Kuberg START 2016 User manual

OWNER’S MANUAL 2016
START, TRIAL, CROSS
ENGLISH

A WORD ABOUT THIS SAFETY MANUAL
DEAR KUBERG CUSTOMER
Congratulations on your purchase of a Kuberg motorcycle. You now own a state of the art electric
motorcycle that will give you endless thrills if you maintain it properly. We welcome you to the
community of KUBERG riders.
Your KUBERG motorcycle is a performance motorcycle that should be treated with caution and
used in safe environments. As the owner of this motorcycle, it is your responsibility for the safety
of the rider at all times. If you defer this task to another adult, you need to pass this owner’s man-
ual and all relevant information to whoever will take on this role, and ensure without question
that the rider is controlled and taught in a safe manner.
Your KUBERG motorcycle is highly adjustable and can be set up specically for the rider.
Please do not allow the bike to be used or adjusted by other operators.
Your KUBERG motorcycle is driven by a powerful electric motor, which requires experience and
careful handling. The speed and torque settings MUST be set to suit the abilities of the rider.
Please remember that even when the torque setting is set to a slow setting, the torque on these
motors is virtually instant. This means that opening the throttle will propel the motorcycle to a
rapid speed almost instantly. For developing good riding skills this is a wonderful feature, as it
will teach riders throttle control gradually with lower power. If the maximum power and torque
is set too aggressively, the rider may accelerate to a speed he/she is not comfortable with. Your
KUBERG motorcycle has great capabilities, and can grow with the skills of the rider to very high
levels of performance, but it is IMPERITIVE that the responsible adult controls the entire learning
process and pays full attention at all times. You need to foresee all potential situations and man-
age the riding environment and the rider accordingly.
KUBERG motorcycles are designed for o road use only and must not be used on public roads
or sidewalks. Please check and obey all local and state laws. KUBERG motorcycles should only be
ridden in safe areas where all laws are being followed and all required permissions are given.
KUBERG motorcycles are amazingly capable, and can be used from the earliest stages of learning
to ride all the way through to veteran riders. The secret of learning to ride well is being able to
ride a lot, and KUBERG motorcycles make this learning process very gratifying teenagers and
adults alike. Thanks again for purchasing a KUBERG motorcycle, and we hope you enjoy the ride!
Michal Kubanek
President, KUBERG, Inc.
KUBERG s.r.o.
Zengrova 630/83
703 00 Ostrava – Vitkovice
Czech Republic
www.kuberg.com

4
OWNER’S MANUAL
TABLE OF CONTENTS
A WORD ABOUT THIS SAFETY MANUAL 2
INTRODUCTION 5
IMPORTANT SYMBOLS AND TERMS 5
SAFETY ADVICE 6
ELECTRIC DRIVETRAIN 6
SAFE RIDING PRACTICES 6
VEHICLE OVERVIEW 9
2016 KUBERG START 9
SPECIFICATIONS – KUBERG START 10
2016 KUBERG TRIAL E 12
SPECIFICATIONS – KUBERG TRIAL E 13
2016 KUBERG CROSS 15
SPECIFICATIONS – KUBERG CROSS 16
BEFORE FIRST RIDE 18
UNPACKING AND ASSEMBLY 18
FIRST SETUP 18
BREAK-IN PERIOD 19
MOTORCYCLE CONTROLS 19
DRIVE TRAIN 20
ADJUSTING CHAIN TENSION 20
MOTOR PERFORMANCE 21
WEATHER EFFECTS ON PERFORMANCE 21
MAINTENANCE 21
BEFORE EACH RIDE 21
DAILY MAINTENANCE AND CLEANING 22
CLEANING 22
FRONT WHEEL REMOVAL AND INSTALLATION 22
REAR WHEEL REMOVAL AND INSTALLATION 23
FRONT BRAKE ADJUSTMENT - KUBERG START 24
REAR BRAKE ADJUSTMENT – KUBERG START 24
FRONT AND REAR BRAKE ADJUSTMENT - KUBERG CROSS AND TRIAL E 24

5
OWNER’S MANUAL
BRAKE SQUEAL 24
ADJUSTING SUSPENSION 25
BATTERY USE, CARE AND MAINTENANCE 25
CHARGING INSTRUCTIONS – KUBERG START 26
CHARGING INSTRUCTIONS – KUBERG TRIAL E 27
CHARGING INSTRUCTIONS – KUBERG CROSS 28
BATTERY REMOVAL AND INSTALLATION 29
LONG TERM STORAGE 29
BATTERY DISPOSAL 30
SETTING UP KUBERG START/TRIAL E/CROSS FOR RIDING 31
SETTING POWER & TORQUE MODES 31
SETTING THE TOP SPEED LIMIT 32
SETTING UP THE BRAKES 33
RIDING INSTRUCTIONS & SAFETY TIPS (NOVICE RIDERS) 33
STATIONARY LEARNING 33
FIRST RIDE (NOVICE RIDERS) 34
LEARNING TO STAND UP 35
CORRECT RIDING TECHNIQUE 35
PROTECTIVE EQUIPMENT 37
HELMETS 37
CLOTHING 37
ACCESSORIES 37
LIMITED WARRANTY 39

6
OWNER’S MANUAL

7
OWNER’S MANUAL
INTRODUCTION
PLEASE READ THIS SAFETY INSTRUCTIONS MANUAL PRIOR TO OPERATION!
To ensure optimum performance from your new KUBERG motorcycle, and to ensure a safe
operation, it is important to fully understand the features of the motorcycle. This manual contains
IMPORTANT INFORMATION that every owner must fully understand. Please read this manual
carefully and completely before operating your Kuberg motorcycle. Do not attempt to operate
this motorcycle until you have attained adequate knowledge of its controls and operating proper-
ties and until you have received training in proper and safe riding techniques.
Motorcycles as well as KUBERG electric motorcycles are single track vehicles. The safe use and
operation of these single track vehicles depends on proper riding techniques and experience of
their riders (operators). 
Please read, understand and follow all Warning, Caution and Note notices on your KUBERG elec-
tric bike and those included in this Manual. If you do not understand any of this important infor-
mation, please contact your selling dealer/distributor or the KUBERG Customer Service (kuberg@
kuberg.com, +420608757353)
Prop 65 WARNING
CALIFORNIA PROPOSITION 65 WARNING:accessories contain lead and lead compounds,
chemicals known to the State of California to cause cancer and reproductive harm. Batteries also
contain chemicals known to the State of California to cause cancer. Wash hands after handling.
IMPORTANT SYMBOLS AND TERMS
This Owner’s Manual uses the following symbols and terms to call your attention to Warnings,
Cautions andNotes:
WARNING!
A Warning indicates a potentially hazardous situation which, if not avoided, could result in bodily
injury or death, in addition to property damage. Read the text accompanying the warning to be
aware of the specic hazard.
CAUTION!
A Caution indicates a potentially hazardous situation which, if not avoided, may result in damage
to equipment or inadvertent system failure. Read the text accompanying the Caution to be aware
of the specic hazard and avoid damage or system failure.
NOTE:
The text accompanying a Note provides helpful or other important related information.

8
OWNER’S MANUAL
SAFETY ADVICE
WARNING!
Failure to obey all of the warnings & instructions contained in this manual may result in serious
injury or death and permanent damage to your KUBERG motorcycle.
SPEED & TORQUE SETTINGS
Your KUBERG motorcycle features a speed and torque control button that must be set for the
abilities of the rider. This must be set by the responsible supervising adult before each and every
ride. Instructing and practicing in a controlled situation will allow the rider to learn how to operate
the motorcycle safely. Go to page xx to nd detailed instructions how to set up dierent speed
and torque modes.
WARNING: ADULT SUPERVISION REQUIRED
This vehicle must be used in the presence of adult supervision to insure that safe riding practices
are established and followed. A parent should supervise their child’s operation of this vehicle at all
times. Parents should permit continued use of this vehicle only if they determine that their child
has the ability and judgment to operate the vehicle safely.
WARNING: OFFROAD USE ONLY
Kuberg motorcycles are designed primarily for OFF-ROAD use. Please check your local, state and
country regulations whether single-track, motorized electric vehicles are legal for road use in your
area. Kuberg Start/Trial E/Cross are not homologated for road use in the European Union.
ELECTRIC DRIVETRAIN
The fully electric drivetrain of this motorcycle is dierent than any gasoline motorcycle:
1There is very little engine braking and no engine noise.
2 When going into corners or coming to a stop the rider will be fully dependenton the bike’s
brakes.
3 Passerby’s might not hear your approach – be extra cautious.Make yourselfconspicuous to
reduce chanceofother trac participants not seeing you approaching.
4 Be aware that your motorcycle is still ON during stops and while at an “idle”.Accidental-
lytwisting the throttle can cause serious harm.
SAFE RIDING PRACTICES
1OPERATOR ONLY! No passengers!
2Long hair, loose clothing or items worn by the rider must be covered to prevent entangle-
ment in moving parts of the vehicle or surroundings while riding.
3 Do not exceed the weight limit. Heavier riders may signicantly reduce performance and/or
render the vehicle unstable and/or over-tax the brakes and other control devices. Heavier
riders may cause structural damage not covered by the warranty.

9
OWNER’S MANUAL
4Do not touch any moving or hot parts.
5DO NOT RIDE AT NIGHT OR UNDER LOW VISIBILITY CONDITIONS. Kuberg Start/Trial E/Cross
is not equipped with lights.
6Do not immerse this vehicle in water.
7Do not ride on steep or uneven surfaces. Steep or uneven surfaces greatly increase the
likelihood of loss-of-control.
8Do not ride faster than conditions permit for safe operation. Excess speed greatly increases
the likelihood of loss-of-control.
9The rider should be securely seated on the vehicle ready to ride with the kickstand up be-
fore turning on the power switch ON.
Ride where other motorists and trac participants can see you. Avoid riding in another motorist’s
blind spot. Know your skills and limits. Stay within your limits to avoid an accident.
NOTE:
Many accidents have been caused by rider error. A typical error made by motorcycle riders is veering
wide on a turn due to EXCESSIVE SPEED or under cornering due to insucient lean angle for the given
speed.
WARNING!
Maintain a proper posture while riding. The posture of rider is important for proper control of the
motorcycle. The rider should keep both hands on the handlebar and both feet on rider’s footrests
during operation to maintain control of the motorcycle. Neverrideundertheinuenceofalco-
holorotherdrugs. Go to page xxx to nd detailed instructions for a proper riding technique.
ONE RIDER ONLY
Your bike was engineered to carry one rider and no (0) passengers. Carrying a passenger would
overload the motorcycle and alter the handling. Do not allow this to happen.
DO NOT OVERLOAD THE BIKE
Exceeding the weight limitations will adversely aect the handling of the motorcycle, and poten-
tially cause damage.
OBEY ALL LAWS
Obey all laws. KUBERG bikes are for OFF-ROAD USE ONLY. KUBERG bikes cannot be used on
public roads or sidewalks. The purchaser, owner, and/or riders of this motorcycle are directly
responsible to know and obey all local, state, and federal laws regarding the riding and use of this
motorcycle.
WEATHER & RIDING CONDITIONS
Don’t ride in the rain or snow. Please be aware that distance to stop under wet conditions may
double or triple over the distance that it takes under dry conditions. Ride more slowly, and antic-
ipate your stops by applying the brakes MUCH earlier. Don’t allow children to ride on slopes that
are too steep for their ability.

10
OWNER’S MANUAL
NIGHT TIME
Don’t ride after dark or in low light conditions.
BATTERIES
We have equipped your KUBERG Start/Trial E/Cross with highly advanced sealed lead-acid batter-
ies. Go to page xxx to learn about the correct charging procedure and batteries.
MIND THE MOTORCYCLE’S CHAIN
Under no circumstances should any hands or other body parts be close to a moving chain. Riders
should wear motorcycle boots without laces, and not have any loose clothing that could be caught
by the chain.

11
OWNER’S MANUAL
VEHICLE OVERVIEW
2016 KUBERG START
Kids just like to have fun. With a rugged build quality, safe design and reliable components, the
Start is perfect for kids who are itching for fun! Ideal for kids from 3 to 5 years.
1Throttle
2Handlebar
3Steering column
4Front brake
5Rear brake
6Number plate
7Safety kill-switch
8 On-o switch/Battery level indicator
9Fender
10 Tire
11 Front fork
12 Speed & torque control button
13 Foot pegs
14 Kick stand
15 Motor
16 Shock absorber
17 Charge port
18 Controller
19 Seat
20 Battery
1
8
4
9
10 5
3
13
6
2
7
19

12
OWNER’S MANUAL
NOTE:
Be aware of the motorcycle’s chain
Under no circumstances should hands or other body parts be close to a moving motorcycle chain.
Riders should wear motorcycle boots without laces, and should not wear any loose clothing that could
be caught by the chain.
WARNING: ALWAYS RIDE WITH THE CHAIN COVER
The chain cover helps to prevent accidental injuries from the chain. Never ride your motorcycle
when the chain cover is not in place. Operating your motorcycle without the chain cover may
result in serious injury.
TOP SPEED 24 KMH (15 MPH)
WEIGHT 21 kg (46 lbs)
POWER 1000 watts, 24 V motor
BATTERIES 2× 9 Ah12 V, sealed lead-acid
CONTROLLER PWM, 30 amp
INPUT STANDARD 110 V or 220 V
11
12
20
14
15
16
17
18

13
OWNER’S MANUAL
TRANSMISSION Clutchless one speed
FINAL DRIVE T90 / 13T chain 25HA
FRAME Steel double cradle tube frame, powder-coated
WHEELBASE 32” (82 cm)
SEAT HEIGHT 15/17” (39 cm without seat, 44 cm with seat option)
HANDLEBAR HEIGHT 25.5” (65 cm)
FRONT BRAKE V type
REAR BRAKE Band type
FORKS Suspension fork with spring
SHOCK ABSORBER Spring
TIRES 12.5” × 2.4”
WEIGHT 72 lbs (33 kg)
COLORS White
WIFI WiFi ready - adapter sold separately
CARRYING CAPACITY Maximum 220 lbs (100 kg)
SPECIFICATIONS – KUBERG START
WARNING!
The KUBERG START is designed to operate at 24 volts only. Use of any battery voltage other than
24 volts will result in motor failure. KUBERG Inc. considers modications and/or changes to its
electrical components to be a material alteration of its products, thereby cancelling any warran-
ties and/ or guarantees in their entirety. Kuberg Inc. will not be responsible for any injuries, and/
or death and/or other damage(s) caused by such modications.

14
OWNER’S MANUAL
2016 KUBERG TRIAL E
Featuring up to 3 kW of smooth, linear power and instant torque, the Trial E is perfect for 5 to
10-year-old riders looking to rip up anything from tracks to trails.
1Throttle
2Handlebar
3Steering column
4Front brake
5Rear brake
6Number plate
7Safety kill-switch
8 On-o switch/Battery level indicator
9Fender
10 Tire
11 Front fork
12 Speed & torque control button
13 Foot pegs
14 Kick stand
15 Motor
16 Shock absorber
17 Charge port
18 Controller
19 Battery
1
2
3
45
6
78
9
10
13
17

15
OWNER’S MANUAL
NOTE:
Be aware of the motorcycle’s chain
Under no circumstances should hands or other body parts be close to a moving motorcycle chain.
Riders should wear motorcycle boots without laces, and should not wear any loose clothing that could
be caught by the chain.
WARNING: ALWAYS RIDE WITH CHAIN COVER
The chain cover helps to prevent accidental injuries from the chain. Never ride your motorcycle
when the chain cover is not in place. Operating your motorcycle without the chain cover may
result in serious injury.
SPECIFICATIONS – KUBERG TRIAL E
TOP SPEED 27 KMH (17 MPH)
WEIGHT 33 kg (72 lbs)
POWER 3000 watts, 36 V motor
BATTERIES 3×12 Ah 12 V, sealed lead-acid
CONTROLLER PWM, 40 amp
INPUT STANDARD 110 V or 220 V
TRANSMISSION Clutchless one speed
11
12
14
15 16
18
19

16
OWNER’S MANUAL
FINAL DRIVE 69T / 10T, chain 219H
FRAME Steel double cradle tube frame, powder-coated
WHEELBASE 37” (94 cm)
SEAT HEIGHT 20.5/23” (52 cm without seat, 59 cm with seat option)
HANDLEBAR HEIGHT 32.5” (83 cm)
FRONT BRAKE AND REAR BRAKES Hydraulic Disc Brake system Tektro Auriga
BRAKE DISCS 160 mm diameter
FORKS Suspension fork Spinner Grind
SHOCK ABSORBER Spring
TIRES 16” × 2.4” KENDA
WEIGHT 72 lbs (33 kg)
COLORS White
WIFI WiFi ready - adapter sold separately
CARRYING CAPACITY Maximum 220 lbs (100 kg)
WARNING!
The KUBERG TRIAL E is designed to operate at 36 volts only. Use of any battery voltage other than
24 volts will result in motor failure. KUBERG Inc. considers modications and/or changes to its
electrical components to be a material alteration of its products, thereby cancelling any warran-
ties and/ or guarantees in their entirety. Kuberg Inc. will not be responsible for any injuries, and/
or death and/or other damage(s) caused by such modications.

17
OWNER’S MANUAL
2016 KUBERG CROSS
With its durable construction, massive power and precision controller, the Cross is perfect for
advanced riders, from 5 to 12 years of age, who want to push their riding to the limits.
1Throttle
2Handlebar
3Steering column
4Front brake
5Rear brake
6Number plate
7Safety kill-switch
8 On-o switch/Battery level indicator
9Fender
10 Tire
11 Front fork
12 Speed & torque control button
13 Foot pegs
14 Kick stand
15 Motor
16 Shock absorber
17 Charge port
18 Controller
19 Seat
20 Battery
1
2
193
45
6
7
9
10
8
13
17

18
OWNER’S MANUAL
NOTE:
Be aware of the motorcycle’s chain
Under no circumstances should hands or other body parts be close to a moving motorcycle chain.
Riders should wear motorcycle boots without laces, and should not wear any loose clothing that could
be caught by the chain.
WARNING: ALWAYS RIDE WITH CHAIN COVER
The chain cover helps to prevent accidental injuries from the chain. Never ride your motorcycle
when the chain cover is not in place. Operating your motorcycle without the chain cover may
result in serious injury.
SPECIFICATIONS – KUBERG CROSS
TOP SPEED 27 KMH (17 MPH)
WEIGHT 35 kg (76 lbs)
POWER 3000 watts, 36 V motor
BATTERIES 3×12 Ah 12 V, sealed lead-acid
CONTROLLER PWM, 40 amp
INPUT STANDARD 110 V or 220 V
TRANSMISSION Clutchless one speed
11
12
14
15 16
18
20

19
OWNER’S MANUAL
FINAL DRIVE 69T / 10T, chain 219H
FRAME Steel double cradle tube frame, powder-coated
WHEELBASE 37” (94 cm)
SEAT HEIGHT 25” (63 cm)
HANDLEBAR HEIGHT 32.5” (83 cm)
FRONT BRAKE AND REAR BRAKES Hydraulic Disc Brake system Tektro Auriga
BRAKE DISCS 160 mm diameter
FORKS Suspension fork Spinner Grind
SHOCK ABSORBER Spring
TIRES 16” × 2.4” Kuberg Knobby
WEIGHT 77 lbs (35 kg)
COLORS White
WIFI WiFi ready - adapter sold separately
CARRYING CAPACITY Maximum 220 lbs (100 kg)
WARNING!
The KUBERG CROSS is designed to operate at 36 volts only. Use of any battery voltage other than
24 volts will result in motor failure. KUBERG Inc. considers modications and/or changes to its
electrical components to be a material alteration of its products, thereby cancelling any warran-
ties and/ or guarantees in their entirety. Kuberg Inc. will not be responsible for any injuries, and/
or death and/or other damage(s) caused by such modications.

20
OWNER’S MANUAL
BEFORE FIRST RIDE
NOTE:
If you purchased your KUBERG motorcycle at a local dealer your motorcycle may be fully adjusted and
ready to ride. If you purchased your KUBERG still in the original packing, please carefully follow the
instructions below and any supplemental instructions to nish the assembly and adjustment of your
KUBERG.
UNPACKING AND ASSEMBLY
WARNING:
Failure to properly assemble and adjust your bike prior to use may result in an accident result-
ing in death, serious injury and/or property damage. If you are uncertain about any aspect of
the assembly and adjustment of your bike, seek help from a qualied mechanic or the KUBERG
Customer Service.
1Remove your KUBERG bike from the box.
2Lower kickstand and place your KUBERG on a solid & level surface.
3Remove all the packing materials.
4Using the supplied Allen wrench, make sure the steering stem is in the forward facing posi-
tion and tighten the top and side bolts securely and evenly. Secure the handlebars tightly in
the steering stem. Double check tightness and alignment.
5Adjust the brake lever positions to suit the rider.
FIRST SETUP
1 Check tire pressure of both tires and conrm they are properly inated. The optimal tire
pressure for Kuberg Start/Trial E/Cross is 35-40 PSI (2.4–2.8 bar) for general use and should
never exceed 50 PSI (3.4 bar).
2Unpack charger from its box and charge the batteries, make sure to follow the correct
charging procedure. Go to page xxx to nd detailed charging instructions.
3Compress each brake lever. The lever should not compress completely to the handlebar.
Each individual brake should hold the bike securely when you push the motorcycle against
the brake. If your brake needs adjustment, follow the instructions on page xxx. For begin-
ner riders adjust the front brake so it will not lock the front wheel easily. All riders should be
aware which lever operates which brake.
4Check the chain for tightness and lubrication.
5Setup up power and speed settings to an adequate level to the rider’s experience and riding
skills. Go to page xxx to nd detailed instructions how to set up top speed limits and dier-
ent riding modes.
