Konan Labs KVC-EB120UIS User manual

VER 2.0
KVC-EB120UIS
18Gbps HDBaseT Extender (150m)
with USB 2.0

Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully
before connecting, operating or adjusting this product. Please keep this manual
for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge
protection systems is highly recommended in order to protect and extend the
life of your equipment.
Table of Contents
1. Introduction...........................................................................................
2. Features.................................................................................................
3. Package Contents................................................................................
4. Specifications.......................................................................................
5. Operation Controls and Functions......................................................
5.1 Transmitter Panel.............................................................................
5.2 Receiver Panel................................................................................
5.3 IR Pin Definition................................................................................
6. Application Example............................................................................
1
1
2
2
4
4
5
6
7

1. Introduction
2. Features
1 / 7
This 18Gbps HDBaseT Extender can extend HDMI signal, bi-directional IR
control signal and USB KVM signal to a distance up to 492ft / 150m (Long
Reach Mode) via a single CAT6 cable. This product converts HDMI signal
to standard HDBaseT signal and transmits it through LAN cable. It can easily
control signal source device or display device from the remote end through
bi-directional IR signal pass-through function. Video resolution is up to 4K2K
@60Hz YUV 4:4:4. It also supports POC function.
The extender can be widely used in other fields such as video conference
system, multimedia signal broadcasting, HDMI signal extension, etc.
☆HDMI 2.0b and HDCP 2.2 compliant
☆Support 18Gbps video bandwidth
☆Support video resolution up to 4K2K@60Hz YUV 4:4:4
☆With Mode DIP switch to select HDBaseT Mode & Long Reach Mode
HDBaseT Mode:
USB supports USB 2.0 transmission (support connecting with USB
camera, USB flash drive and other devices); the audio & video signal
transmission distance can be extended up to 328ft / 100m for 4K60
Long Reach Mode:
USB only supports HID (Human Interface Device) device; the audio &
video signal transmission distance can be extended up to 492ft / 150m
for 1080P or 394ft / 120m for 4K60
☆Bi-directional IR signal and USB KVM signal pass-through are supported
☆Support bi-directional POC (Power over Cable) function
☆Advanced EDID management
☆Compact design for easy and flexible installation

3. Package Contents
4. Specifications
Technical
HDMI Compliance HDMI 2.0b
Video Bandwidth 18Gbps
Video Resolution Up to 4K2K@60Hz YUV 4:4:4
Color Depth 8/10/12bit
Color Space RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
HDR HDR, HDR10, HDR10+, Dolby Vision, HLG
LPCM 7.1CH, Dolby True HD and DTS-HD Master
Audio Format
IR Level
2 / 7
①1 x 18Gbps HDBaseT Extender (Transmitter)
②1 x 18Gbps HDBaseT Extender (Receiver)
③1 x IR Blaster cable (1.5 meters)
④1 x IR Wideband Receiver cable (1.5 meters)
⑤4 x Mounting Ears
⑥ 8 x Machine Screws (KM3*4)
⑦1 x 24V/1A Locking Power Supply
⑧1x User Manual
HDCP Compliance HDCP 2.2
USB Compliance USB 2.0
5Vp-p
Transmission
Distance
IR Frequency Wideband 20K-60KHz
Human body model — ±8kV (Air-gap discharge) &
±4kV (Contact discharge)
ESD Protection
HDBaseT Mode: 4K60 --328ft / 100m
Long Reach Mode: 1080P--492ft / 150m；
4K60 -- 394ft / 120m

Connection
Transmitter
Input: 1×HDMI IN [Type A, 19-pin female]
1×IR IN [3.5mm Stereo Mini-jack]
1×SERVICE [Micro-USB jack]
1×USB [USB-B, 4-pin female]
Output: 1×HDBT OUT [RJ45]
1×IR OUT [3.5mm Stereo Mini-jack]
Receiver
Input: 1×HDBT IN [RJ45 with light]
1×IR IN [3.5mm Stereo Mini-jack]
1×SERVICE [Micro-USB jack]
Output: 1×HDMI OUT [Type A, 19-pin female]
1×IR OUT [3.5mm Stereo Mini-jack]
2×USB 2.0 [USB-A, 4-pin female]
Dimensions
Metal Enclosure
Color Black
Transmitter / Receiver:140mm (W)×65mm (D)×18mm (H)
Housing
DC 24V/1A;
Support
bi-directional POC function
13.2W (Max.)
0°C ~ 40°C / 32°F ~ 104°F
-20°C ~ 60°C / -4°F ~ 140°F
Power Supply
Operating Temperature
Storage Temperature
Relative Humidity 20~90% RH (non-condensing)
Power Consumption
Mechanical
3 / 7
Weight Transmitter: 245g, Receiver: 249g

5. Operation Controls and Functions
5.1 Transmitter Panel
DC 24V
DC 24V/1A power input port.
Note that the extender supports POC function, it means that either
Transmitter or Receiver is connected to 24V/1A power supply, the other
doesn’t need power supply.
HDBT output port, connecting to the HDBT IN port of the
Receiver with CAT6 cable.
HDBT OUT
Firmware update port.
HDMI IN HDMI signal input port, connecting to HDMI source device
such as DVD play or Set Top Box.
4 / 7
Function DescriptionName
PWR LED The red LED is on when the Transmitter is powered on.
SERVICE
No.
1
2
3
Data Signal
Indicator
(Yellow)
▪ Illuminating: HDMI signal with HDCP.
▪ Flashing: HDMI signal without HDCP.
▪ Dark: No HDMI signal.
5
4
7
8
Link Signal
Indicator
(Green)
6
▪ Illuminating: Transmitter and Receiver are in good connection
status.
▪ Flashing: Transmitter and Receiver are in poor connection
status.
▪ Dark: Transmitter and Receiver are not connected.
PWR
COPY
STD SERVICE
EDID
HDBT OUT
HDMI IN IR IN IR OUT
PC
DC 24V
13
2
458 9 11
6 7 10
EDID DIP
switch
Used for audio EDID setting (dial to COPY by default).
COPY: Copy the EDID of the HDMI OUT port of Receiver.
STD: Default 1080P 2CH

5.2 Receiver Panel
IR IN Connect to IR receiver cable, the IR receive signal will emit
to the IR OUT port of the Receiver.
IR OUT Connect to IR blaster cable, the IR emit signal is from the IR
IN port of the Receiver.
PC USB-B port, connecting to PC.
Function DescriptionNameNo.
9
10
11
5 / 7
13
458 9
6 7 10 11
DC 24V
DC 24V/1A power input port.
Note that the extender supports POC function, it means that either
Transmitter or Receiver is connected to 24V/1A power supply, the other
doesn’t need power supply.
HDBT IN HDBT input port, connecting to the HDBT OUT port of the
Transmitter with CAT6 cable.
Function DescriptionName
Power LED The power LED is on when the Receiver is powered on.
No.
1
3
4
5
SERVICE Firmware update port.
SERVICE
PWR
HDBT
Long Reach
MODE
IR IN IR OUTHDMI OUT
HDBT IN
USB 2.0 USB 2.0DC 24V
2
2MODE DIP
switch
Used for Mode switching (dial to HDBT by default).
HDBT: Switching to the HDBaseT Mode.
Long Reach: Switching to the Long Reach Mode.

HDMI OUT HDMI signal output port, connecting to HDMI display device
such as TV or monitor.
Connect to the IR blaster cable, the IR signal is from IR
IN port of the Transmitter.
6 / 7
Function DescriptionNameNo.
IR IN Connect to the IR receiver cable. The IR signal will send
to the IR OUT port of the Transmitter.
IR OUT
Data Signal
Indicator
(Yellow)
▪ Illuminate: HDMI signal with HDCP.
▪ Flash: HDMI signal without HDCP.
▪ Dark: No HDMI signal.
7
8
9
10
11
5.3 IR Pin Definition
IR Receiver and Blaster pin’s definition is as below:
IR RECEIVER IR BLASTER
IR Blaster
IR Receiver IR Blaster Signal
Power
NC
IR Signal
Power
Grounding
Note:
When the angle between the IR receiver and the remote control is ± 45 °, the transmission
distance is 0-5 meters;
When the angle between the IR receiver and the remote control is ± 90 °, the transmission
distance is 0-8 meters.
Two USB-A ports, connecting to USB 2.0 devices. (The
maximum output current of a single USB 2.0 port is 500mA,
exceeding which it will not work.)
USB 2.0
ports
6
Link Signal
Indicator
(Green)
▪ Illuminating: Transmitter and Receiver are in good connection
status.
▪ Flashing: Transmitter and Receiver are in poor connection
status.
▪ Dark: Transmitter and Receiver are not connected.

6. Application Example
7 / 7
Transmitter
Receiver
The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo
are trademarks or registered trademarks of HDMI Licensing LLC in the United States
and other countries.
PWR
COPY
STD SERVICE
EDID
HDBT OUT
HDMI IN IR IN IR OUT
PC
DC 24V
HDBT IN
HDMI OUT IR IN IR OUT
DC 24V USB 2.0
USB 2.0
Power Supply
LAN
LAN
DVD or Blu-ray
Player
IR Receiver
IR Blaster
UHDTV
IR Receiver
IR Blaster
CAT6 Cable PC
USB Camera
USB Disk
SERVICE
PWR
HDBT
Long Reach
MODE
