SOMFY INTEO TELIS 4 RTS User manual

Operating and installation guide
Telis 4 RTS
Ref. 5054465A
www.somfy.com

1. Brief introduction to the Telis 4 RTS remote control 3
1.1 What is the Telis 4 RTS for? 3
1.2 A few denitions 3
2. Safety - Important information 4
2.1 Installation and commissioning 4
2.2 Operating 4
2.3 Environment 5
3. Content of the kit and tools required 5
3.1 List of parts 5
3.2 Tools required 5
4. The Telis 4 RTS in detail 6
4.1 Components 6
4.2 Technical data 6
5. How does the Telis 4 RTS operate? 6
5.1 Channels and indicator lights 6
5.2 Choice of products to be controlled 8
6. Adding a new Telis 4 RTS 12
6.1 Identifying the original control point 12
6.2 One-touch point 13
6.3 Point with Up/STOP/Down buttons 16
6.4 Timer 18
6.5 Situo control point 20
6.6 Telis 1 RTS/Telis Soliris RTS remote controls 21
7. Replacing a lost or broken control point 23
7.1 Sole control point lost or broken 23
7.2 One lost or broken control point amongst others 24
8. Mounting the bracket 24
9. Everyday use of the Telis 4 RTS 24
9.1 Channel selection 24
9.2 Up and Down buttons 25
9.3 My button 25
9.4 Replacing the battery 25
9.5 Maintenance 26
10. Problems with the Telis 4 RTS? 26
Contents
2Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS

Somfy’s expertise delivers satisfaction guaranteed.
Thank you for choosing a Somfy Telis 4 RTS .
Before installing and using the Telis 4 RTS, please read this guide
carefully.
Somfy solutions animate your windows and entrances to bring your
whole house alive. Somfy solutions are designed so that everyone can
enjoy the benets of the products in their home, based on their specic
requirements.
In this guide, the term ‘product’ can include your awning, blind, curtain,
garage door, gate, projection screen, roller shutter.
Well thought-out and easy to use, Somfy solutions are one of life’s little
daily pleasures, making home life more enjoyable.
1. Brief introduction to the Telis 4 RTS remote
control
1.1 What is the Telis 4 RTS for?
The Telis 4 RTS is a wireless radio remote control compatible only
with products tted with Radio Technology Somfy (RTS): roller shutter
motors, awning motors, etc.
The Telis 4 RTS makes it possible to control several products individually
or all at the same time using just this one remote control handset. This is
made possible by the Telis 4 RTS using a 5 channel radio system, each
channel being identied by the indicator lights. The Telis 4 RTS also
makes it possible to control several products at once.
1.2 A few denitions
Installation
All of the Radio Technology Somfy products a house is equipped with.
Favourite position:
The favourite position is your ideal position for your product in certain
common situations, for example, your awning partially extended when
you are dining beneath it in summer but don’t want to deprive your
houseplants of sunlight; shading your computer screen from glare by
partially closing your interior window blinds/curtains etc.
3
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
3

4Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
2. Safety - Important information
2.1 Installation and commissioning
Before installing and using the Telis 4 RTS, please carefully read these
instructions, which describe how to install, commission and operate the
Telis 4 RTS.
Never begin installing without rst checking the compatibility of the Telis
4 RTS with the associated equipment and accessories.
Any incorrect use will invalidate the warranty and Somfy's liability.
2.2 Operating
Somfy recommends that at least one control point is located close to -
the product or group of products.
Do not allow children to play with the xed control points. Keep remote
-
controls out of the reach of children.
Monitor the product (especially roller shutter/awning/garage door/gate)
-
while it is moving, especially during commissioning of the Telis 4 RTS,
and keep people at a distance until the product is completely closed.
Make sure the power supply to the product is turned off before any
-
maintenance operation in the vicinity of the product (for example, when
cleaning windows near your blind).
Avoid moving the product if ice has formed in it, unless the motor is
-
tted with anti-freeze protection.
Do not leave the Telis 4 RTS behind a window in full sunlight: the Telis
-
4 cannot withstand temperatures greater than 60°C.
Do not leave the Telis 4 RTS in a car in winter.
-
Do not immerse or soak the Telis 4 RTS in any liquid.-
Only use maintenance products recommended by Somfy.-
Frequently check the product (e.g. awning) to detect any defects in -
balance or any signs of wear. Do not use the product if a repair or
adjustment is required.

5
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
2.3 Environment
Damaged electrical or electronic products, such as used batteries,
should not be disposed of with household waste. Please take them to
a collection point or an approved centre to ensure they are recycled
correctly.
3. Content of the kit and tools required
3.1 List of parts
-Before starting installation and commissioning of the Telis 4 RTS,
check that all parts listed in the table below are present in the correct
quantity (Q):
No. Components Q.
1Telis 4 RTS remote control 1
2Mounting pin 1
3Bracket 1
4Plug 1
5Screw 1
6Identication sticker 1
3.2 Tools required
• Appropriate screwdriver for
the screws to be used
Insulated athead electricians •
screwdriver
Drill and drill bit•
Pencil•
4
3
1
5
2
1
2
3
4
5
6

6Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
4. The Telis 4 RTS in detail
4.1 Components
A. Up button
B. STOP/my button
C. Down button
D. Indicator lights
E. Selection Button
F. PROG button
4.2 Technical data
Dimensions in mm (H x w x d):
Pure model: 134 x 41 x 21 mm
Lounge, Silver, Patio models: 145 x 49 x 22 mm
Operating temperature: 0°C to + 60°C
Protection rating: Inside use, in a dry room - IP 30
Frequency: 433.42 MHz
Range: 20 m through two concrete walls; 200 m in open space
Battery: 3 V, type CR 2430
5. How does the Telis 4 RTS operate?
5.1 Channels and indicator lights
5.1.1 Description
The Telis 4 RTS allows independent or simultaneous control of different
products.
This functionality is possible thanks to a 5 channel system, identied
by indicator lights: each channel corresponds to an individual remote
control and is associated with one or several indicator lights.
Each channel is independent and controls a product or group of
products. Navigation between the 5 channels is carried out using the
Selection button (E).
my somfy.com
C
B
A
F
D
E

7
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
5.1.2 Channel identication
The rst 4 channels are each represented
by an indicator light, the fth channel by all
4 indicator lights:
• Channel 1: the rst indicator light is
on,
Channel 2: the second indicator •
light is on,
Channel 3: the third indicator light •
is on,
Channel 4: the fourth indicator light •
is on,
Channel 5: all four indicator lights •
are on.
5.1.3 Channel selection
The Selection button (E) allows naviga-
tion between the 5 channels:
Press the Selection button (E) to select
-
the indicator light that corresponds with
the required channel, the channel for
the product to be controlled:
The indicator light will come on for
►
a few seconds and then turn off.
Press one of the three buttons, Up/
-
STOP/Down to control the operations.
Note: the Telis 4 RTS will store the last
channel activated. Press the Selection
button (E), the indicator light of the last
channel used will light up.
Channel 1:
Channel 2:
Channel 3:
Channel 4:
Channel 5:
E

8Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
5.2 Choice of products to be controlled
Note:
This section is illustrated with a specic example to explain the opera-
tion of the Telis 4 RTS and its channels. The blinds identied here can
be replaced with roller shutters or a combination of blinds and roller
shutters.
5.2.1 Context of use
To facilitate explanations, we will use a group of 4 blinds in a home of
the following types:
Kitchen blind,•
Study blind,•
Living Room blind No.1 called Living Room bind 1,•
Living room blind No.2 called Living Room blind 2.•
Each of these blinds are tted with an individual control point.
The purpose in installing the Telis 4 RTS is to be able to control these
4 blinds independently but also on certain occasions all 4 blinds at the
same time.
In order to control these 4 blinds with the Telis 4 RTS, each blind must be
allocated a channel and then all 4 blinds allocated to the fth channel.
5.2.2 Allocating a channel to a blind
Note: This step is to choose which chan-
nel to allocate to which product. It is not
to make the allocation itself.
-Choosing which channel to associate
to which blind:
Channel 1: Kitchen Blind•
Channel 2: Study Blind•
Channel 3: Living Room Blind 1•
Channel 4: Living Room Blind 2•
Channel 5: all 4 Blinds - Kitchen, •
Study, Living Room 1 and Living
Room 2.
Add these names to the identication
-
sticker.
-Apply the sticker to the back of the Telis
4 RTS as a guide.
1
2
3
4
5
Kitchen
Study
Living Room 1
Living Room 2
Kitchen, Study, Living Room 1 and 2

9
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
5.2.3 How can the Telis 4 RTS be
associated to each blind?
Note: A channel is associated with a
blind individually.
Kitchen Blind on channel 1
Identify the original control point asso--
ciated with the Kitchen blind.
Press the PROG button on the origi-
-
nal control point (refer to the section
“Adding a new Telis 4 RTS”) until the
blind moves briey.
-Press the Selection button (E) to light
up the rst indicator light (channel 1).
-Briey press the PROG button (F)
located on the back of the Telis 4 RTS:
The blind will perform a second
►
brief movement to indicate the new
Telis 4 RTS is programmed.
Study Blind on channel 2
Identify the original control point asso--
ciated with the Study blind.
Press the PROG button on the origi-
-
nal control point (refer to the section
“Adding a new Telis 4 RTS”) until the
blind moves briey.
-Press the Selection button (E) to
light up the second indicator light
(channel 2).
-Briey press the PROG button (F) loca-
ted on the back of the Telis 4 RTS:
The blind will perform a second
►
brief movement to indicate the new
Telis 4 RTS is programmed.
E
F
E
F

10 Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
Living Room Blind 1 on channel 3
Identify the original control point -
associated with the Living Room
1 blind.
Press the PROG button on the origi-
-
nal control point (refer to the section
“Adding a new Telis 4 RTS”) until the
blind moves briey.
-Press the Selection button (E) to light
up the third indicator light (channel 3).
Briey press the PROG button (F)
-
located on the back of the Telis 4 RTS:
The blind will perform a second
►
brief movement to indicate the new
Telis 4 RTS is programmed.
Living Room Blind 2 on channel 4
Identify the original control point -
associated with the Living Room
2 blind.
Press the PROG button on the origi-
-
nal control point (refer to the section
“Adding a new Telis 4 RTS”) until the
blind moves briey.
Press the Selection button (E) to
-
light up the fourth indicator light
(channel 4).
-Briey press the PROG button (F) loca-
ted on the back of the Telis 4 RTS:
The blind will perform a second
►
brief movement to indicate the new
Telis 4 RTS is programmed.
F
E
F
E

11
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
4 Blinds (Kitchen, Study, Living Room 1 and 2)
on channel 5
Press the PROG button of the original -
Kitchen blind control point until the
Kitchen blind moves briey.
-Press the Selection button (E) to light
up all 4 indicator lights (channel 5).
Briey press the PROG button (F)
-
located at the rear of the Telis 4 RTS
until the blind moves briey a second
time.
Press the PROG button of the original
-
Study blind control point until the Study
blind moves briey.
Press the Selection button (E) to light
-
up all 4 indicator lights (channel 5).
-Briey press the PROG button (F)
located at the rear of the Telis 4 RTS
until the Study blind moves briey a
second time.
Press the PROG button of the origi-
-
nal Living Room 1 blind control point
until the Living Room 1 blind moves
briey.
Press the Selection button (E) to light
-
up all 4 indicator lights (channel 5).
Briey press the PROG button (F)
-
located at the rear of the Telis 4 RTS
until the Living Room 1 blind moves
briey a second time.
Press the PROG button of the origi-
-
nal Living Room 2 blind control point
until the Living Room 2 blind moves
briey.
Press the Selection button (E) to light
-
up all 4 indicator lights (channel 5).
Briey press the PROG button (F)
-
located at the rear of the Telis 4 RTS
until the Living Room 2 blind moves
briey a second time.
E
F

12 Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
Press the Up button:-
All 4 blinds will move upwards.►
6. Adding a new Telis 4 RTS
6.1 Identifying the original control point
6.1.1 Installation recommendations
To add a Telis 4 RTS, use the control point linked to the product -
which controls only this product: pressing the Down or Up button only
causes movement of the product to which the new Telis 4 RTS must
be connected.
Caution! If there is no longer a control point linked to the product (all
the control points are broken or have been lost), contact the Somfy
assistance service.
N.B.: These instructions only describe the installation procedure for an addi-
tional Telis 4 RTS of the "individual control" type. Refer to the instructions for
advanced functions available on the Internet (address on the back cover of
these instructions) to install a control referred to as "group control".
On some roller products, inputs in programming mode and the addition
-
or deletion of a control point are signalled by a series of beeps emitted
by the motor. On other products, this is signalled by a brief movement
of the product.
Caution: If the product does not emit a beep or make a brief movement,
please contact the Somfy assistance service.
Place the product in the midway position before installing the new
-
Telis 4 RTS so that the movements can be easily seen.
6.1.2 Original control points
Find the original control point in the list below and refer to the para--
graph given to add the new Telis 4 RTS:
1) Control point xed to the wall with a
single button, called a One-touch
point, see paragraph 6.2;
2) Control point xed to the wall with
Up/STOP/Down buttons, called a
Point with Up/STOP/Down buttons,
see paragraph 6.3;
3) Programmer type control point,
called a Timer (3), see paragraph
6.4;
3
2
1

13
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
4) Situo control point xed to the wall,
see paragraph 6.5;
5a) Telis 1 RTS remote control, see
paragraph 6.6 ;
5b) Telis Soliris RTS remote control,
see paragraph 6.6;
6a)Telis 4 RTS remote control, see
paragraph 6.7;
6b) Telis Soliris RTS remote control, see
paragraph 6.7.
6.2 One-touch point
Move close to the product to install the
new Telis 4 RTS.
6.2.1 Identifying the model
Check that the original control point -
has an elongated button.
Bring the product to the midway
-
position.
Remove the front cover from the one-
-
touch point:
One-touch point with a white and grey front
cover
Gently remove the front cover with a -
at, pointed tool (such as a athead
screwdriver) where the white section
and the grey section join.
Lever it and lift the cover, without
-
using force, to detach the mounting
lugs from the front cover.
One-touch point with a white front cover
Lever it with a at, pointed tool -
(such as a athead screwdriver),
without using force, around the
upper section of the front cover to
detach it from its mounting.
45a 5b 6a 6b

14 Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
-Turn the front cover over to nd out the
model:
If there is a metal plate inscribed
-
PROG next to the battery: model A.
If there is no metal plate inscribed
-
PROG next to the battery: model B.
6.2.2 Adding the Telis 4 RTS
Model A:
-Make a contact between the PROG
metal plate on the electrical circuit and
the battery bracket using a athead
screwdriver, until the product moves
briey (or there is a series of 3 beeps):
the programming function is activated
for approximately 2 minutes.
Take the new Telis 4 RTS.
-
-Press the Selection button (E) to light
up the indicator light that corresponds
to the channel to which the product will
be associated.
-Press the PROG button (F) on the
new Telis 4 RTS briey with the tip of
a pencil: the product will make another
brief movement (or emit a series of
8 beeps) to indicate that the new Telis
4 RTS is stored.
A B
E
F

15
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
-Press the Down button on the new Telis
4 RTS:
If the product is lowered, the
-
Telis 1 RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
Replace the original control point front
-
cover:
One-touch point with a white and grey front
cover
Insert the mounting lugs into their -
notches on one side of the front
cover.
Press on the other side until it clicks,
-
to x the front cover in its bracket.
One-touch point with a white front cover
Ret the front cover on its bracket.-
Model B:
-Remove the battery from the original
control point using a plastic object.
Press on the centre section of the one-
-
touch point button.
Ret the battery in the base of its brac-
-
ket (with text legible).
Press the button again until the product
-
moves briey (or there is a series of
3 beeps): the programming function is
activated for approximately 2 minutes.
Take the new Telis 4 RTS.
-
-Press the Selection button (E) to light
up the indicator light that corresponds
to the channel to which the product will
be associated. E

16 Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
Press the PROG button (F) on the -
new Telis 4 RTS briey with the tip of
a pencil: the product will make another
brief movement (or emit a series of
8 beeps) to indicate that the new Telis
4 RTS is stored.
-Press the Down button on the new Telis
4 RTS:
If the product is lowered, the
-
Telis 1 RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
Retting the front cover:
-
One-touch point with a white and grey front
cover:
Insert the mounting lugs into their -
notches on one side of the front
cover.
Press on the other side until it clicks,
-
to x the front cover in its bracket.
One-touch point with a white front cover:
Ret the front cover on its bracket-
6.3 Point with Up/STOP/Down
buttons
Move close to the product to install the
Telis 4 RTS.
6.3.1 Checking the compatibility
-Bring the product to the midway
position.
Cut off the mains power supply or
-
detach the battery connected to the
motor (eg for a battery operated roller
blind).
Remove the front cover:
-
Gently remove the front cover with a -
at, pointed tool (such as a athead
screwdriver) where the white section
and the grey section join.
Lever it and lift the cover, without
-
using force, to detach the mounting
F

17
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
lugs from the front cover.
-Turn the front cover over: the
PROG button is located next to the
battery (b).
Caution! If after removing the front cover,
no PROG button is found, this means
that the control point is not compatible:
the Telis 4 RTS cannot be linked to the
product.
6.3.2 Adding the Telis 4 RTS
Switch the mains power supply back on -
or reconnect the battery to the motor.
-Press the PROG button (b) on the
original control point until the product
moves briey (or a series of 3 beeps is
emitted): the programming function is
activated for approximately 2 minutes.
Take the new Telis 4 RTS.
-
-Press the Selection button (E) to light
up the indicator light that corresponds
to the channel to which the product will
be associated.
-Press the PROG button (F) on the Telis
4 RTS briey with the tip of a pencil:
the product will make another brief
movement (or emit a series of 8 beeps)
to indicate that the new Telis 4 RTS is
stored.
b
b
E
F

18 Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
-Press the Down button on the new Telis
4 RTS:
If the product is lowered, the
-
Telis 4 RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
Replace the original control point front
-
cover:
Insert the mounting lugs into their
-
notches on one side of the front
cover.
Press on the other side until it clicks,
-
to x the front cover in its bracket.
6.4 Timer
Move close to the product to install the
Telis 4 RTS.
6.4.1 Checking the compatibility
-Bring the product to the midway
position.
Cut off the mains power supply or
-
detach the battery connected to the
motor (eg for a battery operated roller
blind).
Remove the front cover:
-
Lever it with a at, pointed tool -
(such as a athead screwdriver),
without using force, around the
upper section of the front cover to
detach it from its mounting.
-The PROG button is located on top
of the screen and is shaped like a
tab (c).
Caution! If after removing the front cover,
no PROG button is found, this means
that the control point is not compatible:
the Telis 4 RTS cannot be linked to the
product.
c

19
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
6.4.2 Adding the Telis 4 RTS
Switch the mains power supply back on -
or reconnect the battery to the motor.
-Press the tab (c) until the product
moves briey (or there is a series of
3 beeps): the programming function is
activated for approximately 2 minutes.
Take the new Telis 4 RTS.
-
-Press the Selection button (E) to light
up the indicator light that corresponds
to the channel to which the product will
be associated.
-Press the PROG button (F) on the
new Telis 4 RTS briey with the tip of
a pencil: the product will make another
brief movement (or emit a series of
8 beeps) to indicate that the new Telis
4 RTS is stored.
-Press the Down button on the new Telis
4 RTS:
If the product is lowered, the
-
Telis 4 RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
Replace the original control point front
-
cover:
Insert the front cover on its brac-
-
ket, allowing the buttons to come
through their housings.
Press the front until it clicks, to x
-
the front cover in its bracket.
c
E
F

20 Copyright © 2008 Somfy SAS. All rights reserved.
Telis 4 RTS
6.5 Situo control point
Move close to the product to install the
Telis 4 RTS.
6.5.1 Adding the Telis 4 RTS
Bring the product to the midway -
position.
-Remove the front cover from the Situo:
Gently remove the front cover with a
-
at, pointed tool (such as a athead
screwdriver) around the lower
section.
Lever it and lift the cover, without
-
using force, to detach the mounting
lugs from the front cover.
Turn the front cover over: the
-
PROG button is located next to the
battery (d).
-Press the PROG button (d) on the
Situo until the product moves briey
(or a series of 3 beeps is emitted): the
programming function is activated for
approximately 2 minutes.
Take the new Telis 4 RTS.
-
-Press the Selection button (E) to light
up the indicator light that corresponds to
the channel to which the product will be
associated.
-Press the PROG button (F) on the new
Telis 4 RTS briey with the tip of a pencil:
the product will make another brief
movement (or emit a series of 8 beeps)
to indicate that the new Telis 4 RTS is
stored.
Press the Down button on the new Telis
-
4 RTS:
If the product is lowered, the
-
Telis 4 RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
d
E
F
