Kohler BARDON K-5486T User manual

-1-
BARDON
BARDON
TOUCH SS HAND DRYER
INSTALLATION INSTRUCTIONS
K-5486T
LE
·
·
·
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning, and
warranty information -
.
please leave instructions for the
consumer
·
·
·-
ã
ã
, 2010
Copyright Kohler China Ltd., 2010
528137
ROUGHING-IN
BEFORE YOU BEGINBEFORE YOU BEGIN
A. Specifications A.
Activation
Dime sions
WHD
n
Voltage/Power
Detection Distance
Air Temperature
Operation Duration
Motor Type
Air Velocity
Activated by an infared sensor. The
machine operates automatically.
305 225 206mm
(12.0 8.9 )
" " 8.1"
220-240V, 50/60Hz, 2400~2800W
65 to 75 (149 F to 167 F) Ambient
temperature 25 (77 F)
ooo o
oo
CC
C
60 (Self-protection
automatic shutoff)
Induction Type (Brushless)
30 4cm for A4 white paper
WHD
/
305 225 206mm
(12.0 8.9 )
" " 8.1"
220-240V, 50/60Hz, 2400~2800W
65~75 (149 F~167 F)
25 (77 F)
ooo
oo
C
C
60
()
AC 220V 50Hz 14m/s 10%
AC 220V 60Hz 17m/s 10%
30 4cm
·
·
This machine is equipped with an infrared sensor for
automatic activation.
The product is made in Taiwan.
·
·
sec
106 2 324 200131
AC 220V 50Hz 14m/s 10%
AC 220V 60Hz 17m/s 10%
WARNING: Risk of electrical shock.
WARNING: Risk of electrical shock.
WARNING: Risk of electrical shock.
A licensed
electrician should make all electrical connections.
Connect only to
a circuit protected by a Ground-Fault Circuit-
Interrupter (GFCI) or Earth-Leakage Circuit-Breaker
(ELCB).
Disconnect
power before servicing.
GFCI ELCB
1045760-T01-D

B. Packing List B.
-2-
Installation Kit
Illustration Description Quantity
Wrench
Plastic Dowel
Fixing Screw
Washer
Spring Washer
1
2
3
4
5
4
4
4
4
1
1047946
Heater Assembly
1047977
Power Board Assembly
1047945
Sensor Assembly
Security Screw
Security Wrench
1047920-*
Casing
4
3
2
1
2
3
4
()
()
()
Casing-CP
Casing-OP
Casing-SH
Sensor assembly
Heater assembly
Power board assembly
1047920-CP
1047920-OP
1047920-SH
1047945
1047946
1047977
1
1045760-T01-D

-3-
NOTE
1. Make sure the sensor is located min
60cm(23 inch) above everthing
bellow to prevent false triggers.
2. Never install hand dryer onto a
wooden or plastic wall finish.
3. Before installation, make sure the
power source complies with
specification of the machine.
1. 60cm
2.
3.
BEFORE INSTALLATIONBEFORE INSTALLATION
60cm 40cm
110~120cm
Operation Diagram
Sensor
Detective
PCB
Relay O/P Neutral
T.S
Heater
Motor
Live Neutral
C
O/P
60cm
STANDARD INSTALLATIONSTANDARD INSTALLATION
1045760-T01-D

-4-
3. Insert screws into dowels and tighten them. (Fig.2)
3. ( 2)
4. Connect AC power cable. (Fig.3)
4. ( 3)
Fig.2
2
Fig.3
3
LIVE NEUTRAL
GND
For CCC
INSTALLATION
A. Installation Steps
1. Paste the installation template at appropriate location on
the wall.
2. Drill four holes, dia 10mm insert plastic dowels. (Fig.1)
2. 10mm
(1)
A.
1.
10mm
Fig.1
1
1045760-T01-D

Fig.4
4
B. Installation Check
1. Check AC power cable connection.
2. Check if AC power on.
3. Put outer cover back.
4. Insert security screws and tighten them.(Fig.4)
B.
1.
2.
3.
4. ( 4)
C. Operation Instructions
1. The machine starts operating automatically when user s
hands are put approximately 20cm (7.78") below the
sensor located next to air louver. Whenever the hands are
moved out of sensing range, the machine will stop after
approx. 2 sec.
2. The 0.5 sec time delay helps avoid false triggers by
unexpected movements.
3. When the air temperature is over 120 C or any fault has
occurred, the security device will shut off the power of the
heater.
4. For safety reasons, the machine will immediately stop
operating when it is used continuously over 60seconds.
The machine resumes to standard function when hands
are moved away.
o
C.
1. 20cm
2
2. 0.5
3. 120 C
4. 60
o
-5-
1045760-T01-D

D. Adjustment of Sensor
1. Loosen Secuity Screws and remove Casing. (Use the
Security Wrench from the attached package in the carton.)
2. Refer to drawing for the location of power board.
3. Use a tiny flat screwdriver to turn adjustment screw in
clockwise direction to lengthen the sensing distance. To
shorten the sensing distance turn in counter-clockwise
direction.
4. After finishing the adjustment, put back Outer Case and
fasten it.
D.
1. (
)
2.
3.
4.
Sensor Range Adjustment
E. Important Notice
1. Turn off power supply prior to removing outer case.
2. Turn off power supply before maintenance or cleaning. If
Casing or Air Louver are covered with dust, do not splash
water onto it. Use only damp sponge or cloth to wipe dirt
off.
3. Do not use eradicator, abrasive powder or oil, acid or alkali
liquid detergent to clean casing or air louver.
4. Never try to put a small screw-driver or any other object
into the holes of air Louver from outside. This might cause
damage to the interior parts, and electric shock may occur.
5. Keep sensor case clean, never use any abrasive cleaning
agent, rough surface articles, steel brush or sandpaper to
rub the sensor case. This will make the sensor case dull
and decrease the sensitivity of sensor.
6. Do not dry other objects except hands to ensure the safety.
7. To avoid damage to the machine or cause physical harm to
the person, please keep the live parts away from water.
8. Do not bump the casing.
9. For indoor installation and use only.
E.
1.
2.
3.
4.
5.
6.
7.
8.
9.
-6-
1045760-T01-D

F. Troubleshooting(For Electrician Use Only) F.
Problem
Hand dryer does
not work
Cold air without heat
Motor out of order
Diagnosis
Check power
supply is on.
The sensor cable
is unplugged.
Sensing distance
too short.
Sensor assembly
or power cord out
of order.
Heater out of order.
Motor out of order.
Motor s condenser
out of order.
Solution
Turn on the power.
Connect the cable
properly.
Adjust sensing
distance.
Refer to item D to
adjust.
Contact the
vendor for service.
(
D)
-7-
Notice: Troubleshooting needs to be done by
professional of KOHLER CHINA. Users are not suggested
to do this without help. Please remember that the
checking and repairs done by users themselves could
easily cause damage to the machine or cause physical
harm to the person.
1045760-T01-D
