Koncar L1A 60 391NF.BS User manual

LEDENICA
FREEZER
L1A 60 391NF.BS

EN - 1 -
Index
BEFORE USING YOUR APPLIANCE .................................................................. 2
General warnings............................................................................................................... 2
Old and out-of-order fridges or freezers ........................................................................... 4
Safety warnings .................................................................................................................. 4
Installing and operating your freezer ................................................................................ 5
Before Using your freezer .................................................................................................. 6
Information on No-Frost Technology ................................................................................ 6
USAGE INFORMATION ...................................................................................... 7
Operating your Freezer ...................................................................................................... 7
MODE Button ................................................................................................................................ 7
SET Button .................................................................................................................................... 7
Freezer Temperature Adjustment and Activating FAST FREEZING Mode ............................ 7
Fast Freezing Mode .................................................................................................................... 8
While SF mode is selected: ........................................................................................................ 8
Economy mode ............................................................................................................................. 9
Warnings about Temperature Adjustments ..................................................................... 9
PLACING THE FOOD ........................................................................................ 10
CLEANING AND MAINTENANCE ....................................................................... 15
Defrosting ......................................................................................................................... 15
SHIPMENT AND REPOSITIONING ....................................................................15
Repositioning the Door ................................................................................................... 16
BEFORE CALLING SERVICE ............................................................................ 16
Advice for Saving Energy.................................................................................................. 19
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ........................20

EN - 2 -
CHAPTER 1. BEFORE USING YOUR APPLIANCE
General warnings
WARNING: Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended
by the manufacturer.
WARNING: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: To avoid a hazard due to the instability of the appliance,
it must be fixed in accordance with the instructions.
• If your appliance uses R600a as a refrigerant – you can learn
this information from the label on the cooler- you should be careful
during shipment and installation to prevent your appliance’s cooler
elements from being damaged. Although R600a is an
environmentally friendly and natural gas. As it is explosive, in the
event of a leak due to damage to the cooler elements, move your
freezer from open flame or heat sources and ventilate the room
where the appliance is located for a few minutes.
• While carrying and positioning the freezer, do not damage the
cooler gas circuit.
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
• This appliance is intended to be used in household and similar
applications such as;
- staff kitchen areas in shops, offices and other working
environments
- farm houses and by clients in hotels, motels and other residential
type environments

EN - 3 -
- bed and breakfast type environments;
- catering and similar non-retail applications
• If the socket does not match the freezer plug, it must be replaced
by the manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
• A specially grounded plug has been connected to the power
cable of your freezer. This plug should be used with a specially
grounded socket of 16 amperes. If there is no such socket in
your house, please have it installed by an authorized electrician.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazard involved.
Children shall not play with the appliance. Cleaning and user
maintenance, shall not be made by children without supervision.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similar qualified persons in
order to avoid a hazard.
• This appliance is not intended for use at altitudes exceeding
2000 m.

EN - 4 -
Safety warnings
• Do not use multiple receptacles or extension cord.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow children to
play with the appliance or let them hang off the door.
• Do not plug-in or out the plug from the receptacle with wet hands to
prevent electrocution!
• Do not place glass bottles or beverage cans in the freezer. Bottles or
cans may explode.
• Do not place explosive or flammable material in your freezer for your
safety.
• When taking ice made in the freezer, do not touch it, ice may cause ice
burns and/or cuts.
Old and out-of-order fridges or freezers
• If your old fridge or freezer has a lock, break or remove the lock before discarding it,
because children may get trapped inside it and may cause an accident.
• Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore,
take care not to harm environment when you are discarding your old fridges or
freezers.
Please ask your municipal authority about the disposal of the WEEE for the
reuse, recycle and recovery purposes.
Notes:
• Please read the instruction manual carefully before installing and using your appliance.
We are not responsible of the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction manual, and keep this
manual in a safe place to resolve the problems that may occur in the future.
• This appliance is produced to be used at houses and it can only be used in house
and for the specified purposes. It is not suitable for commercial or common use.
Such use will cause the guarantee of the appliance to be cancelled and our company
will not be responsible for the losses to be occurred.
• This appliance is produced to be used in houses and it is only suitable for cooling /
storing foods. It is not suitable for commercial or common use and/or for storing
substances except for food. Our company is not responsible for the losses to be
occurred in the contrary case.

EN - 5 -
• Do not touch frozen goods with wet hands! Do not eat ice-cream and ice
cubes immediately after you have taken them out of the freezer!
• Do not re-freeze the frozen goods after being melted. This may cause
health issues like food poisoning.
• Do not re-freeze frozen goods after they have melted. This may cause health issues
like food poisoning.
• Fix the accessories in the freezer during transportation to prevent damage to
accessories.
• When the door of the freezer is closed, vacuum will occur. Wait for about 1 minute
to reopen it.
Installing and operating your freezer
Before starting to use your freezer, you should pay attention to the following points:
• Operating voltage for your freezer is 220-240 V at 50Hz.
• Mains cord of your freezer has a grounded plug. This plug should be used with a
grounded receptacle that has a 16 ampere fuse minimum. If you don’t have a
receptacle confirming with this, please have it done by a qualified electrician.
• We do not take the responsibility of the damages that occur due to ungrounded
usage.
• Place your freezer in a place that it would not be exposed to direct sunlight.
• Your appliance should be at least 50 cm away from stoves, Gas ovens
and heater cores, and should be at least 5 cm away from electrical
ovens.
• Your freezer should never be used outdoors or left under the rain.
• When your freezer is placed next to a deep freezer, there should be at
least 2 cm between them to prevent humidity on the outer surface.
• Do not place anything on your freezer, and install your freezer in a suitable place so
that at least 15 cm is available on the upper side.
• The adjustable front legs should be adjusted to make sure your appliance is level
and stable. You can adjust the legs by turning them clockwise (or in the opposite
direction). This should be done before placing food in the freezer.
• Before using your freezer, wipe all parts back with warm water added with a tea
spoonful of sodium bicarbonate, and then rinse with clean water and dry. Place all
parts after cleaning.
• Install the plastic distance guide (the part with black vanes at the
rear) by turning it 90° as shown in the figure to prevent the
condenser from touching the wall.
• Freezer should be placed against a wall with a free distance not
exceeding 75 mm.

EN - 6 -
Before Using your freezer
• When it is operated for the first time or after transportation, keep
your freezer in the upright position for 3 hours and plug it on to
allow efficient operation. Otherwise, you may damage the
compressor.
• Your freezer may have a smell when it is operated for the first time; the smell will fade
away when your freezer starts to cool.
Information on No-Frost Technology
No-frost freezers differ from other static freezers in their operating
principle.
In normal freezers, the humidity entering the freezer in the door
openings and the humidity of the food causes freezing in the
freezer. To defrost the snow and ice in the freezer, you should
turn off the freezer, take the food that needs to be kept in a
constant temperature off the freezer, and remove the ice gathered
in the freezer periodically.
The situation is completely different in no-frost freezers. Dry and
cold air is blowed to the freezer homogeneously from several
points via a blower fan. Cold air dispersed homogeneously
even between the shelves cools all your food equally and uniformly,
thus prevents humidity and freezing.
Therefore your no-frost freezer allows you ease of use, besides
its huge volume and stylish appearance.

EN - 7 -
CHAPTER 2. USAGE INFORMATION
Operating your Freezer
FREEZER
TEMPERATURE INDICATOR MODE BUTTON
SET BUTTON
ECONOMY MODE
LAMP
POWER LAMP
FAST FREEZING
MODE LAMP
(For some models)
MODE Button
• Mode button allows switching between Freezer
Indicator, Fast Freezing Mode Lamp, Economy
Mode Lamp.
• When you press once, Freezer Indicator starts to
flash.
Set value is ready to be changed.
• When you press twice, Fast Freezing Mode Lamp starts to flash.
• When you press three times, Economy Mode Lamp starts to flash.
SET Button
Allows the temperature adjustment of the related
compartment when Freezer Indicator is selected with
the mode button.
Freezer Temperature Adjustment and Activating FAST FREEZING Mode
• Initial temperature value for Freezer Indicator is
-18oC.
• Press mode button once.
• The set value for freezer indicator starts to flash
when you press this button.
• The value for freezer indicator changes for a lower
temperature each time you press this button when
the indicator is flashing.
( -16oC, -17oC, -18oC, -19oC, -20oC, -21oC, -22oC, -23oC, -24oC)

EN - 8 -
Recommended Temperature Values for Freezer
Fast Freezing Mode
• To freeze plenty of food
• To freeze ready foods
• To freeze foods rapidly
• To store the seasonal foods for a long time
How to use;
• Press the mode button until Fast Freezing mode.
• While Fast Freezing Mode Lamp is flashing if no
button is clicked for 5 seconds then a beep sound
will be heard and the mode will be enabled.
• While the Fast Freezing mode is active the letters
“SF” will be seen at the Indicator of the Freezer.
While SF mode is selected:
To cancel SF Mode and continue with previous set value:
Please press Mode Button 2 times and wait for 5 secs. SF mode will be cancelled and
appliance will start to work according to previous set value.
To cancel SF Mode and continue with new set value:
Please press Mode Button 1 time and in 5 sec, push set button until you see set value you
want and wait for 5 secs. SF mode will be cancelled and appliance will start to work
according to new set value.
To cancel SF Mode and activate Economy Mode:
Please press Mode Button 3 times and wait for 5 secs. SF mode will be cancelled and
appliance will start to work according to Economy Mode.
Note: "Super Freezing" mode will be cancelled automatically after 24 hours or when the
freezer sensor temperature falls below -32°C.
If Super Freeze mode is finished automatically, SF led will continue to light. It is enough to
push mode button to turn off SF led.
When would it be adjusted? Inner Temperature
When small amount of food is stored -16oC, -17oC
In normal usage -18oC, -19oC, -20oC, -21oC
When lots of food is stored -22oC, -23oC, -24oC
• When you wait for 5 seconds without pressing any button after reaching the desired
set value, the set value is activated and your freezer operates with that set value.
• When you press set button until the value for Freezer Indicator reaches -24oC
(maximum cold position), if you press the button again, SF letters will flash.
• If you continue to press the button when SF is flashing, the values will start again
from -16oC.

EN - 9 -
Economy mode
Your freezer will consume minimum energy at -18°C set value which is the most optimum
storage condition.
When to use;
• When you want your freezer to operate economically.
How to use;
• Press the mode button until Economy Mode Led
lights up (3 times).
• While the Economy Mode Led is flashing if no button
is clicked then a beep sound will be heard and the
mode will be enabled.
• During this mode, the freezer operate at the special
temperature value set on the control circuit.
• While the Economy mode is active the letters "Ec" will be seen at the Indicator the
Freezer.
While Economy mode is selected;
To cancel Economy Mode and continue with previous set value:
Please press Mode Button 3 times and wait for 5 secs. Economy mode will be cancelled
and appliance will start to work according to previous set value.
To cancel SF Mode and continue with new set value:
Please press Mode Button 1 time and in 5 sec, push set button until you see set value you
want and wait for 5 secs. Economy mode will be cancelled and appliance will start to work
according to new set value.
To cancel Economy Mode and activate SF Mode:
Please press Mode Button 3 times and wait for 5 secs. Economy mode will be cancelled
and appliance will start to work according to SF Mode.
Warnings about Temperature Adjustments
• Your temperature adjustments will not be deleted when an energy breakdown occurs.
• Do not pass to another adjustment before completing an adjustment
• Temperature adjustments should be made according to the frequency of door
openings, the quantity of food kept inside the freezer and ambient temperature of the
place of your freezer.
• Your freezer should be operated up to 24 hours according to the ambient temperature
without interruption after being plugged in to be completely cooled.
• Do not open doors of your freezer frequently and do not place much food inside it in
this period.
• A 5 minute delaying function is applied to prevent damage to the compressor of your
freezer, when you take the plug off and then plug it on again to operate it or when an
energy breakdown occurs. Your freezer will start to operate normally after 5 minutes.

EN - 10 -
CHAPTER 3. PLACING THE FOOD
• Use your freezer to keep frozen food for a long time and to produce ice.
• Do not place food you want to freeze next to frozen food.
• You should freeze your food (meat, minced meat, fish etc) in portions that allow
consuming in a time.
• Do not put fresh and warm food with frozen food side by side as it can thaw the frozen
food.
• While freezing fresh food (i.e. meat, fish and mincemeat) divide them in parts in
order to use in one time.
• For storing the frozen food; the instructions shown on frozen food packages should
always be followed carefully and if no information is provided, food should not be
stored for more than 3 months from the purchased date.
• Maximum load; if you want to load large quantities and use the maximum net capacity,
you can remove the drawers (Except the bottom one). You can store bulky items
directly on the shelves.
• When buying frozen food ensure that these have been frozen at suitable temperatures
and that the packing is intact.
• Frozen food should be transported in appropriate containers to maintain the quality
of the food and should be returned to the freezing surfaces of the unit in the shortest
possible time.
• If a package of frozen food shows the sign of humidity and abnormal swelling it is
probable that it has been previously stored at an unsuitable temperature and that
the contents have deteriorated.
• The storage life of frozen food depends on the room temperature, thermostat setting,
how often the door is opened, the type of food and the length of time required to
transport the product from the shop to your home. Always follow the instructions
printed on the package and never exceed the maximum storage life indicated.
• If you would use maximum freezing capacity of your freezer
• Take the frozen food in the upper basket to other baskets and activate “Fast Freezing”
mode. “Fast Freezing” mode will be deactivated automatically after 24 hours. Place
the food you want to freeze to the upper basket of the freezer without exceeding the
freezing capacity of your freezer. (Your freezer has the capacity to freeze 15 kg at 25°C
and 14 kg at 32°C) Then reactivate the “Fast Freezing” mode. You can put your food
next to other frozen food after they are frozen (minimum 24 hours after “Fast Freezing”
mode is activated for the 2nd time).
• If you would freeze about 3 kg food in your freezer:
• You can place your food without touching other frozen food and activate “Fast Freezing”
mode. You can put your food next to other frozen food after they are frozen (after
minimum 24 hours).
• Do not re-freeze the frozen goods after being melted. This may cause health issues
like food poisoning.
• Do not place hot food to the freezer before cooling them. This may cause the spoiling
of food frozen before in the freezer.

EN - 11 -
• When you are buying frozen food, make sure that they frozen in proper conditions
and the package is undamaged.
• Follow the instructions for storing conditions on the package of the frozen food while
storing them. If there is no explanation, food must be consumed in a short time.
• If the package of frozen food is humid and smells bad, it may be stored under
inappropriate conditions and spoiled. Do not buy this kind of food!
• Storing time for frozen food may differ according to the ambient temperature, frequency
of door openings, thermostat adjustments, type of food and the time between the
buying of the food and placing of the food in the freezer. Always follow instructions on
the package and do not exceed storing period.
For A+ models
• If there is a power cut or malfunction, do not open the door. This will help maintain the
temperature inside the freezer, ensuring that foods are conserved for about 9,5
hours at 25°C ambient temperature and about 8 hours at 32°C ambient temperature.
Do not re-freeze food that is defrosting or that has already been defrosted. These
foods must be cooked and eaten.

EN - 12 -
Note: Frozen meat should be cooked as fresh meat after being thawed.
If the meat is not cooked after being thawed, it should never be frozen again.
MEAT AND FISH Preparation
Storage
Duration
(months)
Thawing period at
room temperature
(hours)
Beef Steak Wrapped in foil 6-10 1-2
Lamb meat Wrapped in foil 6-8 1-2
Veal roast Wrapped in foil 6-10 1-2
Veal cubes In small pieces 6-10 1-2
Lamb cubes In pieces 4-8 2-3
Minced meat
In the form of oblate
packages without being
spiced
1-3 2-3
Giblets In pieces 1-3 1-2
Bologna / Sausage
/ Salami
Must be packed even if it
has a membrane 1-2 Until it is well thawed
Chicken and turkey Wrapped in foil 7-8 10-12
Goose / duck Wrapped in foil 4-8 10
Venison, pork,
rabbit
Portions of 2.5 kg and with
no bones 9-12 10-12
Freshwater fish,
trout, carp, catfish 2 Until it is well thawed
Lean fish; sea
bass, turbot, sole 4-8 Until it is well thawed
Fatty fish; bonito,
mackerel, blue fish,
anchovy
2-4 Until it is well thawed
Shellfish Cleaned and put into bags 4-6 Until it is well thawed
Caviar In its package, inside an
aluminum or plastic cup 2-3 Until it is well thawed
Snail In salt water, inside an
aluminum or plastic cup 3 Until it is well thawed
It should be washed and
dried after it is well cleaned
inside and scaled, the tail
and head parts should be cut
off where necessary.

EN - 13 -
FRUITS AND
VEGETABLES Preparation
Storage
Duration
(months)
Thawing period at
room temperature
(hours)
Cauliflower
Remove outer leaves and
cut core in pieces. Then
store in a container of
water with a small amount
of lemon juice.
10-12 Can be used without
waiting to be thawed
Green beans,
String beans
Wash them and cut into
small pieces 10-13 Can be used without waiting to be thawed
Peas Hull and wash them 12 Can be used without
waiting to be thawed
Mushrooms and
Asparagus
Wash them and cut into
small pieces 6-9 Can be used without waiting to be thawed
Cabbage In a cleaned fashion 6-8 2-In the room
temperature
Eggplant Cut it into pieces of 2 cm
after washing it 10-12 Can be used without waiting to be thawed
Corn
Clean it and pack it with its
cob or in kernels 12 Can be used without waiting to be thawed
Carrot Clean them and cut into
slices 12 Can be used without waiting to be thawed
Pepper
Remove the stem, cut in
two, and remove the
seeds/core
8-10 Can be used without
waiting to be thawed
Spinach Washed 6-9 2-In the room
temperature
Apple and Pear Peel and slice 8-10 5-In the freezer
Apricot, Peach
Divide it in half and remove
the pit (stone) 4-6 4-In the freezer
Strawberry,
Raspberry Wash and clean them 8-12 2-In the room temperature
Cooked fruits Inside a cup with addition
of 10% of sugar 12 4-In the room temperature
Plums, Cherries,
Sour Cherries
Wash them and remove
the stems 8-12 5-7 - In the room temperature

EN - 14 -
*Should never be frozen with its shell. Albumen and yolk should be frozen individually or
completely mixed.
Some spices in cooked food (aniseed, basil, dill, vinegar, spice mix, ginger, garlic, onion,
mustard, thyme, marjoram, black pepper, bologna sausage etc.) may have a foul taste
when stored for a long time. Therefore, frozen food should be spiced just a little or spice
shoul be added after the food is thawed.
The storing time for the food depends on the oil used. Margarines, veal fat, olive oil and
butter are suitable, peanut oil and lard are not suitable. Cooked food in liquid form should
be frozen in plastic containers, other food should be frozen wrapped in plastic foil or in
plastic bags.
Preparation
Storage
Duration
(months)
Storage Conditions
2-3 Only homogenized
product
In the form of slices 6-8
They may be left in their
original packages for
short time storage. They
should also be wrapped
in plastic foil for long
term storage.
In its own package 6
Egg white 10-12 In a closed container
Egg mixture
(white-yolk)
It is mixed very well, a pinch
of salt or sugar is added to
prevent it from getting too
thick
10 In a closed container
Egg yolk
It is mixed very well, a pinch
of salt or sugar is added to
prevent it from getting too
thick
8-10 In a closed container
Egg*
Dairy Products
and Pastries
Milk
Cheese - other
than white cheese
Butter, margarine
Storage period (months)
Thawing period at
room temperature
(hours)
Thawing duration in
the oven (minutes)
Bread 4-6 2-3 4-5 (220-225 °C)
Biscuits 3-6 1-1,5 5-8 (190-200 °C)
Pie 1-3 2-3 5-10 (200-225 °C)
Tart 1-1,5 3-4 5-8 (190-200 °C)
Phyllo dough 2-3 1-1,5 5-8 (190-200 °C)
Pizza 2-3 2-4 15-20 (200 °C)

EN - 15 -
CHAPTER 4. CLEANING AND MAINTENANCE
• Make sure to unplug the freezer before starting to clean it.
• Do not wash your freezer by pouring water.
• You can wipe the inner and outer sides with a soft cloth
or a sponge using warm and soapy water.
• Remove the parts individually and clean with soapy water.
Do not wash in washing machine.
• Never use flammable, explosive or corrosive material like
thinner, gas, acid for cleaning.
Make sure that your freezer is unplugged while cleaning.
Defrosting
Your freezer defrosts automatically. Water produced
by defrosting flows to evaporating container passing
through water collecting groove, and vaporizes here
by itself.
Eva p or at i o n
container
CHAPTER 5. SHIPMENT AND REPOSITIONING
• Original package and foam may be kept for re-transportation (optionally).
• You should fasten your freezer with thick package, bands or strong cords and follow
the instructions for transportation on the package
for re-transportation.
• Remove movable parts (shelves, accessories,
vegetable bins etc.) or fix them into the freezer
against shocks using bands during re-positioning
and transportation.
Carry your freezer in the upright position.

EN - 16 -
CHAPTER 6. BEFORE CALLING SERVICE
If your freezer is not operating ;
• Is there any electrical faults?
• Is the plug is placed properly in the receptacle?
• Is the fuse of the receptacle that the plug is plugged or the main fuse blown?
• Is there any fault in the socket? Examine this by plugging your freezer into a receptacle
which you are sure that is working.
Repositioning the Door
• It is not possible to change the opening direction of your freezer door, if the door
handles on your freezer are installed from the front surface of the door.
• It is possible to change the opening direction of the door on models without any
handles.
• If the door opening direction of your freezer may be changed, you should contact the
nearest Authorized Service to have the opening direction changed.
WARNING
TYPE MEANING REASON REMEDY
Sr Failure warnings
Appears when one or
more of the freezer parts
fail or there is a problem in
the cooling system.
Call service immediately.
1-) If your frozen food is
thawed, consume them as
soon as possible and do
not freeze them again since
there is a risk of
putrefaction.
2-) Temporarily increase the
freezer temperature setting
to the desired level or
switch the appliance to fast
freezing mode.
LP Low voltage
Freezer switches to the
standby mode when the
voltage supply falls below
170 Volts.
This feature prevents the
compressor from getting
damaged due to low
voltage. Freezer will start
operating automatically
when the voltage restores to
the required level.
LF
Freezer
compartment is
not cold enough
This warning appears if
there has been a power
failure for a long period
and when the freezer is
operated for the first time.

EN - 17 -
Temperature Warning:
The temperature display flashes “LF” and an audible warning sounds, when the
temperature in the freezer is too warm.
A rise in the temperature may be caused by;
• Frequent door opening for long periods of time
• Loading with large quantities of warm foods
• High ambient temperature
• An error with the appliances.
Check Warnings;
Your freezer warns you if the temperatures for freezer compartments are in improper
levels or when a problem occurs in the appliance. Warning codes are displayed in the
Freezer Indicators. Warning codes appear in the Freezer Setting Displays.
Also a warning sound are heared.
Showing code and buzzer will continue until you pushes SET or MODE button. When you
push one of these buttons, buzzer will stop. “LF” warning will be disappear in 15 minutes.
You don’t have to call your service, this condition may appear due to reasons above. You
can keep storing your foods in your freezer. If “LF” warning will not disappear in an hour
after pressing the button, you can call your service and do not re-freeze your food. These
foods must be eaten.
If your freezer is operating too loudly;
Normal Noises
Cracking (Ice cracking) Noise:
• During automatic defrosting.
• When the appliance is cooled or warmed (due to expansion of appliance material).
Short cracking: Heard when the thermostat switches the compressor on/off.
Compressor noise: Normal motor noise. This noise means that the compressor
operates normally Compressor may cause more noise for a short time when it is
activated.
Bubbling noise and splash: This noise is caused by the flow of the refrigerant in the
tubes of the system.
Water flow noise: Normal flow noise of water flowing to the evaporation container
during defrosting. This noise can be heard during defrosting.
Air Blow Noise: Normal fan noise. This noise can be heard in No-Frost freezer during
normal operation of the system due to the circulation of air.
If the edges of freezer cabinet that the door joint contact are warm;
• Especially in summer (hot weather), the surfaces that the joint contact may get
warmer during the operation of the compressor, this is normal.
If humidity builds up inside the freezer;
• Are all food packed properly? Are the containers dried before placing them in the
freezer?
• Is the freezers door opened frequently? Humidity of the room gets in the freezer when

EN - 18 -
the doors are opened. Humidity build up will be faster when you open the doors
more frequently, especially if the humidity of the room is high.
If the door is not opened and closed properly;
• Do the food packages prevent closing of the door?
• Are door joints broken or torn?
• Is your freezer on a level surface?
If your freezer is not cooling enough;
Your freezer is designed to operate in the ambient temperature intervals stated in the
standards, according to the climate class stated in the information label. W e do not
recommend operating your freezer out of stated temperatures value limits in terms of
cooling effectiveness.
Climate Class Ambient Temperature (°C)
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
This appliance is designed for use at an ambient temperature within the 16°C - 43°C
range.
IMPORTANT NOTES:
• Compressor protection function will be activated after sudden power breakdowns or
after unplugging the appliance, because the gas in the cooling system is not
stabilized yet. Your freezer will start after 5 minutes, there is nothing to worry about.
• If you will not use your freezer for a long time (e.g. in summer holidays) unplug it.
Clean your freezer according to Chapter 4 and leave the door open to prevent humidity
and smell.
• If the problem persists after you have followed all the instructions above, please
consult to the nearest Authorized service.
• The lifetime of your appliance stated and declared by the Department of the Industry
is 10 years (the period for retaining parts required for the proper functioning of the
appliance).

EN - 19 -
Advice for Saving Energy
• Do not install the appliance close to heat producing appliances. Such as cooker,
oven, dishwaher or radiator, and locate the appliance in the coolest part of the room.
• Locate the appliance ina cool well ventilated room and make sure that the air openings
of the appliances are not obstructed.
• Always leave warm food to cool down to room temperature before placing in the
freezer.
• Try to avoid keeping the door open for long periods or opening the door too frequently
as warm air will enter the cabinet and cause the compresor to switch on
unnecessarily often.
• Ensure there are no obstructions preventing the door from closing properly.
• Cover foods before placing them in the freezer. This cuts down on moisture build-up
inside the unit.
• Refer to the “temperature settings” section for the suggested temperature control
settings.
• Do not block cold air vents. Doing so causes the freezer to run longer and use more
energy.
• Keep freezer full.
• Level the freezer so that the door closes tightly.
• Occasionally clean the rear of the appliance with a vacuum cleaner or paint brush to
prevent an increased power consumption.
• Keep door gaskets clean and pliable. Replace gaskets if worn.
