  Stand Halogen Floodlight KH 4077
Operating Instructions
Powerfix
IB_KH4077_KO2561_UK.qxd 05.03.2007 11:52 Uhr Seite 2

IB_KH4077_KO2561_UK.qxd 05.03.2007 11:52 Uhr Seite 3

w
e
r
t
q
u
y
i
1!
a
o
d
f
g
IB_KH4077_KO2561_UK.qxd 05.03.2007 11:52 Uhr Seite 4

- 3 - 
KH4077
Content Page
Safety instructions 4
Description of the appliance 5
Assembly 5
Removing the halogen lamps. 6
Inserting the halogen lamps 6
Cleaning 6
Troubleshooting 6
Disposal 7
Technical data 7
Service 7
Importer 7
Read the operating instructions carefully before using the appliance for the first time
and preserve this booklet for later reference. Hand over the manual to whomsoever
you pass the appliance on to.
IB_KH4077_KO2561_UK.qxd 05.03.2007 11:52 Uhr Seite 3

- 4 -

Stand Halogen Floodlight
Safety instructions
 Danger of electrical shock!
• Only connect the Stand Halogen
Floodlight to correctly installed wall
sockets having a mains current of
220 - 240 V at 50 Hz.
• Unplug the Stand Halogen Floodlight
from the socket if you notice any faulty
operation and when you decide to
clean it.
• Under no circumstances may the
Stand Halogen Floodlight be immersed
in liquids, or liquids be permitted to
permeate into the housing.
Should liquids nonetheless gain entry
into the appliance housing, immedia-
tely unplug the appliance from the
mains supply and arrange for it to be
repaired by qualified specialists.
• Never touch the Stand Halogen
Floodlight, power cable or plug with
wet hands
• To unplug the appliance, always pull
the plug from the socket, do not pull
the cord itself
• Do not crease or crimp the power
cable and place it in such a way as to
prevent anyone from stepping on or
tripping over it.
• If the power cable or the Stand
Halogen Floodlight become damaged,
you must have the Stand Halogen
Floodlight repaired by qualified speci-
alists before re-using it.
• Separate your Stand Halogen
Floodlight from the mains supply
immediately after use.The appliance
is only completely switched off
after having been unplugged.
Danger of injuries
• Always keep the Stand Halogen
Floodlight beyond the reach of children
Do not allow children to use it.
Attention
• Always remove the plug from electrical
sockets before exchanging the halogen
lamps.
• Allow the halogen lamps to cool
before removing them.
• Switch the Stand Halogen Floodlight
off only with the ON/OFF switch.
• Never touch the glass covering, the
power cable or the metal housing
whilst it is in operation.
These parts of the appliance will become
very hot during use.
To avoid burn injuries, do not touch
these surfaces!
• Arrange for a defective glass cover to
be immediately replaced by a suitable
new one.
• Never direct the halogen floodlights
towards each other. The appliance
could be damaged by the large gene-
ration of heat.
• Always ensure that the Stand Halogen
Floodlight is sufficiently distant from
yourself and easily meltable items.
• To avoid eye damage, do not look
directly into the Stand Halogen
Floodlight.
• Never place the Stand Halogen
Floodlight in the close proximity of
easily inflammable materials.
• Use exclusively halogen lamps up to
500 Watt.
• Never touch the lightbulb with bare
hands.Always use a dry lint-free cloth.
• Read and observe all safety and
operating instructions.
KH4077
IB_KH4077_KO2561_UK.qxd 05.03.2007 11:52 Uhr Seite 4

- 5 - 
• Ensure that the Stand Halogen
Floodlight has cooled down before
storing it away.
Description of the appliance
qON/OFF Switch
wFloodlight lever
eHalogen floodlight
rProtective grill
tKnurled screw
yCrossbeam
uTelescopic stand
iPower cable
oKnurled screw
aFixing ring
sDistributor box
dKnurled screw
fFixing screw
gGlass cover
Assembly
Danger of electrical shock
Never insert the plug into an electrical
socket until the appliance has been
completely assembled.
Danger of burns
Only touch the halogen lamps when
they are in a switched-off and cooled-
down condition. The halogen lamps will
get very hot. Never touch the lightbulb
with bare hands, always use a clean and
dry lint-free cloth.
Opening up the pedestal base
➩To set up the telescopic stand u, loosen
the knurled screw, o. The pedestal base
can now be opened out to the floor.
➩Turn the knurled screw ountil it is
tight.
Mounting the halogen floodlights e
on the crossbeam.
➩Insert the knurled screw twith the
washer through the hole in the bracket
of the halogen floodlight e.
➩Insert the halogen floodlight ewith
the knurled screw tin the pre-drilled
hole on the crossbeam y. Ensure that
the Stoppers are located behind the
halogen floodlights e.
➩Turn the knurled screw tuntil it is
tight.
Assembling the crossbeam on the
telescopic stand.
➩Insert the knurled screw d first of all
through the hole in the distributer
box s, then through the hole in the
crossbeam y.
➩Now assemble the crossbeam yand
the distributor box swith the assi-
stance of the knurled screw don
the telescopic stand u.
➩Turn the knurled screw duntil it is
tight.
Adjusting the height of the Stand
Halogen Floodlight
➩Loosen the fixing ring a by turning
it in an anti-clockwise direction.
➩Adjust the telescopic stand uto
the desired height.
➩Retighten the fixing ring a by
turning it in a clockwise direction.
 Important! To adjust the halogen
floodlight e, use the knurled screw
t, the fixing screw fand the flood-
light lever w.
KH4077
IB_KH4077_KO2561_UK.qxd 05.03.2007 11:52 Uhr Seite 5

- 6 -

The horizontal position is adjusted in
that the knurled screw tis loosened
and, with the assistance of the flood-
light lever w, it is placed in the desired
position. Retighten the knurled screw t
when the optimal position has been
found.
The vertical position is adjusted in that
the fixing screw fis loosened and and,
with the assistance of the floodlight lever
w, it is placed in the desired position.
Retighten the fixing screw, fwhen
the optimal position has been found.
 Important! During the adjustments
always hold the floodlight lever w
firmly.
 Important! Do not use extension
cables that are longer than 15 m.
Removing the halogen lamps.
1. Switch the appliance off with the
ON/OFF switch q, remove the plug
from the socket and allow the Floor
Halogen Floodlight to cool down.
2. Remove the middle screw on the
top of the lamp housing. Loosen
the glass cover g.
3. Use a dry cloth to take out the
halogen lamp.
4. Remove the halogen lamp.
Inserting the halogen lamps
1. Ensure that the Floor Halogen Flood-
light is switched-off and completely
cooled down.
2. Take the new halogen lamp from its
packaging with a dry cloth. Place a
ceramic end on the appropriate retainer.
3. Place the other ceramic end on the
opposite retainer. Ensure that contact
has been made on both sides. The
retainers should now hold the halogen
lamp securely, such that the halogen
lamp can no longer move itself.
4. Now close the glass cover gand
replace and retighten the middle screw.
5. Switch the Floor Halogen Floodlight
on with the ON/OFF switch q.
6. Should it not function, repeat steps
1- 5.
Cleaning
Danger of electrical shock
Always remove the plug from the socket
before cleaning the Stand Halogen
Floodlight.
Under no circumstances may the appli-
ance be immersed in water or held un-
der running water during cleaning.
Clean the exterior of the Stand Halogen
Floodlight with a moist cloth.
Attention!
Ensure the Floor Halogen Floodlight
is inaccessible for children.
Troubleshooting
Symptom:
The Stand Halogen Floodlight will not
switch on.
Possible cause and remedy:
Check if the Stand Halogen Lamp has
been correctly assembled or if it is possi-
bly damaged. Replace the halogen
lamps if necessary.
KH4077
IB_KH4077_KO2561_UK.qxd 05.03.2007 11:52 Uhr Seite 6

- 7 - 
A domestic electrical fuse is defect.
Check the domestic fuses and, if neces-
sary, renew them.
The power socket is defective.
Try another wall socket.
The Floor Halogen Floodlight is possibly
defect.
Check the connecting lead and the
power plug for damages. Have the
Floor Halogen Floodlight checked over
by specialists.
Disposal
Do not dispose of the device in
normal domestic waste.
Dispose of the device over a registered
waste disposal firm or through your
communal waste disposal facility.
Observe the currently valid regulations.
In case of doubt, consult your waste
disposal facility.
Dispose of the packaging materi-
als in an environmentally respon-
sible manner.
Technical data
Mains voltage: 220 - 240 V ~ / 50 Hz
Rated output: 2 x 500 Watt
Service
DES Ltd
Units 14-15
Bilston Industrial Estate
Oxford Street
Bilston
WV14 7EG
Tel.:[phone]
Fax:[phone]
e-mail: [email protected]
Kompernass Service Ireland
c/o Irish Connection
41 Harbour view
Howth Co. Dublin
Tel: [phone]
Fax:[phone]
e-mail: [email protected]
