Kronoterm WPLV-09-S1 NT User manual

Installation manual
For the Air-Water Heat Pump
WPLV-09-S1 NT
WPLV-14-S1 NT
The manual has to be handed over to the end user after installation.
ENG
Id.: 17-16-24-3006-03 | 12.2016

©Termo-tehnika, d.o.o.
2
ID.: 17-16-24-3006-03 | 12.2016
Installation manual for the air-water heat pump with inverter
WPLV-09-S1 NT; WPLV-14-S1 NT
Id: 17-16-24-3006-03 | 12.2016
Printed in Slovenia, copyright: Termo-tehnika, d.o.o.
This document is copyrighted. Any use outside the provisions of the copyright law without the
permission of Termo-tehnika, d.o.o. is illegal and punishable by law. All previous versions of this
document are void. We reserve the right to make changes and mistakes in print.

©Termo-tehnika, d.o.o.
ID.: 17-16-24-3006-03 | 12.2016 3
1. Important information 5
1.1 Symbols 5
1.2 General 6
1.3 Safety warnings and instructions 6
1.4 Obligations of the manufacturer 9
1.5 Obligations of the installer during installation 9
1.6 Obligations of the authorised contractor for commissioning at first commission. 9
1.7 Obligations of the user 9
1.8 Factory testing 10
2. Transport and installation of the device 10
2.1 Transport 10
2.2 Installation of the device 10
2.3 Storing and warehousing of the device 10
3. Delivery package 11
3.1 The delivery package includes 11
3.2 Internal device 11
3.3 Package and worn-out device management 11
4. Installation of the device 12
4.1 General 12
4.2 Location of the device 15
4.2.1 Set up and connection of the external sensor. 16
4.2.2 Minimal clearance from the device 16
4.2.3 Levelling of the device 17
4.2.4 Removal of side 17
4.2.5 Concrete pedestal 18
4.2.6 Wall penetration for the refrigerant and electro-communication connection 19
4.3 Refrigerant pipe connection of the exterior and interior device 19
4.3.1 Determining the length of the connection pipes 19
4.3.2 Pipe connection protection 21
4.3.3 Preparation of the refrigerant pipe 21
4.3.4 The execution of connecting the pipe-refrigerant connection on the exterior device23
4.3.5 Leak test 25
4.3.6 Vacuuming of the system 26
4.3.7 The release of the refrigerant from the external device into the finished system 26
4.3.8 Condensate drainage 27
4.4 Electrical connection 28
4.5 Removal of the external device cover 29
4.6 Connecting the external unit 29
4.6.1 Power cable connection of the external unit 29
4.6.2 The connection of the plated communication cable to the external unit 31
4.7 Connecting the internal device 32
4.8 Spatial corrector 32
5. Commissioning of the device 32
6. Maintenance 32
6.1 Cleaning of the heat exchanger 33

©Termo-tehnika, d.o.o.
4
ID.: 17-16-24-3006-03 | 12.2016
6.1.1 Cleaning the heat source (air side) 33
6.2 Disturbances in the operation 33
7. Technical data 34
7.1 Dimensions of the device 34
7.2 Technical data 35
7.2.1 External device 35
7.3 Range of operation 37
7.3.1 Heating mode 37
7.3.2 Cooling mode 37
7.4 Noise 38

©Termo-tehnika, d.o.o.
ID.: 17-16-24-3006-03 | 12.2016 5
1. Important information
The manual describes the process of installation and maintenance of the device. The installation and
maintenance can only be performed by qualified personnel. Read the manual carefully before the
installation, this way you will be informed about the intended use, functionality and process of handling
the device.
The manual has to be handed over to the end user after installation.
In case the product shall be given to a third person for use, the manual has to be handed over
to them as well.
Definitions
An informed person is a person who reads this manual.
A qualified person has a certificate of expert qualifications.
An authorised commission contractor is trained by the manufacturer and authorised to perform
commission.
The authorised technician is trained and authorised by the manufacturer to perform
maintenance and servicing of the device.
The user uses the device according to its use.
The installer is a person professionally trained for performing hardware and/or electro-
installation work and mounting of the device.
Incorrect use of the device can lead to damage of the device, property or injury to the user. To reduce
risk the manual points out important information with the use of symbols.
1.1 Symbols
These symbols mark various risks for the user or the device.
DANGER:
Risk of situations which can lead to serious physical injuries.
WARNING: Risk of situations which can lead to minor physical injuries.
CAUTION: Risk of situations which can lead to damage or malfunction of the
device.
This symbol marks information for the user.
NOTE:
A notice which holds important information regarding requirements
of the manufacturer and the device.

©Termo-tehnika, d.o.o.
6
ID.: 17-16-24-3006-03 | 12.2016
1.2 General
NOTE
Read the instructions for use and installation before installation.
NOTE
Any remaking or replacement of original components of the device
eliminates the manufacturer’s guarantee for safe and functional operation. In
the case of undesignated and incorrect use of the device the manufacturer
is not responsible for the consequences and will not acknowledge claims for
damages in these cases. The user is solely responsible for injuries and
damages on the device itself or on other objects resulting from undesignated
and incorrect use of the device.
NOTE
The installation of the device has to be performed in accordance with the
manual; otherwise the manufacturer does not acknowledge the warranty.
DANGER
Failure to comply with the manual and good practise while connecting the
device to the power supply can lead to serious injury or death.
WARNING
Connecting the device to the power source can only be performed by a
qualified installer.
1.3 Safety warnings and instructions
DANGER
It is prohibited to move, shift, clean or service the device while in operation.
WARNING
It is prohibited to play with the device. Children are not allowed to clean the
device without supervision.
WARNING
The device can be operated independently only by informed persons who
are familiar with the safe operation of the device and understand possible
hazards of its operation. Children older than 8 and people with reduced
physical and mental capacities and with lack of experience and knowledge
can only operate the device under the supervision of an informed person.
WARNING
Before installation and any further adjustments to the device, it is necessary
to consider the manual for safe use and maintenance.
WARNING
Installation has to be performed in accordance with national regulations on
electrical installations and with the instructions of the manufacturer. It has
to be performed by a professionally trained person.

©Termo-tehnika, d.o.o.
ID.: 17-16-24-3006-03 | 12.2016 7
WARNING
It has to be made sure that the device does not endanger anybody. Access
to the device has to be denied to children and persons who are not informed
about the operation of the device.
WARNING
The device must never be cleaned with cleaning agents containing sand,
soda, acid or chlorides because these might damage the surface of the
device.
WARNING
The device contains the refrigerant HFC which is classified as a greenhouse
gas according to the Kyoto protocol. This is why tampering with the device
is only allowed to persons authorised for working with the refrigerant as
defined by the national legislation in force. While performing works on the
device, it is necessary to prevent the refrigerant to leak into the atmosphere.
WARNING
It is necessary to consider all technical data and instructions in this manual
as well as all warnings and notes during planning, design, installation and
use of the device.
WARNING
Electrical installations have to be inspected in accordance with regulations
on the requirements for low voltage electrical installations in buildings by
the installer of electrical installations.
DANGER
Connecting the devices power cable must be performed by a qualified
electrician. During the procedure the device must not be live.
WARNING
In case the power cable of the device is damaged it has to be immediately
replaced. The replacement can only be performed by the manufacturer and
authorised maintenance worker.
WARNING
Before opening the device disconnect all electrical circuits and make sure
the device is not live.
CAUTION
Putting any kinds of items on or next to the device is prohibited.
CAUTIO
N
The device must not be placed in a room where it cannot be removed. Later
walling or setting up of other obstacles next to the device is forbidden.

©Termo-tehnika, d.o.o.
8
ID.: 17-16-24-3006-03 | 12.2016
CAUTION
In three-phase versions of the device it is necessary to ensure the correct
arrangement of phases when connecting it to the power supply.
CAUTION
For the correct operation of the device, the electrical distributor has to
provide electricity of adequate quality (SIST EN 50160). In normal
conditions this is within ± 10 % of the rated voltage. The data about the state
of the electrical grid have to be acquired from the electrical distributor.
CAUTION
Connecting the device to the electrical network has to be performed in
accordance with the standards for connecting devices to the electrical
network. Connect the device to the electrical network via the power supply
cut-off which is installed into the electrical installation under the regulations
in force.

©Termo-tehnika, d.o.o.
ID.: 17-16-24-3006-03 | 12.2016 9
1.4 Obligations of the manufacturer
The manufacturer guarantees that the device is in accordance with current European directives and
standards. The device is marked with the mark CE and it has all the necessary documentation.
We reserve the right to make changes to the manual without prior notice.
As manufacturer we do not take responsibility for the consequences arising from:
Non-compliance with the manual for the device.
Incorrect and/or inadequate maintenance of the device.
Non-compliance with the manual for the installation of the device.
1.5 Obligations of the installer during installation
The installer is responsible for installing the device in accordance with the following requirements:
To thoroughly study the instructions for use and installation accompanying the device before
installation.
To install the device in accordance with the instructions and national legislation, policies and
standards in force.
1.6 Obligations of the authorised contractor for commissioning at
first commission.
CAUTION
The first commission can only be performed by the contractor of commissions appointed by
the manufacturer in accordance with the instructions for commission.
The contractor for commissions is responsible for commissioning the device in accordance with the
following requirements:
Performs the first commission and eliminates all eventual irregularities found at the commission.
To train the user for operating the device and settings.
Alerts the user to regularly maintain the device for keeping the device functioning properly
throughout its entire lifespan.
Gives the user all the documentation accompanying the device.
1.7 Obligations of the user
For ensuring unobstructed and effective operation of the device, the user has to follow the following
instructions:
To thoroughly study the instructions for use and installation accompanying the device before
use.
To have a qualified and authorised installer perform the installation of the device.
To have a contractor for commissions perform the commission.
Allow the authorised contractor for commissioning or ask him to thoroughly explain the
functioning and how to operate the device.
Ensure regular yearly inspections and maintenance of the device by the authorised
maintenance worker.
Store this manual in an appropriate dry place close to the device.

©Termo-tehnika, d.o.o.
10
ID.: 17-16-24-3006-03 | 12.2016
1.8 Factory testing
For ensuring the high quality standard every device is tested in production for the following:
Tightness of the cooling cycle,
Electrical safety and
Functionality.
2. Transport and installation of the device
2.1 Transport
CAUTION
The device must be transported with transport devices.
Secure the device during transport to prevent damage.
Transport the device in vertical position.
It is prohibited to tilt the device above 45°. Otherwise, damage to the cooling system
may occur.
It is prohibited to place objects on the device.
2.2 Installation of the device
2.3 Storing and warehousing of the device
The device has to be stored in a dry and clean place. The allowed storing temperature is between 10 °C
and 45 °C, for a short period (up to 24h) also up to 55 °C.
CAUTION
Appropriate transport equipment must be used for installing the device. Safety regulations
and good practise have to be used.

©Termo-tehnika, d.o.o.
ID.: 17-16-24-3006-03 | 12.2016 11
3. Delivery package
3.1 The delivery package includes
The heat pump with separate condenser (device) for external installation (external unit).
WPL-09 S1 NT WPL-14 S1 NT
Installation instructions.
Instructions for use (accompanying the internal unit).
Plugs for plugging the holes of the condensation vessel.
Fitting for attaching the condenser’s drainage pipes.
Rubber support legs (4x).
3.2 Internal device
The internal device is installed depending on the design of the heating system:
Hydro module - see Installation Manual – Hydro Module.
3.3 Package and worn-out device management
Sort the package according to cardboard, wood and foil and dispose of it in appropriate
containers.
After the lifespan of the device ends it has to be disposed of in accordance with the legislation
on waste electrical and electronic devices in force.
Refrigerant
The device holds the HFC refrigerant which is a fluorinated greenhouse gas covered in the Kyoto
protocol. You have to prevent leakage of the gas into the atmosphere. During a maintenance procedure
or removal of the device it has to be made sure that the gas is removed in accordance with the current
regulations on the use of substances harmful to the ozone and fluorinated greenhouse gasses.
STANDARD
LABEL

©Termo-tehnika, d.o.o.
12
ID.: 17-16-24-3006-03 | 12.2016
4. Installation of the device
4.1 General
The device provides a hardware connection with the utility room from three different sides. From the
side, the back and the front. With the installation of V1 and V2 two most common installations are
shown.
INSTALLATION-V1
V1
P1
P11
P4
P7
P5
P13
P10
min
300 mm
P15
P3
P5
P8
P7
P9
P6
D D
E E
C C
P9
P12
P17
P8
P5
P16

©Termo-tehnika, d.o.o.
ID.: 17-16-24-3006-03 | 12.2016 13
INSTALLATION-V2
P9
P3
P5
P8
P10
P7
P9
P6
C C
D D
E E
V2
P1
P11
P4
P7
P5
P12
P13
min
300 mm
P15
P17
P8
P16
C Electrical and communication
connection P7 Communication cable - connection between external and
internal control unit
D Refrigerant (freon) line - for
liquids
P8 An adequate protection hose separate for power /
communication
E Refrigerant (freon) line - for
gas
P9 Heat insulation with appropriate screen (for example ALU
harness)
P1
Heat pump - external device P10
Wall penetrations must be water-proofed and adequately
insulated
P3
Electrical cabinet P11
Concrete pedestal for the device
P4
Cooling (freon) line P12
Condensate drainage (drained through the holes on the
bottom of the condensation vessel)
P5
Power cable - external control
unit P13
Sink
P6
Power cable - internal control
unit P15
Frost limit (depending on the geographical location)
P17
Temperature sensor for external temperature

©Termo-tehnika, d.o.o.
14
ID.: 17-16-24-3006-03 | 12.2016
Devices for external installation must be placed on a level concrete foundation (chapter 4.2.5). For exact
position and dimensions of pipe connections, see technical data (chapter 7). Along with pipes for the
hydraulic connection, install also pipes with wire rope (it is advisable to separate the power / sensors).
Use this wire rope to lay the two external device’s power cables and the jacketed communication cable
from the utility room. The recommended diameter of this pipe is given in the table below and depends
on the dimension of the power cable.
Dimension of the power cable (mm
2
)
The recommended diameter of the ribbed
protective pipe (mm
2
)
5 x 2.5 35
5 x 4 35
5 x 6 40
For the appropriate diameter of the power cable, see technical data (chapter 7.2).
Make a sink for the condensate forming in the evaporator of the device underneath the concrete
foundation. The sink must be under the frost limit to ensure unobstructed drainage.
Sink in installations V1 or V2
When installing the pedestal, the installations V1 and V2 can be chosen according to the connection
with the utility room.
Sink in installation V1
Sink in installation V2
P10
P4
P2
P9
P19
400 200
V1
400
P2
200
P4
P9
P10
P19
V2
Legend:
P2 External device P9 Concrete pedestal serving as shaft -
recommended dimensions: 1050 x 420
P4 Condensate drainage (drained through
the holes on the bottom of the device) P10 Stones
P19 Frost limit (depending on the geographical
location)

©Termo-tehnika, d.o.o.
ID.: 17-16-24-3006-03 | 12.2016 15
4.2 Location of the device
CAUTION
The concrete pedestal must carry the weight of the device. See technical
information.
The device must be levelled
NOTE
It is obligatory to consider the minimal clearance from obstacles for ensuring unobstructed
access for maintenance and service of the device.
NOTE
The location of the device has to be accessible with manual transport devices to ensure
undisturbed delivery of replacement parts and equipment for maintenance and servicing.
Costs connected with hiring special equipment for installing the device, servicing and
maintenance are charged the operator separately and are not subject of the warranty.
The device must not be set up at a location, which is subject to stronger and lengthy gusts of wind (i.e.
bora wind); they could obstruct the normal air circulation through the evaporator which could result in
disruptions in operation.
In case the device is installed in the wind direction, it is necessary to install adequate wind protection.
Wind protection must be robust enough to prevent the influence of the wind. The best option is
a concrete or brick version.
The height and width of the wind protection must be at least 150 % of the basic dimensions of
the device. Only these dimensions enable adequate wind protection of the device.
The wind protection must be located at least 3000 mm away from the external device to ensure
sufficient air flow.
NOTE
The device must be set up in a leeward location.
NOTE
Salt or dust gathering on the outer heat conductor must be regularly cleaned (dust once
yearly and salt in coastal regions at least three times yearly) or rinsed with water.

©Termo-tehnika, d.o.o.
16
ID.: 17-16-24-3006-03 | 12.2016
4.2.1 Set up and connection of the external sensor.
For controlling the heating according to the external temperature, it is necessary to install the external
temperature sensor.
CAUTION
The sensor must be set up in a shady spot.
The sensor must not be set up above a window or door. It must be located
away from heat sources.
For measuring external temperature, the sensor type PT 1000 is used.
Temperature sensor for external temperature.
The direction of connecting cables.
T
Temperature sensor for external temperature.
CAUTION
The external sensor must be connected and watertight to prevent water penetration.
4.2.2 Minimal clearance from the device
The air direction and minimal clearances of the external device from walls for seamless operation,
maintenance and servicing.
min. 300 mm
min. 1500 mm
min. 300 mm
min. 2000 mm

©Termo-tehnika, d.o.o.
ID.: 17-16-24-3006-03 | 12.2016 17
The clearances for the internal device are provided in the document Installation Manual –
Hydro Module.
4.2.3 Levelling of the device
The external device must be levelled in the horizontal position as shown on the diagrams below:
4.2.4 Removal of side
Unscrew 3 screws of the side Electrical and machine connections
Unscrew the screws marked with 1 on the front and right side of the device.
Pull down the lower part of the side (2) and open it towards you.
2
1
1

©Termo-tehnika, d.o.o.
18
ID.: 17-16-24-3006-03 | 12.2016
4.2.5 Concrete pedestal
The installation (connections above or below ground) routed from the utility room to the device does not
influence the make of the concrete pedestal.
Because of greater safety, installation using an underground cable duct is recommended (installation
V1).
Installation of the concrete pedestal
The reinforced concrete pedestal must be installed on a suitable buffered base. The recommended
minimal edge thickness of the pedestal is 60 mm. Width 1050 mm, depth 420 mm and height 600 mm.
CAUTION
The device must be screwed on the designated places (1) to the concrete pedestal because
of the possibility of stronger gusts of wind.
Legend:
1 Attachment points at the concrete pedestal
2 Attachment points of the device
2
2

©Termo-tehnika, d.o.o.
ID.: 17-16-24-3006-03 | 12.2016 19
4.2.6 Wall penetration for the refrigerant and electro-communication connection
When installing a refrigerant and electro-communication connection between the internal and external
device, please note:
The passage through the wall must be drilled with a crown drill with the diameter of 70 mm for
laying pipe connections.
The hole for the pipe connection must be slightly sloped in the direction towards the external
device to prevent water penetrating into the building. See the diagram below.
1
Internal device
3
External device
2
Wall
4.3 Refrigerant pipe connection of the exterior and interior device
Connect the exterior and interior device with refrigerant pipes.
NOTE
Use insulated pipes for the installation of the connection between external and internal
device.
CAUTION
The refrigerant pipes filled with nitrogen are always laid closely sealed to prevent impurities,
air, moisture and contaminants penetrating the interior.
4.3.1 Determining the length of the connection pipes
When determining the length of connection pipes, follow the instructions for the maximal
allowed pipe length and the height difference between the devices.
CAUTION
The refrigerant pipes must not be installed alongside the heating in the screed or alongside
any kind of source of heat or cold.
The data on permitted lengths and height differences between devices
1
Internal device
2
External device

©Termo-tehnika, d.o.o.
20
ID.: 17-16-24-3006-03 | 12.2016
The average length of the refrigerant connection between the devices is 7.5 m. The external device is
factory filled for connections of up to 15 m. For longer connections, it is necessary to supplement
the refrigerant according to the table below.
Model
Pipe diameter [mm]
Length A [m]
Length B [m]
Supplement of
refrigerant [g/m]
Gas Liquid Min. Max. Normal Max.
WPLV
-
09
-
S1 NT
15.88
(5/8'')
9.52
(3/8'') 3 30 0 12 30
WPLV
-
14
-
S1 NT
15.88
(5/8'')
9.52
(3/8'') 3 30 0 12 60
WPLV-09-S1 NT
Example 1: When installing the external device and accompanying internal device with the distance of
30 m, it is necessary to supplement the system with additional refrigerant. The quantity of the refrigerant
is calculate with the following equation:
(30 m – 15 m) x 30 g/m = 450 g
In the given example, it is necessary to supplement the system with 450 gof refrigerant R410 A.
WPLV-14-S1 NT
Example 2: When installing the external device and accompanying internal device with the distance of
30 m, it is necessary to supplement the system with additional refrigerant. The quantity of the refrigerant
is calculate with the following equation:
(30 m – 15 m) x 60 g/m = 900 g
In the given example, it is necessary to supplement the system with 900 g of refrigerant R410 A.
NOTE
In case of installing an internal device which is higher than the external device and when
the height difference is 4 m or more, a qualified person has to manufacture oil siphons for
every 4 m of height difference to enable adequate oil transport.
In case the external device is higher than the internal device, oil filters are not necessary.
WARNING
The device contains the refrigerant HFC which is classified as a greenhouse gas according
to the Kyoto protocol. This is why operating the device is only allowed to persons authorised
for working with the refrigerant as defined by the national legislation in force. While
performing works on the device it is necessary to prevent the refrigerant to leak into the
atmosphere.
