Kogan KAMN142CHFA User manual

CHEST FREEZER WITH ELECTRIC
CONTROL PANEL
142L, 198L
KAMN142CHFA, KAMN198CHFA

Ensure to read all instructions and warnings in this user guide prior to first use. Retain this
user guide for future reference.
•This appliance is intended to be used in households and for similar applications such
as:
•Staff kitchen areas in shops, offices and other working environments
•Farmhouses
•By clients in hotels, motels, and other residential type environments
•Bed and breakfast type environments
•Catering and similar non-retail applications
•Do not use this appliance for any other purpose (for example, storing blood, drugs, or
other biological products).
•This appliance is not intended to be used as a built-in appliance.
•This appliance can be used by children aged from 8 years and above and by persons
with reduced physical, sensory, or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
•Children must be supervised at all times to ensure that they do not play with or
become trapped in the appliance.
•Cleaning and user maintenance shall not be done by children without supervision.
•Ensure the power cord is not trapped or damaged.
•Do not damage the power cord.
•If the power cord is damaged or worn, stop use immediately and contact
help.Kogan.com for assistance.
•In the event of a power failure, unplug the power cord immediately and do not
reconnect for at least five minutes to prevent damage.
•Do not attempt to repair the appliance yourself.
WARNING
:
•Risk of fire/flammable materials.
•This freezer contains flammable R600a refrigerant.
• Connect to potable water supply only.
• Risk of child entrapment. Before disposing an old
refrigerator/freezer, remove the doors and leave the shelves in
place to ensure children do not climb inside.
•To avoid a hazard due to instability of the appliance, it must be
fixed in accordance with this user guide.
SAFETY & WARNINGS

•Maintenance must be conducted by a professional.
•Do not store explosive substances (for example, aerosol cans with a flammable
propellant) in this appliance.
•Do not put flammable, explosive, volatile, and highly corrosive items in or near the
appliance to prevent damages or fire accidents.
•Do not place regulators or any electrical appliances on top of the freezer.
•Do not use electrical appliances inside the food storage compartments of the
appliance.
•The appliance must be unplugged after use and before carrying out cleaning and
maintenance.
•The appliance may not operate consistently if it is placed in temperatures outside of
the operating range.
•Keep ventilation openings in the appliance enclosure or in the built-in structure clear
of obstructions.
•Keep the appliance away from heat sources and direct sunlight.
•Do not place the appliance in humid areas/areas near water or any other liquid to
prevent rust and reduced insulating abilities of the appliance.
•Do not use mechanical devices or other means to accelerate the defrosting process
other than those recommended.
•Do not damage the refrigerant circuit.
•Do not locate multiple portable power outlets or portable power supplies at the rear
of the appliance.
•Do not use extension cords or ungrounded two prong adapters with this appliance.
•Do not vibrate or turn the appliance upside down.
•When carrying the appliance, do not tilt it more than 45°.
•Do not hold the lid and hinge when moving this appliance.
•If the LED lamps need to be replaced, contact help.Kogan.com for assistance. The
replacing process must be performed by a professional. Do not attempt this process
yourself.
•Continuous operation is recommended when the appliance has started
operating. Under regular circumstances, to preserve its service life, do not turn the
appliance off.
Electricity related warnings
•Do not pull on the power cord when pulling the power plug of the freezer. Instead,
firmly grasp the plug and pull out it from the socket directly.
•The power plug must be firmly contacted with the socket otherwise there may be
fires.
•Ensure that the grounding electrode of the power socket is equipped with a reliable
grounding line.
•If any gas is leaking, contact a qualified professional immediately. Turn off the valve
of the leaking gas and then open the lid and windows.
•Do not unplug the freezer and other electrical appliances when the power outlet is
switched on.

Use related warnings
•Store raw meat and fish in suitable containers in the refrigerator so that it is not in
contact with or drip onto other food.
•Do not pick up foods or containers with wet hands in the freezer when running,
especially metal containers to avoid frostbite.
•Do not allow children to enter or climb into the freezer to prevent entrapment.
•Do not insert fingers into the gaps between the lid.
•Be careful when opening appliance to avoid food from falling out.
•Do not spray or wash the freezer.
•To avoid injury from falling objects, do not place heavy objects on the top of the
freezer.
•Do not store effervescent drinks in the appliance.
•Do not store bottled or closed containers of fluids for extended periods.
•It is not recommended to store fresh food in the freezer.
•There is a small deviation between the temperature inside the freezer and the set
temperature. This is normal and does not affect regular use.
•Opening the lid for long periods can cause a significant increase of the temperature
in the compartments of the appliance.
•Do not exceed the storage times recommended by food manufacturers for any kind
of food, particularly commercially quick-frozen food.
•Food should be consumed within the recommended shelf time.
•If defrosting the appliance, due to the rise in temperature, take relevant precautions
on the food (for example, wrapping food in layers of newspaper).
Disposal related warnings
•The freezer's refrigerant and cyclopentane foam materials are combustible.
Discarded freezers should be isolated from fire sources and cannot be burned. They
must be disposed by professionals.
•Due to the flammable blowing gas and refrigerant, if disposing the appliance, follow
local regulations.
This marking indicates that this appliance should not be disposed with
other household wastes. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources.

OVERVIEW
Water outlet
Control panel
Cover plate
Power cord
Hinge
Basket
Light
Lid handle
Note:
Images in this user guide are for reference only.
Lid

Control panel
Electronic Control
TEMP
SUPER
Temperature button
Display
Super freeze indicator
Super freeze/lock button
Fahrenheit indicator
Celsius indicator
Temperature warning
indicator

1. Remove all packaging from the freezer,
tearing off the protective film on the lid
and freezer body.
2.Using a screwdriver (not supplied),
unscrew and remove the cover plate.
Uncoil the power cord.
3.Allow two hours for the freezer’s refrigerant
to settle. Not doing so may lead to
decreased cooling capabilities and cause
damage to the freezer.
Placement
Place the freezer indoors on a flat, dry surface
that is well-ventilated. Ensure it is away from
other heat sources and direct sunlight.
There should be at least a 70cm clearance
above the freezer, and at least 20cm away
from all other sides.
Running prior to use
Plug the power cord into a power outlet and
turn on the outlet.
Operate the freezer for 2–3 hours before
loading fresh or frozen foods. If the ambient
temperature is high (for example, in the
summer), operate the freezer for 4 hours prior
to loading food.
BEFORE FIRST USE
70cm
20cm
20cm

Powering
Plug the power cord into a power outlet and turn on the outlet. The display will turn on for
three seconds then show ‘–18°C’ to reflect the default temperature of the freezer.
Locking and unlocking the control panel
After the freezer is turned on, the control panel will automatically lock itself to prevent
accidental touches changing the settings of the appliance. When wanting to use the
control panel:
•Press and hold the super freeze/lock button for three seconds. The display will flash
once and become unlocked.
•After 30 seconds of inactivity, the control panel will flash once and automatically lock
itself. Alternatively, press and hold the super freeze/lock button for three seconds to
lock the control panel.
Adjusting the temperature
This freezer has a temperature range between –30°C–10°C/–22°F–50°F.
•Press the temperature button to see the currently set temperature.
•To adjust the temperature, continue pressing the temperature button until the
desired temperature is displayed. The display will cycle through the temperatures as
seen below.
OPERATION
Notes:
•If setting to –30°C, it is highly recommended the ambient temperature is at or
below 25°C.
•In the event of a power failure, the freezer will run on the previously set
temperature when power is recovered.

Switching between Celsius and Fahrenheit
If wishing to switch temperature units, press and hold the temperature button for three
seconds.
The Celsius indicator will illuminate when the freezer is using Celsius, and the Fahrenheit
indicator will illuminate if the freezer is using Fahrenheit.
Super freeze mode
The super freeze mode sets the freezer to –30°C for up to 24 hours. To activate super freeze
mode, press the super freeze/lock button and the super freeze indicator will illuminate.
To exit super freeze mode, press the super freeze button again.
Sleep function
When activated, the sleep function turns off the display after 30 seconds of inactivity to
conserve energy. This function is enabled by default.
•To turn off the sleep function, press and hold the temperature and super freeze
buttons for five seconds. The display will stay on and show the currently set
temperature.
•To turn on the sleep function, press and hold the temperature and super freeze
buttons for five seconds. This display will show ‘ON’ to confirm the sleep function is
activated.
Temperature warning indicator
If the freezer becomes too hot, the freezer will sound an alarm and the temperature warning
indicator will illuminate.
Energy saving tips
•Allow hot foods to cool to room temperature before placing in the appliance.
Overloading the appliance forces the compressor to run longer, and foods that freeze
too slowly may lose quality or spoil.
•Ensure to wrap foods properly and wipe containers dry before placing them in the
appliance. This cuts down on frost build-up inside the appliance.
•Compartments should not be lined with aluminium foil, wax paper, or paper towel.
Liners interfere with cold air circulation, making the appliance less efficient.
•Organise and label food to reduce lid openings and extended searches. Remove as
many items as needed at one time and close the lid as soon as possible.
Notes:
•After 24 hours of using the super freeze mode, the freezer will also automatically
exit super freeze mode.
•In the event of a power failure or sensor failure, the freezer will also exit super
freeze mode when recovered.

Dust build-up in and around the freezer will lead to reduced cooling capabilities and
increased energy use.
Ensure the freezer is turned off and unplugged before cleaning.
Interior
The interior of the freezer should be cleaned regularly to avoid odour.
1. Combining two tablespoons of baking soda with a litre of warm water, use a soft
cloth or sponge to clean the inside of the freezer.
For header to reach areas (for example, gaps, corners), use a soft brush. If necessary,
other tools may be used to ensure no contaminants or bacteria accumulate in these
areas.
2.Using soapy water or diluted detergent, wipe the lid seal with a soft cloth to ensure
there is no debris.
3.Rinse with water and wipe clean.
4.After cleaning, open the lid and let it dry naturally before turning on the power.
Exterior
Wipe the exterior with a soft cloth dampened with soapy water or detergent, then wipe dry.
Water outlet
Unscrew the drain plug over the water outlet and drain regularly.
CLEANING & CARE
Notes:
•Do not use soaps, detergents, and spray cleaners to clean the inside of your
freezer as these may create odours or contamination.
•Do not rinse the freezer directly with water or any other liquids.
Notes:
•Do not use hard brushes, clean steel balls, wire brushes, abrasives (for
example, toothpastes), organic solvents (for example, alcohol, acetone),
boiling water, acid, or alkaline items as they may damage the freezer
surface and interior.
•Boiling water and organic solvents (for example, benzene) may deform or
damage plastic parts.

Basket
Clean the basket with a soft cloth dampened with soapy water or diluted detergent. Allow
to air dry or use another soft cloth to wipe dry.
Defrosting
Frost will accumulate in the freezer over extended use and the freezer will need to be
defrosted. It is recommended to defrost when the frost is about half a centimetre thick. To
defrost:
1. Unplug the freezer and open the lid. Remove any foods and the basket, then place
the foods in a cool area.
2.Place a container under the water outlet. Unscrew the drain plug over the water
outlet and allow any water to flow out.
3.As the freezer defrosts, wipe the interior with a dry, soft cloth. An ice scraper may be
used to accelerate the cleaning process.
4.Once defrosted and cleaned, place the basket and any foods back into the freezer.
Light
If the light needs maintenance or needs to be replaced, contact a qualified professional to
perform this procedure.
Do not attempt to perform maintenance or replace the light yourself.
Storage
If the freezer will not be used for an extended period, unplug the power cord, and leave the
lid open to prevent odours.
Note:
Do not use mechanical devices or other means to accelerate the defrosting process
as this may cause damage to the refrigerant circuit.

Issue Reasoning/solutions
The freezer is not
working.
•Ensure the power cord is fully plugged in and the power
socket is switched on.
•Ensure the voltage used is between 220–240V.
•Check for a power failure and ensure the circuit has not
overloaded.
The display is not
responding. Ensure the display is unlocked.
There is an odour
emitting from the
freezer.
•Ensure foods with a strong smell have been closely
wrapped.
•Check if any food has become rotten.
•Check if the interior needs cleaning, then clean if necessary.
The compressor is
running for longer than
usual.
•When the ambient temperature is high, it is normal for the
compressor to run longer than usual.
•If foods have not been allowed to cool, the compressor will
run longer to cool the freezer to the set temperature. It is
recommended to cool food first before placing it into the
freezer.
•If the freezer is frequently opened, the compressor will run
longer to keep the freezer cool.
•There may be a thick layer of frost. In this case, defrost the
freezer.
•Ensure the freezer is not overfilled.
The light is not working.
•Ensure the power cord is fully plugged in and the power
socket is switched on.
•Check if the light is damaged. If damaged, stop use and
contact help.Kogan.com for assistance.
The lid cannot be
closed properly.
•Frozen food has stuck to the lid.
•The freezer is overfilled. Remove food if necessary.
•The freezer is unbalanced. Ensure the freezer is placed on a
flat surface.
The freezer is making
loud noises. Ensure the freezer is placed on a flat, stable surface.
TROUBLESHOOTING

There is an air flowing
sound emitting from the
freezer.
Refrigerants circulating in the refrigerant lines will produce
loud noises. This is normal and does not affect the cooling
capabilities of the freezer.
There is a buzzing
sound emitting from the
freezer.
When the freezer is being turned on or off, the compressor will
run and make a buzzing sound.
There is a clattering
sound emitting from the
freezer.
The solenoid valve or electric switch valve will make a
clattering sound when operating. This is normal and does not
affect freezer operation.
There is a slight
difficulty when opening
the lid.
When the freezer is operating, there will be a pressure
difference between the inside and outside of the freezer. This
results in difficulty when opening the lid and is a normal
phenomenon.
The walls on the side of
the freezer are heating
up.
The freezer may emit heat during operation, particularly when
the ambient temperature is high. This is caused by the
radiation of the condenser and is a normal phenomenon.
There is condensation
on the surface of the
freezer.
•When the ambient temperature is high, it is normal to
detect condensation on the exterior surface and lid seal on
the freezer.
•Wipe the condensation off with a dry towel.
The display is showing
‘E2’.
There is a temperature sensor failure. Stop use immediately
and contact help.Kogan.com for assistance.

Specification KAMN142CHFA KAMN198CHFA
Dimensions 632 x 550 x 850mm 816 x 550 x 850mm
Refrigerant R600A, 46g R600A, 56g
Comparative
energy
consumption
220kWh/year (Freezer)
94kWh/year (Refrigerator)
255kWh/year (Freezer)
108kWh/year (Refrigerator)
Net weight 29kg 33kg
Volume 142L 198L
Rated voltage 220–240V~
Frequency 50Hz
Rated current 0.8A
Temperature range –30°C–10°C
Climate class N, SN, ST, T
IEC protection
class I
Noise level 41dB
SPECIFICATIONS

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
