Automatic fireplace on pellets
<<EKO-LINE>>
INSTALLATION, USE
AND MAINTENANCE

USER MANUAL
www.kovan.ba
2
4 •1. EC statement of compliancy
5 •2. Warranty
6 •3. General warnings
7 •3.1. Basic safety rules
8 •4. Instructions for safe work
8 •4.1. Explanation of signs
9 •4.2. In case of fuel gass smell appearance
10 •4.3. Transfer to another type of fuel
10 •4.4 Maintenance
10 •4.5. Combustion air/air in the premise
11 •5. Information about the fireplace
11 •5.1. Quality statement
12 •5.2. Fireplace type
12 •5.3. Technical information
13 •5.4. Fireplace description
14 •5.5. Applied regulations
15 •5.6. Scope of delivery
15 •6. Fireplace installation
15 •6.1. Important instructions
16 •6.2. Selection of the mounting location
16 •6.3. Chimney connection
17 •6.4. Preparing for installation
17 •6.5. Electrical connection
20 •6.6. Putting into operation
21 •7. Configuration of the fireplace
21 •7.1. Function description

USER MANUAL
www.kovan.ba
3
22 •7.2. Ignition of the fireplace
26 •7.3. Regulation
27 •7.4. Other functions
27 •7.4.1. Hysteresis
27 •7.4.2. Cleaning period
28 •7.4.3. Cleaning duration
28 •7.4.4. Language
29 •7.4.5. Input - phone
29 •7.4.6. Clock
30 •7.4.7. Timer
31 •8. Cleaning and maintenance
32 •8.1. Cleaning of metal components
33 •8.2 Cleaning of outer mantle
33 •8.3. Cleaning of the furnace
34 •8.4. Cleaning of the glass
34 •8.5. Exchange of door glass
34 •8.6. Annual maintenance/cleaning
35 •8.7. Period when the fireplace is not in use
36 •9. Device errors
36 •9.1. Smoke pipe system error
36 •9.2. Error of motor for pellet input
36 •9.3. Activation error
36 •9.4. Break in supply of electrical energy
37 •10. List of disorders, their causes and instructions for elimination
42 •11. Instructions for quality evaluation of pellets during the purchase

USER MANUAL
www.kovan.ba
4
1. EC statement of compliancy
In accordance with following guidelines:
The European directive 73/23 EEZ and later amendments
93/68, 89/336 EEC and later amendments 92/31 EEC, 93/97
EEC
„KOVAN“M.I. - ul. Branilaca grada bb, 75320 Gračanica,
under our sole liability, we state that the series of Ekoline
fireplaces has been designed and constructed as required by
safety standards for the CE mark.
Dear user!
Thank you for choosing our "Eko-Line" fireplace. A modern,
quality and highly efficient product which ensures the largest
comfort of heating, on a long period of time by its reliability
and safety.
The maintenance is simple and it can be performed
personally and easily, as well as it can be confide to Technical
service of manufacturer „Kovan", whose servicemen are
trained for the maintenance of fireplaces and if necessary,
they have all the needed spare parts for the fireplace.
This manual contains important information and
recommendations which are needed to comply with, in order
to execute simple installation and to properly use the
fireplace for a long time.
Manager Ltd. «Kovan» M.I. Gračanica

USER MANUAL
www.kovan.ba
5
2. Warranty
Our «Eko-line» fireplaces hold a SPECIFIC WARRANTY
approved by the manufacturer Ltd. «Kovan» M.I. Gračanica.
The manufacturer and the distributor guarantee that the
product will function correctly in the warranty period at the
normal use subject to compliance of this Manual and
conditions of warranty.
The warranty is a part of this product, and its value is
conditional by readable and filling up true data in it.
We recommend you to confide putting the fireplace into
operation to a professionally trained individual or contact our
Technical Service «Kovan» who will on your request put the
boiler into operation in manner that is specified by this
manual.
Obligatorily before undertaking any activities on the fireplace,
carefully study this manual and read the condition from the
warranty.

USER MANUAL
www.kovan.ba
6
3. General warnings
You should study this Manual carefully to familiarize
yourselves with the correct installation, handling, use and the
maintenance of the fireplace.
This product is delivered in one package, ensured from
fracture in accordance with the regulations, and in the case
that contents do not match the order, please address to
department of « Kovan » that sold you the fireplace or to
your distributor.
All local regulations, including national and European
standards must be followed while installing the device.
The fireplace must be only intended for use and purpose
which is specified by the manufacturer and for which it has
been constructed. « Kovan » m.i. excludes any liability
contractual or non contractual for the incurred damage to
people, animals or objects due to errors at the installation,
regulation and the maintenance and due to the inadequate
use.
Maintenance of the boiler must be performed at least once
an year.
This manual is an integrated part of the fireplace and needs
to be kept carefully. It should be enclosed beside the fireplace
even when the fireplace is given to a second owner or being
transported on an other installation. If damaged or lost,
request a new one from the Technical service «Kovan» m.i.

USER MANUAL
www.kovan.ba
7
3.1.Basic safety rules
Use of products which use fuels, electricity and water,
request that we comply with some safety rules:
Children, irresponsible and inexpert persons are
prohibited of operating the fireplace.
If felt smell of combustible substances in the
accommodation room, air out the space by opening
the door and windows, stop the work of the fireplace
and request help of a qualified professional person or
Technical services «Kovan» m.i.
The fireplace is an electric device and in accordance
with that it is prohibited to touch it barefooted or
with wet body parts
It is prohibited to interven or to clean the fireplace
while it is plugged into electrical supply or before it
has been shut off by setting the selector of functions
on “off”.
It is prohibited to adjust the fireplace safety
appliances or regulators without instructions and
permits from the manufacturer
It is prohibited to drag, disconnect and touch
electrical wirings even when the fireplace is
disconnected from electrical supply
It is prohibited to hold flammable materials in the
same room with the fireplace. Do not use or leave
easily flammable materials nearby the (fluent fuels,
dissolver, colors, etc.)

USER MANUAL
www.kovan.ba
8
4. Instructions for safe work
4.1. Explanation of signs
Words (Caution, Warning, and Danger) mark the importance
of danger which could appear if measures for the damage
mitigating would not be respected.
Caution indicates that minor material damages can
appear
Warning means that minor injuries or heavy material
damage can appear
Danger means that severe injuries can emerge. In
particularly severe cases exists danger for life
Remarks contain important information in cases when there
is no threat of any danger for the man or the boiler.
Instructions for safe work are marked
with a warning triangle
Remarks in the text are marked with a
sign like this one

USER MANUAL
www.kovan.ba
9
4.2. In case of fuel gas smell appearance
Turn off the fireplace
Open windows and doors
Seek instructions or help from a qualified person or
your serviceman
In case that the chimney has caught fire (which can be
diagnosed by some of the following ways: visually - there can
be seen glittering sparks or flame on the upper output side of
the chimney, by hearing –muffled roar, blare or rumble
inside the chimney, and by touching only if it is possible
because of a danger of burn –unusually high temperature of
the chimney flue) stop the fireplace operation. All openings
on the fireplace (burner's door) must be closed and sealed.
Possible additional openings on the chimney (door for
cleaning and possible spare openings) should also be closed
and made sure they will not self-open because of the
increased pressure of the gases in the chimney. During
burning and later after self quenching and cooling the
chimney should be constantly monitored and all noticed
critical spots should be controlled. It is strictly forbidden to
cool the chimney directly by water in order to put it out since
by doing that we will certainly cause a chimney explosion and
fire in the building. It is allowed, in case of need, to cool
endangered objects in the vicinity of the burning chimney if
you think that they can be caught by fire. Beside all these
safety measures you should also inform a fireman on duty of
the competent fire station by dialling number 123.

USER MANUAL
www.kovan.ba
10
4.3. Transfer to another type of fuel
Installment of additional devices and using other type of fuel
is not allowed as well as any kind of changes or alternations
on the fireplace itself.
4.4. Maintenance
The user is responsible for the safety and the environmental
acceptability of the installation.
Use only original spare parts recommended by the
manufacturer!
4.5. Combustion air/air in the premise
Do not close nor reduce the air hole and ventilation. If the
premise has airtight windows, ensure the supplying of
combustion air.
Combustion air / air in the premise maintain without
aggressive substances (e.g. halogenic hydrocarbons which
contains compounds of chlorines or fluorines). In that manner
you will avoid corrosion.

USER MANUAL
www.kovan.ba
11
5. Information about the fireplace
5.1. Quality statement
The construction of the fireplace is in accordance with the
European Directive CEE 73/23 and amendments 93/68 CEE,
CEE 89/336 and amendments 93/68 CEE; 92/31CEE; 93/97
CEE and European norms. Our product complies with the
standards of burning tests, electric tests in accordance with
the standards EN 60335 and EN 60366.
All necessary mechanical tests in conjunction with the
materials of which the fireplaces were built, were carried out
in a specialized laboratory for testing materials and structures
- "Rudarski institut” d.d. – Tuzla.
About all this we have the correct documentation and quality
reports.
Ensuring product quality guarantees our implementation of
the approved quality system for production, final inspection
and testing TÜV cert 15 100 7505 4 in accordance with the
reference standard EN 9001:2000.
Within the approved quality system, every boiler is checked
and carried out to appropriate tests. Our production is also
under the regular supervision of the control house, which has
conducted the tests.

USER MANUAL
www.kovan.ba
12
5.2. Fireplace type
EKO-1-7.5
7,5 kW
Explanation of simbols:
EKO –ecological fireplace (fulfills all requirements of
European Directives)
1 –number of production version
7.5 –heating power
5.3. Technical information
Parameters
MU
7,5 kW
Fireplace type
-
EKO-1-7.5
Width, depth, height
cm
75/59/131
Weight
kg
105
Tube / air entrance
mm
60
Tube / fume exit
mm
80
Heating capacity
m2
70
Operation autonomy
sat
10
Nominal thermal power
kW
7,5
Fuel type
Wood pellet 6mm
Fuel consumption (min/max)
kg/sat
0,75-2,4
Percentage of efficiency
%
90
Storage capacity
kg
16
Consumption of electrical energy
W
60
Voltage
V/Hz/faza
AC 230/50/1
Driving voltage
V
DC 12
Installed power
W
450
Colour options
Yellow, beige, red, gray, white

USER MANUAL
www.kovan.ba
13
5.4. Fireplace description
The fireplace is constructed so as to operate with pellet. The
construction of the fireplace is made of steel, carried out by
plate welding. It consists of an inner ardent and outer
protective mantle, a circuit of the torch and pellet storage.
The ardent mantle is made of cooper plates 4 /W4/HII / DIN
17155.
The fireplace is equipped with a ventilator for equal
distribution of warm air, with the fluidity of ca 60m3/h. In this
way the warmth is equally distributed in the room where the
fireplace is installed.
The motion of flue gases from the torch rises up in the space
chamber where they cool down exchanging the temperature
with the mantle, and then pressed by another wave of flue
gas move to another space: exchange chamber. The mantle of
the chamber is a barrier around which the flue gases move,
exchanging their temperature, which is at the other side
taken by the ventilator and spread around the room. This
enables the warmth to be most efficiently used before it is
vacuumed into the funnel.
The furnace is constructed as a compact module. An electric
heater is used as an igniter that turns on and off
automatically. The heater is placed close to the electric
turbine. Controlled air supply is carried out by the electric
turbine by regulating the number of rotations of the turbine.
The supply of electrical energy is in accordance with all safety
regulations. The device is supplied with electrical energy per
plug device, that is in the case of fireplace supplied over a
inseparable cable (directly connected to voltage) per breaker.

USER MANUAL
www.kovan.ba
14
The conductor wire is ensured with a protective cable,
sections 3x1.5mm2.
All components of the fireplace that are exposed to high
temperatures are protected with fire proofed colors that
resist temperatures up to 700 degrees of Celsius. All other
parts are protected with an anticorrosive color in two
mantles. The outer mantle is protected with plastificaition.
There is no emission of gases into the room the fireplace is
placed in.
5.5. Applied regulations
During designing and construction of the fireplace, following
directives and regulations are applied:
Construction of the fireplace is harmonized in
compliance with European directives 98/37/EC,
97/23/EC and European standards EN 292-1:1991, EN
292-2:1991, EN 12952-2, EN 12952-3, EN 12952-4, EN
12952-5, EN 60335-2
BS EN 292-1:1991 - Safety of machinery. Basic concepts,
general principles for design. Basic terminology, methodology
BS EN 292-2:1991 - Safety of machinery. Basic concepts,
general principles for design. Tech. principles and
specifications
BS EN 60335-2-88:2002 - Specification for safety of household
and similar electrical appliances. Particular requirements.
Particular requirements for humidifiers intended for use with
heating, ventilation, or air-conditioning systems

USER MANUAL
www.kovan.ba
15
5.6. Scope of delivery
Fireplace
Instructions for handling and use
Warranty card
5. Fireplace installation
6.1. Important instructions
Before the first commissioning, carefully study the technical
manual. For possibly not understanding the instructions, and
other uncertainties contact a qualified service person or the
manufacturer.
Make sure that the pellets you are using have the required
quality standards.
It is strictly prohibited burning and incineration of waste and
any other combustible materials in the fireplace.
It is strictly forbidden to add fuel in liquid form.
Never open the door while the fireplace is in operation.
During the operation the glass and other parts become hot.
Note: Installation, connection to voltage
and activation should be done after
reading the user manual

USER MANUAL
www.kovan.ba
16
6.2. Selection of the mounting location
It is recommended to install the fireplace into a big centred
room in the house in order to ensure equal distribution of
warm air.
It is important to ensure enough air in the fireplaces room.
Before you install the fireplace into an apartment or flat, ask
for the approval of the authorised official first.
It is important to move any flammable materials, such as
wood furniture, carpets and liquids at least one meter away
from the fireplace.
The fireplace should be placed on a flat and incombustible
surface.
You should leave the installation to a competent person.
While setting and installing the device it is important to
follow certain standards and international norms. In cases
when rules or regulations collide, please follow the national
norms.
Safe and economic operation of the fireplace will be ensured
if the installer follows the given instructions and regulations.
6.3. Chimney connection
The complex effects of the chimney to the fireplace are
eliminated by a fan, installed at the exit of the fireplace as its
integral part. Controlling the number of revelations of the fan
there’s always achieved the needed Vacuum to overcome
resistance in the flues and to realize the need Vacuum in the

USER MANUAL
www.kovan.ba
17
burner. Before letting the fireplace in operation, check the
patency of the chimney, flue pipe, as well as any devices for
protection from the wind.
6.4. Preparing for installation
The fireplace is supplied wrapped in protective foil. Beneath
the sheet, on top of the fireplace, you can find the
corresponding instructions and the guarantee card.
Place the fireplace on the planned installation location.
Connect the fireplace to the chimney so that there’s allowed
a slight drop to the fireplace or a horizontal position.
Connect the fireplace to electrical supply.
6.5. Electrical connection
DANGER OF ELECTRIC STRIKE
Before work on electrical parts, the
boiler must always be turned off from
the electrc power supply by physical
separation of the socket device from the
source of electric power

USER MANUAL
www.kovan.ba
18
All regulatory, controlling and safety appliances of boiler have
been wired and tested in the factory.
On an accessible place of the boiler ensure a connecting place
with a 1-phase outlet.
The place of the outlet should be properly selected so that
the socket device is always easily accessible.
Danger: In case of damage to the power
cable it is necessary to replace it with a
correct cable. Cable replacement should
be delegated to a competent person or
to the producers service.

USER MANUAL
www.kovan.ba
19
Electric circuits of the fireplace are secured by an electric
safety fuse with a melting string of 2A. In case of fuse failure,
a professional qualified person needs to check the causes and
then carries out the fuse replacement with genuine fuse for
the same nominal electricity. Improvisation and „ patching “of
the fuse is strictly forbidden.
Note:
Electrical connection must
match the current regulations
for electrical installations in
households
You must have a protective
conductor
In the case of a direct power
cable connect, it is necessary to
install a switching device that
provides a reliable turning off of
the fireplace. The distance
between the contacts of the
device should allow the
exclusion of the overvoltage
category III conditions, in
accordance with the norms
Installation

USER MANUAL
www.kovan.ba
20
Electric switch on/switch off the boiler
Switching on: Switch on the fireplace by plugging the
electrical cable into an accessible 1-phase outlet on the wall.
The illuminated display shows that the fireplace is under
voltage. Wait for a few seconds that the system needs to set
up. Afterwards, by the function keys you pass through the
access menu and perform any necessary adjustments.
Switching off: By pressing the button for switching off, the
fireplace goes in the switcing off process. That is the
procedure which, depending on the fireplaces working mode
lasts for a few minutes. After the switcing off process, when
displaying OFF on the display, the fireplace can also be
physicall separated from the electrical power source.
6.6. Putting into operation
Check if the type of pellet described in this manual matches
the type of pellet in your storage. The storage can be filled to
the top with pellet. Refill the storage with pellet when
needed.
Ignition and heating
The fireplace needs to be cleaned of ash and slug.
If an additional temperature regulator has been installed set
the wanted room temperature. All customers who have an
additional temperature regulator should activate it in the
fireplaces menu.
