Kortex KX EasyBackUp Pro User manual

Kx EasyBackUp Pro
User’s Guide
Version: 1.1
Date: October 4, 2011
KORTEX PSI
91 rue Réaumur
75002 Paris
Tel: [phone]
e-mail: [e-mail]

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
2
Revision History
Version Date Changes
1.0 December 197, 2008 First Release of Kx EasyBackUp Pro User’s Guide
1.1 October, 4 2011 Logo & address update

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
3
Table of Contents
Revision History.......................................................................................................................................................................................... 2
TABLE OF CONTENTS..................................................................................................................................................................... 3
1. PRODUCT OVERVIEW ................................................................................................................................................................ 6
1.1 I NTRODUCTION ............................................................................................................................................................................ 6
1.2 F EATURES ..................................................................................................................................................................................... 7
1.3 P ACKAGE C ONTENTS .................................................................................................................................................................... 7
2. PHYSICAL DESCRIPTION .......................................................................................................................................................... 8
2.1 P ANELS ......................................................................................................................................................................................... 8
2.1.1 Front Panel.......................................................................................................................................................................... 8
2.1.2 Rear Panel........................................................................................................................................................................... 9
2.2 I LLUSTRATION ............................................................................................................................................................................ 10
2.2.1 Front Panels Information .................................................................................................................................................. 10
SIM Card Slot ........................................................................................................................................................................................... 10
LEDs .......................................................................................................................................................................................................... 10
2.2.2 Rear Panel Information..................................................................................................................................................... 10
wifi ANT SMA Connector ........................................................................................................................................................................ 10
3G ANT SMA Connector.......................................................................................................................................................................... 11
Power Supply Connector.......................................................................................................................................................................... 11
WAN Port .................................................................................................................................................................................................. 11
LAN Port ................................................................................................................................................................................................... 11
Reset Button .............................................................................................................................................................................................. 11
2.2.3 LED Description on the Front Panel................................................................................................................................. 12
3. WEB-BASED MANAGEMENT................................................................................................................................................... 13
3.1. B ASIC ......................................................................................................................................................................................... 15
3.1.1 Wizard................................................................................................................................................................................ 15
3.1.2 WAN................................................................................................................................................................................... 15
3.1.2.1 Static WAN Mode........................................................................................................................................................................... 15
3.1.2.2 DHCP WAN Mode ........................................................................................................................................................................ 15
3.1.2.3 PPPoE ............................................................................................................................................................................................ 17
3.1.2.4 PPTP .............................................................................................................................................................................................. 18
3.1.2.5 L2TP .............................................................................................................................................................................................. 19
3.1.3 DIALUP............................................................................................................................................................................. 21
3.1.4 LAN.................................................................................................................................................................................... 25
3.1.5 DHCP ................................................................................................................................................................................ 25

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
4
3.1.6 Wireless.............................................................................................................................................................................. 29
3.2. AD V ANCED HELP .................................................................................................................................................................. 33
3.2.1 Virtual Server...................................................................................................................................................................... 33
3.2.1.1 Add/Edit Virtual Server ................................................................................................................................................................. 33
3.2.1.2 Virtual Servers List ......................................................................................................................................................................... 34
3.2.2 Special Applications .......................................................................................................................................................... 35
3.2.2.1 Add/Edit Special Applications Rule ............................................................................................................................................. 36
3.2.2.2 Special Applications Rules List .................................................................................................................................................... 37
3.2.3 Gaming .............................................................................................................................................................................. 38
3.2.3.1 Add/Edit Game Rule..................................................................................................................................................................... 38
3.2.3.2 Game Rules List ............................................................................................................................................................................ 39
3.2.4 QoS.................................................................................................................................................................................... 40
3.2.4.1 QoS Setup ...................................................................................................................................................................................... 40
3.2.4.2 Add/Edit QoS Rule........................................................................................................................................................................ 41
3.2.4.3 QoS Rules List............................................................................................................................................................................... 42
3.2.5 Routing .............................................................................................................................................................................. 43
3.2.5.1 Add/Edit Route.............................................................................................................................................................................. 43
3.2.5.2 Routes List..................................................................................................................................................................................... 43
3.2.6 Access Control................................................................................................................................................................... 43
3.2.6.1 Enable ............................................................................................................................................................................................ 44
3.2.6.2 Policy Wizard ................................................................................................................................................................................ 44
3.2.6.3 Policy Table.................................................................................................................................................................................... 44
3.2.7 Web Filter .......................................................................................................................................................................... 45
3.2.7.1 Add/Edit Web Site......................................................................................................................................................................... 45
3.2.7.2 Allowed Web Site List ................................................................................................................................................................... 45
3.2.8 MAC Address Filter ........................................................................................................................................................... 46
3.2.8.1 Enable MAC Address Filter......................................................................................................................................................... 46
3.2.8.2 Filter Settings ................................................................................................................................................................................ 46
3.2.8.3 Add/Edit MAC Address................................................................................................................................................................ 46
3.2.8.4 MAC Address List......................................................................................................................................................................... 46
3.2.9 Firewall ............................................................................................................................................................................. 47
3.2.9.1 Enable SPI ..................................................................................................................................................................................... 47
3.2.9.2 Enable DMZ .................................................................................................................................................................................. 47
3.2.9.3 DMZ IP Address............................................................................................................................................................................ 47
3.2.10 Inbound Filter.................................................................................................................................................................. 47
3.2.10.1 Add/Edit Inbound Filter Rule .................................................................................................................................................... 48
3.2.10.2 Inbound Filter Rules List ........................................................................................................................................................... 48
3.2.11 Advanced Wireless ........................................................................................................................................................... 48
3.2.12 Schedules......................................................................................................................................................................... 49
3.2.12.1 Add/Edit Schedule Rule.............................................................................................................................................................. 50

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
5
3.2.12.2 Schedule Rules List ..................................................................................................................................................................... 50
3.2.13 Ping WAN ........................................................................................................................................................................ 51
3.3. TOOLS H ELP .......................................................................................................................................................................... 53
3.3.1 Admin ................................................................................................................................................................................ 53
3.3.2 Time ................................................................................................................................................................................... 54
3.3.2.1 Time Configuration....................................................................................................................................................................... 54
3.3.2.2 Automatic Time Configuration .................................................................................................................................................... 54
3.3.2.3 Set the Date and Time Manually.................................................................................................................................................. 54
3.3.3 Syslog ................................................................................................................................................................................ 55
3.3.3.1 Enable Logging to Syslog Server ................................................................................................................................................. 55
3.3.3.2 Syslog Server IP Address .............................................................................................................................................................. 55
3.3.4 Email ................................................................................................................................................................................. 55
3.3.4.1 Enable ............................................................................................................................................................................................ 55
3.3.4.2 Email Settings................................................................................................................................................................................ 55
3.3.4.3 Email Log When Full or on Schedule.......................................................................................................................................... 56
3.3.5 System................................................................................................................................................................................ 57
3.3.5.1 Reboot the Device.......................................................................................................................................................................... 57
3.3.5.2 Restore all Settings to the Factory Defaults ................................................................................................................................ 57
3.3.5.3 Restore Configuration from File.................................................................................................................................................. 57
3.3.5.4 Save Configuration ....................................................................................................................................................................... 57
3.3.6 Firmware ........................................................................................................................................................................... 57
3.3.6.1 Firmware Information.................................................................................................................................................................. 58
3.3.6.2 Firmware Upgrade........................................................................................................................................................................ 58
3.3.7 Dynamic DNS .................................................................................................................................................................... 59
3.3.7.1 Enable Dynamic DNS ................................................................................................................................................................... 59
3.4. ST A T US HELP .......................................................................................................................................................................... 60
3.4.1 Device Info ........................................................................................................................................................................ 60
3.4.1.1 DHCP Connection......................................................................................................................................................................... 60
3.4.1.2 PPPoE, PPTP, L2TP Connection ................................................................................................................................................. 60
3.4.1.3 BigPond Connection ..................................................................................................................................................................... 60
3.4.1.4 LAN Computers ............................................................................................................................................................................ 61
3.4.2 Wireless.............................................................................................................................................................................. 61
3.4.3 Routing .............................................................................................................................................................................. 61
3.4.4 Logs ................................................................................................................................................................................... 62
3.4.5 Statistics............................................................................................................................................................................. 63
3.4.6 Active Sessions................................................................................................................................................................... 63

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
6
1. Product Overview
1.1 Introduction
Kx EasyBackUp Pro, a 3G/3.5G WiFi Router, with a built-in modem, it has failover function using the
dial-up modem. Not only can it be used as a regular router to connect to ADSL / Cable modem but
also as a PPP router using the dial-up modem to connect to the ISP. The dial-up modem could be
PSTN V.90, GPRS, CDMA, EVDO, 3G / 3.5G HSDPA and Edge modem, etc.
The router will use WAN as the first priority and the dial-up modem as the backup. Once the WAN
port is active, it will switch to WAN and disconnect the dial-up connection. The router will
automatically dial to ISP if WAN is not active and there is data to be transmitted.

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
7
1.2 Features
Automatically backup and restore broad band WAN and Dialup WAN.
As VPN client or pass-through.
1.3 Package Contents
― 1 x Kx EasyBackUp Pro Router
― 1 x CD with Quick Installation Guide and User’s Manual
― 1 x RJ45 Ethernet Cable
― 1 x Power Adapter

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
8
2. Physical Description
The following information contains the physical description of Kx EasyBackUp Pro router. This
includes the functions and the locations of each connector and indicator. This information provides
useful reference when installing the product. Please familiarize yourself with Kx EasyBackUp Pro.
2.1 Panels
2.1.1 Front Panel
For more related description, please refer to the Section 2.2 and Section 2.2.1.
1
2

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
9
2.1.2 Rear Panel
For more detailed description, please refer to the Section 2.2 and Section 2.2.2.
5
6
4
8
7
3

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
10
2.2 Illustration
No. in
Figures
Name on Kx
EasyBackUp Pro Description Remark
1 SIM Card Slot To connect with the internal
modem
Refer to section 2.2.1 for the front
panel information
2 LEDs To display the status of Kx
EasyBackUp Pro
Refer to section 2.2.3 for the LED
description on the front panel
3 Wifi ANT SMA
Connector
To connect with the wifi
antenna
Refer to section 2.2.2 for Real
panel information
4 3G ANT SMA
Connector
To connect with the 3G
antenna
Refer to section 2.2.2 for Real
panel information
5 Power Supply
Connector
To connect with the Kx
EasyBackUp Pro and the
power adapter
Refer to section 2.2.2 for Real
panel information
6 WAN Port For the access of Internet
Refer to section 2.2.2 for Real
panel information
7 LAN1~LAN 4
Network Connectors
To connect to the device and
Ethernet port via RJ45 cable
Refer to section 2.2.2 for Real
panel information
8 Reset Button
To reset the Kx
EasyBackUp Pro to its
factory defaults
Refer to section 2.2.2 for Real
panel information
2.2.1 Front Panels Information
SIM Card Slot
Plug the internal modem.
LEDs
Include the LED of POWER, Dialup status, WLAN (Wireless LAN), WAN 100/10 or Link, LAN 100/10
or Link.
2.2.2 Rear Panel Information
wifi ANT SMA Connector
Support WEP and WPA modes for wireless access.

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
11
3G ANT SMA Connector
Support 3G mode for wireless access.
Power Supply Connector
Plug the power adapter. The specifications of Kx EasyBackUp Pro’s power adapter are as follows:
Input: 100 ~ 240V AC, 50/60Hz
Output: 12V DC / 1.5A
WAN Port
Offer the access of Internet.
LAN Port
Kx EasyBackUp Pro is designed for 10/100Mbps Ethernet networks. Kx EasyBackUp Pro connects
to the network via category 5 cable.
Reset Button
Support the hardware reset function.

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
12
2.2.3 LED Description on the Front Panel
LED Color Status
POWER Green Lit when +12V DC power is on and working.
Dialup status Green
Lit when dialup is connected.
Flash when dialup is connecting at 1Hz rate.
Off when dialup is disconnected.
Flash when any traffic is present.
WLAN(Wireless LAN) Green Lit when device is normal.
Flash when any traffic is present.
WAN 100/10 or Link
WAN 100/10 Green Lit when connection with remote device is 100MHz.
Off when connection with remote device is 10MHz.
WAN Link Green
Lit when connection with remote device is good.
Flash when any traffic is present.
Off when cable connection is not good.
LAN Port 1 to 4 100/10 or Link
LAN 100/10 Green Lit when connection with remote device is 100MHz.
Off when connection with remote device is 10MHz.
LAN Link Green
Lit when connection with remote device is good.
Flash when any traffic is present.
Off when cable connection is not good.

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
13
3. Web-Based Management
This chapter instructs you how to configure and manage the Kx EasyBackUp Pro through the web
user interface it supports. With this facility, you can easily access and monitor through any one LAN
port of the Kx EasyBackUp Pro router.
After Kx EasyBackUp Pro has been connected to your PC via RJ45 network cable, type
http://192.168.8.1 in IE browser, it will show the following screen and ask you to input the user name
and password in order to login and access authentication. The default user name is “admin” or
“user”, and the password is blank. With the former user name to login, the user is able to fully
access and configure the system. As to the latter, the user merely owns the right to read the system.
For the first time to use, please enter the default user name and keep the password blank, then click
the Log In button. The setup page for Kx EasyBackUp Pro will be displayed once the login process
is successful.

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
14
In the router, it supports a simple user management function to configure the system. As the figure
below shows, for example, left section is the whole list of sub functions while each of main functions,
including BASIC, ADVANCED, TOOLS, STATUS AND HELP is selected.

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
15
3.1. Basic
3.1.1 Wizard
Internet Connection Setup Wizard:
This wizard guides you through the following basic router setup steps:
Set your Password
Select your Time Zone
Configure your Internet Connection
3.1.2 WAN
The WAN (Wide Area Network) section is where you configure your Internet connection type.
There are several connection types to choose from: Static IP, DHCP, PPPoE, PPTP, L2TP, and
BigPond. If you are unsure of your connection method, please contact your Internet Service
Provider. Note: If using the PPPoE option, you will need to ensure that any PPPoE client software
on your computers is removed or disabled.
3.1.2.1 Static WAN Mode
Used when your ISP provides you a set IP address that does not change. The IP information is
manually entered in your IP configuration settings. You must enter the IP address, Subnet Mask,
Gateway, Primary DNS Server, and Secondary DNS Server. Your ISP provides you with all of this
information.
3.1.2.2 DHCP WAN Mode
A method of connection where the ISP assigns your IP address when your router requests one from
the ISP's server. Some ISP's require you to make some settings on your side before your router can
connect to the Internet.
Host Name: Some ISP's may check your computer's Host Name. The Host Name identifies
your system to the ISP's server. This way they know your computer is eligible to receive an IP
address. In other words, they know that you are paying for their service.

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
16
Use Unicasting: This option is normally turned off, and should remain off as long as the
WAN-side DHCP server correctly provides an IP address to the router. However, if the router
cannot obtain an IP address from the DHCP server, the DHCP server may be one that works
better with unicast responses. In this case, turn the unicasting option on, and observe whether
the router can obtain an IP address. In this mode, the router accepts unicast responses from
the DHCP server instead of broadcast responses.
Enable BigPond: Check this option to connect to the Internet through Telstra BigPond Cable
Broadband in Australia. Telstra BigPond provides the values for BigPond Server, BigPond
User Id, and BigPond Password.

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
17
3.1.2.3 PPPoE
Select this option if your ISP requires you to use a PPPoE (Point to Point Protocol over Ethernet)
connection. DSL providers typically use this option. This method of connection requires you
to enter a Username and Password (provided by your Internet Service Provider) to gain
access to the Internet.
Dynamic IP: If your ISP has assigned a fixed IP address, select this option. The ISP provides
the value for the IP Address.
Static IP: If the ISP's servers assign the router's IP addressing upon establishing a
connection, select this option.
Service Name: Some ISP's may require that you enter a Service Name. Only enter a Service
Name if your ISP requires one.
Reconnect Mode: Typically connections are not always on. The KORTEX PSI router allows
you to set the reconnection mode. The settings are:
Always on: A connection to the Internet is always maintained.
On demand: A connection to the Internet is made as needed.
Manual: You have to open up the web-based management interface and click the
Connect button manually any time that you wish to connect to the
Internet.
Maximum Idle Time: Time interval the machine can be idle before the PPPoE connection is
disconnected. The Maximum Idle Time value is only used for the "On demand" connection
mode.

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
18
3.1.2.4 PPTP
PPTP (Point to Point Tunneling Protocol) uses a virtual private network to connect to your ISP. This
method of connection is primarily used in Europe. This method of connection requires you to
enter a Username and Password (provided by your Internet Service Provider) to gain access to
the Internet.
Dynamic IP: If your ISP has assigned a fixed IP address, select this option. The ISP provides
the values for the following fields: PPTP IP Address, PPTP Subnet Mask, and PPTP Gateway
IP Address.
Static IP: If the ISP's servers assign the router's IP addressing upon establishing a connection,
select this option.
PPTP Server IP Address: The ISP provides this parameter, if necessary. The value may be the
same as the Gateway IP Address.
Reconnect Mode: Typically PPTP connections are not always on. The KORTEX PSI router
allows you to set the reconnection mode. The settings are:
Always on: A connection to the Internet is always maintained.
On demand: A connection to the Internet is made as needed.
Manual: You have to open up the web-based management interface and click
the Connect button manually any time that you wish to connect to the
Internet.
Maximum Idle Time: Time interval the machine can be idle before the PPTP connection is
disconnected. The Maximum Idle Time value is only used for the "On demand" connection
mode.

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
19
3.1.2.5 L2TP
L2TP (Layer Two Tunneling Protocol) uses a virtual private network to connect to your ISP. This
method of connection requires you to enter a Username and Password (provided by your Internet
Service Provider) to gain access to the Internet.
Dynamic IP: If your ISP has assigned a fixed IP address, select this option. The ISP provides the
values for the following fields: L2TP IP Address, L2TP Subnet Mask, and L2TP Gateway IP
Address.
Static IP: If the ISP's servers assign the router's IP addressing upon establishing a connection,
select this option.
L2TP Server IP Address: The ISP provides this parameter, if necessary. The value may be the
same as the Gateway IP Address.
Reconnect Mode: Typically L2TP connections are not always on. The KORTEX PSI router
allows you to set the reconnection mode. The settings are:
Always on: A connection to the Internet is always maintained.
On demand: A connection to the Internet is made as needed.
Manual: You have to open up the web-based management interface and click the
Connect button manually any time that you wish to connect to the
Internet.
Maximum Idle Time: Time interval the machine can be idle before the L2TP connection is
disconnected. The Maximum Idle Time value is only used for the "On demand" connection
mode.
Use These DNS Servers: This option should be enabled if your ISP requires you to enter the
DNS Server information. You will then be able to enter a primary and secondary DNS server.
Advanced >>: These options apply to all WAN modes.
Use the default MTU: If this option is checked (the default case), the router selects the
usual MTU settings for the type of WAN interface in use. If this option is unchecked, the
router uses the value of the MTU option (which follows).

http://www.kortex-psi.fr
Kx EasyBackUp Pro User’s Guide
Copyright © KORTEX PSI 2011
20
MTU: The Maximum Transmission Unit (MTU) is a parameter that determines the largest
packet size (in bytes) that the router will send to the WAN. If LAN devices send larger
packets, the router will break them into smaller packets. Ideally, you should set this to
match the MTU of the connection to your ISP. Typical values are 1500 bytes for an
Ethernet connection and 1492 bytes for a PPPoE connection. If the router's MTU is set
too high, packets will be fragmented downstream. If the router's MTU is set too low, the
router will fragment packets unnecessarily and in extreme cases may be unable to
establish some connections. In either case, network performance can suffer.
WAN Port Speed: Normally, this is set to "auto". If you have trouble connecting to the
WAN, try the other settings.
Respond to WAN Ping: If you leave this option unchecked, you are causing the public
WAN IP address of the router not to respond to ping commands. Pinging public WAN IP
addresses is a common method used by hackers to test whether your WAN IP address is
valid.
WAN Ping Inbound Filter: Select a filter that controls access as needed for WAN pings.
If you do not see the filter you need in the list of filters, go to the Advanced -> Inbound
Filter screen and create a new filter.
MAC Cloning Enabled: Some ISP's may check your computer's MAC address. Each
networking device has its own unique MAC address defined by the hardware
manufacturer. Some ISP's record the MAC address of the network adapter in the
computer or router used to initially connect to their service. The ISP will then only grant
Internet access to requests from a computer or router with this particular MAC address.
Your new KORTEX PSI router has a different MAC address than the computer or router
that initially connected to the ISP. To resolve this problem, the KORTEX PSI router has a
special feature that allows you to clone (that is, replace the router's MAC address with)
another MAC address.
MAC Address: If you have enabled MAC Cloning, you can either type in
an alternate MAC address (for example, the MAC address of the router initially
connected to the ISP) or copy the MAC address of a PC. To copy the MAC address of the
computer that initially connected to the ISP, connect to the KORTEX PSI router using that
computer and click the Clone Your PC’s MAC Address button. The WAN port will then
use the MAC address of the network adapter in your computer.
