0KUENDER Co., Ltd.
KUENDER
Remote controller
KD-TPMS-C02
User’s Guide
Version 4.1c

1KUENDER Co., Ltd.
Content
1. Warning...........................................................................................................................2
2. Specification ...................................................................................................................3
3. Contents list.....................................................................................................................3
4. Description of the interface of remote controller and operating function settings
(option):...............................................................................................................................4
Appendix.............................................................................................................................9

2KUENDER Co., Ltd.
1. Warning
FCC warning
The system is in compliance with U.S. FCC regulation term 15th requirements.
However, users are advised to aware the following matters: (1) The system may be not
work due to surrounding interferences. (2) The system may be failed due to incorrect
operation.
Warning: Any changes or modifications are not expressly approved by the
manufacturer could void the user's authority to operate the equipment.
Function of the warning system
• Pressure Low warning: (when tire pressure lower than warning value (default= 23
psi))
• Pressure High warning: (when tire pressure higher than warning value (default= 45
psi))
• Battery operation voltage low warning: (when battery operation voltage is in low
level)
• Temperature abnormal warning: (when tire temperature higher than warning value
(default= 185℉))
Warnings in using the device:
• In order to operate the system in normal condition, do not dismantle any element or
outer shell of the system.
• The front shield glass should avoid from using metallic heat insulation film.

3KUENDER Co., Ltd.
2. Specification
Spec. of remote controller:
System power CR-2032 (3V)
Working temp. 14℉~ 167℉
Storage temp. -4℉~185℉
Working frequency 433.92MHz
Modulation method FSK
Life cycle > 1 year
3. Contents list
The contents of the wireless pressure monitoring system include:
NO. Items Q’ty
1 Remote controller (option): 1
Remote controller

4KUENDER Co., Ltd.
4. Description of the interface of remote controller and operating
function settings (option):
The interface of remote controller:
The settings of operating function:
The remote controller is incorporated with KD-TPMS-T04R05. It is necessary to
enter into receiver setting mode before setting the remote controller functions which is
shown as follows:
1. Turn on remote controller: Insert ID card into the remote controller (any one
of the 4 colors cards) as shown below:
2. Press the “Enter” key of the remote controller several times within 10sec. after
turn on the receiver and wait until ID, ℉、psi indicators all light up and enter
Push button
indicator
Battery cover
Direction key/ numerical +/-key
Function confirmation key
Function exiting key

5KUENDER Co., Ltd.
into the setting mode as shown below for menu selecting:
ID card insert remote controller
Product KD-TPMS-T04R05
A. The setting of pressure warning value
Tire pressure setting menu: select P and press Enter to show up the upper/ lower
limit value of the front/ rear tires. In which, the upper value of the front wheel will be
flashed first for setting. Press Enter to confirm and jump to the lower value of the front
Insert ID card here
Setting Hi/Lo tire pressure
warningvalue
Front wheel
Rear wheel
Upper limit lower limit

6KUENDER Co., Ltd.
wheel in flashing for setting. The sequence of flashing and setting is: upper limit/ front
wheel Ælower limit/ front wheel Æupper limit/ rear wheel Ælower limit/ rear wheel.
Press Return key to finish setting mode and the setting is finished after re-start.
Initial value: upper limit at 45 psi, lower limit at 23 psi.
B. The setting of temperature warning value
In setting mode, press ↑to select ℉and enter into the temperature setting of upper
limit (with ℉indicator lighted). To use direction key (↑↓) on the remote controller to
adjust the temperature value as required, then press Enter to complete and go back to the
menu. Press Return to exit setting mode and the device will be had sat after restarting.
Initial value: upper value at 185℉
C. The exchange of tire location
In setting mode, press ↑key to select ID, then press Enter to go into ID setting
mode with left upper wheel displayed in “---”. Select the tire location to be exchanged,
insert the ID card and press Enter to complete the setting with SET displayed on the
screen and “b” twice. Press Return to go back to the setting menu. Press Return again to
exit. Re-start the device to complete.
Four colors ID cards in red, yellow, green and blue represent the right front, right
rear, left rear and left front wheel location respectively and correspond to the color label
on the sensor as follows:
Setting upper limit
temp. warning value

7KUENDER Co., Ltd.
Example of operating
The setting process of exchanging left rear wheel to the left front:
1. Enter into setting mode
2. Select ID in menu as shown in figure:
3. Press Enter to go into the ID setting mode. The left front wheel will display
“---“ as shown below:
4. Insert the ID card of the left rear wheel into the remote controller, then press
Enter to complete with “SET” displayed and “b” twice, then go back to “---
“in2seconds. as shown below:

8KUENDER Co., Ltd.
5. Press Return and go back to the setting menu as shown below:
6. Press again the Return key and exit the setting mode, re-start up the device to
complete the tire exchanging.
7. The process of exchanging other wheels is the same as above from step1~step
6.
***Users are advised to keep ID card safely and securely. In case of
missing, please inquire from the manufacturer (by providing the sensor
serial no.).
***Users without remote controller should bring ID card to the original
installation factory if changing tire location is required.

9KUENDER Co., Ltd.
Appendix
Unit :
1 psi = 6.895 kpa
1 kpa=0.145 psi
℃= (ºF -32)*5/9
Normal range of tire pressure:
The slight variation of tire pressure resulted from some external factors during the
driving is normal. Generally speaking, variation scope shall be within 3 ~ 2 psi according
to standard tire pressure of 32 psi. Hence, variation of 29 psi ~ 35 psi is normal during the
driving.
The replacement of sensor:
The battery life of the sensor is at least 3 years in normal operating condition.
The warranty of the sensor is one year.
Knowledge of using tires:
It is important to keep the correct tire pressure all the time that the life cycle
can be extended and the accident can be avoided. Besides, never flat the tire when tire
is hot. Don’t use recycled tires or never to use the different model of tires on the same
axle. Keep in mind these important rules would guarantee the safety of tires and
vehicles.
