1. USER INFORMATION
1.1 AboutThisManual
This document provides information about products from Kontron Embedded
Computers AG and/or its subsidiaries. No warranty of suitability, purpose, or
fitness is implied.
While every attempt has been made to ensure that the information in this
document is accurate, the information contained within is supplied “as-is” and is
subject to change without notice.
For the circuits, descriptions and tables indicated, Kontron assumes no
responsibility as
1.2 JUMPtecBrand
JUMPtec Industrielle Computertechnik AG and Kontron Embedded Computers
AG merged in July 2002.JUMPtec is now known as Kontron Embedded Modules
GmbH.
Products labeled and sold under the Kontron Embedded Modules name (formerly
JUMPtec) are now consideredKontron products for all practical purposes,
including warranty and support.
DIMM-PC®, PISA®, ETX Components SBC,JUMPtec®, and Kontron Embedded
Modules are registered trademarks ofKontron Embedded Modules GmbH.
1.3 CopyrightNotice
Copyright © 2002 Kontron Embedded Computers AG.
All rights reserved. No part of this manual may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means (electronic, mechanical,
photocopying, recording, or otherwise), without the express written permission of
Kontron.
1.4 Trademarks
The following lists the trademarks of components used in this board.
• IBM, XT, AT, PS/2 and Personal System/2 are trademarks of International
Business Machines Corp.
• Microsoft is a registered trademark of Microsoft Corp.
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 4Revision 1.2
• All other products and trademarks mentioned in this manual are trademarks of
their respective owners.
1.5 Standards
Kontron Embedded Modules is certified to ISO 9000 standards.
1.6 Warranty
This Kontron Embedded Modules product is warranted against defects in
material and workmanship for the warranty period from the date of shipment.
During the warranty period, Kontron Embedded Modules will at its discretion
decide to repair or replace defective products.
Within the warranty period, the repair of products is free of charge as long as
warranty conditions are observed.
You may receive a bill for test costs if Kontron Embedded Modules finds no fault
with the product. You also may receive a bill for repairs if a product’s warranty
has expired.
For warranty service or repair, return the product to aKontron Embedded
Modules service facility listed in the Technical Support section of this document.
The warranty does not apply to defects resulting from improper or inadequate
maintenance or handling by the buyer, unauthorized modification or misuse,
operation outside of the product’s environmental specifications or improper
installation or maintenance.
Kontron Embedded Modules will not be responsible for any defects or damages
to other products not supplied byKontron Embedded Modules that are caused by
a faulty Kontron Embedded Modules product.
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 5Revision 1.2
1.7 TechnicalSupport
Technicians and engineers from Kontron Embedded Modules and/or its
subsidiaries are available for technical support. We are committed to making our
product easy to use and will help you use our products in your systems. Before
contacting Kontron Embedded Modules technical support, please consult our
Web site for the latest product documentation, utilities, and drivers. If the
information does not help solve the problem, contact us by email or telephone.
The table below lists technical support contacts and service facilities for Kontron
Embedded Modules.
Asia Europe North/South America
Kontron Asia Kontron Embedded Modules Kontron Americas
5F-1, 341, Sec 4
Chung HsiaoE.Road
Taipei,Taiwan
Brunnwiesenstr.16
94469 Deggendorf–Germany 3988TrustWay
Hayward,CA94545
Tel:+886227517192 Tel:+49(0)991-37024-0 Tel:510-732-6900
Fax: +886 2 2772 0314 Fax:+49(0)991-37024-104 Fax:510-732-7655
http://www.jumptec.com.tw/
http://www.kontron.com.tw/
http://www.jumptec.de/
http://www.kontron.de/
http://www.adastra.com/
http://www.kontron.com/
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 6Revision 1.2
2. INTRODUCTION
2.1 JFLEX-Multimedia
TheJFLEX-Multimedia is an extension for Kontrons JRex 3,5’’ SBC family.
Following features are provided by the JFLEX-Multimedia:
•One Realtek ALC650 sound controller compatible to IntelAudio Codec
´97 Rev. 2.2
Input connectors: Microphone, Line, CD-ROM (internal)
Output connectors: Line, Amp (6W/channel @ 4Ω?), S/PDIF (optical)
•3,3V switching regulator to run the JRex system on 5V only
•IEEE1394 (Firewire) controller
•DVI digital
•TV-Out through S-Video connector
•IrDA Connector
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 7Revision 1.2
•
3. SPECIFICATIONS
3.1 MechanicalSpecifications
•Mechanical: 140,6mm x 82,5mm L-shape
140,6
80,2
82,5
33,0
5
11
13
12,6
23,3
33,9
44,6
54,9
81,4
72,4
112,1
124,7
4,95
11,6 12,1
All dimensions are given in Millimeters [mm].
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 8Revision 1.2
3.2 ElectricalSpecifications
3.2.1 Supply Voltage for Sound
•5V DC +/- 5%
•3,3V DC +/- 5%
3.2.2 Supply Voltage Ripple
•100 mV peak to peak 0-20 MHz
3.2.3 SupplyCurrent
•@ 3.3V max. 750mA
•@ 5V max. 200mA
•@ 12V max. 100mA (excluding Firewire device)
3.2.4 Output Voltage
•3,3V DC +/- 5% max 3,5A
3.3 EnvironmentalSpecifications
3.3.1 Temperature
•Operating: 0 to + 60°C
•Storage: -10 to + 85 °C
3.3.2 Humidity
•Operating: 10% to 90% (non condensing)
•Storage: 5% to 95% (non condensing)
To protect the externalpowerlines to peripheral devices the customer has to take
care about:
•The wires to the external device have the right diameter to withstand the max.
available current.
•The housing of the external device fulfills the fire protectingrequirements of
IEC/EN 60950.
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 9Revision 1.2
4. MODULE FUNCTIONS
4.1 AC’97SoundController
The JFLEX-Multimedia uses a Realtek ALC650 sound codec. The ALC650 is an
18-bit, full duplex AC’97 2.2 compatible stereo audio CODEC designed for PC
multimedia systems, including host/soft audio and AMR/CNR based designs. The
ALC650 incorporates proprietary converter technology to achieve a high SNR,
greater than 90 dB.
The ALC650 also supports an AC’97 2.2 compliant S/PDIF out function which
allows easy connection from the PC to consumer electronic products, such as
AC3 decoder/speaker and mini disk.
All major operating systems support the interface.
TheALC650 provides:
•High performance CODEC with high S/N ratio (>90 dB)
•18-bit ADC and 20-bit DAC resolution
•Compliant with AC’97 2.2 specifications
•18-bit stereo full-duplex CODEC with independent and variable sampling rate
•1 analog line-level stereo input with 5-bit volume control: LINE_IN, (CD_IN is
possible)
•Stereo output with 5-bit volume control
•1 MIC input
•Power management capabilities
•Embedded 50mW/20ohm OP at front LINE output
•Digital S/PDIF output
4.1.1 Line-In Connector X8
4.1.2 Line-Out Connector X11
Pin Signalname
1GND
2L_IN Left
3L_IN Right
Pin Signalname
1GND
2L_OUT Left
3L_OUT Right
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 10 Revision 1.2
4.1.3 Microphone-IN Connector X9
4.1.4 Amplified-OUT Connector X10
4.1.5 S/PDIF-OUT Connector X12
4.1.6 CD-ROM Input X7
Pin 1
Pin Signalname
1GND
2MIC_IN Left
3not connected
Pin Signalname
1GND
2AMP_Out Left
3AMP_Out Right
Fiber Output Power -21 ... –15 dBm
Wavelength 660 nm
Pin Signalname Function
1CD_INRight AudioInputRightChannel
2NC
3CD_IN Left AudioInputLeftChannel
4GND SignalGround
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 11 Revision 1.2
4.2 TV-out
The JFLEX-Multimedia provides FBAS and S-Video output signals for interfacing
certain displays or beamers for example.
4.2.1 S-Video Connector X13
Pin Name Description
1GND Ground (Y)
2GND Ground (C)
3YIntensity (Luminance) / Composite
4CColor (Chrominance)
4.3 DVI (Digital Video Interface)
The JFLEX-Multimedia is equipped with a standard Digital Video Interface. DVI
has the potential to unify the digital display industry. The DVI 1.0 specification
was endorsed in April 1999 by the Digital Display Working Group (DDWG), an
industry organization established by Intel. Membership consists of major PC and
display manufacturers. TI is a DDWG participant.
DVI is based on Transition-Minimized Differential Signaling (T.M.D.S.), a
technology that offers advantages in video data transmission. DVI adds a specific
hardware interface that is compatible with older T.M.D.S.-based interfaces such
as the Plug & Display (P&D) and Digital Flat Panel (DFP) standards endorsed by
the Video Electronics Standards Association (VESA). DVI technology is non-
proprietary to encourage the most widespread adoption.
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 12 Revision 1.2
4.3.1 DVIConnector
Pin Signal Pin Signal Pin Signal
1T.M.D.S. Data 2- 9T.M.D.S. Data 1- 17 T.M.D.S. Data0-
2T.M.D.S. Data 2+ 10 T.M.D.S. Data 1+ 18 T.M.D.S. Data0+
3GND 11 GND 19 GND
4NC 12 NC 20 NC
5NC 13 NC 21 NC
6DDCClock 14 + 5V Power 22 GND
7DDCData 15 GND 23 T.M.D.S.Clock+
8NC 16 Hot Plug Detect 24 T.M.D.S. Clock-
C1 NC C2 NC C3 NC
C4 NC C5 GND
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 13 Revision 1.2
4.4 IEEE1394Controller
TheJFLEX-Communication1 IEEE 1394 interface use VIA VT6306 PCI Host
Controller. This is a 1394A OHCI Host Controller with integrated 3-PORT 400
MBIT PHY.
TheVT6306 provides:
•32 bit CRC generator and checker for receive and transmit data
•On-chip isochronous receive and transmitFIFOs for packets
•8isochronous transmit / receive contexts
•2-deep physical response queue
•3-deep physical post-write queue
•Dual buffer mode enhancements
•Skip Processing enhancements
•Block Read Request handling
•Ack_tardy processing
•Compliant with 1394 Open HCI Specifications v1.0 and v1.1
•Descriptor based isochronous and asynchronous DMA channels for
receive / transmit packets
•Compliant with PCI specification v2.2
•Supports I2C EEPROM and 4-Wire Serial ROM with GUID PROM Shadow
to EEPROM
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 14 Revision 1.2
4.4.1 Connector (X5)
6 PIN IEEE1394 female connector
4.4.2 Connector Pinout
Pin SignalName Function In/Out
1Power 12V DC Output
2Ground Ground return for power and inner cable shield
3TPB- Twisted-pair B, differential signals Differential Output
4TPB+ Twisted-pair B, differential signals Differential Output
5TPA- Twisted-pair A, differential signals Differential Output
6TPA+ Twisted-pair A, differential signals Differential Output
Note: The current of the power lines is internal limited to 1500mA
4.4.3 IEEE Technical Support
For technical support, contact either Kontron Embedded Modules or get
support information from http://www.via.com.tw/en/Communications/prodviafire2.jsp.
1
45
3
6
2
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 15 Revision 1.2
4.5 IrDA-ConnectorX15
IRDA(namedafterthestandardizinggroup”InfraRedDataAssociation”)definesastandardfor
highspeedinfrareddatatransfer(overdistancesofabout1meter).
For the infrared feature to be available, you must connect an infrared module to
the IrDA connector and configure the infrared settings in BIOS setup. The IrDA
connector supports the optional wireless transmitting and receiving infrared
module.
The connector with eight positions used on JFLEX-Multimedia for connecting an
infrared module is from manufacturer BERG and the corresponding counterpart
is specified as following:
Manufacturer: BERG Electronics
Type: DUBOXsystem,Housing,singlerow,2,54mm
Order number: 65240-008
Fitting crimp contacts:
Manufacturer: BERG Electronics
Type: DUBOXsystem,Contactcrimptowire,2,54mm
Order number: 76357-301 (Wire size 22-30, Insulation O.D.0,9-1,5,Loosepiececontacts)
Pin Signalname Function
1NC
2NC
3IRTX Infrared transmit
4GND Ground
5IRRX Infrared receive
6VCC +5V
7NC
8NC
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 16 Revision 1.2
4.6 Power
If a not self powered Firewire (1394) device is connected it is strictly
recommended to use this power connector for additional power supply.
Otherwise the JFLEX-Multimedia or the JRex board can get permanently
damaged.
4.6.1 Connector (X6)
Pin Pin Function
1+5V DC
2GND
3GND
4+12V DC
4.6.2 3,3V DC-DC Switching Regulator
When operating the JRex CPU board with a 5V-only Power supply the JFLEX-
Multimedia with assembled 3,3V option can be used to generate the desired 3,3V
for the CPU board.
This is done with a LM2636 Switching regulator. The maximum current is 2,5 A.
Attention: Most current from 3,3V is drawn by the SDRAM module. The user
has to make sure when selecting a SDRAM module not to exceed
the maximum current.
Attention: Do not connect an ATX power supply with 3,3V output, when
JFLEX-Multimedia with mounted 3,3V regulator is connected. The
3,3V source will get permanently damaged !
1 2 3 4
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 17 Revision 1.2
5. APPENDIX A: BLOCK DIAGRAM
+5V
+3.3V
AC ‘97
Realtek
ALC650
3,5 mm female
connector
X11
3,5 mm female
connector
X9
3,5 mm female
connector
X8
S/PDIF
connector
X12
Optional 3,3V
DC-DC regulator +3.3V
Via
VT 6306
PCI
FireWire
connector
X6
TI
TFP410
DVI
connector
X14
TV Out
Converter
S-Video
Connector
X13
3,5 mm female
connector
X10
Digital Panel Signals
Digital Panel Signals
Amplifier
CD-Sound
Connector
X7
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 18 Revision 1.2
6. APPENDIX B: MECHANICAL DIMENSIONS AND
CONNECTOR LAYOUT
All dimensions are given in Millimeters [mm].
33
140,6
82,5
33,0
Product Manual JFLEX-Multimedia
Kontron Embedded Modules GmbH 19 Revision 1.2
7. APPENDIX C: LITERATURE AND STANDARDS
Below is a list of information sources to help you to further understand PC architecture.
7.1 BusesandGeneralPC Architetcure
7.1.1 PCI
PCI spec. @ http://www.pcisig.com/home/
•The PCI-SIG provides a forum for its ~900 member companies, who
develop PCI products based on the specifications that are created by the PCI-
SIG.
•PCI & PCI-X Hardware and Software Architecture & Design, Fifth Edition,
Edward Solari and George Willse,Annabooks, 2001, ISBN 0-929392-63-9.
•PCI System Architecture,Tom Shanley and Don Anderson, Addison-
Wesley, 2000, ISBN 0-201-30974-2.
7.1.2 USB
USB spec. @ http://www.usb.org/
USB Implementers Forum, Inc. is a non-profit corporation founded by the
group of companies that developed the Universal Serial Bus specification.
The USB-IF was formed to provide a support organization and forum for the
advancement and adoption of Universal Serial Bus technology.
7.1.3 AC ’97
AC ’97 spec. @ http://www.intel.com/labs/media/audio/
The specification defines the Audio Codec ’97 (AC ’97) Architecture and Digital
Interface (AC-link) specifically designed for implementing audio and modem I/O
functionality in PC systems. This specification does not explicitly define the
companion AC ’97 Digital Controller component (sometimes referred to or
Table of contents
