Koldwave 6HK13BEH0 User manual

Owner’s Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate
or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions
could result in personal injury and / or property damage! Retain instructions for future reference.
Description
Portable Heat Pump feature spot cooling/heating
for large areas where cooling/heating of the entire
area is not practical. A dedicated spot cooling/heating
thermostat controls the unit in this application.
This unit can also be used in smaller areas for room
cooling/heating. A control panel provides ease of use
and contains a self-diagnostic function and display,
showing operating modes, room and set temperatures,
and faults.
If an abnormal operation occurs, a visual display of
the fault is shown. Caster wheels are included for easy
portability. Suitable applications include: a factory or work
place, industrial kitchen, computer room, emergency
cooling/heating, supplement cooling/heating etc.
Unpacking
After unpacking the unit, carefully inspect unit for any damage that may have occurred during transit. Check for any
loose, missing, or damaged parts.
Specications
6HK13BEH0
Figure 1
Portable Heat Pump
6HK13-IOM
6HK13BEH0
Model No. Power Supply
Ph-V-Hz
Cooling Capacity
Btu/h
Power Consumption
Watts
Rated Current
Amps
EER
Btu/Wh
6HK13BEH0 Single Phase,
115V, 60Hz
13,200 (Cooling)
14,300 (Heating)
0.94kW (Cooling)
0.95kW (Heatling)
8.58A (Cooling)
8.53A (Heatling) 11.0
Model No. Power Cord Gauge
AWG
Power Cord
Length ft
Dimensions
W x D x H - in. (mm)
6HK13BEH0 12 6 20.6 x 26.4 x 41.1
(523 x 670 x 1044)

2
Owner’s Manual 6HK13BEH0
Specications (Continued)
Thank you for selecting this Koldwave Portable Heat pump. It provides you with spot cooling/heating for large
areas where cooling/heating of an entire area is not practical or possible. Please read this manual before
installing the 6HK13BEH0 as it provides important information that should be followed during installation and
maintenance of the Portable Heat pump, allowing you to correctly set up your system for the maximum safety
and performance. Included is information on customer support and service, if it is required. If you experience
a problem with the unit, please refer to the Troubleshooting section in this manual to correct the problem. If the
problem is not corrected, please collect information so that the Technical Support personnel can more effectively
assist you.
Model No. Weight (Net / Gross) Lbs (kg) Condensate Tank
Gallons (Liters)
Setting Temperature
(In temp mode) °F (°C)
6HK13BEH0 190 / 196 lbs. (86 / 89 kg) 3.17 (12) Cooling 64~113 (18~45)
Heating 56~80 (12~27)
Model No. Application Area
(Room cool mode) ft² (m²)
Refrigerant
Type / oz (g) Design Pressure - Hi/Low Psig
6HK13BEH0 376 (35) R-410A /
52.2 (1,480) 450 / 250
Model No. Wheels
pcs / diameter
Hot Air Duct Diameter
In. (mm) Maximum Duct Length ft (m)
6HK13BEH0 4 / 76mm 12 (300) 50 (15)
Safety Devices Compressor overload protector, Anti-freezing thermister, Full drain tank switch, Automatic restart (Power interruption),
Compressor time delay program, High pressure sensor, Low pressure sensor.
Features Temperature control, Self-diagnostic function, Six speed fan, Optional drain pump kit, Washable lters, °F (°C) display,
Off-timer, Auto fan speed option.

3
Owner’s Manual 6HK13BEH0
General Safety Information
Please read this manual carefully for instructions on correct installation and usage. Please read all safeguards.
1. Transport and store the unit in an upright position only. Leave unit in an upright position for at least 3 hours
before rst use.
2. Always place the unit on an even, level surface.
3. Ensure the unit is connected to a grounded power supply of the correct rating / capacity.
4. The unit will cool when the room temperature is between 64°F (18°C) ~ 113°F (45°C) and heat when the room
temperature is between 56°F (12°C) ~ 80°F (27°C), depending on the thermostat setting.
5. DO NOT use this unit for functions other than those described in this instruction manual.
6. DO NOT tilt the unit.
7. DO NOT cover or obstruct the unit’s inlet and outlet grilles.
8. DO NOT use the unit in areas where it will be exposed to rain or water.
9. NEVER unplug the unit while it is operating.
DO NOT use the unit in wet environments, such as a laundry room, to avoid the risk of
electrical shock.
10. DO NOT place any foreign objects on the unit.
11. DO NOT operate the unit with wet or damp hands.
12. DO NOT allow chemical substances to come into contact with the unit.
13. DO NOT operate the unit in the presence of ammable substances or vapors such as alcohols, pesticides,
gasoline, etc.
DO NOT operate the unit in explosive or ammable environments.
14. DO NOT use the plug to start and to stop the unit. Always use the control panel to start and to stop the unit.
15. Always turn off the unit when it is not in use and unplug the power plug from the electrical outlet.
16. Always turn the unit off and unplug the main power plug from the electrical outlet before cleaning, moving or
performing maintenance.
17. AVOID the use of adapter plugs or extension cords. If it is necessary to use an extension cord or an adapter
plug to operate the unit, ensure that they are correctly rated for the application. Consult a local qualied
electrician and all local electrical codes to ensure proper setup. Any extension cord used with this device
must be rated for a minimum of 120V. (20A)
18. DO NOT unplug the unit by pulling on the electrical cord. Keep electrical cord away from heat sources and
always completely unroll the cord to avoid overheating. If the power cord becomes damaged, a qualied
service agent, qualied electrician, or similarly qualied person must replace it, in order to avoid a hazard
or shock.

4
Owner’s Manual 6HK13BEH0
DO NOT operate a unit with a damaged power cord.
19. The lters must be used with the product at all times. When the lters are removed for cleaning, always
ensure that the unit has been turned off and unplugged from the electrical outlet.
20. Regularly clean the lters to maintain efciency. If the lters are not cleaned regularly, the units output
performance and efciency will decline and energy consumption will increase.
21. DO NOT operate the unit with a damaged power cord or plug, after it malfunctions, has been dropped or
damaged.
22. Only use in the upright position on an even, at surface. Unit must be positioned at least 24 inches (60 cm)
from the nearest object in any direction.
23. Stop operation immediately if abnormal noise or odor is noticed. Contact a local service center.
24. Appliance is not to used by children or persons with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given supervision or instruction.
25. Children being supervised not to play with appliance.
26. That the appliance shall be installed in accordance with national wiring regulations.
27. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied
persons in order to avoid a hazard.
SAVE THESE INSTRUCTIONS

5
Owner’s Manual 6HK13BEH0
Assembly (6HK13BEH0)
5
6HK13BEHO
Owner’s Manual
Assembly (6HK13BEHO)
Front and Right Side View
Display / Control board
Top fan exhaust flange
Evaporator / filter
Guide bar for condensate water tank
Condensate water tank (Water level is
sensed, and the unit opera on is stopped
when tank is full. An alarm will be
displayed. Empty the tank and replace to
resume operaon)
1. Take out the cord holder from
the accessory box.
2. Place the cord holder on the
back side of the unit
3. Use screws (enclosed inside
of accessory box with cord holder)
to install the cord holder on the
e 4.
POWER CORD HOLDER
DISCHARGE DUCTS/SUPPLY AIR DUCT
Figure 3Figure 2
Figure 4Figure 5
Power cord holder
Caster
Electrical access panel
Condenser / filter
1. Remove the top fan exhaust
flange from carton.
2. Place the top fan exhaust flange
on the top of the unit.
3. Use screws (enclosed inside
of box with the top fan exhaust
flange) to install the top fan
exhaust flange on the unit
as shown in Figure 6.
TOP FAN EXHAUST FLANGE
Figure 6Figure 7
Figure 8
ABC
Condenser plenum can be purchased separately. Condenser plenum
fits over the condenser to duct condenser air to the unit to improve
cooling efficiency.
1. Remove the Filter("A")
2. Check the Filter("C") is inserted properly in Condenser plenum("B")
3. Install "B" which contains "C" by using driver with enclosed
bolts(6EA) as Figure 8.
CONDENSER PLENUM
Component parts
1. Remove cool air outlet hose(s)
from carton.
2. Place the cool air outlet hose(s)
on the front top of the unit
3. Use screws (enclosed inside of box
with cool air outlet hose(s) to
install the cool air outlet hose(s) on
the unit as shown in Figure 5.
EVAPORATOR PLENUM
An evaporator plenum can be purchased
separately. Plenum fits over the evaporator
to duct evaporator air to the unit to
improve cooling efficiency.
1. Remove the evaporator cover from the
unit.
2. Remove the filter from the evaporator
cover and put it into the plenum.
3. Install the plenum in front of the
evaporator.

6
Owner’s Manual 6HK13BEH0
Installation
WARNINGS REGARDING PROPER LOCATION FOR INSTALLATION
Do not use the unit in explosive environments or in areas where ammable gas leakage
may occur.
Do not use the unit in areas where it will be exposed to rain or water.
Do not use the unit in a corrosive atmosphere.
Do not use the unit above 54°F (12°C) ~ 113°F (45°C).
Do not install the unit on uneven or sloping surface. The unit may roll or topple over
even if the casters are set to the locked position.
MOVING THE UNIT
Unlock the casters and push the unit using the side handles to a at, level surface and set the caster brakes to
the locked position.
PLUGGING IN THE UNIT
Check the prongs and surface of the power cord plug for dust/dirt. If dust and/or dirt are present, wipe off with a
clean, dry cloth.
Check the power cord, plug and prongs for damage or excess play.
If any damage or excess play is found, contact a qualied repair technician or a qualied electrician to perform
replacement or repair of the power cord, plug or prongs.
If the power cord or plug is damaged, repair should only be performed by qualied
electrical personnel.
Do not connect / disconnect the power cord or attempt to operate buttons with wet
hands. This could result in electrical shock.
NOTE: Make sure the AC outlet is free of dirt, dust, oil, water, or any other foreign material. The unit is equipped
with an approved NEMA plug conguration.

7
Owner’s Manual 6HK13BEH0
Operation
CONTROL PANEL
When power is connected POWER lamp will be on.
1. POWER BUTTON
- Activates unit when POWER BUTTON is pressed for 2 seconds. If POWER BUTTON is pressed for 2
seconds during operation, unit stops.
Note: It will take more than 10 seconds to start fans.
2. FAN SPEED BUTTON
- Changes fan speed from (AUTO) to (MANUAL) when pressed.
- When MANUAL lamp is on, change fan speed between 1 and 6 step by pressing UP/DOWN BUTTONS.
- When AUTO lamp is on, fan speed is changed automatically between 1 and 6 step. When COOL mode, fan
speed starts in high speed. When HEAT mode, fan speed starts in low speed.
3. TEMP SELECT BUTTON
- Choose temperature sensor by pressing this button shortly.
- When IN lamp is on, inlet temperature sensor works so it is used to control inside of a room.
- When OUT lamp is on, outlet temperature sensor works so it is used to provide cool air or hot air directly to
people or material.
- By pressing this button for 2 seconds, SET lamp will be on and SET mode activates. Then set the target
temperature by pressing UP/DOWN BUTTONS. After setting the target temperature, press TEMP SELECT
BUTTON for 2 seconds and SET lamp will be off and setting temperature will be memorized.
7
6HK13BEHO
Owner’s Manual
Oper on
CONTROL PANEL
1
. POWER BUTTON
vates unit when POWER BUTTON is pressed for 2 seconds. If POWER BUTTON is pressed for 2
seconds during oper on, unit stops.
2
. FAN SPEED BUTTON
- Changes fan speed from (AUTO) to (MANUAL) when pressed.
- When MANUAL lamp is on, change fan speed between 1 and 6 step by pressing UP/DOWN BUTTONS.
- When AUTO lamp is on, fan speed is changed automa cally between 1 and 6 step. When COOL mode,
fan speed starts in high speed. When HEAT mode, fan speed starts in low speed.
3
. TEMP SELECT BUTTON
- Choose temper on shortly.
- When IN lamp is on, inlet temperature sensor works so it is used to control inside of a room.
- When OUT lamp is on, outlet temperature sensor works so it is used to provide cool air or hot air
directly to people or material.
- By pr on fo vates. Then set the
target temperature by pressing UP/DOWN BUTTO er se ng the target temperature, press
TEMP SELECT BUTTON for 2 seconds and SET lamp will be off and se ng temperature will be
memorized.
When power is connected POWER lamp will be on.
12 3 4
5
9 687
Figure 9
Note :
It will take more than 10 seconds to start fans.

8
Owner’s Manual 6HK13BEH0
4. MODE
- Choose cooling, heating or auto by pressing this button. When all lamps are off, it is blower mode so only
fan operates without operating compressor.
- When AUTO lamp is on, it activates cooling or heating automatically according to TARGET TEMP. It
activates cooling when TARGET TEMP is lower than CURRENT TEMP and will change to activate heating
when CURRENT TEMP reach over the TARGET TEMP by 6°F( 3°C) and change to activate cooling when
CURRENT TEMP reach over the TARGET TEMP by 6°F( 3°C).
5. UP/DOWN BUTTONS
- Change TARGET TEMP value by +/-1.
6. ALARM
- ALARM indicator lights (blinks) and indicates abnormal system operation. If ALARM occurs, compressor
stops. System operation stops when ALARM light is activated (blinks) longer than 3 minutes.
7. CURRENT TEMP
- When IN lamp is on in TEMP SELECT, it displays current room temperature.
- When OUT lamp is on in TEMP SELECT, it displays outlet (cool/hot air) temperature.
- Initial unit is °F. In order to change from °F to °C, press POWER BUTTON and MODE BUTTON together for
2 seconds. Choose 7 by pressing UP/DOWN BUTTON. Choose 0 by pressing UP/DOWN BUTTON. Press
MODE BUTTON for 2 seconds then gure will change to °C
8. TARGET TEMP
- Displays the unit set temperature.
- When OUT lamp is on in TEMP SELECT, always set TARGET TEMP value 32°F (0°C) for COOL mode and
122°F (50°C) for HEAT mode.
- When IN lamp is on in TEMP SELECT, recommendable TARGET TEMP is between 64°F and 113°F
(18°C and 45°C) for both COOL mode and HEAT mode. Recommendable TARGET TEMP for Auto mode is
between 70°F and 113°F (21°C and 45°C)
9. EVAP FAN STEP
- Lamp(s) is(are) on according to evap fan speed. 1 lamp is on when 1 step and 2 lamps are on when 2 step
… 6 lamps are on when 6 step.
OFF-TIMER
-Enter to timer setting mode by pressing FAN SPEED BUTTON and TEMP SELECT BUTTON together for 2
seconds.
- Press UP/DOWN BUTTON to set the timer until it shows the gure you want to set. Setting range is
between 30 minutes and 12 hours.
- If you press MODE BUTTON for 2 seconds, the gure will be memorized and the compressor will stop after
the time set.
- Display will show CURRENT TEMP (for 5 seconds) and remaining time (for 2 seconds) in turn repeatedly.
AUTO RESTART
- If the unit goes off due to an electrical interruption, the unit will automatically restart when the power
resume.

9
Owner’s Manual 6HK13BEH0
Maintenance
FILTER CLEANING (See Figures 10 and 11)
There are two lters in the unit. The evaporator lter is located at the front of the unit. The condenser lter is
located at the back of the unit.1. Transport and store the unit in an upright position only. Leave unit in an upright
position for at least 3 hours before rst use.
1. Pull the lter frame forward to remove the front lter.
2. Slide lter up and use a vacuum cleaner to remove the dust from the lter.
3. If the lter is heavily covered with dust and dirt, warm water and mild soap or neutral detergent may be used
to wash the lter. Do not use any other chemicals to clean lter, as they will likely damage the lter.
4. Dry the lter in a shaded area before replacing it. Do not operate the unit without the lter installed and the
lter guard in the closed position.
5. Replace the clean lter and close the lter guard.
6. To clean the condenser lter, lift up on the rear lter from the middle bar slightly and then angle the lter
outwards from the bottom and remove.
7. Use the same cleaning procedure as above (3 – 5).
8. To replace the condenser lter, place the top of the lter in the guide and slide the lter up until the bottom of
the lter clears the frame. Then push the bottom of lter into the guide and let lter gently fall inside the guide.
NOTE: For effective cooling clean the lter at least every 2 weeks.
Do not operate without the lter tted.
Do not operate the unit with a damaged cord or plug, after the unit malfunctions, or if
the unit has been dropped or damaged.
– For your convenience, record the complete model number and product name (located on the Product
Identication Plate), the purchase date, purchase location, serial number, and warranty period in the table
below.
– Also, attach your purchase receipt as proof of purchase to this instruction manual for future reference.
– To ensure your product is covered by warranty, the complete faulty product along with your original purchase
receipt must be provided at the place of purchase.
9
6HK13BEHO
Owner’s Manual
Maintenance
FILTER CLEANING (See Figures 10 and 11)
There are two fi lters in the unit. The evaporator fi lter is located at the front of the unit. The
condenser fi lter is located at the back of the unit.
1. Pull the fi lter frame forward to remove the front fi lter.
2. Slide fi lter up and use a vacuum cleaner to remove the dust from the fi lter.
3. If the fi lter is heavily covered with dust and dirt, warm water and mild soap or neutral deter-
gent may be used to wash the fi lter. Do not use any other chemicals to clean fi lter, as they will
likely damage the fi lter.
4. Dry the fi lter in a shaded area before replacing it. Do not operate the unit without the fi lter
installed and the fi lter guard in the closed posi on.
5. Replace the clean fi lter and close the fi lter guard.
6. To clean the condenser fi lter, up on the rear fi lter from the middle bar slightly and then
angle the fi lter outwards from the bo om and remove.
7.Use the same cleaning procedure as above (3 – 5).
8. To replace the condenser fi lter, place the top of the fi lter in the guide and slide the fi lter up
un l om of the fi lter clears the frame. Then push the bo om of fi lter into the guide
and let fi lter gently fall inside the guide.
NOTE: For eff e ve cooling clean the fi lter at least every 2 weeks.
– For your convenience, record the complete model number and product name (located on the
Product Iden fi c on Plate), the purchase date, purchase loca on, serial number, and war-
ranty period in the table below.
– Also, a ach your purchase receipt as proof of purchase to this instruc on manual for future
reference.
– To ensure your product is covered by warranty, the complete faulty product along with your
original purchase receipt must be provided at the place of purchase.
Do not operate without the filter fied.
Do not operate the unit with a damaged cord or plug, a er the unit malfunc-
ons, or if the unit has been dropped or damaged.
– Pull the filter frame forward
to remove the front filter
– Slide filter up and use
a vacuum cleaner to remove
the dust from the filter.
– Remove dust from the filter
using a vacuum cleaner
achment.
– If required wash the filter in
lukewarm water with a mild
detergent. Leave to dry in
a shaded area before
reinstalling.
Figure 10 – Removing Filters Figure 11 – Removal of Dust

10
Owner’s Manual 6HK13BEH0
Maintenance (Continued)
– To ensure your product is covered by warranty, the complete faulty product along with your original purchase
receipt must be provided at the place of purchase.
SPRING REPLACEMENT (See Figure 12)
SELF-DIAGNOSTIC CODES (See Table 1)
The alarm light is activated if abnormal operation occurs, and a code is displayed on the control panel. The
compressor and condenser fan motor will stop operating. The evaporator fan will continue to run for 3 minutes. If
the fault is rectied within 3 minutes, the unit will resume operation. If the fault persists for more than 3 minutes,
the evaporator fan also stops. The fault must be rectied before the unit can resume normal operation.
10
6HK13BEHO Owner’s Manual
Maintenance (Con nued)
–
To ensure your product is covered by warranty, the complete faulty product along with your
original purchase receipt must be provided at the place of purchase.
ProductP oner
Model No.
Date of Purchase
Place of Purchase
Serial No.
Period of Warranty
Customer: Please read and keep this
manual for future reference and keep
sales receipt as proof of purchase.
SPRING REPLACEMENT (See Figure 12)
SELF-DIAGNOSTIC CODES (See Table 1)
vated if abnormal oper on occurs, and a code is displayed on the control
panel. The compressor and condenser fan motor will stop oper ng. The evaporator fan will con-
nue to run for 3 minutes. If the fault is re fi ed within 3 minutes, the unit will resume opera-
on. If the fault persists for more than 3 minutes, the evaporator fan also stops. The fault must
be r fi ed before the unit can resume normal oper on.
There are two springs on the rear of condensate water tank guide.
1. Release the screw on the spring hook.
2. Take off the spring hook, and then pull out the opposite spring
hook from hole in the condensate water tank guide.
3. Replace with a new spring in reverse order.
4. Repeat this cycle for the other spring.
Figure 12 – The process of
spring replacement
10
6HK13BEHO
Owner’s Manual
Maintenance (Con nued)
– To ensure your product is covered by warranty, the complete faulty product along with your
original purchase receipt must be provided at the place of purchase.
ProductP oner
Model No.
Date of Purchase
Place of Purchase
Serial No.
Period of Warranty
Customer: Please read and keep this
manual for future reference and keep
sales receipt as proof of purchase.
SPRING REPLACEMENT
(See Figure 12)
SELF-DIAGNOSTIC CODES
(See Table 1)
vated if abnormal oper on occurs, and a code is displayed on the control
panel. The compressor and condenser fan motor will stop oper ng. The evaporator fan will con-
nue to run for 3 minutes. If the fault is re fi ed within 3 minutes, the unit will resume opera-
on. If the fault persists for more than 3 minutes, the evaporator fan also stops. The fault must
be r fi ed before the unit can resume normal oper on.
There are two springs on the rear of condensate water tank guide.
1. Release the screw on the spring hook.
2. Take off the spring hook, and then pull out the opposite spring
hook from hole in the condensate water tank guide.
3. Replace with a new spring in reverse order.
4. Repeat this cycle for the other spring.
Figure 12 – The process of
spring replacement

11
Owner’s Manual 6HK13BEH0
11
6HK13BEHO
Owner’s Manual
Table 1-1- Alarm Codes
-
Table 1-1- Alarm Codes

12
Owner’s Manual 6HK13BEH0
12
6HK13BEHO
Owner’s Manual
-
Table 1-2- Alarm Codes
Table 1-2- Alarm Codes

13
Owner’s Manual 6HK13BEH0
Wiring Diagram
13
6HK13BEHO
Owner’s Manual
Wiring Diagram
Figure 13 - 6HK13BEHO

14
Owner’s Manual 6HK13BEH0
Troubleshooting chart
14
6HK13BEHO
Owner’s Manual
Tr ng chart
SymptomPossible Cause(s) Corr ve Ac on
Water leakage
High water level in con-
densate tank
1. Remove blockage from drain
hose
2. Remove any object stuck under-
neath of the black panel under
the water tank
The unit doesn’t work
1. Check the power supply
to verify that power is
available to the unit
1. Reset the circuit breaker and
restart the unit
2. Verify that the power
cord is connected
3. No cause
2. Connect power cord
3. Wait for 20 seconds
No cold air flows from the
cold air outlet
1. Ambient air cannot be
properly cooled if the
filter is dirty and not
regularly cleaned
1. Clean the filter
2. Compressor will not
work if the unit is
turned off and on
quickly
2. Wait 2 minutes a er unit is
turned off before turning the
unit back on
3. The ambient air tem-
perature may be too
high
3. The temperature of the com-
pressor can be higher when
the ambient temperature is
too high. The compressor will
not work unless the ambient
air temperature is within the
acceptable oper ng range of
the unit
Water flow can be heard
er compressor shuts off
No causeCommon to hear coolant flowing
er unit shuts off
Alarm displays “FT”with
less than half of condensate
water in the tank
Spring is possibly broken
Spring is possibly broken Replace a new spring
(See Maintenance page 10)

15
Owner’s Manual 6HK13BEH0
Replacement Parts
Description Part Number
Cool Air Grill KWPHGRL
Evaporator Filter KWPHFLT-03E
Condenser Filter KWPHFLT-03C
Evaporator Fan Motor KWPHMTRE-03
Condenser Fan Motor KWPHMTRC-03
Evaporator Fan KWPHFANE-03
Condenser Fan KWPHFANC-03
Cap Evaporator Motor KWPHCAPM-03E
Cap Condenser Motor KWPHCAPM-03C
HP Sensor KWPHHPS-01
LP Sensor KWPHLPS-01
Compressor KWPHCOMP-03
Comp Cap KWPHCAPC-03
Top Panel KWPHPNTP-03
Left Panel KWPHPNLF-03
Right Panel KWPHPNRT-03
Front Panel KWPHPNFT-03
Front Grill KWPHPNGR-03
Rear Panel KWPHPNBK-03
Condenser Coil KWPHCOND-03
Evaporator Coil KWPHEVA-03
Cool Air Duct Bracket KWPHBRCK

Owner’s Manual 6HK13BEH0
LIMITED PRODUCT WARRANTY
Koldwave warrants all Koldwave products to be free from defects in materials or workmanship, under normal use
and service, for a period of twelve (24) months from date of shipment from the factory. Koldwave further warrants
that the refrigeration compressor will be free from defects in materials and workmanship for (3) years from date of
shipment from the factory.
Koldwave’s obligation under this warranty is limited to the repair or replacement at its option, of any part or parts
which, upon Koldwave’s examination at its factory, are shown to be defective or at Koldwave’s option, the return
of the purchase price to the purchaser. Correction of such defects by repair or replacement, or, at Koldwave’s
option, the return of the purchase price shall constitute fulllment of warranty obligations to the purchaser.
This warranty does not cover corrosion or normal deterioration, or any transportation or labor charges paid for
replacement of parts, adjustments, repairs or any other work. All replacement parts shall be shipped F.O.B. from
Koldwave, Farmville, North Carolina, and all parts returned to Koldwave’s factory shall be at buyer’s expense.
Replacement of all parts hereunder shall not operate to extend the original warranty period as to any part,
including replacement parts supplied hereunder.
THE ABOVE WARRANTY HEREWITH SET FORTH IS IN LIEU OF AND SUPERCEDES ALL OTHER
WARRANTIES INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A
PARTICULAR PURPOSE.
Koldwave shall not be liable for any loss, damage, cost of repair or incidental or consequential damages of
any kind in connection with the sale, use or repair of any Koldwave products. Any repairs made outside of
Koldwave’s factory without its written consent will void this limited warranty. This limited warranty shall be void if
the equipment has been subjected to misuse, negligence, free chemicals in the system, improper maintenance or
is operated contrary to the manufacturer’s recommendations, or if the serial number has been altered, defaced or
removed. Buyer assumes all liability for damages resulting from such handling, possession or use of the product.
No representative of Koldwave or its distributors or dealers is authorized to assume for us any obligation or
liability in connection with this product, nor to alter the terms of this warranty in any way.
LIABILITY UNDER THIS WARRANTY SHALL NOT ATTACH AND BECOME EFFECTIVE UNTIL KOLDWAVE
HAS BEEN PAID IN FULL FOR PRODUCT SUPPLIED.
260 North Elm St.
Westeld, MA 01085
Phone: [phone]
www.Koldwave.com
