Konica Minolta BIZHUB PRO 1050 User manual

• Machine Status Screen Setting
Section 1: Paper Setting
Section 2: Adjustment Setting
Section 3: Controller Setting
• Utility Screen Setting
Section 4: User Setting
Section 5: Machine Manager Setting
• Browser Control Setting
Section 6: Browser Control Setting
• Appendix
How to Input Characters
Setting Data for Import/Export
Configuration Setting
Font List
Glossary
POD Administrator’s Reference

Recycled paper is used for the inside pages of this book.
bizhub PRO 1050
User's Guide
POD Administrator’s Reference

FEDERAL OR STATE STATUTES MAY PROHIBIT THE COPYING OF CERTAIN
DOCUMENTS OR INFORMATION, RESULTING IN FINES OR IMPRISONMENT FOR
VIOLATORS.
ACKNOWLEDGEMENTS:
• bizhub PRO is a trademark of KONICA MINOLTA BUSINESS TECHNOLOGIES, Inc.
• Microsoft, MS, Windows and MS-DOS are registered trademarks or trademarks of Microsoft
Corporation in the United States and / or other countries.
• IBM is a registered trademarks of the IBM Corporation.
• Macintosh and PowerMac are registered trademarks or trademarks of Apple Computer, Inc.
in the United States and / or other countries.
• Adobe, Adobe Logo, Acrobat, Acrobat Logo, PostScript and PostScript Logo are registered
trademarks or trademarks of Adobe Systems, Inc.
•RC4
®is a registered trademark or trademark of RSA Security Inc. in the United States and/
or other countries.
• Other company names and product names used in this manual are the registered
trademarks or trademarks of their respective companies.
Copyright © 2004 KONICA MINOLTA BUSINESS TECHNOLOGIES, Inc.
EXEMPTION
• No part of this manual may be used or duplicated without permission.
• Manufacturer and Sales Company will have no liability for any influences caused by using the
printing system and this User’s Guide.
• The information written in this Network Scanner User’s Guide is subject to change without
prior notice.

Composition of User's Guide
This machine is provided with the following user's guides as printed matters.
*bizhub PRO 1050 User's Guide - Copier
This guide describes an outline of the machine and copy operations.
Please refer to this guide for safety information, turning on/off the machine, paper
supply, dealing with machine trouble such as paper jam, and copy operation
available on the machine.
* bizhub PRO 1050 User's Guide - POD Administrator's Reference
<This book>
This guide provides you with detailed information about the machine management
and how to customize the machine according to your daily use.
Please refer to this guide for a setup and management of the machine including
registration of copy paper, tray setting, and a network setup.
* bizhub PRO 1050 User's Guide - Network Scanner
This guide describes the operation of the network scanner function equipped for the
machine as standard.
Please refer to this guide for full information on storing data (Scan to HDD, Scan to
E-Mail, Scan to FTP, Scan to SMB) or reading data.
*bizhub PRO 1050 User's Guide - Security
This guide describes the security functions.
Please refer to this guide for how to use the Enhanced Security mode, and for
detailed machine operation in Enhanced Security mode.
The following user's guide is also provided as a PDF file.
* bizhub PRO 1050 User's Guide - Printer
This guide describes the operation of the printer function equipped for the machine
as standard.
Please refer to this guide for how to use Adobe PS driver, Konica Minolta PS driver,
and PageScope Web Connection in user mode.
To operate safely, be sure to read "Section 1 Safety Information" in "bizhub PRO
1050 User's Guide - Copier" before using the machine.

i
Contents
Machine Status Screen
Setting
Machine Status Screen Setting Outlines .......................................M-1
Section 1: Paper Setting
Paper Setting Outlines....................................................................1-2
Setting Items in Paper Setting ........................................................... 1-2
Recommended Setting of Paper Type/Weight................................... 1-6
Register Paper Type/Weight ..........................................................1-7
Set Paper Size, Conditions, Air Assist Function for a Tray.......................1-10
Change Paper Type/Weight Specified for a Tray .........................1-15
Section 2: Adjustment
Machine Adjustment Outlines.........................................................2-2
01 Magnification Adjustment ..........................................................2-3
01 Printer Drum Clock Adjustment <SIDE1> ..................................... 2-3
02 Printer Drum Clock Adjustment <SIDE2> ..................................... 2-5
03 Printer Horizontal Adjustment <SIDE1>........................................ 2-7
04 Printer Horizontal Adjustment <SIDE2>........................................ 2-9
02 Timing Adjustment...................................................................2-11
01 Printer Restart Timing Adjustment <SIDE1> .............................. 2-11
02 Printer Restart Timing Adjustment <SIDE2> .............................. 2-13
03 Scanner Restart Timing Adjustment ........................................... 2-15
04 ADF Restart Timing Adjustment ................................................. 2-16
03 Centering Adjustment ..............................................................2-17
01 Printer Centering Adjustment...................................................... 2-17
Finisher Adjustment......................................................................2-18
01 Stapler Position Adjustment ....................................................2-19
01 Stapling Center Position Adjustment .......................................... 2-19
02 Paper Width Adjustment ............................................................. 2-21
02 Multi Folder (Punch) Adjustment .............................................2-23
01 Paper Width Adjustment ............................................................. 2-23
02 Hole-Punch Vertical Position Adjustment ................................... 2-24
03 Multi Folder (Fold) Adjustment ................................................2-26
01 Folding Position Adjustment ....................................................... 2-26
02 Letter Fold-in Position Adjustment .............................................. 2-28
03 Letter Fold-out Position Adjustment............................................ 2-30

Contents (continued)
ii
04 Double Parallel Position Adjustment........................................... 2-32
05 Z-Fold Position Adjustment......................................................... 2-34
06 Gate Position Adjustment ........................................................... 2-36
04 Stacker Adjustment .................................................................2-38
01 Paper Width Adjustment ............................................................. 2-38
02 Paper Length Adjustment ........................................................... 2-39
Section 3: Controller Setting
Function Overview..........................................................................3-2
01 Report Type...............................................................................3-7
02 Printer Setting............................................................................3-8
03 Select Printer Setting...............................................................3-13
04 Spool .......................................................................................3-14
05 Interface Setting ......................................................................3-15
Utility Screen Setting
Utility Screen Setting Outlines ....................................................... U-1
Section 4: User Setting
01 System Setting................................................................. 4-2
01 Language Setting ......................................................................4-2
02 Buzzer Setting ...........................................................................4-3
01 Buzzer ON/OFF, Volume Setting .................................................. 4-3
02 Buzzer for Job Stop Setting .......................................................... 4-4
03 1SHOT Indication Time .............................................................4-5
04 Default Screen Setting...............................................................4-6
05 Auto Reset Setting.....................................................................4-7
06 Key Response Time ..................................................................4-8
07 Change User Password.............................................................4-9
02 Function Setting............................................................. 4-10
01 Feed Tray Setting ....................................................................4-10
01 Feed Tray Auto Selection ........................................................... 4-10
02 ATS Permit.................................................................................. 4-11
03 Auto Paper Type ......................................................................... 4-12
02 Each Function Setting .............................................................4-13

Contents (continued)
iii
03 Density Setting ........................................................................4-14
01 Density Shift for Enhance Mode ................................................. 4-14
02 User Density Setting ................................................................... 4-15
03 Photo Mode Density Setting ....................................................... 4-16
04 Image Density Selection ............................................................. 4-17
04 Preset Zoom ............................................................................4-18
03 Copy Setting .................................................................. 4-19
01 Reset Setting ...........................................................................4-19
01 Initial Setting ............................................................................... 4-19
02 Reset Function Setting................................................................ 4-21
03 Initial by Key Counter Insert........................................................ 4-22
02 Each Function Setting .............................................................4-23
04 Scanner Setting ............................................................. 4-25
01 Default Address Setting...........................................................4-25
02 Each Function Setting .............................................................4-26
05 Touch Screen Adjustment ............................................. 4-27
Section 5: Machine Manager Setting
Machine Manager Setting Outlines ................................................5-2
How to access the Machine Manager Setting Menu.......................... 5-2
01 System Setting................................................................. 5-4
01 Power Save Setting ...................................................................5-4
02 Time and Date Setting...............................................................5-5
03 Weekly Timer Setting ................................................................5-6
01 Weekly Timer On/Off Setting ........................................................ 5-7
02 Timer Setting................................................................................. 5-8
03 Timer Action On/Off Setting ........................................................ 5-10
04 Lunch Hour Off Setting ............................................................... 5-11
05 Set Password for Timer Interrupt ................................................ 5-12
04 Management List Print.............................................................5-13
05 Operation Prohibit Set .............................................................5-16
06 Expert Adjustment ...................................................................5-18
01 Original Scan Area Setting.......................................................... 5-18
02 ADF Frame Erasure Setting........................................................ 5-19
03 Non Image Area Erase Setting ................................................... 5-20
07 Size Setting .............................................................................5-21

Contents (continued)
iv
02 Manager/Machine Register............................................ 5-22
01 Machine Manager Register .....................................................5-22
03 Use Auth./Volume Track................................................ 5-23
01 Authentication Method.............................................................5-23
01 Authentication Setting ................................................................. 5-23
02 Section Management Setting ...................................................... 5-25
02 Volume Track ..........................................................................5-27
03 User Authentication Set...........................................................5-30
04 Non register/Output Set...........................................................5-34
04 Network Setting ............................................................. 5-35
01 Machine NIC Setting................................................................5-35
02 Controller NIC Setting..............................................................5-36
01 TCP/IP ........................................................................................ 5-45
02 NetWare...................................................................................... 5-48
03 IPP .............................................................................................. 5-50
04 FTP ............................................................................................. 5-52
05 SNMP.......................................................................................... 5-54
06 SMB ............................................................................................ 5-55
07 AppleTalk .................................................................................... 5-57
08 E-Mail.......................................................................................... 5-58
09 HDD ............................................................................................ 5-61
10 Alert Mail ..................................................................................... 5-62
11 CSRC.......................................................................................... 5-63
12 IS OpenAPI ................................................................................. 5-66
13 PSWC ......................................................................................... 5-68
14 Network Setting Clear ................................................................. 5-69
05 Copy/Printer Setting....................................................... 5-70
01 JOB Offset Operating ..............................................................5-70
02 Continuation Print(Print) ..........................................................5-71
03 Page No. Position (Booklet) ....................................................5-72
04 Fixing Prerotation Set ..............................................................5-73
05 Image Auto Rotation................................................................5-74
06 Interruption Suspend ...............................................................5-75
07 Copy Reserve Operation .........................................................5-76
08 Scan Stop (pull out tray) ..........................................................5-77
09 Continuation Print (Copy) ........................................................5-78
10 Original Glass SDF..................................................................5-79

Contents (continued)
v
11 SDF Auto Setting.....................................................................5-80
06 System Connection........................................................ 5-81
01 User Call..................................................................................5-81
07 Security Setting.............................................................. 5-82
01 Machine Manager Password ...................................................5-82
02 HDD Management Setting.......................................................5-83
01 Folder Box List/Delete................................................................. 5-83
02 HDD Data Auto Delete Period Setting ........................................ 5-85
03 Change HDD Lock Password ..................................................... 5-86
03 Security Strengthen mode .......................................................5-87
08 Scanner Address Register............................................. 5-88
01 Send Address Edit/Delete .......................................................5-88
Browser Control Setting
Section 6: Browser Control Setting
About PageScope Web Connection ...............................................6-2
System Requirements........................................................................ 6-2
Access ............................................................................................6-3
Operation ........................................................................................... 6-3
Screen Configuration......................................................................6-4
Logging in Using Administrator Mode ................................................ 6-5
Administrator Mode ........................................................................6-6
System Tab ........................................................................................ 6-6
Print Tab .......................................................................................... 6-12
Scan Tab.......................................................................................... 6-15
Network Tab..................................................................................... 6-18
Appendix
How to Input Characters................................................................ A-1
About keys on the character input screen..........................................A-1
About character input.........................................................................A-1
Setting Data for Import/Export ....................................................... A-2
Configuration Setting ..................................................................... A-5
Font List......................................................................................... A-9

Contents (continued)
vi
PCL Font List............................................................................... A-20
Glossary ...................................................................................... A-23
Index

Machine Status Screen Setting Outlines
Section 1:
Paper Setting
Section 2:
Adjustment
Section 3:
Controller Setting
Machine Status
Screen
Setting

M-1
Machine Status Screen Setting Outlines
Machine Status Screen Setting Outlines
The Paper Set,Adjustment, and Controller keys are located at the bottom of the
Machine Status Screen, to display each setting screen.
Paper Set: The Paper Set popup screen is displayed.
Set the tray size, paper type/weight, air assist on/off of the tray that paper is loaded.
For the details, see p. 1-2.
You may set the other settings on another screen while specifying the paper
setting. Press the tab key to switch the screens.
Adjustment: The Adjustment mode menu screen is displayed.
Adjust the settings of Image Control and Output options. For the details, see p.2-2.
After completing the Adjustment mode settings, touch Return to exit the Adjustment
mode.
You cannot set the other settings while specifying the Adjustment mode.

Machine Status Screen Setting Outlines (continued)
M-2
Controller: The Controller Setting Menu Screen is displayed.
Specify the settings concerning the Print Controller. For the details, see p.3-2.
Touch the MACHINE tab to exit the Controller Setting mode.

1
Section 1: Paper Setting
Section 1:
Paper Setting
How to operate Paper Setting to
be designated for paper tray
Paper Setting Outlines...................................................... 1-2
Register Paper Type/Weight ............................................. 1-7
Set Paper Size, Conditions, Air Assist Function for a Tray ....... 1-10
Change Paper Type/Weight Specified for a Tray............. 1-15

1-2
Paper Setting Outlines
This machine provides the optimum print result according to each characteristics of
copy paper by specifying paper size, paper type/weight, and air assist function for
each tray (Tray Setting).
The paper type/weight can be programmed in advance, and then applied to each tray
as required (Register Type/Weight).
The programmed properties can also be altered and newly registered at any time.
Setting Items in Paper Setting
Paper Setting includes three setting items; paper size, paper type/weight, and air
assist function.
Select one of the following four items as paper size.
(1) Standard Size
(2) Custom Size
(3) Wide Size Paper
(4) Tab Paper
Set paper type/weight by specifying the following five items and paper name.
(1) Type
Select one of the following nine types.
Coated A, Coated B, Fine, Normal, Book/News, Embossed, User, Blank Insert,
OHP
(2) Weight
Select one of the following eight types.
50-61g, 62-71g, 72-91g, 92-130g, 131-161g, 162-209g, 210-244g, 245-300g
See p. 1-3 for details of paper type specifications and relation between paper
type and weight.
(3) Colored Paper
Select one of the following six types.
White, Transparent, Yellow, Pink, Blue, Green
(4) Hole-Punch
Select either condition.
With Punch Hole or No Punch Hole
(5) Both Sides Adjustment
Specify the Vertical zoom, Horizontal zoom, Up/Down shift amount, and Right/
Left shift amount for both front and back pages.
Vertical zoom : 0.5% to -0.5% (in 0.05% increments)
Horizontal zoom : 10% to -10% (in 0.1% increments)
Up/Down shift amount : 10 to -10mm (in 0.1mm increments)
Right/Left shift amount : 10 to -10mm (in 0.1mm increments)
Use the Air Assist function to blow air to the paper from the guide plate inside the tray
in order to prevent feeding troubles which a specific paper type tends to cause.
Select one of the following three conditions.
Auto : Activate the function according to the paper feed timing.
On : Always activate the function.
Off : Always deactivate the function.

Paper Setting Outlines (continued)
1-3
Section 1: Paper Setting
Paper Type Specifications
The following six paper types are provided according to the plainness of paper.
Coated A, Coated B, Fine, Normal, Book/News, Embossed
The special paper types that are not included in the above six types are set
separately.
Blank Insert, OHP, User
The following describes the specifications of each paper type.
Coated A
The coated paper is an art paper or coated paper, applied approximately 20 to 40g of
coating per 1 m2to on top of both side of fine paper. The coated paper is mostly
used for luxury art books, calendars, car brochures, books, magazines, leaflets, and
posters. Always specify [Coated A] to a tray to which the coated paper is loaded.
Coated B
Specify [Coated B] when overlay printing on the offset printed coated paper. If a
trouble occurs in feeding the coated paper when [Coated A] is specified, select
[Coated B].
When using the overlay printed paper, you are required to specify specific
settings besides [Coated B] to the tray to which this type of coated paper is
load. Contact your sales representative.
Fine
The Fine paper is a non-coated paper generally used for offset printing. The fine
paper has a high degree of whiteness and used for various purposes. Specify [Fine]
to a tray to which the fine paper is loaded.
Normal
The Normal paper is used for copying in general and is called "PPC paper." The
normal paper is usually not a recycled paper. Specify [Normal] to the tray to which
the normal paper or the recycled paper for copying is loaded.
Book/News
The Book/News paper is used for a body part of a book. It is a highly opaque paper
to prevent prints to be seen from the back, or a cream-colored paper for ease of
reading. Specify [Book/News] to a tray to which this type of paper is loaded.
Embossed
The Embossed paper has a non-smooth surface on which a toner is hard to be fixed.
Specify [Embossed] to a tray to which this type of paper is loaded.
Blank Insert
Blank Insert is not a category of the paper type. This is only fed without being
printed. When the Cover With Blank Sheet, Blank Insert, or OHP interleave blank
function is used, specify [Blank Insert] to a tray to which a paper already printed and
not copied by this machine is loaded, or a blank paper only to be fed is loaded.
User
When a paper type other than that of which can be specified on this machine is used,
use this function. For the details, contact your service representative.
OHP
Specify [OHP] to a tray to which transparent films are loaded.

Paper Setting Outlines (continued)
1-4
Weight is classified into eight types as shown in the following table.
: Air Assist becomes activated.
: Tray adjustment (installing an assist plate, etc.) is required by your service
representative.
: Able to be specified only to Tray 4.
: Copying speed becomes a little slow. Copying speed is 90 sheets per
minute when printing A4 in the simplex print mode.
: Copying speed becomes slow. Copying speed is 63 sheets per minute
when printing A4 in the simplex print mode.
Paper type and weight
Coated A Coated B Fine Normal Book/News Embossed
(Disable)
Type
Weight
(Disable)
(Disable)
