Kooltronic KP2E192/40 User manual

Keep This Manual
With Pagoda
PAGODA SERIES
OPERATOR'S MANUAL
900-057-04 (12/18)
(CDR: 20111)
Pagoda Series
Packaged Blowers
CAUTION
BEFORE INSTALLING AND
USING THIS AIR CONDITIONER,
IT IS IMPORTANT THAT THIS
MANUAL BE READ AND
UNDERSTOOD THOROUGHLY
KOOLTRONIC, INC.
30 Pennington-Hopewell Road
Pennington, NJ 08534
609•466-3400
FAX: 609 • 466-1114
www.kooltronic.com
Find additional information on this
model at kooltronic.com, or use the
Technical Documents QR code
below.
Technical
Documents

2
TABLE OF CONTENTS
Page
I. Introduction 2
II. Incoming Inspection 3
III. Product Handling 3
IV. Product Identification and Nameplate 3
V. Installation Instructions 3
VI. Drawings and Dimensions 4
VII. Specific Model Data 5
Technical Data
Major Component Replacement
VIII. Packing Procedure for Warranty Return 5
IX. Warranty 7
I. Introduction
This Manual provides you with the necessary general information for properly installing and operating
Pagoda Packaged Blowers. Unit specific technical data and mounting instructions are presented later in the
Manual.

3
II. Incoming Inspection
Pagoda Packaged Blowers are designed, built, and packaged to withstand the shock and vibration associated
with shipment by common carriers. Occasionally improper handling during shipping causes damage.
Therefore, a thorough inspection should be performed upon receipt of all shipments. Any carton tears, dents,
scratches, or loose articles should be noted on the Freight Bill. Cartons should be opened promptly and the
units inspected for CONCEALED DAMAGE.
An immediate claim MUST be filed with the freight carrier and an inspection requested. Retain all packing
materials. Kooltronic cannot assume responsibility for Consignee's failure to file a timely freight claim.
III. Product Handling
■Do not attempt to operate your Pagoda unit until you read and thoroughly understand this Manual.
■Before operating this unit, all electrical wiring must be checked to assure the proper connections.
IV. Product Identification and Nameplate
Each Pagoda unit includes an identification nameplate. This nameplate provides:
V. Installation Instructions
The Pagoda Series uses motorized impeller blowers for maximum efficiency and performance at reduced noise
levels and have been designed for mounting on the top or sides of the cabinet. Air flows out of the cabinet into
the inlet of the blower, exiting on all four sides. A three foot [0.9m] (minimum) 3-wire power cord is standard with
these units. See page 4 for location of mounting holes.
CAUTION
Operate this unit only on the proper voltages and frequencies as noted on the nameplate
➀Model Number
➁Electrical Power Characteristics
➂Date of Manufacture
We recommend you copy this information from your
unit.
➀When ordering parts, specify
the Model Number.
➁Before operating, be sure
that the power source
matches these requirements.
KP2E192/40
115V 50/60HZ
11/07
➀
➁
➂

4
VI. Drawings and Dimensions
(4) .250 [6.4] DIA. HOLES
A
B
C
D
EF
A
E
F
B
(4) .312 [7.0] DIA. HOLES
MOUNTING PLAN
G
G
0.38
[9.7]
H
2.00
[50.8]
J
ENCLOSURE AIR INLET
DISCHARGE AIR OUTLET
(ALL 4 SIDES)
POWER CORD EXITS
WITHIN THIS AREA
POWER CORD
2
2
1
1
2
1
Dimensions, inches[mm] are for reference only and subject to change.
Model A B C D E
KP2E192/40 13.50 [342.9] 11.38 [289.1] 5.18 [131.6] 12.00 [304.8] 12.75 [323.9]
KP2E220/45 13.50 [342.9] 11.38 [289.1] 5.18 [131.6] 12.00 [304.8] 12.75 [323.9]
KP2E225/40 13.50 [342.9] 11.38 [289.1] 5.18 [131.6] 12.00 [304.8] 12.75 [323.9]
KP2E225/63 13.50 [342.9] 11.38 [289.1] 5.18 [131.6] 12.00 [304.8] 12.75 [323.9]
KP2E250/56 15.50 [393.7] 13.38 [339.9] 7.00 [177.8] 14.00 [355.6] 14.75 [374.7]
KP4E192/40 13.50 [342.9] 11.38 [289.1] 5.18 [131.6] 12.00 [304.8] 12.75 [323.9]
KP4E225/63 13.50 [342.9] 11.38 [289.1] 5.18 [131.6] 12.00 [304.8] 12.75 [323.9]
KP4E280/80 15.50 [393.7] 13.38 [339.9] 7.00 [177.8] 14.00 [355.6] 14.75 [374.7]
KP4E315/101 15.50 [393.7] 13.38 [339.9] 7.00 [177.8] 14.00 [355.6] 14.75 [374.7]
KP4R355/127 16.75 [425.5] 15.25 [387.3] 10.65 [270.5] 15.25 [387.3] 16.00 [406.4]
Model F G H J
KP2E192/40 7.38 [187.5] 9.50 [241.3] 2.00 [50.8] 0.94 [23.9]
KP2E220/45 7.38 [187.5] 9.50 [241.3] 2.00 [50.8] 0.94 [23.9]
KP2E225/40 7.38 [187.5] 9.50 [241.3] 2.00 [50.8] 0.94 [23.9]
KP2E225/63 7.38 [187.5] 9.50 [241.3] 2.00 [50.8] 0.94 [23.9]
KP2E250/56 9.38 [238.3] 12.00 [304.8] 1.75 [44.5] 0.69 [17.5]
KP4E192/40 7.38 [187.5] 9.50 [241.3] 2.00 [50.8] 0.94 [23.9]
KP4E225/63 7.38 [187.5] 9.50 [241.3] 2.00 [50.8] 0.94 [23.9]
KP4E280/80 9.38 [238.3] 12.00 [304.8] 1.75 [44.5] 0.69 [17.5]
KP4E315/101 9.38 [238.3] 12.00 [304.8] 1.75 [44.5] 0.69 [17.5]
KP4R355/127 9.38 [238.3] 14.00 [355.6] 1.38 [35.0] 0.63 [16.0]
Dimensions, inches [mm], are for reference only and subject to change.

Technical Data*
Major Component Replacements
5
VII. Specific Model Data
VIII. Packing Procedure For Warranty Repair
Pack the Pagoda in an appropriate carton (preferably the original carton), with adequate internal protective
packaging, making sure carton is marked properly.
Approximate
CFM @ Cutoff Weight
Model Type 0" S.P. S.P. dBA Amps Watts Lbs. Kg.
KP2E192/40 2-Pole 319 1.72 63.6 0.74 85 11 5.0
KP2E220/45 2-Pole 418 1.94 68.6 1.05 120 10 4.5
KP2E225/40 2-Pole 338 1.71 71.7 1.11 127 13 5.9
KP2E225/63 2-Pole 421 2.66 73.4 1.89 215 14 6.4
KP2E250/56 2-Pole 688 2.68 77.6 2.33 269 17 7.7
KP4E192/40 4-Pole 182 0.55 55.6 0.25 26 11 5.0
KP4E225/63 4-Pole 253 0.81 59.1 0.62 56 12 5.5
KP4E280/80 4-Pole 630 1.18 65.8 0.94 101 16 7.3
KP4E315/101 4-Pole 749 1.46 68.7 1.36 156 18 8.2
KP4R355/127 4-Pole 1615 1.93 74.0 4.00 450 36 16.3
* 115V, 60 Hz. operation
Pagoda Model Voltage Impeller Capacitor
KP2E192/40 115 0194-76 0452-65
KP2E220/45 115 0194-87 0452-65
KP2E225/40 115 0194-14 0452-65
KP2E225/63 115 0194-85 0452-69
KP2E250/56 115 0194-103 0452-32
K2P2E192/40 230 0194-101 0452-64
K2P2E220/45 230 0194-82 0452-81
K2P2E225/40 230 0194-15 0452-64
K2P2E225/63 230 0194-108 0452-43
K2P2E250/56 230 0194-50 0452-75
KP4E192/40 115 0194-94 0452-60
KP4E225/63 115 0194-74 0452-60
KP4E280/80 115 0194-83 0452-62
KP4E315/101 115 0194-49 0452-53
KP4R355/127 115 0194-45 0452-88
K2P4E192/40 230 0194-102 0452-64
K2P4E225/63 230 0194-09 0452-64
K2P4E280/80 230 0194-26 0452-81
K2P4E315/101 230 0194-27 0452-35
K2P4R355/127 230 0194-28 0452-76

6
This page intentionally left blank.

IX. Standard Warranty
THIS WARRANTY CONSTITUTES THE ENTIRE WARRANTY WITH RESPECT TO THE PRODUCT AND IS IN
LIEU OF ALL OTHERS, EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY
AND WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND IN NO EVENT IS KOOLTRONIC
RESPONSIBLE FOR ANY CONSEQUENTIAL DAMAGES OF ANY NATURE WHATSOEVER.
RETURN AUTHORIZATION (RA) PROCEDURE
KOOLTRONIC products are warranted to be free of defects
in workmanship, materials and components. The following
warranty periods apply from date of shipment:
■Air moving devices/components and hermetic system
components: 1 year
■Spare parts, except filters: 90 days
The above warranty applies when the equipment is operated
under the following conditions:
■Ambient temperature not in excess of 125°F (52°C) in
normal atmosphere or as stated on product nameplate
■Voltage variation no greater than ± 10% from nameplate
rating
■Frequency variation no greater than ±3Hz from nameplate
rating
■Maximum cooling load no higher than air conditioner
nameplate rating
■Waiting five minutes before restarting air conditioner after
intentional or accidental shutoff
■Compliance to all other installation, maintenance and
operating instructions, as supplied
■The purchaser assumes the responsibility of grounding
the unit and installing it in accordance with local electrical
and safety codes, as well as the National Electric Code
(NEC) and OSHA
KOOLTRONIC cannot assume responsibility for
mis-application of its products or the erroneous
selection of an inappropriate product by a non-
authorized KOOLTRONIC representative. Our
applications engineers will gladly assist in the
selection of the proper product, provided all
required details of the application are furnished.
■All returns require a Return Authorization number whether
the return is for warranty or non-warranty repair, rotation of
stock, damage or any other reason. Returns without an RA
number will be refused.
■Customer must call KOOLTRONIC After Sale Kare (ASK),
Pennington, New Jersey (609 • 466 • 3400) to obtain an RA
number, or email [email protected].
■The following information is required when an RA is
requested:
- Original customer Purchase Order number and date
- Date product was received by customer
- Number of parts to be returned
- Product description, model and serial number
- Reason for return
- Action requested
- Contact name, telephone, FAX numbers and e-mail address
■Pack unit in a suitable container for shipment, preferably the
original packaging if available. All Heat Exchangers must
be returned in an upright position properly secured to a
pallet. Improper packaging may void warranty claim. If
a Heat Exchanger is received laying down or shipped via
UPS or similar small parcel service the warranty will be void.
■Mark carton prominently with KOOLTRONIC’s Return
Authorization Number.
■Enclose all pertinent documents.
■Freight charges on all products returned to KOOLTRONIC
shall be paid by the customer. Unauthorized collect shipments
will be refused.
■If a unit is repaired under Warranty, KOOLTRONIC will pay
the freight charges both ways within the Continental USA
at KOOLTRONIC’s negotiated rates. Warranty repaired
units will be returned to customer at KOOLTRONIC expense
only within the Continental USA.
■All authorized returns are subject to a restocking fee.
KOOLTRONIC assumes no liability beyond the repair or
replacement of its own product. This Warranty does not
cover:
■Labor or reimbursement of labor for evaluation, removal,
installation, repair, or cost of any warranted part, unless
authorized in writing by KOOLTRONIC
■Use of equipment for other than its designed purpose or
operating conditions
■Operation in harsh, oily, corrosive or other abnormal
environmental conditions, without the proper filtration,
sealing, protective coatings and/or weather protection
■Damage to hermetic system resulting from continuous
operation with dirty or clogged air filters or improper or
negligent maintenance
■Use of refrigerant other than designated
■Customer modification or abuse
■Shipping damage or other accident (Claims for shipping
damage are the responsibility of the customer. Timely
claims must be filed by the customer with the freight carrier)
■Cracked or broken hermetic tubing, brazed joints or other
internal damage caused by shipping or mishandling
■Damage caused by shipping units attached to an
enclosure
■Any and all conditions resulting from noncompliance with
the preceding operating conditions
■Returned freight must be paid by customer
■This standard warranty does not apply to custom
products. Consult your KOOLTRONIC representative
for limitations
7
