Konica Minolta bizhub PRO 1051 Series Installation manual

bizhub PRO 1200/1200P/1051
Additional Information
Perfect Binder PB-503 option is newly provided to bizhub PRO 1200/1200P/
1051.
Please refer to this guide for the operation and safety information on Perfect
Binder PB-503, and keep it inside the user’s guide of copier so that it is read-
ily available for reference.

Contents
1 Precautions for Installation and Use
1.1 Caution Label ........................................................................................ 1
1.2 Precautions for Paste Pellets and the Perfect Binder ...................... 2
1.3 bizhub PRO 1200/1051 Installation Space ......................................... 3
1.4 bizhub PRO 1200P Installation Space .............................................. 12
2 Machine Configuration
2.1 Standard/Optional Equipment ........................................................... 20
2.2 Perfect Binder PB-503 ....................................................................... 28
3 Paper Information
3.1 Paper Weight ...................................................................................... 33
3.2 Tray Capacity ...................................................................................... 33
3.3 Paper Size ........................................................................................... 34
4 Using Perfect Binder PB-503
4.1 Turning On/Off the Heater of the Perfect Binder ............................ 36
4.2 Loading Cover Paper for Perfect Binding ........................................ 41
4.3 Overview of Perfect Binding .............................................................. 44
4.4 Making Perfect-Bound Booklets (bizhub PRO 1200/1051) ............. 48
4.5 Taking Out Perfect-Bound Books from the Perfect Binder Tray ... 59
5 Maintenance & Troubleshooting
5.1 Adding Paste Pellets .......................................................................... 62
5.2 Emptying Trim Scrap Box .................................................................. 65
5.3 If Paper Jam Indicator Lights ............................................................ 68
6 Specifications
6.1 Perfect Binder PB-503 ....................................................................... 70

7 Correction in bizhub PRO 1200/1200P/1051 User’s
Guides
7.1 List of the Administrator’s Setting (p. 6-6 of bizhub PRO 1200/1051
POD Administrator’s Reference) ....................................................... 71
7.2 List of the Administrator’s Setting (p. 6-5 of POD Administrator’s
Reference in bizhub PRO 1200P Main Body) ................................... 71
7.3 09 Perfect Binding Setting - 01 Useful Paper Weight (p. 6-44 of
bizhub PRO 1200/1051 POD Administrator’s Reference) ............... 72

Precautions for Installation and Use 1
bizhub PRO 1200/1200P/1051 Additional Information 1
1 Precautions for Installation and Use
1.1 Caution Label
7 CAUTION
Precaution for caution labels
If you touch the part applied with a caution label, you may get burned.
%Do not remove caution labels. Should any caution label be illegible due
to soilage, clean the label. If any caution label is removed or cleaning
does not render the label legible, please contact your service repre-
sentative.
The paste tank unit
is very hot.
To avoid getting
burned DO NOT
TOUCH.
CAUTION

1Precautions for Installation and Use
2 bizhub PRO 1200/1200P/1051 Additional Information
1.2 Precautions for Paste Pellets and the Perfect Binder
To ensure safety and product reliability, observe the precautions for using
paste pellets and the Perfect Binder.
Precautions for Paste Pellets
-Paste pellets are not edible; do not put them in your mouth nor swallow
them.
-Keep paste pellets out of reach of children.
-Store paste pellets in dark, cool indoors at temperature between 5 and
35 degrees Celsius, avoiding direct sunlight or exposure to water.
-Paste pellets may become degraded by such products as common oils,
organic solvents, solvents used in ink formulations, or volatile fragrances.
Such degradation may cause deterioration in adhesiveness, resulting in
poor binding performance.
Precautions for Perfect Binder
-Use only the paste GC-501 for this binder.
-Handle melted hot paste only with great care.
-If you need to clean or replace melted hot paste, contact your service
representative.
-In order to prevent degradation of paste owing to heating, ensure that the
machine is turned off when it is not in use. It is recommended that you
adjust the time settings for the low power mode and shut-off mode of the
main body to suit the usage of the perfect binder, since then apply to the
binder as well.
-Do not overload the paste hopper with paste pellets.
-Do not touch the lever in the paste hopper with your hand to avoid break-
down.

Precautions for Installation and Use 1
bizhub PRO 1200/1200P/1051 Additional Information 3
1.3 bizhub PRO 1200/1051 Installation Space
Allow sufficient space for facilitating copy operation, changing parts, and pe-
riodic inspection. Leave an adequate space behind the machine to let hot air
out from the rear fan.
The whole machine may weigh approx. 3,867.6 lb (1,758 kg) at maximum,
depending on the combination of options. Be sure to choose a level and solid
floor for the installation place.
76.0"
37.4" 30.7"
7.9"
40.2"
48.5"
62.2"
57.4"
76.6"
30.2" 30.7"
7.9"7.9"
40.2"
48.5"
62.2"
57.4"
(Unit: inches) (Unit: inches)
bizhub PRO 1200/1051 - PF-702 PB-503 - RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-703

1Precautions for Installation and Use
4 bizhub PRO 1200/1200P/1051 Additional Information
39.0"13.8"
88.5"
RU-506 - bizhub PRO 1200 - PF-702
31.9" 3.9"
17.3"
40.2"
48.5"
62.2"
57.4"
25.6"
8.3"
39.0"13.8"
91.0"
RU-506 - bizhub PRO 1200 - PF-703
34.3" 3.9" 34.3"13.8"
125.3"
34.3"13.8"
122.9"
17.3"
40.2"
48.5"
62.2"
57.4"
25.6"
8.3"
39.0"13.8"
122.9"
RU-506 - bizhub PRO 1200 - PF-703 - PF-702
34.3" 31.9"
3.9"
34.3"13.8"
157.2"
17.3"
40.2"
48.5"
62.2"
57.4"
25.6"
8.3"
39.0"13.8"
125.3"
RU-506 - bizhub PRO 1200 - PF-703 - PF-703
34.3" 34.3" 3.9" 34.3"13.8"
159.6"
17.3"
40.2"
48.5"
62.2"
57.4"
25.6"
8.3"
RU-506 - PI-PFU - (bizhub PRO 1200 - PF-702)
RU-506 - PI-PFU - (bizhub PRO 1200 - PF-703)
RU-506 - PI-PFU - (bizhub PRO 1200 - PF-703- PF-702)
RU-506 - PI-PFU - (bizhub PRO 1200 - PF-703- PF-703)
(Unit: inches)(Unit: inches)
(Unit: inches)
(Unit: inches)
(Unit: inches)
(Unit: inches)
(Unit: inches)
(Unit: inches)

Precautions for Installation and Use 1
bizhub PRO 1200/1200P/1051 Additional Information 5
39.0"
74.8"
bizhub PRO 1051 - PF-702
31.9" 3.9"
17.3"
40.2"
48.5"
62.2"
57.4"
25.6"
8.4"
39.0"
77.2"
bizhub PRO 1051 - PF-703
34.3" 3.9" 34.3"13.8"
125.3"
34.3"13.8"
122.9"
17.3"
40.2"
48.5"
62.2"
57.4"
25.6"
8.4"
39.0"
109.1"
bizhub PRO 1051 - PF-703 - PF-702
34.3" 31.9"
3.9"
34.3"13.8"
157.2"
17.3"
40.2"
48.5"
62.2"
57.4"
25.6"
8.4"
39.0"
111.5"
bizhub PRO 1051 - PF-703 - PF-703
34.3" 34.3" 3.9" 34.3"13.8"
159.6"
17.3"
40.2"
48.5"
62.2"
57.4"
25.6"
8.4"
RU-506 - PI-PFU - (bizhub PRO 1051 - PF-702)
RU-506 - PI-PFU - (bizhub PRO 1051 - PF-703)
RU-506 - PI-PFU - (bizhub PRO 1051 - PF-703 - PF-702)
RU-506 - PI-PFU - (bizhub PRO 1051 - PF-703 - PF-703)
(Unit: inches)(Unit: inches)
(Unit: inches)
(Unit: inches)
(Unit: inches)
(Unit: inches)
(Unit: inches)
(Unit: inches)

1Precautions for Installation and Use
6 bizhub PRO 1200/1200P/1051 Additional Information
39.0"12.0"13.8"
100.6"
RU-506 - GP-501 - bizhub PRO 1200/1051 - PF-702
31.9" 3.9"
17.3"
40.2"
48.5"
62.2"
57.4"
25.6"
8.4"
39.0"12.0"13.8"
103.0"
RU-506 - GP-501 - bizhub PRO 1200/1051 - PF-703
34.3" 3.9"
17.3"
40.2"
48.5"
62.2"
57.4"
25.6"
8.4"
39.0"12.0"13.8"
134.9"
RU-506 - GP-501 - bizhub PRO 1200/1051 - PF-703 - PF-702
34.3" 31.9"
3.9"
17.3"
25.6"
8.4"
39.0"12.0"13.8"
137.3"
RU-506 - GP-501 - bizhub PRO 1200/1051 - PF-703 - PF-703
34.3" 34.3" 3.9"
17.3"
25.6"
8.4"
(Unit: inches)
(Unit: inches)
(Unit: inches)
(Unit: inches)
40.2"
48.5"
62.2"
57.4"
40.2"
48.5"
62.2"
57.5"

Precautions for Installation and Use 1
bizhub PRO 1200/1200P/1051 Additional Information 7
39.0"12.0"13.8"
134.9"
RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-702
31.9" 3.9"
17.3"
40.2"
48.5"
62.2"
57.4"
25.6"
8.4"
39.0"12.0"13.8"
137.3"
RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-703
34.3" 3.9"
17.3"
40.2"
48.5"
62.2"
57.4"
25.6"
8.4"
39.0"12.0"
34.3"
34.3"
34.3"13.8"
169.2"
RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-703 - PF-702
34.3" 31.9"
3.9"
17.3"
25.6"
8.4"
39.0"12.0" 34.3"13.8"
171.6"
RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-703 - PF-703
34.3" 34.3" 3.9"
17.3"
25.6"
8.4"
(Unit: inches)
(Unit: inches)
(Unit: inches)
(Unit: inches)
40.2"
48.5"
62.2"
57.4"
40.2"
48.5"
62.2"
57.4"

1Precautions for Installation and Use
8 bizhub PRO 1200/1200P/1051 Additional Information
62.2"
48.2"
40.2"
53.8"
3.9"
Total Width
146.0" : PB-503 - (RU-506 - bizhub PRO 1200 - PF-702)
148.5" : PB-503 - (RU-506 - bizhub PRO 1200 - PF-703)
180.3" : PB-503 - (RU-506 - bizhub PRO 1200 - PF-702 - PF-703)
182.8" : PB-503 - (RU-506 - bizhub PRO 1200 - PF-703 - PF-703)
156.0" : PB-503 - (RU-506 - GP-501 - bizhub PRO 1200/1051 - PF-702)
160.5" : PB-503 - (RU-506 - GP-501 - bizhub PRO 1200/1051 - PF-703)
192.3" : PB-503 - (RU-506 - GP-501 - bizhub PRO 1200/1051 - PF-702 - PF-703)
194.8" : PB-503 - (RU-506 - GP-501 - bizhub PRO 1200/1051 - PF-703 - PF-703)
132.2" : PB-503 - (bizhub PRO 1051 - PF-702)
134.7" : PB-503 - (bizhub PRO 1051 - PF-703)
166.6" : PB-503 - (bizhub PRO 1051 - PF-702 - PF-703)
169.0" : PB-503 - (bizhub PRO 1051 - PF-703 - PF-703)
192.3" : PB-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-702)
194.8" : PB-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-703)
226.7" : PB-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-702 - PF-703)
229.1" : PB-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-703 - PF-703)
180.3" : PB-503 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-702)
182.8" : PB-503 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-703)
214.6" : PB-503 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-702 - PF-703)
217.1" : PB-503 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-703 - PF-703)
(Unit: inches)

Precautions for Installation and Use 1
bizhub PRO 1200/1200P/1051 Additional Information 9
30.9"
53.5" 46.0"
3.9"
Total Width
223.0" : PB-503 - SD-506 - LS-505 - (RU-506 - bizhub PRO 1200 - PF-702)
225.5" : PB-503 - SD-506 - LS-505 - (RU-506 - bizhub PRO 1200 - PF-703)
257.3" : PB-503 - SD-506 - LS-505 - (RU-506 - bizhub PRO 1200 - PF-702 - PF-703)
259.8" : PB-503 - SD-506 - LS-505 - (RU-506 - bizhub PRO 1200 - PF-703 - PF-703)
235.0" : PB-503 - SD-506 - LS-505 - (RU-506 - GP-501 - bizhub PRO 1200 - PF-702)
237.5" : PB-503 - SD-506 - LS-505 - (RU-506 - GP-501 - bizhub PRO 1200 - PF-703)
269.3" : PB-503 - SD-506 - LS-505 - (RU-506 - GP-501 - bizhub PRO 1200 - PF-702 - PF-703)
271.8" : PB-503 - SD-506 - LS-505 - (RU-506 - GP-501 - bizhub PRO 1200 - PF-703 - PF-703)
132.2" : PB-503 - SD-506 - LS-505 - (bizhub PRO 1051 - PF-702)
177.3" : PB-503 - SD-506 - LS-505 - (bizhub PRO 1051 - PF-703)
209.2" : PB-503 - SD-506 - LS-505 - (bizhub PRO 1051 - PF-702 - PF-703)
211.6" : PB-503 - SD-506 - LS-505 - (bizhub PRO 1051 - PF-703 - PF-703)
269.3" : PB-503 - SD-506 - LS-505 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-702)
271.8" : PB-503 - SD-506 - LS-505 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-703)
303.6" : PB-503 - SD-506 - LS-505 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-702 - PF-703)
306.1" : PB-503 - SD-506 - LS-505 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-703 - PF-703)
257.3" : PB-503 - SD-506 - LS-505 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-702)
259.8" : PB-503 - SD-506 - LS-505 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-703)
291.6" : PB-503 - SD-506 - LS-505 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-702 - PF-703)
294.1" : PB-503 - SD-506 - LS-505 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-703 - PF-703)
62.2"
48.2"
1020
(Unit: inches)

1Precautions for Installation and Use
10 bizhub PRO 1200/1200P/1051 Additional Information
62.2"
40.2"
53.5"21.4"10"
3.9" 4.6"
Total Width
182.0" : FS-521 - PB-503 - (RU-506 - bizhub PRO 1200 - PF-702)
184.5" : FS-521 - PB-503 - (RU-506 - bizhub PRO 1200 - PF-703)
216.4" : FS-521 - PB-503 - (RU-506 - bizhub PRO 1200 - PF-702 - PF-703)
218.8" : FS-521 - PB-503 - (RU-506 - bizhub PRO 1200 - PF-703 - PF-703)
194.1" : FS-521 - PB-503 - (RU-506 - GP-501 - bizhub PRO 1200 - PF-702)
196.5" : FS-521 - PB-503 - (RU-506 - GP-501 - bizhub PRO 1200 - PF-703)
228.5" : FS-521 - PB-503 - (RU-506 - GP-501 - bizhub PRO 1200 - PF-702 - PF-703)
230.8" : FS-521 - PB-503 - (RU-506 - GP-501 - bizhub PRO 1200 - PF-703 - PF-703)
168.3" : FS-521 - PB-503 - (bizhub PRO 1051 - PF-702)
170.7" : FS-521 - PB-503 - (bizhub PRO 1051 - PF-703)
202.6" : FS-521 - PB-503 - (bizhub PRO 1051 - PF-702 - PF-703)
205.0" : FS-521 - PB-503 - (bizhub PRO 1051 - PF-703 - PF-703)
228.4" : FS-521 - PB-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-702)
230.8" : FS-521 - PB-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-703)
262.7" : FS-521 - PB-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-702 - PF-703)
265.1" : FS-521 - PB-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-703 - PF-703)
216.4" : FS-521 - PB-503 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-702)
218.8" : FS-521 - PB-503 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-703)
250.7" : FS-521 - PB-503 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-702 - PF-703)
253.1" : FS-521 - PB-503 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-703 - PF-703)
(Unit: inches)

Precautions for Installation and Use 1
bizhub PRO 1200/1200P/1051 Additional Information 11
Total Width
243.9" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - bizhub PRO 1200 - PF-702)
246.3" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - bizhub PRO 1200 - PF-703)
278.2" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - bizhub PRO 1200 - PF-702 - PF-703)
280.6" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - bizhub PRO 1200 - PF-703 - PF-703)
255.9" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - GP-501 - bizhub PRO 1200 - PF-702)
258.3" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - GP-501 - bizhub PRO 1200 - PF-703)
290.2" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - GP-501 - bizhub PRO 1200 - PF-702 - PF-703)
292.6" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - GP-501 - bizhub PRO 1200 - PF-703 - PF-703)
230.1" : FS-521 - PB-503 - SD-506 - FD-503 - (bizhub PRO 1051 - PF-702)
232.5" : FS-521 - PB-503 - SD-506 - FD-503 - (bizhub PRO 1051 - PF-703)
264.4" : FS-521 - PB-503 - SD-506 - FD-503 - (bizhub PRO 1051 - PF-702 - PF-703)
266.9" : FS-521 - PB-503 - SD-506 - FD-503 - (bizhub PRO 1051 - PF-703 - PF-703)
290.2" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-702)
292.6" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-703)
324.5" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-702 - PF-703)
327.0" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200/1051 - PF-703 - PF-703)
278.2" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-702)
280.6" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-703)
312.5" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-702 - PF-703)
314.9" : FS-521 - PB-503 - SD-506 - FD-503 - (RU-506 - PI-PFU - bizhub PRO 1200/1051 - PF-703 - PF-703)
46.1" 15.8"
21.4"
10" 53.5"
3.9" 4.6"
62.2"
40.2
(Unit: inches)

1Precautions for Installation and Use
12 bizhub PRO 1200/1200P/1051 Additional Information
1.4 bizhub PRO 1200P Installation Space
Allow sufficient space for facilitating print operation, changing parts, and pe-
riodic inspection. Leave an adequate space behind the machine to let hot air
out from the rear fan.
The whole machine may weigh approx. 3,801.6 lb (1,728 kg) at maximum,
depending on the combination of options. Be sure to choose a level and solid
floor for the installation place.
76.0"
bizhub PRO 1200P - PF-702
37.4" 30.7" 7.9"
40.2"
62.2"
57.4"
76.6"
PB-503 - RU-506 - PI-PFU - bizhub PRO 1200P - PF-703
30.2" 30.7" 7.9"7.9"
40.2"
62.2"
57.4"
(Unit: inches) (Unit: inches)

Precautions for Installation and Use 1
bizhub PRO 1200/1200P/1051 Additional Information 13
39.0"13.8"
88.5"
31.9" 3.9"
17.3"
40.2"
62.2"
57.4"
39.0"13.8"
91.0"
34.3" 3.9" 34.3"13.8"
125.3"
34.3"13.8"
122.9"
17.3"
40.2"
62.2"
57.4"
39.0"13.8"
122.9"
34.3" 31.9"
3.9"
34.3"13.8"
157.2"
17.3"
40.2"
62.2"
57.4"
39.0"13.8"
125.3"
34.3" 34.3" 3.9" 34.3"13.8"
159.6"
17.3"
40.2"
62.2"
57.4"
RU-506 - PI-PFU - (bizhub PRO 1200P - PF-702)
RU-506 - PI-PFU - (bizhub PRO 1200P - PF-703)
RU-506 - PI-PFU - (bizhub PRO 1200P - PF-703- PF-702)
RU-506 - PI-PFU - (bizhub PRO 1200P - PF-703- PF-703)
(Unit: mm) (Unit: mm)
(Unit: mm) (Unit: mm)
(Unit: mm) (Unit: mm)
(Unit: mm) (Unit: mm)
RU-506 - bizhub PRO 1200P - PF-702
RU-506 - bizhub PRO 1200P - PF-703
RU-506 - bizhub PRO 1200P - PF-703 - PF-702
RU-506 - bizhub PRO 1200P - PF-703 - PF-703

1Precautions for Installation and Use
14 bizhub PRO 1200/1200P/1051 Additional Information
39.0"12.0"13.8"
100.6"
RU-506 - GP-501 - bizhub PRO 1200P - PF-702
31.9" 3.9"
17.3"
40.2"
62.2"
57.4"
39.0"12.0"13.8"
103.0"
RU-506 - GP-501 - bizhub PRO 1200P - PF-703
34.3" 3.9"
17.3"
40.2"
62.2"
57.4"
39.0"12.0"13.8"
134.9"
RU-506 - GP-501 - bizhub PRO 1200P - PF-703 - PF-702
34.3" 31.9"
3.9"
17.3"
39.0"12.0"13.8"
137.3"
RU-506 - GP-501 - bizhub PRO 1200P - PF-703 - PF-703
34.3" 34.3" 3.9"
17.3"
(Unit: inches)
(Unit: inches)
(Unit: inches)
(Unit: inches)
40.2"
62.2"
57.4"
40.2"
62.2"
57.5"

Precautions for Installation and Use 1
bizhub PRO 1200/1200P/1051 Additional Information 15
39.0"12.0"13.8"
134.9"
RU-506 - GP-501 - PI-PFU - bizhub PRO 1200P - PF-702
31.9" 3.9"
17.3"
40.2"
62.2"
57.4"
39.0"12.0"13.8"
137.3"
RU-506 - GP-501 - PI-PFU - bizhub PRO 1200P - PF-703
34.3" 3.9"
17.3"
40.2"
62.2"
57.4"
39.0"12.0"
34.3"
34.3"
34.3"13.8"
169.2"
RU-506 - GP-501 - PI-PFU - bizhub PRO 1200P - PF-703 - PF-702
34.3" 31.9"
3.9"
17.3"
39.0"12.0" 34.3"13.8"
171.6"
RU-506 - GP-501 - PI-PFU - bizhub PRO 1200P - PF-703 - PF-703
34.3" 34.3" 3.9"
17.3"
(Unit: inches)
(Unit: inches)
(Unit: inches)
(Unit: inches)
40.2"
62.2"
57.4"
40.2"
62.2"
57.4"

1Precautions for Installation and Use
16 bizhub PRO 1200/1200P/1051 Additional Information
62.2"
48.2"
40.2"
53.8"
3.9"
Total Width
146.0" : PB-503 - (RU-506 - bizhub PRO 1200P - PF-702)
148.5" : PB-503 - (RU-506 - bizhub PRO 1200P - PF-703)
180.3" : PB-503 - (RU-506 - bizhub PRO 1200P - PF-702 - PF-703)
182.8" : PB-503 - (RU-506 - bizhub PRO 1200P - PF-703 - PF-703)
158.0" : PB-503 - (RU-506 - GP-501 - bizhub PRO 1200P - PF-702)
160.5" : PB-503 - (RU-506 - GP-501 - bizhub PRO 1200P - PF-703)
192.3" : PB-503 - (RU-506 - GP-501 - bizhub PRO 1200P - PF-702 - PF-703)
194.8" : PB-503 - (RU-506 - GP-501 - bizhub PRO 1200P - PF-703 - PF-703)
132.2" : PB-503 - (bizhub PRO 1200P - PF-702)
134.7" : PB-503 - (bizhub PRO 1200P - PF-703)
166.6" : PB-503 - (bizhub PRO 1200P - PF-702 - PF-703)
169.0" : PB-503 - (bizhub PRO 1200P - PF-703 - PF-703)
192.3" : PB-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200P - PF-702)
194.8" : PB-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200P - PF-703)
226.7" : PB-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200P - PF-702 - PF-703)
229.1" : PB-503 - (RU-506 - GP-501 - PI-PFU - bizhub PRO 1200P - PF-703 - PF-703)
180.3" : PB-503 - (RU-506 - PI-PFU - bizhub PRO 1200P - PF-702)
182.8" : PB-503 - (RU-506 - PI-PFU - bizhub PRO 1200P - PF-703)
214.6" : PB-503 - (RU-506 - PI-PFU - bizhub PRO 1200P - PF-702 - PF-703)
217.1" : PB-503 - (RU-506 - PI-PFU - bizhub PRO 1200P - PF-703 - PF-703)
(Unit: inches)
