Kontron AdvancedTCA RTM8020 User manual

RTM8020 User's Guide
Document Revision 1.1
May 2009

i RTM8020 User's Guide
Customer Service
Visit our site at:www.kontron.com
© 2009 Kontron, an International Corporation. All rights reserved.
The information in this user's guide is provided for reference only. Kontron does not assume any liability arising out of the
application or use of the information or products described herein. This user's guide may contain or reference information
and products protected by copyrights or patents and does not convey any license under the patent rights of Kontron, nor
the rights of others.
Kontron is a registered trademark of Kontron. All trademarks, registered trademarks, and trade names used in this user's
guide are the property of their respective owners. All rights reserved. Printed in Canada. This user's guide contains
information proprietary to Kontron. Customers may reprint and use this user's guide in other publications. Customers may
alter this user's guide and publish it only after they remove the Kontron name, cover, and logo.
Kontron reserves the right to make changes without notice in product or component design as warranted by evolution in
user needs or progress in engineering or manufacturing technology. Changes that affect the operation of the unit will be
documented in the next revision of this user's guide.
Contact Information: Kontron Canada, Inc.
4555, Ambroise-Lafortune
Boisbriand, Québec, Canada
J7H 0A4
Tel: [phone]
[phone]
Fax: [phone]
E-mail: suppor[email protected]on.com
Kontron Modular Computer GMBH
Sudetenstrasse 7
87600 Kaufbeuren
Germany
[phone]
[phone]
suppor[email protected]

Table of Contents
ii RTM8020 User's Guide
Table of Contents
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
When Working Inside a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .v
Preventing Electrostatic Discharge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Preface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
How to Use This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii
Customer Comments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Advisory Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Powering Up the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Adapter Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Storing Boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Regulatory Compliance Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .x
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
1. Product Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 What’s Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.3 Board Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.4 Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.5 Hot-Swap Capability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.6 Interfacing with the Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.6.1 RTM (rear transition module) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2. Board Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1 Block Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 USB 2.0 Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 SAS Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.4 SAS Hard Drive Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.5 Serial Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.6 Redundant MMC Flash & FWUM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Table of Contents
iii RTM8020 User's Guide
2.7 Hardware Management Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.7.1 Sensor Data Record (SDR). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.7.2 Hardware Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.7.3 Field Replaceable Unit (FRU) Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.7.4 E-Keying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.7.5 MMC Firmware Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
2.7.6 MMC Firmware Upgrade Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
2.7.7 FWUM Firmware Upgrade Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
2.8 Debugging Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.8.1 IPMI controlled LED (LED3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2.8.2 RTM Health (LED2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2.8.3 Out of service (LED1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
3. Installing the Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.1 Board Hot Swap and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.1.1 Installing the RTM in the chassis. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
3.1.2 Removing the RTM from the chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
A. Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1
A.1 CONNECTORS AND HEADERS SUMMARY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1
A.2 ATCA I/O RTM Connector (P30) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-2
A.3 USB Port (J2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-2
A.4 SAS Faceplate Connector (J3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-3
A.5 SERIAL PORT(J5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-3
A.6 POST Code Connector (J7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-4
A.7 SAS Hard Drive Connector (J10). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-4
B. Software Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-1
B.1 IPMC Firmware Update Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-1
C. Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-1
C.1 Returning Defective Merchandise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2
C.2 When Returning a Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3

Safety instructions
iv RTM8020 User's Guide
Safety instructions
Before You Begin
Before handling the board, read the instructions and safety guidelines on the following pages to prevent
damage to the product and to ensure your own personal safety. Refer to the "Advisories" section in the
Preface for advisory conventions used in this user's guide, including the distinction between Warnings,
Cautions and Notes.
• Always use caution when handling/operating the computer. Only qualified, experienced,
authorized electronics service personnel should access the interior of the computer. The power
supplies produce high voltages and energy hazards, which can cause bodily harm.
• Use extreme caution when installing or removing components. Refer to the installation
instructions in this user's guide for precautions and procedures. If you have any questions, please
contact Kontron Technical Support
WARNING
High voltages are present inside the chassis when the unit's power cord is plugged
into an electrical outlet. Turn off system power, turn off the power supply, and then
disconnect the power cord from its source before removing the chassis cover. Turning
off the system power switch does not remove power to components.

Safety instructions
v RTM8020 User's Guide
When Working Inside a Computer
Before taking covers off a computer, perform the following steps:
• Turn off the computer and any peripherals.
• Disconnect the computer and peripherals from power sources or subsystems to prevent electric
shock or system board damage. This does not apply to when hot-swapping parts.
• Follow the guidelines provided in "Preventing Electrostatic Discharge" on the following page.
• Disconnect telephone or telecommunications lines from the computer.
In addition, take note of these safety guidelines when appropriate:
• To help avoid possible damage to system boards, wait five seconds after turning off the computer
before removing a component, removing a system board, or disconnecting a peripheral device from
the computer.
• When you disconnect a cable, pull on its connector or on its strain-relief loop, not on the cable
itself. Some cables have a connector with locking tabs. If you are disconnecting this type of cable,
press in on the locking tabs before disconnecting the cable. As you pull connectors apart, keep
them evenly aligned to avoid bending any connector pins. Also, before connecting a cable, make
sure both connectors are correctly oriented and aligned.
CAUTION
Do not attempt to service the system yourself, except as explained in this user’s
guide. Follow installation and troubleshooting instructions closely.

Safety instructions
vi RTM8020 User's Guide
Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD
procedure to reduce the risk of damage to components. Kontron strongly encourages you to follow proper
ESD procedures, which can include wrist straps and smocks, when servicing equipment.
Take the following steps to prevent damage from electrostatic discharge (ESD):
• When unpacking a static-sensitive component from its shipping carton, do not remove the
component's antistatic packing material until you are ready to install the component in a
computer. Just before unwrapping the antistatic packaging, be sure you are at an ESD workstation
or grounded. This will discharge any static electricity that may have built up in your body.
• When transporting a sensitive component, first place it in an antistatic container or packaging.
• Handle all sensitive components at an ESD workstation. If possible, use antistatic floor pads and
workbench pads.
• Handle components and boards with care. Don't touch the components or contacts on a board.
Hold a board by its edges or by its metal mounting bracket.
• Do not handle or store system boards near strong electrostatic, electromagnetic, magnetic, or
radioactive fields.

Preface
vii RTM8020 User's Guide
Preface
How to Use This Guide
This user's guide is designed to be used as step-by-step instructions for installation and as a reference for
operation, troubleshooting, and upgrades.
You can find the latest release of this User's Guide at:
http://www.kontron.com or at: ftp://ftp.kontron.ca/support/
For the circuits, descriptions and tables indicated, Kontron assumes no responsibility as far as patents or
other rights of third parties are concerned.
The following is a summary of chapter contents:
• Chapter 1, Product Description
• Chapter 2, Board Features
• Chapter 3, Installing the board
• Appendix A, Connector Pinout
• Appendix B, Software Update
• Appendix C, Getting Help

Preface
viii RTM8020 User's Guide
Customer Comments
If you have any difficulties using this user's guide, discover an error, or just want to provide some feedback,
please send a message to: [email protected]. Detail any errors you find. We will correct the errors
or problems as soon as possible and post the revised user's guide on our Web site. Thank you.
Advisory Conventions
Seven types of advisories are used throughout the user guides to provide helpful information or to alert you
to the potential for hardware damage or personal injury. They are Note, Signal Paths, Jumpers Settings, BIOS
Settings, Software Usage, Cautions, and Warnings. The following is an example of each type of advisory. Use
caution when servicing electrical components.
Disclaimer: We have tried to identify all situations that may pose a warning or a caution condition in this
user's guide. However, Kontron does not claim to have covered all situations that might require the use of a
Caution or a Warning.
Note:
Indicate information that is important for you to know.
Signal Path:
Indicate the places where you can fin the signal on the board.
Jumper Settings:
Indicate the jumpers that are related to this sections.
BIOS Settings:
Indicate where you can set this option in the BIOS.
Software Usage:
Indicates how you can access this feature through software.
CAUTION
Indicate potential damage to hardware and tells you how to avoid the problem.
WARNING
Indicates potential for bodily harm and tells you how to avoid the problem.

Preface
ix RTM8020 User's Guide
Unpacking
Follow these recommendations while unpacking:
• Remove all items from the box. If any items listed on the purchase order are missing, notify
Kontron customer service immediately.
• Inspect the product for damage. If there is damage, notify Kontron customer service immediately.
• Save the box and packing material for possible future shipment.
Powering Up the System
Before any installation or setup, ensure that the board is unplugged from power sources or subsystems.
If you encounter a problem, verify the following items:
• Make sure that all connectors are properly connected.
• Verify your boot devices.
• If the system does not start properly, try booting without any other I/O peripherals attached,
including AMC adapters.
Make sure your system provides the minimum DC voltages required at the board's slot, especially if DC power
is carried by cables.
If you are still not able to get your board running, contact our Technical Support for assistance.
Adapter Cables
Because adapter cables come from various manufacturers, pinouts can differ. The direct crimp design offered
by Kontron allows the simplest cable assembly. All cables are available from Kontron Sales Department.
Storing Boards
Electronic boards are sensitive devices. Do not handle or store device near strong electrostatic,
electromagnetic, magnetic or radioactive fields.

Preface
x RTM8020 User's Guide
Regulatory Compliance Statements
FCC Compliance Statement for Class B Devices
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generated, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experience radio/TV technician for help.
UL Certification
This product bears the combined UL Recognized Component Mark for Canada and U.S. It indicates
investigations to the UL Standard for Safety of Information Technology Equipment, Including
Electrical Business Equipment. It is destinated to be used in end-product equipment where the
acceptability of the combination is determined by Underwriters Laboratories Inc.
CE Certification
The product described in this user's guide was tested in a representative system and is found to be
compliant with the CE marking requirements. For computer systems to remain CE compliant, only
CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling
techniques. Although Kontron offers accessories, the customer must ensure that these products
are installed with proper shielding to maintain CE compliance. Kontron does not offer engineering
services for designing cabling systems. In addition, Kontron will not retest or recertify systems or
components that have been reconfigured by customers.
WARNING
This is a Class B product. If not installed in a properly shielded enclosure and used in
accordance with this User's Guide, this product may cause radio interference in
which case users may need to take additional measures at their own expense.

Preface
xi RTM8020 User's Guide
Limited Warranty
Kontron grants the original purchaser of Kontron's products a TWO YEAR LIMITED HARDWARE WARRANTY as
described in the following. However, no other warranties that may be granted or implied by anyone on behalf
of Kontron are valid unless the consumer has the express written consent of Kontron.
Kontron warrants their own products, excluding software, to be free from manufacturing and material
defects for a period of 24 consecutive months from the date of purchase. This warranty is not transferable nor
extendible to cover any other users or long- term storage of the product. It does not cover products which
have been modified, altered or repaired by any other party than Kontron or their authorized agents.
Furthermore, any product which has been, or is suspected of being damaged as a result of negligence,
improper use, incorrect handling, servicing or maintenance, or which has been damaged as a result of
excessive current/voltage or temperature, or which has had its serial number(s), any other markings or parts
thereof altered, defaced or removed will also be excluded from this warranty.
If the customer's eligibility for warranty has not been voided, in the event of any claim, he may return the
product at the earliest possible convenience to the original place of purchase, together with a copy of the
original document of purchase, a full description of the application the product is used on and a description
of the defect. Pack the product in such a way as to ensure safe transportation (see our safety instructions).
Kontron provides for repair or replacement of any part, assembly or sub-assembly at their own discretion, or
to refund the original cost of purchase, if appropriate. In the event of repair, refunding or replacement of
any part, the ownership of the removed or replaced parts reverts to Kontron, and the remaining part of the
original guarantee, or any new guarantee to cover the repaired or replaced items, will be transferred to cover
the new or repaired items. Any extensions to the original guarantee are considered gestures of goodwill, and
will be defined in the "Repair Report" issued by Kontron with the repaired or replaced item.
Kontron will not accept liability for any further claims resulting directly or indirectly from any warranty
claim, other than the above specified repair, replacement or refunding. In particular, all claims for damage
to any system or process in which the product was employed, or any loss incurred as a result of the product
not functioning at any given time, are excluded. The extent of Kontron liability to the customer shall not
exceed the original purchase price of the item for which the claim exists.
Kontron issues no warranty or representation, either explicit or implicit, with respect to its products
reliability, fitness, quality, marketability or ability to fulfil any particular application or purpose. As a result,
the products are sold "as is," and the responsibility to ensure their suitability for any given task remains that
of the purchaser. In no event will Kontron be liable for direct, indirect or consequential damages resulting
from the use of our hardware or software products, or documentation, even if Kontron were advised of the
possibility of such claims prior to the purchase of the product or during any period since the date of its
purchase.
Please remember that no Kontron employee, dealer or agent is authorized to make any modification or
addition to the above specified terms, either verbally or in any other form, written or electronically
transmitted, without the company's consent.

Product Description
1 RTM8020 User's Guide
1. Product Description
1.1 Product Overview
For additional connectivity, the AT8020 is available with the RTM8020, a single slot (6HP) AdvancedTCA rear
transition module. The RTM8020 features one serial port, two 3Gbit/s SAS links and integrates an onboard
SAS drive for either additional functionality or extended customization by saving an AdvancedMC slot on the
processing blade for other IO or processing modules.
1.2 What’s Included
This board is shipped with the following items:
• One RTM8020 board
• One CD-ROM containing documentations and drivers.
• Cables that have been ordered
If any item is missing or damaged, contact the supplier.

Product Description
2 RTM8020 User's Guide
1.3 Board Specifications
* Designed to meet or exceed
Features Description
Compatible Products • AT8020
Compliancy
• PICMG3.0 R2.0
• SAS1R10
• SFF-8470
IPMI Features
• Management Controller compliant to PICMG 3.0 and IPMI v1.5 rev 1.1.
• Management Controller is run time field reprogrammable without payload impact.
• Robust fail safe reprogramming implementation (which includes two firmware
images) that could perform automatic or manual rollback if a problem occurs during
critical reprogramming phase.
• Remote upgrade capability from all IPMI interfaces (via IPMB).
• Management Controller self test which can detect failure under its code integrity and
trig an automatic rollback.
Supervisory • Hardware system monitor through IPMI (voltages, currents, temperature),
temperature monitor / alarm; board temperature sensor, power failure.
Mechanical • 322.25 x 93.74 x 29 mm
Power Requirements 25W maximum
Environmental
Temperature*
Operating: 0-55°C/32-131°F with 30CFM airflow
Storage and Transit: -40 to +70°C/-40 to 158°F
Environmental
Humidity*
Operating: 15% to 90% @55°C/131°F non-condensing
Storage and Transit: 5% to 95% @ 40°C/104°F non-condensing
Environmental Altitude* Operating: 4,000 m / 13,123 ft
Storage and Transit: 15,000 m / 49,212 ft
Environmental Shock* Operating: 30G, half-sine 11ms, each axis
Storage and Transit: Bellcore GR-63-CORE Section 4.3
Environmental
Vibration*
Operating: 1.0G, 5-500Hz each axis
Storage and Transit: 2.0G, 5-50Hz; 3.0G, 50-500Hz each axis
Reliability
• MTBF: > TBD hours @ 30 C / 77 F (Telcordia SR-332, Issue 1)
• Whole board protected by active breaker
• USB voltage protected by an active breakers
Safety / EMC
Meet or exceed:
Safety: UL 60950-1 1st Ed.; CSA C22.2 No 60950-1-03; EN 60950-1:2001; IEC60950-1
EMI/EMC: FCC 47 CFR Part 15, Class B; CE Mark to EN55022/EN55024
Warranty Two years limited warranty

Product Description
3 RTM8020 User's Guide
1.4 Compliance
This product conforms to the following specifications:
• PICMG3.0 R2.0 ECN002 - Advanced Telecommunication Computing Architecture
• SAS1R10 - Serial Attached SCSI - 1.1 Revision 10. (SAS-1.1)
• SFF-8470 (T10 Technical Committee and SCSI Trade Association
1.5 Hot-Swap Capability
The RTM8020 supports Full Hot Swap capability as per PICMG3.0R2.0. It can be removed from or installed in
the system while it is on (without powering-down the system). Please refer to the PICMG3.0R2.0
specification for additional details.

Product Description
4 RTM8020 User's Guide
1.6 Interfacing with the Environment
1.6.1 RTM (rear transition module)
The RTM8020 is a single slot (6HP) ATCA Rear Transition Module. This module provides additional
connectivity for AT8020 CPU front blade.
1.6.1.1 Standard Compliance
• PICMG3.0 R2.0 ECN002 - Advanced Telecommunication Computing Architecture
• SAS1R10 - Serial Attached SCSI - 1.1 Revision 10. (SAS-1.1)
• SFF-8470 (T10 Technical Committee and SCSI Trade Association)
1.6.1.2 SAS Feature
• Total of two (2) 3Gbit/s SAS ports available on the RTM face plate through one external SAS connector
• Compliant to SAS-1.1 Revision 10 / SFF-8470
• SAS signal integrity guarantee over a four meters cable
1.6.1.3 Serial Port Feature
• One (1) serial port available on the RTM face plate through one (1) RJ-45 connector.
• RS-232 signals level at RTM face plate connector.
• Serial port speed capability is: 9kbits/s to 115kbits/s.
1.6.1.4 Onboard SAS Drive
• Support one (1) 2.5” SAS Drive
• Support dual-port SAS Drive
1.6.1.5 FRU Data EEPROM
• FRU Data EEPROM size is 64Kbit (8K * 8 bit)
1.6.1.6 Hot Swap
The RTM8020 supports hot swapping by using the switch connected to the face plate lower ejector. This
switch indicates the coming hot swap action. The insertion of the RTM to a slot is always done over a non
powered connector. During the extraction procedure, the management power is disabled only when the
RTM8020 is removed. This procedure meets the ATCA AMC behavior.

Product Description
5 RTM8020 User's Guide
1.6.1.6.1 Inserting the RTM8020 into the slot
The presence of the RTM is indicated by two signals. The front blade IPMC recognizes the RTM insertion when
the two signals are low (lower ejector handle closed). After recognizing the RTM, the MMC turns the blue LED
ON and enables the 3.3V_SUS to the RTM. Once the I2C link is working, the MMC accesses the serial EEPROM
to retrieve FRU data. After knowing the type of RTM inserted, the MMC negotiates with System Manager in
order to activate the +12V payload power. After RTM local voltages have been ramped up, the MMC enables
the RTM Link.
After this the IPMC informs the CPU SW there is a functional RTM blade present.
1.6.1.6.2 Removing the RTM8020 from the slot
The RTM_EJECT signal goes HIGH by opening the RTM lower ejector handle. This indicates to the front blade
IPMC that a hot swap action is going to take place. The MMC then negotiates the removal with the System
manager and if it is granted, it proceeds with the removal process.
The MMC first notifies the CPU SW of coming hot removal. After the CPU SW has disabled SAS links, it notifies
the MMC that the RTM blade can be removed. The MMC then activates reset to the RTM blade (via the
Expander), disables the RTM Link and turns OFF the payload +12V power. When it is safe to remove the RTM
blade from the slot, the MMC turns the Blue / Hot Swap LED ON. Front Blade IPMC turns OFF the management
power only when their is no RTM detected. (RTM8020 removed from the slot)

Board Features
6 RTM8020 User's Guide
2. Board Features
2.1 Block Diagram

Board Features
7 RTM8020 User's Guide
2.2 USB 2.0 Interfaces
USB features include:
• Capability to daisy chain as many as 127 devices per interface
• Fast bi-directional
• Isochronous/asynchronous interface
• 480 MBPS transfer rate
• Standardization of peripheral interfaces into a single format
• Backward compatible with USB 1.1 devices
USB supports Plug and Play and hot-swapping operations (OS level). These features allow USB devices to be
automatically attached, configured and detached, without reboot or running setup.
Pin Signal
1VCC
2DATA-
3DATA+
4GND
Signal Path:
The USB Port is available through the RTM front plate (J2).

Board Features
8 RTM8020 User's Guide
2.3 SAS Link
The RTM8020 has two (2) 3Gbits/s SAS links available on the face plate through one (1) SAS connector. These
links are coming from the front blade through the zone 3 connector. A SAS signal conditioner is needed to
guarantee SAS signal integrity over the cable between two RTM blades. The maximum SAS cable length
between two RTM blades is 4m.
2.4 SAS Hard Drive Option
Kontron offers the option of adding a SAS hard drive on the RTM8020. This hard drive is located on the
component side of the PCB, in the lower part of the RTM8020.
2.5 Serial Port
The RTM8020 has one serial port available on the RTM face plate. Serial port signals are coming from the
front blade through zone 3 connector. Serial Port on this RTM is COM2 from the AT8020. A RS232 buffer is
used on the RTM to convert signal TTL level from zone 3 to RS232 signal level at the face plate connector.
Serial port works from 9kbits/s to 115kbits/s.
Pin Signal
1RTS
2DTR
3TX#
4GND/DCD
5GND
6RX#
7DSR
8CTS
Note:
Standard product uses a RJ-45 8 pins connector. RI (ring indicator) and DCD (data carrier detect)
signals are not available.
The pinout is a custom one, not the same as RS-232D TIA/EIA-561.
