Kramer PT-872xr User manual

PT-872xr Quick Start (P/N: 2900-301005QS REV 1)
P/N:
2900- 301005QS
Rev:
1
Scan for full manual
PT-872xr Quick Start Guide
This guide helps you install and use your PT-872xr for the first time.
Go to www.kramerav.com/downloads/PT-872xr to download the latest user manual and check if
firmware upgrades are available.
Step 1: Check what’s in the box
PT-872xr HDMI 4K Line Receiver
4 Rubber feet
1 Quick start guide
1 Power adapter and cord
1 Bracket set
Step 2: Get to know your PT-872xr
#
Feature
Function
1
LED Indicators
IN
Lights when an active source is connected to HDMI IN on the WP-871xr.
2
OUT
Lights when an active acceptor is connected to HDMI OUT on the PT-872xr.
3
ON
Lights when power is connected to the device.
4
HDMI OUT Connector
Connect to an HDMI acceptor.
5
SETUP DIP-switches
Set the operation DIP-switches. Both DIP-switches are set to OFF (up) by default.
Always set the DIP-switches identically on transmitter and receiver devices.
DIP-switch 1:
Compression Options
OFF (up) –Standard compression level.
ON (down) –High compression level for additional range extension.
DIP-switch 2:
Compression Setup
OFF (up) –Enable compression (mandatory).
ON (down) –For future use.
6
DGKAT2 IN RJ-45 Connector
Connect to the DGKat-2.0 OUT connector on the WP-871xr using twisted pair cable.
7
12V DC Connector
Connect the power adapter to the device.
Step 3: Install the PT-872xr
Install PT-872xr using one of the following methods:
•Attach the rubber feet and place the unit on a flat surface.
•Fasten a bracket (included) on each side of the unit and attach it to a flat surface. For
more information go to www.kramerav.com/downloads/PT-872xr.
•Mount the unit in a rack using an optional RK-4PT rack adapter.
Step 4: Connect the inputs and outputs
Always switch OFF the power on each device before connecting it to your PT-872xr. For best results, we recommend that you
always use Kramer high-performance cables to connect AV equipment to the PT-872xr.

We highly recommend using only Kramer UNIKAT cables with these products. If using 3rd party shielded CAT-6A cables,
both ends of the shield must be soldered to the connectors for the products to function properly. Do not use any jumpers,
unshielded wall plates or mid-span cable connections. These extenders are not compatible with HDBaseT technologies.
Prior to signal extension, ensure that the extension line cable is lying straight and not coiled.
Step 5: Connect the power
Connect the 12V power adapter to the PT-872xr and plug it into the mains electricity. This device provides power to its counterpart
via DGKat 2.0. Each device can provide or accept power over cable (PoC) via DGKat 2.0.
Safety Instructions
Caution:
There are no operator serviceable parts inside the unit.
Warning:
Use only the Kramer Electronics power supply that is provided with the unit.
Warning:
Disconnect the power and unplug the unit from the wall before installing.
See www.KramerAV.com for updated safety information.
Technical Specifications
Inputs
1 DGKAT 2.0
On a female RJ-45 connector
Outputs
1 HDMI
On a female HDMI connector
Video
Transmitted Data Bandwidth
Up to 18Gbps (6Gbps per graphic channel)
Max Resolution
3840x2160@60Hz (4:4:4) 24bpp at high compression level
4096x2160@60Hz (4:4:4) 24bpp at standard compression level
Compliance
HDMI 2.0, HDCP 2.2, HDR 10
Reach Extension
We recommend that you use Kramer shielded cables to achieve optimum extension ranges.
Standard Compression Level
Up to 40m (130ft) at 4K@60Hz (4:4:4)
Up to 70m (230ft) at 4K@60Hz (4:2:0) or full HD (1080p @60Hz 36bpp)
High Compression Level
Up to 60m (200ft) at 4K@60Hz (4:4:4)
Up to 70m (230ft) at 4K@60Hz (4:2:0) or full HD (1080p @60Hz 36bpp)
Controls
Front Panel
IN, OUT and ON LEDs
Rear Panel
DIP-switches
Power
Consumption
12V DC, 600mA when coupled with a compatible transmitter
Source
12V DC, 2A
Environmental
Conditions
Operating Temperature
0° to +40°C (32° to 104°F)
Storage Temperature
-40° to +70°C (-40° to 158°F)
Humidity
10% to 90%, RHL non-condensing
Regulatory
Compliance
Safety
CE, UL
Environmental
RoHs, WEEE
Enclosure
Size
Pico Tool
Net Dimensions (W, D, H)
6.2cm x 5.2cm x 2.5cm (2.4" x 2.05" x 1")
Shipping Dimensions (W, D, H)
15.7cm x 12cm x 8.7cm (6.2" x 4.7" x 3.4")
Net Weight
0.1kg (0.2lbs)
Shipping Weight
0.52kg (1.2lbs) approx.
Type
Aluminum
Cooling
Convection ventilation
Accessories
Included
1 Power adapter, 1 power cord
Specifications are subject to change without notice at www.kramerav.com
