Installation Instructions
MODEL:
VS-1616D
VGA and Analog Audio Card
P/N:
2900-301406
Rev:
5
SAFETY WARNING
Disconnect the unit from the power supply before opening andservicing
For the latest information on our products and a list of Kramer distributors, visit our Web site where
updates to this user manual may be found.
We welcome your questions, comments, and feedback.
www.KramerAV.com
[e-mail]

Kramer Electronics Ltd.
VS-1616D –VGA and Analog Audio Card
2
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
The VS-1616D VGA and Analog Audio Card mounts in one of the 16 slots on the rear of the
VS-1616D chassis. Slots are numbered from left to right. Audio output is accessed by
connecting the two supplied Kramer C-GF/GMAF-30 cables to each VGA port.
WARNING: An input card must only be mounted in a slot designated for input cards (slots 1
to 4 and 9 to 12) and an output card must only be mounted in a slot designated for output
cards (slots 5 to 8 and 13 to 16).
Installing I/O Card
1. Power off the VS-1616D and all devices
connected to it.
2. Using a Phillips screwdriver, loosen the screws
at the top and bottom of the blanking plate.
3. Remove the blanking plate from the slot and
store it for possible future use.
4. Remove the new card from its shipping box and
anti-ESD bag.
5. Holding the card by the lower handle, align the
card with the plastic guide rails.
6. Slide the card into the chassis until the front of
the card makes contact with the connector
inside the chassis.
7. Press the card firmly into the slot until the
connector plate is flush with the rear panel of
the chassis and the connector is fully seated.
8. Using a Phillips screwdriver, tighten the
retaining screws at the top and bottom of the
card to secure it to the chassis.
9. Power on the VS-1616D and follow the
procedure in the VS-1616D User Manual (see
Section 9) to configure the new card.
10.Power on the peripheral devices.
For optimal performance, use the recommended Kramer cables available at
www.kramerav.com/product/VS-1616D.
Using third-party cables may cause damage!
