Kogan NC-700 User manual

NC-700 WIRELESS ACTIVE NOISE
CANCELLING HEADPHONES
KAANCHP700A

1 Volume+/Next Track Press for volume up. Press and hold to skip to next track.
2 Multifunction Button
Power On/Off: Press and hold for 2 seconds to power on,
press and hold for 4 seconds to power off. Once powered
on, pairing mode begins automatically after 10 seconds.
Phone Call Control: Press to answer/hang up. Press and
hold to refuse. Press two times to redial last outbound
phone number. Double click to start Siri.
3 Volume-/Previous Track Press to volume down/press and hold to play previous
track.
4 Type-C USB Insert the charging cable; the indicator will illuminate red and will turn blue as the headphones charge. Do not use
the headphones whilst charging.
5 Mic Microphone for calling.
6 Active Noise
Cancellation Control Press and hold 2 seconds to turn the ANC function on/off.
7 3.5mm Earphone Jack When plugged in, Bluetooth turns off automatically and
microphone and battery functions are disabled.
OVERVIEW

Connection
1. Press and hold the multifunction button for 2 seconds until the headphones power
on; they will enter pairing mode automatically after 10 seconds. The LED indicator
flashes blue and red alternately. The headphones will power off after 5 minutes if
no Bluetooth device is connected.
2. Activate Bluetooth on the audio device and set it to search for new devices.
iPhone Settings > Bluetooth > On
Android Settings > Bluetooth: On > Scan for devices
3. Select “M6” If necessary, enter four zeros (0000) for the passcode and accept the
connection. Once successfully paired, the headphone LED indicator flashes blue.
Dual device connection
The headphones can be paired with two devices simultaneously. After connecting the first
audio device, turn off the headphones and Bluetooth on the device. Restart the
headphones and pair with the second device and maintain the connection. Finally, open
Bluetooth on Phone A and select “M6” in the menu.
Wired connection
Use the included audio cable to connect. Bluetooth turns off automatically and microphone
and battery functions are disabled when using a wired connection
INSTRUCTIONS
Note:
Menus may vary by device
Note:
The headphones can only play music from one device, even if two devices are
successfully connected at the same time.

Active Noise Cancellation (ANC)
 Press and hold the ANC button for 2 seconds to activate the active noise
cancelling function. The LED will illuminate in green.
 Press and hold for 2 seconds to turn off the ANC function and LED.
Charging
Plug the Type-C USB cable into the headphone charging port and connect the other side
with a USB wall charging adapter or computer. The LED indicator turns red while charging
and turns blue when fully charged. The headphones will alert the user every 15 minutes
when the battery power is below 10%.
Maintenance
 Do not use non-original accessories to avoid performance degradation or electrical
short circuiting.
 Do not attempt to disassemble or repair the device.
 Keep the headphones away from dusty or humid environments.
 Do not allow children less than 3 years of age to play with or use the device.
 Do not place the product in an overheated or super-cooled environment.
 Clean the headphones with a clean, soft, and dry cloth.
 Place the headphones in the original package, or in a secure location when not in
use.
Battery maintenance
 Do not attempt to remove or replace the battery. Contact Kogan.com if battery
maintenance is required.
 The charging temperature of the battery is between 10 and 45°C.
 Charge the headphones at least once a month if not in use for an extended period.
 Battery usage time and standby time are related to usage conditions and are
provided only for reference.
CLEANING & CARE

Notes
 Most Bluetooth devices will automatically save the “M6” device information after
the first-time connection. If there are issues reconnecting, remove “M6” from the
paired device list, then search for and reconnect to M6 again.
 When the headphones cannot be powered on, the battery will likely be short of
charge. Charge the headphones to continue use.
 Ensure that the headphones are not used at an excessive volume for an extended
period to avoid hearing damage.
 Do not attempt to disassemble or repair the headphones. Contact Kogan.com for
any maintenance requirements.
 Do not place strong pressure or heavy objects on the product.
Tips
 Active Noise Cancelling Technology can effectively reduce background noise in a
busy environment, such as traffic or heavy vehicle sounds (low-frequency waves,
150-450Hz).
 Human voice (high-frequency waves) and part of the medium frequency band
cannot be eliminated.
Bluetooth version V5.0 Talking time 50H
Speaker 32Ω 40mm
20-20KHz Music playback time 50H
Standby time 90 days ANC playback time 25H
Frequency 2400MHz-2480MHz Charge current <1A
Microphone Sensitivity: -42 ±3dB
Frequency: 100-10KHz Charge voltage 5V
ANC function Yes Charging time 2-3H
Protocol supported
HSP HFP
A2DP AVRCP Bluetooth distance 10m
Battery capacity 1050mAh
SPECIFICATION

Problem Remedy
The indicator blinks red
quickly or continuously  Battery is low – charge the headphones as soon
as possible.
Headphones will not
power on  Ensure that the battery is charged.
No indicator when
charging
 There may be no indication when charging for the
first few minutes. If the battery is completely
exhausted or charged for the first time after not
being used for a long period, the indicator glows
red to indicate the charging state after short time.
No audio during
Bluetooth connection
 Ensure the headphones are switched on.
 Ensure the music sound output on the device is set
to the headphones (M6).
 Ensure the Bluetooth headphones and the audio
device are paired and connected successfully.
 Ensure the distance between the headphones and
audio device is less than 10 meters/32.8ft.
 Ensure the audio device is not connected to other
Bluetooth headphones or speakers.
No audio during wired
connection
 Ensure the correct 3.5mm audio cable is used and
connected securely. Note that the headphone
buttons and microphone do not work when using a
wired connection.
 Make sure the audio device is in normal working
condition and without damage.
Bluetooth connection is
not successful
 Ensure both the headphone and audio device’s
Bluetooth connections are open.
 Ensure the headphone enters Bluetooth pairing
mode (LED indicator blinks blue)
 Try to ignore the previously connected Bluetooth
devices and empty the Bluetooth device list.
Search for the headphones again.
TROUBLESHOOTING

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
