Kondo ROBO F2-850 User manual

ThankyouforpurchasingthisROBOPowerCellLi‐Febattery.Thisinstructionmanualcontains
importantsafetyprecautionsandinstructionsonhowtohandlethisproduct.
■ Read First
Precautions for Use
Warning
■ Failuretoobeytheinstructionsbelowmayresultinadangeroussituation
inwhichisithighlylikelythatdeathorseriousinjurymayoccur.
ROBO Power Cell （Li-Fe）
F2/F3-850/1450/2100
Important
DonotchargeusingtheMX‐201charger(charger
providedwithKHR‐3HV,KMR‐P6,KMR‐P4models)
TheMX‐201chargerisspecificallyforusewith
nickel‐cadmiumbatteries,andwillcausefireifused
tochargeLi‐Febatteries.
Instruction Manual
1.Donotreverseconnect/shortthebattery.
Shortingtheterminalscausesdamagetothebattery,whichintheworstcasemayresultinthebatteryemittingsmokeor
fire.Holdtheterminalsfirmlywhendisconnectingthebattery.Donotpullonthecables.Nevertrytomodifythegenuine
connectors.Continuedusemayresultintheframeorpartsbecomingscratched,andtheouterinsulationofwiresmay
becomesplit.Checkthewiresperiodicallytoensureashortcircuitdoesnotoccur.
2.Donotuseatlowvoltage.Becarefulofoverdischarging.
Whenbatteriesareusedforalongperiodofthetime,thecapacitymayreduceandvoltagemaydrop.Thesameoccurs
withLi‐Fe.Usinga9.9vrated3‐cellbatteryatlowerthan8.7vora6.6vratedbatteryatlowerthan5.8v(*)maydamage
thebatterycausingittoswell.Thisisknownasoverdischarging.Continueduseinthisstatemayresultinfire.
*2.9vfor1cell.

3.Donotdamagethebattery.Donotdroporsubjecttostrongimpact.
Donotdisassembleormodify.
Iftheinteriorofthebatteryisexposed,gasmayleakandignite.Whenusingthebattery,besuretocheckthattheouter
coveringisundamaged,thatthebatteryisfittedsecurelyintherobotbody,andthatitcannotbedamagedbyimpactdue
tofalling,etc.beforeturningtheswitchon.Ifthebatteryappearsdamagedduetoimpactorifitappearsunusualinany
way,donotuseorrechargeit.

4.Donotuseifthewireinsulationissplit.
Repeatedusemayresultinthewireinsulationbecomingdamagedandsplit.Pullingwiresacrosstheframeburringor
allowingthebatterytofall,etc.withthewiresexposedmaycausedamagetothewires.Checkthewiresperiodically,as
wiresexposedthroughsmallgapsintheinsulationmayresultinshorting.

5.Donotcarryaroundorstoreuncovered.
Carryingthebatteryaroundinabag,etc.uncoveredmayresultinmetallicobjectscomingintocontactwiththebattery
causingashortoutordamagingthebatteryresultinginashortout.Furthermore,storinginthewronglocationsmay
resultinitemsfallingonthebatteryorwaterbeingsplashedonthebatteryresultinginashortout.Alwaysplaceinside
anLi‐Fesafetybagwhencarryingorstoringthebattery.

6.Usethecorrecttypeofcharger,andmakesureallsettingvaluesare
correct.Becarefulnottooverchargethebattery.
Therearevarioustypesofchargersavailableatawidevarietyofprices,andsuchchargersaredesignedtocharge
specifictypesofbatteries.BesuretouseanLi‐Fecompatiblechargerthatcanprovidebalancedcharging.Furthermore,
thecapacityofbatteriesdiffers.Besuretosetthechargertotheratedvoltageofthebatteryandthechargecurrent
belowthecapacityofthebattery.Repeatedlychargingthebatterytounnecessarilyhighsettingsmaycausedamageto
thebatteryorfire.Beextremelycarefulwhenchargingbatteriesanddonotleavethebatterybyitselfduringcharging.
7.Donotuse/storeinhightemperature/humidity.
Donotuseorstoreinalocationthatissubjecttodirectsunlight,orinalocationthatmaybecomehotsuchasinside
acarornearaheater.Donotuseorrechargeinlocationswhereitmaybesplashedwithwaterorwherethereisalotof
humidity.
8.Donotuseifthebatteryisswollen.
Swellingisasignthatthebatterymustnotbeusedanylonger.Disposeofthebatteryinaccordancewiththelawsand
rulesinyourregion.

■ Repairs/Inquiries
■ Specifications
■ Charging Method
■ Disclaimer
Kondo Kagaku Co., Ltd. Service Department 4‐17‐17 Higashi Nippori, Arakawa‐ku, Tokyo 116‐0014
TEL : [phone]（Direct line to service department）E-Mail : [e-mail]
Opening times: Monday – Friday (excluding national holidays) 9：00am ‐12：00pm,
Torequestrepairs,sendtheproducttogetherwithadescriptionoftheissuetoourservicedepartmentatthefollowingaddress.
Check our website for the latest information! http://kondo-robot.com
UseaKondorecommendedchargerandchargetothesamecapacityasthebatterycapacity.
*Checkthetypeofconnectoronyourbattery
KONDOcannotacceptanyresponsibilitywhatsoeverforanyproblemsthatarise
throughuseofthisproductwithadevice,methodorforapurposeotherthanthose
describedinthismanual,orproblemsthatariseduetoanyothercause.
Connecttochargingterminalthat
conformstotheno.ofcells
(Besuretodisconnectfrompower
supplyconnectorbeforeconnecting)
XHBalancedCharging
VHSupplyConnector
Connecttopowerharness
(besuretodisconnect
beforecharging)
Besuretodisconnectthepowersupplyconnectorbeforecharging.Thisdevice
cannotbechargedwhileconnectedtoadevice.Chargingandsupplyingpower
atthesametimewilldamagethedevice.
ROBO POWER
CELL
mAh V
0000
Li-Fe 0S1P
0.0
Discharge 20C Continuous40C Burst
Short/Thin
Thick/Long
Important
ProductNo.
Capacity(mAh）
L/W/H:±5％（mm）
Voltage
No.of
BalancedCharging
PowerSupplyConnector
CRate(Continuous/Burst)
6.6
2S
VH(2Pin）
XH（3Pin）
VH(3Pin）
２Cell：VH(2Pin）
2Cell：XH(3Pin） ３Cell：XH(4Pin）
３Cell：VH(3Pin）
XH（4Pin）
20C/40C
55/30/18 55/43/19 87/34/23.3 98/30/3087/34/15.5
9.9
3S
F3-2100F3-1450F3-850F2-1450F２-850
2100
1450 1450850 850
850mAh
1450mAh
2100mAh
ChargingCurrent ForBX‐10L
0.8A
1.4A
2A
0.5A
1A
2A
