KonNad C2000-S1-TH05E02-D01 User manual
Last updated: 2019-11-7
C2000-S1-TH05E02-D01
User Manual
RS485
-10~50℃ / 5~95% RH
Sensor — Temperature & Humidity Sensor
SinoCon Co., Ltd.
Copyright Notice
©2000 - 2019 SinoCon Co., Ltd. All Rights Reserved.
Trademarks
The KonNaD logo is a registered trademark of SinoCon Co., Ltd. All other trademarks or registered marks in this
manual belong to their respective manufacturers.
Disclaimer
This document only provides information about KonNaD products. No license to any intellectual property rights is
granted by this document, including any intellectual property licenses, expressed or implied, or by any means.
SinoCon assumes no responsibility other than the liability stated by SinoCon in the terms and conditions of sale of
its products and SinoCon makes no warranties regarding the sale or use of KonNaD products, including the
suitability for the specific use of the products, and marketability, and SinoCon doesn't guarantee that it won't
infringe any patent, copyright or other intellectual property rights, etc.
Information in this document is subject to change without notice and does not represent a commitment on the
part of SinoCon.
Contact US
SinoCon Co., Ltd.
Address: 16th Floor, Tower A, Zhongyin Building, Caitian Road, Futian District, Shenzhen, China
Web: www.sinoconsys.com
Tel: +86 0755-88865168
C2000-S1-TH05E02-D01 User Manual
3 / 12
SinoCon Co., Ltd. www.sinoconsys.com
C2000-S1-TH05E02-D01 User Manual
4 / 12
SinoCon Co., Ltd. www.sinoconsys.com
1. Hardware Description
1.1. Specifications
Classification Parameter Specification
Sensor Parameters Temperature Meauring
Range
-10 ~ 50℃
Temperature Measuring
Accuracy
±0.5℃
Humidity Meauring Range 0-95% RH
Humidity Measuring
Accuracy
±3.0%
Upstream Serial
Port
Serial Standrad RS485
No. of Ports 1
Connector RJ45
Industrial Protocol Standard Modbus RTU Protocol
Baud Rate 1200~115200bps
Communication Distance 1200m
Downstream Serial
Port
Serial Standard RS485
No. of Ports 1
Connector RJ45
Serial Protocol Modbus RTU
Power Power Connector RJ45 (integrated with RS485)
Input Voltage 9~16VDC (RJ45 integrated power supply)
Current ≤ 15mA
Other Parameters Temperature & Humidity
Display
Support temperature, humidity and 485 address
display
C2000-S1-TH05E02-D01 User Manual
5 / 12
SinoCon Co., Ltd. www.sinoconsys.com
RS485 Address Settings 6-digit DIP switch sets the sensor address, address
range 0-63
Physical
Characteristics
Dimensions 45*94.7*27.1mm
Installation Magnet
Environmental
Limits
Operating Temperature -10℃ ~ 50℃
Ambient Relative Humidity 0% ~ 95% RH, non-condensing
Classification Parameter Specification
C2000-S1-TH05E02-D01 User Manual
6 / 12
SinoCon Co., Ltd. www.sinoconsys.com
3. Warranty Policy
In the normal use of the products you purchased, free warranty service will be provided from the date of
purchase whenever the quality problems caused by raw materials or production process are concerned. However,
due to the user's failure to install, disassemble or improperly use the product according to the requirements of this
product manual, the company provides maintenance services, but charges appropriate maintenance fees. The
warranty period is as follows:
Product category Warranty Period
Shelled product 6years
Unshelled product 3years
Note: Accessories are not covered by warranty.
Warranty Terms:
1. From the date of purchase, in the case of normal use (determined by the company's authorized
technicians), the failed product will be repaired free of charge during the warranty period.
2. Products that have been repaired or modified by a maintenance personnel other than our company
during the warranty period, or that have been improperly installed, incorrectly input voltage, improperly
used, accidental events or natural disasters, etc., are not covered by the warranty.
3. Before accepting the warranty service, the customer is required to prove the date of purchase of the
product by presenting the warranty card or purchasing the invoice. Otherwise, the warranty cannot be
guaranteed.
4. For all warranty or repair products, the customer bears the risk of shipping and shipping costs.
5. If the product exceeds the warranty period or does not meet the warranty requirements, the company will
provide charge maintenance.
6. The warranty terms for customized and ODM products should be defined in the contract.
7. Other verbal commitments that conflict with this warranty would be executed with reference to this
warranty.
8. Our company's responsibility for the manufacture, sale and use of the products shall not exceed the
original cost of the products. The company does not assume any joint responsibility.
9. The right to interpret this clause belongs to the company.
