Kogan KASPAMSDLTA User manual

DELIGHT INFLATABLE PORTABLE
OUTDOOR HOT TUB
MASSAGE SPA
6 PERSONS
KASPAMSDLTA

2
Safety & Warnings 3
Components 7
Before First Use 8
Assembly 11
Operation 16
Cleaning & Care 19
Troubleshooting 24
Specifications 27

3
Ensure to read all warnings and instructions in this user guide prior to first use. Retain this
user guide for future reference.
•WARNING: This spa is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience and knowledge
unless they have been given supervision or instruction concerning use of the spa by a
person responsible for their safety. Children should be supervised to ensure that they
do not play with the spa.
•Risk of accidental drowning:Extreme caution must be exercised to prevent
unauthorised access by children. To avoid accidents, ensure children cannot use this
spa unless they are supervised at all times.
•For the safety of children, and to minimise drowning risk, always fit the spa cover after
each use.
•Risk of injury:Do not operate the spa if inlet or outlet pipes are broken or missing.
Stop use immediately and contact help.Kogan.com for assistance.
•Do not attempt to replace the inlet and outlet pipes.
•Examine the components before use. If any listed components are damaged or
missing, contact help.Kogan.com for assistance.
•This spa is intended for household use. It is not intended for commercial use.
•Risk of electric shock:Do not install the spa within 2 metres of all metal surfaces.
•Risk of electric shock:Never operate any electrical appliance when in the spa or
when your body is wet.
•Do not place any electrical appliance (for example, a light, telephone, radio, or
television) within 2 metres of the spa.
•Do not use the spa when it is raining.
•WARNING: Always keep the power cord dry. Do not plug/unplug the power cord with
wet hands.
•WARNING: For electrical safety, this spa is equipped with a leakage current detecting
device. If a leakage current exceeding 10mA is detected, the device will cut off the
power supply. If this occurs, unplug the power cord, stop using the spa immediately,
and contact help.Kogan.com for assistance. Do not attempt to reset the spa by
yourself.
SAFETY & WARNINGS
WARNING: When installing this spa, all safety precautions must be
followed.

4
•Caution: To avoid a hazard due to inadvertent resetting of the thermal cut-off, this
spa must not be supplied through an external switching device (for example, a timer),
or be connected to a circuit that is regularly switched on and off.
•The spa must be supplied through an isolating transformer or supplied through a
residual current device (RCD) having a rated residual operating current not exceeding
30mA.
•The pump must be tested before each use. Refer to the ‘PRCD testing’ section of this
user guide for instructions.
•If the power cord is damaged, stop use immediately and contact help.Kogan.com for
assistance.
•Do not use extension cords, plug adaptors, or converter plugs to connect the spa to
the electrical supply.
•Ensure the power cord is directly connected only to a grounded power socket.
•Ensure the power cord is easily accessible.
•Components containing live parts (except parts supplied with a low voltage not
exceeding 12V) must be out of reach and inaccessible to people in the spa.
•Parts incorporating electrical components (except remote control devices) must be
located or fixed so that they cannot fall into the spa pool.
•Keep the plug of the pump more than 3.5 metres away from the spa at all times.
•The power source on the wall of the building should be at least 4 metres away from
the spa and at a height of at least 1.2 metres.
•Always unplug the spa:
oon rainy days
obefore cleaning or other maintenance
oif leaving unattended for a long period (for example, going on holiday)
•When the spa will be not used for an extended period (for example, during winter), the
spa should be disassembled and stored indoors.
•Do not wear contact lenses when in the spa.
•Do not use skin care products or sunscreen while using the spa.
•Do not use the spa during chemical maintenance.
•Cleaning and user maintenance must be performed by an adult above 18 years old
who understands the risk of electric shock.
•Do not bury the cord. Ensure the power cord is always visible to minimise damage
from hazards (for example, lawn mowers, hedge trimmers, other equipment).
•If pregnant, soaking in hot water may result in serious injury or death to the unborn
child. Limit use to 10 minutes at a time and be conscious of temperature.

5
To reduce the risk of injury:
•The water in a spa should never exceed 40°C. A water temperature between 38°C
and 40°C is considered safe for a healthy adult. Lower water temperatures are
recommended for young children, or if the spa will be used for more than 10 minutes.
•Since excessive water temperatures have a high potential for causing fetal damage
during the early months of pregnancy, users who are pregnant or possibly pregnant
should limit spa water temperature to 38°C.
•Before entering a spa, the user should measure the water temperature with an
accurate thermometer since the tolerance of the water temperature regulating device
may vary.
•The use of alcohol, drugs, or medication before or during spa use may lead to
unconsciousness with the possibility of drowning.
•The use of alcohol, drugs, or medication can greatly increase the risk of fatal
hyperthermia. Hyperthermia occurs when the internal body temperature reaches a
level that is several degrees above normal body temperature (37°C).
The symptoms of hyperthermia include an increase in the internal temperature of the
body, dizziness, lethargy, drowsiness, and fainting.
The effects of hyperthermia include failure to perceive heat, failure to recognise the
need to exit the spa, unawareness of impending hazards, fetal damage for pregnant
women, physical inability to exit the spa, and unconsciousness resulting in the danger
of drowning.
•Obese persons and persons with a history of heart disease, low or high blood pressure,
circulatory system problems, or diabetes should consult a physician before using a
spa.
•Persons using medication should consult a physician before using the spa as some
medication may induce drowsiness, while other medication may affect heart rate,
blood pressure, and circulation.
•Consult your physician for recommendations.
•Do not pour water with a temperature higher than 40°C into the spa pool directly.
•Electric installations must follow national wiring rules. If unsure, consult a qualified
electrician.
Caution:
•It is strongly recommended not to unfold and inflate the spa if the ambient
temperature is below 15°C. Inflate the spa indoors and then continue setting up
outdoors.
•Do not use the spa alone.
•People with infectious diseases should not use a spa.
•Do not use the spa immediately following strenuous exercise.

6
•Always enter and exit the spa slowly and cautiously. Beware of wet slippery surfaces.
•To avoid damage to the pump, do not operate the spa unless it is filled with water.
•Leave the spa immediately if the user feels uncomfortable or sleepy.
•Do not add water to chemicals. Always add chemicals to the water to avoid strong
fumes or violent reactions.
•Refer to the Cleaning and care’ section of this user guide regarding information about
cleaning, maintenance, and disposal of water.
After using your spa for 3–5 years, you should contact your local qualified maintenance
technician to ensure the safety and performance of the spa. The main components (for
example, the heating element, air blower motor, non-return valves) within the electric unit
should be checked and replaced (if necessary) by professionals.

7
ASpa cover
BSpa tub
CWired controller
DDigital lock
EFilter cartridge and
cartridge base
FDrain valve adapter
GRepair kit
HWrench
COMPONENTS

8
Zones Description
Zone 0 Zone 0 is the interior of the basin including any recesses in their walls
or floors.
Zone 1
Zone 1 is limited by:
•Zone 0
•A vertical plane 2.5 metres from the rim of the basin.
•The floor or the surface expected the be occupied by persons.
•The horizontal plane 2.5m above the floor or the surface.
Zone 2
Zone 2 is limited by:
•A vertical plane external the zone 1 and parallel plane 1.5m from the
former.
•By the floor or surface intended to be occupied by persons.
Note:
The measured zone dimensions are limited by walls and fixed partitions.
BEFORE INSTALLING

9
Site preparation and requirements
•The spa can be installed indoors or outdoors in around 10 minutes. This spa is for
household use only.
•The spa must be set up on a flat, smooth, and supporting surface that can support
the maximum load of the filled spa with the maximum number of occupants.
•Ensure the area is free of sharp objects under or around the spa. Uneven or unsound
surfaces can damage the spa. Level the surface if needed before filling the spa with
water.
•Provide adequate drainage around the spa to deal with the overflowing of water and
splashes.
•Ensure there is enough clearance around the spa for full access to the spa equipment
for maintenance and/or service.
Additional requirements for indoor installation
•Verify the supporting floor can support the filled weight of the spa with the maximum
number of occupants. Check with a qualified contractor or structural engineer to verify
the requirement.
•Ensure the floor is water-resistant and provides a non-slip surface. Do not install the
spa on carpet or any other material that could be damaged by moisture.
•Humidity is a normal side effect when using the spa indoors. Ensure the room where
the spa is installed is properly ventilated to allow moisture to escape. It is strongly
recommended to install a ventilating system to prevent excess condensation moisture
in the room.
Additional requirements for outdoor installation
•Do not set up the spa on grass or dirt as this increases the amount of debris entering
the spa and can cause damage to the spa floor.
•To maximise the life of the spa, do not leave the spa tub exposed to direct sunlight.
•Always keep the manometer in the yellow section when using the spa at a
temperature higher than 20°C, or when it is exposed to sunlight for a short time.
•It is not recommended to install and leave the spa outside at a temperature lower
than 4°C. This ensures the water inside the circulation system, pump, and pipe do not
become frozen. Place a heat preservation mat (not included) between the spa bottom
and the ground to prevent heat loss from the bottom of the spa and to provide better
heat retention.

10
PRCD testing
1. Plug the power cord into a power outlet. Do not use plug boards or faulty sockets.
2.Press the RESET button on the PRCD. The indicator will turn red.
3.Press the TEST button on the PRCD. The red light on the indicator should disappear.
4.Press the RESET button on the PRCD again. The indicator should turn red, and the
spa is now ready for use.
Controller connection
A qualified electrician should wire the controller to the household equipotential terminal
using a minimum 1.5mm²solid copper conductor.
Indicator
Reset
Test
WARNING: Risk of electric shock: This product is provided with a PRCD located at
the end of the power cord. The PRCD must be tested before each use.
Do not use the spa if the PRCD does not function properly.
Disconnect the power cord until the fault has been identified and corrected. Contact a
licensed electrician to correct the fault.
There are no serviceable parts inside the PRCD.
Note:
If the red light does not disappear, the PRCD is faulty. Do not use the spa and contact
a qualified electrician to correct the fault.
✓
✗

11
1. Move the entire package to the selected site. Do not drag the spa tub across the
ground as this can cause damage and future leakage. Open the packaging carefully
as it can be re-used to store the spa during long-term storage or when not in use.
2.Lay out all components on the ground and check all components are located. Ensure
the spa tub is facing the right side up.
3.Spread out the spa tub over the ground and point the drain valve towards a suitable
draining area.
4. Heater resetting
•The heater should be reset when the spa is used for the first time, or after long periods
of storage.
•To reset, find the yellow ring as shown in the picture. Pull it down gently and then
release it.
INSTALLATION
Note:
The heater cannot work or be reset if the
water temperature or ambient
temperature is higher than 40°C.

12
5.Spa inflation
•Plug the spa into a grounded power socket.
•Press ‘RESET’ on the PRCD and the screen on the controller will display numbers.
•Turn the inflation knob to ‘ON’ and press and hold the bubble button on the controller
for at least 2 seconds to start inflating.
•Inflate until the yellow section of the manometer is pushed out. Stop pressing the
bubble button and turn the inflation knob to ‘OFF’.
Spa deflation
•Unscrew the manometer cap on the spa pool to deflate
the spa.
•Once deflation is complete, place the cap back onto the
spa.
Bubble
ON
OFF
Yellow
Notes:
•Before inflation, check whether the manometer cap is screwed tight on the valve
of spa tub. If not screwed tight, tighten it then inflate. After inflation, the
manometer cannot be removed. Removing the manometer will cause air to
escape.
•The spa will require additional air to be added from time to time. Changes in
temperature from day to night will change the pressure in the spa and may
cause a certain amount of deflation.

13
Ensure the manometer shows the Yellow section in the
following conditions:
•After inflation but before filling the spa with water.
•When leaving the spa outdoors unattended for an
extended period at a temperature higher than 20°C.
Ensure the manometer shows the Green section in the
following conditions:
•When the spa is filled with water.
•When the spa is being used.
WARNING: If the manometer shows the White section, the
spa is over-inflated.
•Slightly rotate the manometer cap anti-clockwise to
release some air.
•Tighten the cap after the pointer returns to the Green or
Yellow section.
6.Installing the filter cartridge
•Attach the cartridge base to the spa tub inlet (upper position) and turn it clockwise to
secure.
•Put the mesh cover on the filter cartridge then attach the filter cartridge to the
cartridge base. The filter cartridge should stay secure when the spa is filled with
water.
Yellow
Yellow
Green
Green
Yellow
White
Notes:
•The cartridge base is designed to be screwed on and off. Do not exert force as
this could cause damage.
•Always use a filter cartridge when the spa is in use and filled with water.

14
7. Water filling
•Confirm the spa’s location and point the drain valve towards a suitable draining area
before filling water.
•Fill the spa tub with fresh water to a level between the minimum and maximum line
marked on the inside of the spa wall. Do not overfill the spa.
•After the spa is filled, check the spa pool air pressure and ensure the manometer
shows the Green section.
8.Water heating
Refer to the ‘Operation’ section of this user guide for heating instructions. The maximum
heating temperature is 40°C. The hourly heating rate is around 1.2°C–1.8°C.
Maximum
Minimum
Notes:
•If the water level does not fall between the two lines, this may cause a pump
and control system failure.
•Never pour water with a temperature higher than 40°C into the spa directly. It
is recommended to fill the spa tub with lukewarm water to allow the water to
reach an ideal temperature quickly and save electricity and time on heating.

15
9.Digital lock operation
Place the spa cover over the spa tub and make sure the zipper on the spa cover is closed.
Lock the cover with the digital lock.
The default password is “000”. Follow the steps below to change the password:
•Push the button (a) down to unlock the digital lock.
•Set your preferred password in 3 digits by turning the number dials (b) on the bottom
of the lock.
•Insert the cable (c) back into the lock to secure. The new password is now set.
IMPORTANT:
•Inspect the spa air pressure regularly for leak, premature wear, or deterioration.
•Check and wax the zipper regularly, to ensure it is smooth and avoids splitting.

16
Controller
Temperature display
Once the spa is turned on, press RESET on the PRCD. The display
will show the current water temperature.
Heating
Press the HEATER button to turn the heating system on/off.
•If the light on the heater button is red, the heating system is
activated. If the light on the heating button is green, the water is at
the set temperature and the heating system is at rest, keeping the
water at the desired temperature.
IMPORTANT: The following conditions will lead to slower heating:
•If the ambient temperature is lower than 10°C.
•Outdoor wind speed is above 3.5-5.4m/s.
•When the massage system is activated.
•If the spa is not properly covered with the spa cover.
Filter button
Timer button
Down button
Heater button
Bubble button
Up button
OPERATION
Temperature display
Note:
When turned on, the spa’s filter will automatically run for 15
seconds to test the heater’s functionality. This is normal. In
standard use, the heater will then heat the water towards the
set temperature.

17
Filtration
Press the FILTER button to turn the filtration function on/off. The light
on the button will turn green when activated.
•The filtration system will automatically start when heating is
activated. It cannot be turned off while the heating system is in
operation.
•After turning off the heating, the filtration system will automatically
stop after 30 seconds. The filtration system can then be activated
separately if desired.
•The auto-filtration system is activated every 4 hours.
Bubble massage
•Press the BUBBLE button to turn the massage system on/off. The
light on the button will turn green when activated.
•For your safety, the massage system will automatically turn off
after 20 minutes of use. It can be re-activated after 10 minutes.
Adjustment buttons
•Pressing the UP or DOWN buttons will cause the temperature
display to start flashing. Using the UP and DOWN buttons, adjust
the water to the desired temperature setting (from 20°C to 40°C)
within 3 seconds. The new temperature value will remain on the
temperature display to confirm.
•If any other buttons are pressed during the 3 second period,
adjustments to the temperature will be voided.
•Press the UP and DOWN buttons at the same time for 3 seconds
to lock the controller. In the locked mode, all current settings of the
spa are kept. Pressing any buttons in this mode will not change the
settings. To unlock, press the UP and DOWN buttons at the same
time for 3 seconds again.
Note:
If the light on the FILTER button is flashing red and green
(when the function is on) or flashing red (when the function is
off), the filter cartridge must be cleaned or replaced. Once
cleaned/replaced, press and hold the FILTER button for 3
seconds to reset.
Note:
The massage system can only be activated when the inflation
knob is in the ‘OFF’ position.
Note:
The default setting temperature is 38°C.

18
Heating timer
•Press the TIMER button to set up a timer that alerts the spa to
start heating after a user-determined time of up to 99 hours. The
button will turn green when pressed.
•Press the UP and DOWN buttons to adjust the time when the spa
will start heating.
•The timer is confirmed if either no buttons are pressed for 3
seconds, or by pressing the TIMER button again.
•The heater will then start operating after the determined time. The
time can be modified by pressing the TIMER button and repeating
the process as above.
•To cancel the timer, press and hold the TIMER button for 3
seconds.
Note:
The timer cannot be activated if the spa is already heating, or
if the spa is being restarted.

19
Spa water
Protect all the spa occupants from possible water related illnesses by keeping the spa water
clean and sanitised. Always practice good hygiene. Ensure spa water quality by following
these procedures:
•Change the spa water every 3–5 days depending on spa use. If dirt is visible in the
water, or the water becomes cloudy and proper water chemistry does not clear it up,
change the water and clean the spa tub. See the “Spa Tub Cleaning” section for
further instructions.
•Use spa chemicals to maintain proper water conditions. Consult with your local spa or
pool retailer for more information on chemical use.
•All occupants must shower before entering the spa. Do not use skin care products or
sunscreen while using the spa.
Water sanitation
The spa owner must regularly check and keep the spa water sanitised with scheduled
maintenance (daily, if necessary). Adding sanitiser or other chemicals will control bacteria
and virus reproduction in the spa water. The maintenance of a proper water balance through
appropriate use of sanitisers is the most important factor in maximising the life and
appearance of the spa as well as ensuring clean, healthy, and safe water.
Proper technique is important for water testing and treating the spa water. See your spa
professional for questions on chemicals, sanitisers, test kits, and testing procedures.
Water treatment:
•Always follow the chemical manufacturer's directions and the health and hazard
warnings.
•Never mix different chemicals. Add the chemicals to the spa water separately.
Thoroughly dissolve each chemical before adding the next one to the water.
•IMPORTANT: Chlorine and bromine products should never be mixed. This is extremely
dangerous. If you usually use chlorine-based products and want to switch to bromine-
based products or vice versa, it is mandatory to completely change the spa water
before any product changes.
•Do not add chemicals if the spa is occupied. This can cause skin or eye irritation.
•Do not overuse the chemicals or use concentrated chlorine. This can damage the spa
tub and cause potential harm to your skin.
CLEANING & CARE

20
Water balance
Follow the guidelines below to maintain the water balance of the spa water.
Parameter
Test frequency
Correct level
pH Daily 7.2–7.6 when using Chlorine
7.2–7.8 when using Bromine
Free chlorine Daily 3–5 ppm
Bromine residual Daily 2–4 ppm
Total alkalinity (TA) Weekly 80–120 ppm
Total hardness (TH) Weekly 200–500 ppm
Spa drainage
1. Turn off all the functions on the controller.
2.Connect the spa drain valve adapter to a
garden hose and point the other end of the
garden hose to a suitable draining area in line
with local environmental regulations.
3.Open the spa drain valve cap from the
outside of the spa tub and attach the drain
valve adapter with the garden hose to the
spa drain valve.
Note:
Always check there is the correct chemical balance in the water. Failure to do so may
cause damage to the spa tub and pump.
