Krups XP42 User manual

XP4200 www.krups.com
EN
FR
ES
www.krups.com
NC00026258-01
EN . . . . . . . . . . . . . . . . . p.7
FR . . . . . . . . . . . . . . . p. 27
ES . . . . . . . . . . . . . . . p. 47
h
i
k
g
j
c
f3
f
e
f1
f2
f4
f
b
d
a
WWW.KRUPS.COM
XP42
EN
FR
ES
Réalisation : Espace Graphique
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 14:02 PageC1

12
3
PUSH
!
2
1
Fig.1 Fig.2 Fig.3
Fig.4 Fig.5 Fig.6
Fig.7 Fig.8 Fig.9
Fig.10 Fig.11 Fig.12
Fig.13 Fig.14 Fig.15
Fig.16 Fig.16.2 Fig.16.3
Fig.17 Fig.18.1 Fig.18.2
Fig.19 Fig.20 Fig.21
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 14:02 PageC4

1
2
Fig.22 Fig.23
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 PageC7

Filter-holder position for 1 cup
Position du porte-filtre pour 1 tasse
Posición del portafiltro para 1 taza
Filter-holder position for 2 cups
Position du porte-filtre pour 2 tasses
Posición del portafiltro para 2 tazas
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 PageC8

English
TABLE OF CONTENTS
1. DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 11
2. TECHNICAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . p. 11
3. TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 12
4. BEFORE FIRST USE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 13
5. MAKING AN ESPRESSO. . . . . . . . . . . . . . . . . . . . . . . . . p. 13
6. MILK FROTHING FUNCTION . . . . . . . . . . . . . . . . . . . . . p. 16
7. CLEANING AND MAINTENANCE . . . . . . . . . . . . . . . . . . p. 18
8. DESCALING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 19
9. PROBLEMS, PROBABLE CAUSES
AND CORRECTIVE ACTIONS. . . . . . . . . . . . . . . . . . . . . p. 22
10. DISPOSING OF YOUR MACHINE. . . . . . . . . . . . . . . . p. 24
11. WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 25
7
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page7

English
8
IMPORTANT
SAFEGUARDS
When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric
shock, and/or injury to persons including the following :
1. Read all instructions prior to first use.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against fire, electric shock and injury to persons,
do not immerse cord, plugs or machine in water or other
liquid.
4. Not intended for use by children.
5. Close supervision is necessary when any machine is used
near children. Keep machine out of reach of children.
6. This appliance is not designed to be used by children or
people without knowledge or experience with the product,
unless they are supervised or given prior instructions
concerning the use of the appliance by someone
responsible for their safety.
7. Children must be supervised to ensure that they do not play
with the appliance.
8. Burns can occur from touching hot plate, hot water or
steam. Exercise caution.
9. Exercise caution when using the steam nozzle as steam can
cause scalding.
10. Unplug machine from outlet when not in use and when
cleaning. Allow to cool before putting on or taking off parts,
before cleaning the machine, and before storing.
11. All machines are subject to stringent quality control.
Practical tests using machines taken at random are
conducted and this may explain any slight marks or coffee
residue prior to use.
12. Do not operate any machine with a damaged cord or plug
or after the machine malfunctions, or has been damaged in
any manner. Return machine to the nearest Krups Service
Center for examination, repair or adjustment or your
respective countries Consumer Service Department.
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page8

English
13. To reduce the risk of injury do not drape cord over the
counter top or table top where it can be pulled on by
children or tripped over accidentally.
14. Do not let cord hang over edge of table or counter, or touch
hot surfaces.
15. The use of accessory attachments not recommended by
Krups may result in fire, electric shock or injury to persons.
16. Do not use outdoors.
17. Do not place on or near a hot gas or electric burner, or in a
heated oven.
18. To disconnect the machine, Turn the machine OFF by
pressing the button, then remove plug from wall outlet.
Do not yank cord, instead grasp plug and pull to
disconnect.
19. Do not use this machine for anything other than it’s intended
use.
20. Do not pour liquids other than water and descaling
solutions specified in this manual into the water tank.
21. Protect the machine against humidity and freezing.
22. This machine is for household use only.
SAVE THESE
INSTRUCTIONS
9
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page9

English
10
CAUTION
This machine is intended for household use only. Any servicing
other than cleaning and user maintenance should be performed
by the nearest authorized Krups Service Center.
Visit our website at www.krupsusa.com in the USA or
www.krups.ca in Canada or contact your respective country's
Consumer Service department for the service center nearest to
you, or contact your respective country’s Consumer Service
department.
To reduce the risk of fire or electric shock, do not attempt to
disassemble the machine. Repair should be done by an
authorized Krups Service Center only.
SHORT CORD INSTRUCTIONS
A. We do not recommend using an extension cord with
this device.
B. If an extension cord is absolutely necessary,
1) the marked electrical rating of the extension cord
should be at least as great as the electrical rating
of the machine,
2) the longer cord should be arranged so that it will
not drape over the counter top or table top where
it can be pulled on by children or tripped over.
C. This machine has a polarized plug (one blade is wider
than the other). To reduce the risk of electric shock,
this plug is intended to fit into a polarized outlet only
one way. If the plug does not fit fully into the outlet,
reverse the plug. If it still does not fit, contact a
qualified electrician. Do not attempt to modify the
plug in any way.
In the interest of improving products, Krups reserves the right
to change specifications without prior notice.
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page10

English
Your Krups espresso machine is equipped with a filter-holder that has
three patented systems designed to help you make the perfect espresso
at home.
1. KRUPS Precise Tamp: gradual tamping of the espresso ground
coffee as the filter-holder is turned ensures that coffee is tamped
precisely each time.
2. Coffee ejection system under the filter-holder for clean removal of
the cake each time.
3. The filter-holder is compatible with all types of pods including
E.S.E. and soft pods.
The filter-holder is also removable and can be frequently cleaned to
maintain the filter-holder system in perfect working order. For your safety,
the filter-holder is equipped with a locking system when pressure rises.
1. DESCRIPTION
2. TECHNICAL INFORMATION
nPump: 15 bars
nFilter-holder with grounds or pod ejection system. Compatible with
espresso ground coffee and all types of pods including E.S.E. and
soft pods.
nSteam function 11
a Water tank lid
b Removable water tank
c Measuring spoon
d Cup warming tray
eOn/Off button with LED
indicator
f Function switch
f1. Coffee position
f2. Off position
f3. Steam preheating
position
f4. Steam position
gBrewing head
hFilter holder with grounds or
pod ejection system and gra-
dual coffee tamping system:
KPT "Krups Precise Tamp":
Compatible with ground coffee
(1 or 2 cups) and ESE or soft
pods
i Drip tray grid
jDrip tray with overflow indica-
tor
kSteam nozzle
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page11

English
12
nAutomatic shutoff.
nRemovable water tank (capacity: 0.86 litres).
nPower: 1450 W
nVoltage: 120V – 60Hz
nAnti overheating safety mechanisms
nDimensions : H. 322,5 mm, L. 291 mm, P. 214 mm
IMPORTANT!
Operating voltage: This device is designed to work only at
alternating current 120V.
Type of use: This machine is designed EXCLUSIVELY for
household use only. Any non-residential use including
commercial purposes will void the warranty.
3. TIPS
nTo extract the fullest flavor from your beans, we recommend using whole
coffee beans that have been freshly ground each time espresso is
prepared. Take care to make sure your coffee is ground to the proper
size for espresso. Too fine a grind will result in espresso that is over-
extracted and bitter. Too coarse a grind will result in espresso that is
under-extracted and weak in flavor. The perfect espresso grind will feel
like fine grains that do not clump when pressed together.
nStore your espresso grounds in an airtight container, and in a cool, dry
place to retain the flavor. Grounds should not be kept for long periods
of time as the flavor will be reduced over time.
nDo not fill your filter holder to the brim. Using the measuring spoon
included, use 1 level spoon of grounds per shot of espresso.
nIf you do not use the machine for more than 5 consecutive days, rinse
and drain the water tank.
nBefore removing the water tank to fill or empty it, always turn the machine
off.
nAlways place the unit on a flat, stable, heat-resistant work surface.
nTo obtain an espresso at exactly the right temperature, we recommend
that you preheat your cups.
IMPORTANT!
Before using for the first time, after a prolonged period
of inactivity or after descaling, the machine must be
cleaned as described in Section 4: “BEFORE FIRST
USE”.
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page12

English
4. BEFORE FIRST USE
Before using your espresso machine for the first time, clean all
accessories using warm water and a gentle dishwashing liquid, and rinse
well before replacing.
PRIMING OF YOUR MACHINE:
Use the following procedure to prime the machine:
nOpen the lid and remove the water tank by lifting up on the handle
(fig.1).
nFill it with water (fig. 2).
nReplace the water tank by positioning it firmly, to ensure the water
inlet is in place, and close the lid (fig.3).
nPress the on/off button to turn the machine on (fig.4).
nInsert the filter holder (without espresso grounds) in the machine and
turn to the right (fig.7).
nPlace a container under the filter holder large enough to hold all the
water in the water tank.
nOnce the machine has reached the correct temperature, the on/off
button will stop blinking. Turn the dial to the position (fig.8) and
let all the water in the tank run through.
nIf the container you are using has a smaller capacity than the water tank,
turn the dial back to the to pause the water flow when necessary.
Empty the container, replace under the filter holder, and turn the dial back
to the position.
nRepeat as necessary until the water tank is empty. (fig.9).
nOnce all the water has been drained from the water tank, remove and
empty the container, press the button on the filter holder and turn
the filter holder handle to the left to remove (fig.10).
5. MAKING AN ESPRESSO
In order to extract the maximum flavor from the beans, this machine
pre-infuses each cup. The pump works for 3 seconds, pauses for
3 seconds, and then continues until the cup is finished.
PREHEATING THE ACCESSORIES
For the best results, we recommend that you preheat the filter holder
before espresso grounds are added, and warm the cups.
13
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page13

English
14
nFill the water tank with fresh cold water and turn the machine on
(fig 1-4).
nPut the filter holder in place, place the cups below.
As soon as the required temperature is achieved, the light will stop
flashing.
nTurn the dial to the position (fig.8).
nWhen the cups are filled with hot water, turn the dial to the position
(fig.9).
nRemove the cups, taking care to not spill the water.
nUnlock the filter holder by pressing the button on the handle while
turning the handle to the left to release, and remove the filter holder
from the machine (fig.10).
Note: Use the cup warming tray to warm espresso cups.
WITH GROUND COFFEE
The type of coffee you choose strongly influences the strength and
flavor of your espresso. Always use coffee beans ground to the
proper size for espresso. Too fine a grind will result in espresso that
is over-extracted and bitter. Too coarse a grind will result in
espresso that is under-extracted and weak in flavor. The perfect
espresso grind will feel like fine grains that do not clump when
pressed together.
Store your espresso grounds in an airtight container, and in a cool,
dry place to retain the flavor. Grounds should not be kept for long
periods of time as the flavor will be reduced over time.
Do not use instant coffee, or coffee for drip coffee machines.
nFill the water tank to the maximum line with fresh cold water and turn
the machine on (fig. 1-4). While the machine is preheating, the light
will flash.
nUsing the measuring spoon, add 1 level spoon of espresso grounds
per cup of espresso (fig.5).
nRemove any excess espresso grounds from the edge of the filter.
Important:
Do not tamp the coffee down in the filter holder. The
coffee is automatically tamped to the optimum level by
the Krups Precise Tamp (KPT) system.
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page14

English
nInsert the filter holder and turn the handle to the right as far as it will go.
You will hear a clicking sound as the Krups Precise Tamp (KPT) system
automatically adjusts the tamping level depending on the amount of
coffee grounds used. The handle will become progressively harder to
turn as you approach the optimum tamping level, do not force the handle
past this point. Use the “one cup” and “two cup” markings on the
brewing head as a guideline of where to stop. Because the Krups
Precise Tamp automatically adjusts the tamping level, you may find that
you do not always stop at the same point each time. Never turn the
handle past the far right edge of the “one cup”marking (fig.7).
nPut one or two cups under the filter holder as desired.
As soon as the required temperature is achieved, the light will stop
flashing.
nTurn the dial to the position (fig.8).
nWhen the cups are filled with the desired amount of espresso, turn
the dial back to the position.
nUnlock the filter holder by pressing the button on the handle while
turning the handle to the left to release, and remove the filter holder
from the machine.
nRemove the used espresso grounds using the ejection system by
holding the filter holder upside down over a trash receptacle. Press
the « PUSH » button located between the two coffee outlet nozzles
on the underside of the filter holder (fig.11). Rinse the filter holder
under running water, pressing « PUSH » while rinsing to release any
remaining grounds. Once the filter holder has been rinsed and dried
it can be refilled to prepare more espresso.
IMPORTANT: Do not store the filter holder in the locked
position when the machine is not in use to avoid
unnecessary wear to the seal.
WITH AN “E.S.E." ESPRESSO POD
“ESE” for “Easy Serving Espresso" is a packaged pod (44 mm
diameter) of 7g of selected coffee, ground and compacted between
two paper filters, specially designed to make Italian style ristretto
(tight) espressos.
This system allows for simple and clean use of your machine.
nFill the water tank with fresh cold water to the maximum line and turn
on the machine (fig.1, 2, 3 and 4). The light will flash while the
machine preheats 15
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page15

English
16
nRemove the excess paper from the E.S.E. pod, and place the pod in
the filter holder with the red writing facing down.
nTake care to make sure that the pod is centered in the filter holder
with no paper hanging out, as this may cause leaks and/or
unsatisfactory results.
nNever use more than one pod at a time.
nThen follow the steps above for figure 7-11 to make your espresso.
WITH A SOFT POD
Your machine is also compatible with soft pods, which are usually
smaller in diameter than E.S.E. pods. However since soft pods are
not specifically designed for use with espresso machines, you will
get a less flavorful espresso than with an E.S.E. pod.
nFill the water tank with fresh cold water to the maximum line and turn
on the machine (fig.1, 2, 3 and 4). The light will flash while the
machine preheats.
nPlace the soft pod in the filter holder.
nTake care to make sure that the pod is centered in the filter holder
with no paper hanging out, as this may cause leaks and/or
unsatisfactory results.
nNever use more than one pod at a time.
nThen follow the steps above for figure 7-11 to make your espresso.
6. MILK FROTHING FUNCTION
nSteam can be used to froth milk by using the steam wand with frothing
nozzle (for example to make a cappuccino or latte).
nAs the machine produces steam, the pump will make a thumping sounds.
This sound is normal and is an indication that the machine is operating
properly.
nAfter using the steam function, the machine purges automatically
to cool down by pumping cold water through the heating system.
During the purging cycles of cold water, the excess steam in the
heating system is released with hot water into the drip tray.
nThe steam and noise that accompany this phase are important
for cooling the machine.
Caution: During and after using the steam wand, the metal
parts of the steam wand can become very hot. Take care
when handling the steam wand to avoid injury.
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page16

English
USING THE STEAM NOZZLE TO FROTH MILK
nFill the water tank with fresh cold water to the maximum line and turn
the machine on (fig.1, 2, 3 and 4).
nTurn the dial to the position (fig.12). The indicator light will flash
to show that the machine is preheating.
nPosition the steam nozzle so that it points away from the machine.
nPour 2 to 3 oz (1/4 – 1/3 cup) of fresh milk in a small container that
is short enough to fit under the steam nozzle. Both the milk and the
container should be cold for optimum results.
nPasteurised or UHT milk is recommended. Whole, lowfat, or skim milk
can all be frothed.
nAs soon as the preheating indicator light stops blinking, plunge the
steam nozzle into the milk.
nTurn the dial to the position (fig.13).
nFor optimal results, froth from the bottom of the container and slowly
move upwards. Hold the nozzle towards the bottom of the container
without touching the bottom for about 25 seconds. Then gradually
lower the container so that the steam nozzle moves up towards the
surface of the milk. Do not allow the nozzle to come completely out of
the milk, nor allow the milk level to cover the black plastic ring at the
top of the nozzle.
nOnce the frothing is complete, turn the dial to the position (fig.15).
The machine will then begin 3 pumping cycles to automatically cool
the system. Once cooling is complete, another espresso can be made.
Important: To prevent clogging of the steam nozzle, make
sure the milk foam does not cover the black plastic ring at
the top of the steam nozzle.
It is important to clean the steam nozzle after each use to prevent milk
from hardening and drying inside the nozzle which can result in the tube
blowing off due to pressure build-up. To clean the nozzle :
nPlace the steam nozzle in a small container filled with water.
nTurn the dial to the position (fig.12).
nOnce the indicator light has stopped blinking, turn the dial to the
position (fig.13) to remove any remaining milk. Run in the steam
position for at least 30 seconds.
nThen turn the dial to th position and wipe the outside of the steam
nozzle with a clean cloth.
For thorough cleaning of the steam nozzle, see Section 7, “Cleaning of
the Steam Nozzle”.
17
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page17

English
18
7. CLEANING AND MAINTENANCE
IMPORTANT: Your espresso machine accessories are not
dishwasher-safe. Do not wash the spoon, the drip tray, the
filter holder and the water tank in the dishwasher.
CLEANING OF THE MACHINE
nAlways unplug the machine before cleaning and allow to cool down
to avoid injury.
nWipe the outside of the machine with a clean damp cloth. Do not use
harsh or abrasive cleaners, or alcohol/solvent-based cleaners to clean
the machine. Use only gentle dishwashing liquid and warm water. After
each use, rinse out the water tank and empty before replacing in the
machine.
nWhen a thin white layer of powder starts to form in the tank, this is a
sign that descaling is necessary. See Section 8 for details on
descaling. Please note that descaling should be performed
periodically to maintain optimum performance of your machine.
CLEANING OF THE DRIP TRAY
nThe drip tray must be emptied each time the machine is used. The
presence of water in the drip tray is normal and is not the sign of a
leak. Lift up the tray slightly and pull out to remove from the machine.
nIf multiple espressos are prepared one after the other, the drip tray
should be emptied every few espressos to prevent overflowing.
nThe red overflow indicators in the tray will float up and become visible
to remind you to empty the drip tray before it overflows. When
emptying the drip tray, remove the metal tray and rinse out the
compartment below. If necessary, both the metal tray and the
compartment can be cleaned with warm water and a gentle
dishwashing liquid. Rinse well and dry completely before replacing
the drip tray in the machine. Make sure when replacing the drip tray
to push it all the way into the machine to avoid leaking.
CLEANING OF THE BREWING HEAD AND FILTER
HOLDER
nBoth the brewing head and filter holder should be cleaned after each use.
nWipe the brewing head with a clean damp cloth. (fig.21).
nWash the filter holder with warm water and a gentle dishwashing
liquid.
nDo not use harsh or abrasive cleaners, or alcohol/solvent-based
cleaners to clean the brewing head or filter holder.
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page18

English
nWhen cleaning the filter holder, hold under running water and press
the « PUSH » button several times to remove all remaining espresso
grinds.
nRinse well and dry carefully.
nWhen not using the espresso machine, do not store the filter holder
in the locked position. This will avoid unnecessary wear to the seal.
For more thorough cleaning, disassemble the filter holder:
nRemove the black plastic part with the coffee outlets and « PUSH »
button by turning it to the left and pulling (fig.22).
nRinse the various components under running water. If necessary, use
gentle dishwashing liquid.
nRinse and dry all components well before re-assembling.
nReplace the black plastic part in the metal part, turning in the opposite
direction to that shown in Figure 22.
nIf the brewing head is heavily clogged, unscrew the grid using a
screwdriver, rinse well, dry, and then replace in the machine.
CLEANING OF THE STEAM WAND AND STEAM
NOZZLE
nThis accessory consists of 2 parts: one part which is the plastic
support and the other which is the metal protection cylinder.
nBefore cleaning, unlock the nozzle from the articulated arm by turning
it to the left. (fig.16, 16.2)
nThen slide the metal cylinder along the plastic support (fig.16.3).
nClean these two parts with tap water and some mild washing-up liquid
(fig.17).
nRinse and dry.
nOnce the parts have been properly cleaned, put the metal cylinder
back on the support.
nMake sure that you don’t damage the silicone seal which makes the
nozzle watertight (fig.16.3).
nInsert the nozzle on the articulated arm then lock to the right (fig.18.1,
18.2).
8. DESCALING
The warranty does not cover machines which have become faulty
because descaling was not periodically performed.
Descale your espresso machine regularly using Krups descaling kits
(model F054), available in Krups authorized service centers (go to
Krupsonlinestore.ca for Canadian residents only).
19
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page19

English
20
In addition to two packets of descaling powder, the kit also includes a
water hardness tester to help you determine the proper schedule for
descaling your machine in normal use. The amount of scale that develops
depends on the hardness of the water used, but also the level of use.
The schedule indicated by the water hardness tester is a general
guideline only. Keep in mind that you may have to descale more
frequently than indicated.
If in doubt, it is recommended to descale every month.
DESCALING THE MACHINE
nEmpty the tank and replace.
nFollow the instructions for using the Krups descaling powder inside
the kit.
nThen insert the filter holder (without espresso grounds) and lock into
place by turning to the right.
nPlace a container under the steam wand to catch the water.
nPress the button to turn the machine on, and then immediately turn
the dial to the position, without stopping at the position).
nLet the mixture run through the nozzle until steam appears,
nThen turn the dial back to the position
nPlace the container under the filter holder.
nOnce the indicator light stops blinking, turn the dial to the position
and run half of the remaining water through.
nTurn the machine OFF by pressing the button and leave the dial at
the position. Empty the container under the filter holder then
replace it.
nAfter 15 minutes, turn the machine back on.
nLet the rest of the water run through until the water tank is empty.
nThen turn the dial to the position.
DESCALING FREQUENCY
Avg. number of
uses per week
Soft water
(<19°th)
Hard water
(19-30°th)
Very hard water
(>30°th)
Less than 7 Once a year Every 8 months Every 6 months
From 7 to 20 Every 4 months Every 3 months Every 2 months
Over 20 Every 3 months Every 2 months Every month
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page20

English
21
RINSING
IMPORTANT!
After descaling, rinse 2-3 times with clean water as
described in Section 4 “BEFORE FIRST USE”.
Then rinse the steam nozzle by following the instructions
below:
nFill the water tank with clean water. Then place a container under the
steam nozzle.
nPress the button to turn the machine on, and then immediately turn
the dial to the position, without stopping at the position.
nLet the water run through the nozzle until steam appears.
nTurn the dial back to the position.
nThe machine is now descaled and ready to be used again.
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page21

English
22
9. PROBLEMS, PROBABLE CAUSES AND
CORRECTIVE ACTIONS
Problems Possible causes Solutions
The espresso
is not hot
enough.
The cups and the
filter holder are
cold.
Preheat the accessories: cups and
filter holder (see paragraph 5).
The filter
holder is
locked.
You forgot to unlock
the filter. Press « » while turning the filter
holder to the left.
The grounds
are not dry
after water has
run through.
You have not
tightened the filter
holder properly.
Tighten the filter holder by turning it
to the right as far as it will go.
The coffee
flows too
slowly.
You have tightened
the filter holder too
much.
The ground coffee
is too fine, too oily
or floury.
The filter holder is
dirty.
The water drip-
through grid is
clogged.
Loosen it slightly.
Choose a larger grind of coffee.
The perfect espresso grind will feel
like fine grains that do not clump
when pressed together.
Clean your filter holder (see
paragraph 7).
When the machine has cooled,
clean the brewing head with a
clean damp cloth (fig.21).
The water
does not run
through.
No water in the tank.
The tank is not
properly in place.
The filter is
clogged. The
ground coffee is
too fine.
Your machine
needs to be
descaled.
Fill the tank.
Replace the tank in the correct
position.
Clean the filter holder (see Section
7) and try a larger grind of coffee.
The perfect espresso grind will feel
like fine grains that do not clump
when pressed together.
Descale the machine (see Section 8).
Water leaks
from the filter
holder after an
espresso has
been made.
The dial has not been
returned to the
position.
Your machine needs
to be descaled.
Turn off your machine by moving the
dial back to the position (fig.9).
Descale the machine (see Section 8).
IFU_KR_XP4200_NAFTA_NC00026258-01 18/11/11 13:47 Page22
