon.
Condensation of freezer enclosure
• Condensation phenomenon will be
detected on the exterior surface and
door seals of the freezer when the
ambient humidity is high, this is a normal
phenomenon and the condensation can
be wiped away with a dry towel.
• The freezer enclosure may emit heat
during operation especially in summer,
this is caused by the radiation of
the condenser and it is a normal
phenomenon.
For our full FAQ and troubleshooting
guide, head online to help.kogan.com

13
Capacity
Volume 198L
Dimensions
Dimensions (W x D x H): 945 x 525 x 855mm
Packaged Dimensions (W x D x H): 985 x 545 x 870mm
Weight 35.7kg
Electrical
Refrigerant R600a, 56g
Hardware
Compressor Type HDL125A
Power
Current 0.45A
Energy Consumption 219kWh per year
Energy Rating 3.5 Star
Rated Power 105W
Voltage 220-240V/50Hz
SPECIFICATIONS
Note:
• Design and specifications are subject to change without notice.
• Weight and dimension shown are approximate.

14
NOTES

15

Need more information?
We hope that this user guide has given you the
assistance needed for a simple set-up. For the
most up-to-date guide for your product, as well
as any additional assistance you may require,
head online at help.kogan.com
