Kuppersberg F103510 Installation and maintenance instructions

DISHWASHER
ПОСУДОМОЕЧНАЯ МАШИНА
Technical passporT
пАспорт технического изделиЯ
GL6088

2
Technical passporT english
dishwasher
CONTENTS
HEALTH AND SAFETY GUIDE
SAFETY INSTRUCTIONS...............................................................................................................3
SAFEGUARDING THE ENVIRONMENT..................................................................................5
DECLARATION OF CONFORMITY............................................................................................5
USE AND CARE GUIDE
PRODUCT DESCRIPTION..............................................................................................................6
APPLIANCE ..........................................................................................................................................6
CONTROL PANEL..............................................................................................................................6
FIRST TIME USE ................................................................................................................................6
REFINED SALT AND RINSE AID................................................................................................6
DETERGENT.........................................................................................................................................8
PROGRAMS TABLE...........................................................................................................................9
PROGRAMS DESCRIPTION..........................................................................................................9
OPTIONS AND FUNCTIONS.........................................................................................................10
LOADING THE RACKS.....................................................................................................................10
UPPER RACK........................................................................................................................................11
LOWER RACK.......................................................................................................................................12
CUTLERY RACK..................................................................................................................................12
DAILY USE.............................................................................................................................................12
TIPS..........................................................................................................................................................13
CARE AND MAINTENANCE..........................................................................................................13
CLEANING THE WATER INLET HOSE....................................................................................14
CLEANING THE FILTER ASSEMBLY........................................................................................14
CLEANING THE SPRAY ARMS....................................................................................................15
TROUBLESHOOTING ......................................................................................................................16
INSTALLATION...................................................................................................................................17
AFTER-SALES SERVICE.................................................................................................................18
INSTALLATION GUIDE.....................................................................................................................19

3
english Technical passporT
dishwasher
THANK YOU FOR BUYING
A KUPPERSBERG PRODUCT.
In order to receive a more complete
assistance, please register your appliance on
www.kuppersberg.ru
HEALTH AND SAFETY GUIDE
SAFETY INSTRUCTIONS
IMPORTANT TO BE READ AND
OBSERVED
Before using the appliance carefully read
these safety instructions.
Keep them close at hand for future reference.
These instructions and the appliance itself
provide important safety warnings, to be
observed at all times.
The manufacturer declines any liability for
failure to observe these safety instructions, for
inappropriate use of the appliance or incorrect
setting of controls.
SAFETY WARNINGS
Very young (0-3 years) and young children
(3-8 years) shall be kept away from the
appliance unless continuously supervised.
Children from 8 years old and above and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge can use this appliance only
if they are supervised or have been given
instructions on safe use and understand the
hazards involved. Children must not play with
the appliance. Cleaning and user maintenance
must not be carried out by children without
supervision.
PERMITTED USE
CAUTION: The appliance is not intended to
be operated by means of an external timer or
separate remote controlled system.
This appliance is solely for domestic, not
professional use.
Do not use the appliance outdoors.
Do not store explosive or  ammable
substances such as aerosol cans and do not
place or use gasoline or other  ammable
materials in or near the appliance: a  re may
break out if the appliance is inadvertently
switched on.
This appliance is intended to be used in
household and similar applications such as:
Âstaff kitchen areas in shops, of ces and
other working environments;
Âfarm houses;
Âby clients in hotels, motels and other
residential type environments;
Âbed and breakfast type environments.
The appliance must be used only to wash
domestic crockery in accordance with the
instructions in this manual.
The water supply tap must be shut off
and the plug should be removed from the
electrical socket at the end of every cycle and
before cleaning the appliance or carrying out
any maintenance work.
Disconnect also the appliance in the event
of any malfunction.
INSTALLATION
The appliance must be handled and installed
by two or more persons. Use protective gloves
to unpack and install the appliance.
Installation and repairs must be carried
out by a quali ed technician, in compliance
with the manufacturer’s instructions and local
safety regulations. Do
not repair or replace any part of the
appliance unless speci cally stated in the user
manual.
Children should not perform installation
operations. Keep children away during
installation. Keep the packaging materials
(plastic bags, polystyrene parts, etc.) out
of reach of children, during and after the
installation.
After unpacking the appliance, make sure
that it has not been damaged during transport.

4
Technical passporT english
dishwasher
In the event of problems, contact the dealer or
your nearest Aftersales Service.
The appliance must be disconnected from
the power supply before any installation
operation.
During installation, make sure the appliance
does not damage the power cable.
Only activate the appliance when the
installation has been completed.
Connection to the mains water supply must
be carried out by a qualied technician in
compliancewiththemanufacturers instructions
and applicable local safety regulations.
The appliance is to be connected to the
water mains using new hose sets. The old
hose-sets should not be reused. All hoses must
be securely clamped to prevent them coming
loose during operation. All local waterboard
regulations must be complied with. Water
supply pressure 0.05 - 1.0 MPa.
The inlet water temperature depends on the
dishwasher model. If the installed inlet hose
is marked «25°C max», the maximum allowed
water temperature is 25°C. For all other models
the maximum allowed water temperature is
60°C.
Do not cut hoses and, in the case of
appliances tted with a waterstop system, do
not immerse the plastic casing containing the
inlet hose in water.
If hoses are not long enough, contact your
local dealer.
Make sure the inlet and drain hoses are
kink-free and are not crushed. Before using the
appliance for the rst time, check the water
inlet and drain hose for leaks.
During use, the access to the rear wall
should be limited in a sustainable manner
such as approaching the device to the wall or
furniture board.
When installing the appliance make sure
that the four feet are stable and resting on the
oor, adjusting them as required, and check
that the appliance is perfectly levelled using
a spirit level.
If installing the appliance at the end of a
row of units making the side panel accessible,
the hinge area must be covered to prevent risk
of crushing.
For dishwashers having ventilation
openings in the base, the openings must not
be obstructed by a carpet.
ELECTRICAL WARNINGS
For installation to comply with current
safety regulations, an omnipolar switch with
minimum contact gap of 3mm
is required and the appliance must be
earthed.
If the power cable is damaged, replace
with an identical one. The power cable must
only be replaced by a qualied technician in
compliance with the manufacturer instruction
and current safety regulations. Contact an
authorized service centre. If the tted plug is
not suitable for your socket outlet, contact a
qualied technician. The power cable must be
long enough to connect the appliance, once
tted in its housing, to the main power supply.
Do not pull the power supply cable.
Do not use extension leads, multiple sockets
or adapters.
Do not operate this appliance if it has a
damaged mains cord or plug, if it is not working
properly, or if it has been damaged or dropped.
Keep the cord away from hot surfaces. The
electrical components must not be accessible
to the user after installation. Do not touch the
appliance with any wet part of the body and do
not operate it when barefoot.
CORRECT USE
The water in the dishwasher is not potable.
The maximum number of place settings is
shown in the product sheet.
The door should not be left in the open
position since this could present a tripping
hazard. The open dishwasher door can only

5
english Technical passporT
dishwasher
support the weight of the loaded rack when
pulled out. Do not rest objects on the door or
sit or stand on it.
Use only detergent and rinse additives
designed for an automatic dishwasher.
WARNING: Dishwasher detergents are
strongly alkaline. They can be extremely
dangerous if swallowed. Avoid contact with
the skin and eyes and keep children away from
the dishwasher when the door is open.
Check that the detergent receptacle is
empty after completion of the wash cycle.
Store the detergent, rinse aid and salt out of
reach of children. WARNING: Knives and other
utensils with sharp points must be loaded in
the basket with their points down or placed in
a horizontal position.
The water supply tap must be shut off and
the plug should be removed from the electrical
socket at the end of every program and before
cleaning the dishwasher or carrying out
any maintenance work. Disconnect also the
dishwasher in the event of any malfunction.
CLEANING AND MAINTENANCE
Never use steam cleaning equipment.
Wear protective gloves for cleaning and
maintenance.
The appliance must be disconnected from
the power supply before any maintenance
operation.
SAFEGUARDING
THE ENVIRONMENT
DISPOSAL OF PACKAGING MATERIALS
The packaging material is 100% recyclable
and is marked with the recycle symbol:
The various parts of the packaging must
therefore be disposed of responsibility and in
full compliance with local authorityregulations
governing waste disposal.
SCRAPPING OF HOUSEHOLD
APPLIANCES
When scrapping the appliance, make it
unusable by cutting off the power cable and
removing the doors and shelves (if present) so
that children cannot easily climb inside and
become trapped.
This appliance is manufactured with
recyclable
or reusable materials. Dispose of it in
accordancewithlocalwaste disposalregulations.
For further information on the treatment,
recovery and recycling of household electrical
appliances, contact your competent local
authority, the collection service for household
waste or the store where you purchase the
appliance.
This appliance is marked in compliance
with European Directive 2012/19/EU, Waste
Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of
correctly, you will help prevent potential
negative consequences for the environment and
human health, which could otherwise be caused
by inappropriate waste handling of this product.
The symbol on the product
or on the accompanying documentation
indicates that it should not be treated as
domestic waste but must be taken to an
appropriate collection centre for the recycling
of electrical and electronic equipment.
DECLARATION OF CONFORMITY
This appliance has been designed,
constructed and distributed in compliance with
the requirements of European Directives:
LVD 2014/35/EU,EMC 2014/30/ EU and RoHS
2011/65/EU.
This appliance has been designed,constructed
and distributed in compliance with the
Ecodesign and energy Labelling Requirements
of EC Directives: 2009/125/EC and 2010/30/EU.

6
Technical passporT english
dishwasher
PRODUCT DESCRIPTION
APPLIANCE
FIRST TIME USE
ADVICE REGARDING THE FIRSTTIME USE
After the installation, remove the stoppers
from the racks and the retaining elastic
elements from the upper rack.
WATER SOFTENER SETTINGS
Before starting the  rst wash program, set
the hardness level of the water from the mains
supply FILLING THE SALT RESERVOIR.
First load the softener tank with water, then
introduce about 1 kg of salt. It is perfectly
normal for water to  ow out.
As soon as this procedure is complete, run
a program without loading. The «Pre-wash»
program alone is NOT suf cient.
Residual saline solution or grains of salt
can lead to deep-down corrosion, irreparably
damaging the stainless steel components.
The guarantee is not applicable if faults are
caused by such circumstances.
      
designed for dishwashers.
After the salt has been poured into the
machine, the SALT REFILL indicator light
switches off.
  
softener and the heating element may be
damaged as a result.
REFINED SALT AND RINSE AID
      
     
especially if the water is hard or very hard
(follow the instructions given on the packaging).

REFILL and RINSE AID REFILL indicator lights
will remain lit.
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of
LIMESCALE on the dishes and on the machine’s
functional components.
ÂIt is important that the salt reservoir be
never empty.
1. Upper rack
2. Cutlery rack
3. Foldable  aps
4. Upper rack height
adjuster
5. Upper spray arm
6. Lower rack
7. Lower spray arm
8. Filter Assembly
9. Salt reservoir
10. Detergent and Rinse
Aid dispensers
11. Rating plate
12. Control panel

1. On-Off/Reset button with
indicator light
2. Program selection button
3. Salt re ll indicator light
4. Rinse Aid re ll indicator
light
5. Program number and
remaining time indicator
6. Delay indicator light
7. Display
8. Multizone indicator light
9. Delay button
10. Multizone button
11. Tablet (Tab) button with
indicator light

7
english Technical passporT
dishwasher
ÂIt is important to set the water hardness.
The salt reservoir is located in the lower part
of the dishwasher PRODUCT DESCRIPTION and
should be  lled:
Âwhen the SALT REFILL indicator light
on the control panel is lit.
1. Remove the lower rack and unscrew the
reservoir cap (anticlockwise).
2. Position the funnel (see gure) and  ll the
salt reservoir right up to its edge (approximately
1 kg); it is not unusual for a little water to leak
out.
3. Remove the funnel and wipe any salt
residue away from the opening.
Make sure the cap is screwed on tightly, so
that no detergent can get into the container
during the wash program (this could damage
the water softener beyond repair).
      
recommend carrying out the procedure before
the washing cycle is started.
SETTING THE WATER HARDNESS
To allow the water softener to work in
a perfect way, it is essential that the water
hardness setting is based on the actual water
hardness in your house. This information can
be obtained from your local water supplier.
The factory setting is for average (3) water
hardness.
1. Switch on the appliance by pressing the
ON/OFF button.
2. Switch off the appliance by pressing the
ON/OFF button.
3. Hold down button P for 5 seconds, until
you hear a beep.
4. Switch on the appliance by pressing the
ON/OFF button.
5. The current selection level number and
the salt indicator light both  ash.
6. Press button P to select the desired
hardness level (see Water Hardness Table).
7. Switch off the appliance by pressing the
ON/OFF button.
Setting is complete!
Even if using multi-functional tablets, the
salt dispenser should still be  lled.
Water Hardness Table
Level °dH
German degrees
°fH
French degrees
1Soft 0 - 6 0 - 10
2 Medium 7 - 11 11 - 20
3 Average 12 - 17 21 - 30
4 Hard 18 - 34 31 - 60
5 Very hard 35 - 50 61 - 90
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The
rinse aid dispenser A should be  lled when
the RINSE AID REFILL indicator light on the
control panel is lit.
1. Open the dispenser B by pressing and
pulling up the tab on the lid.
2. Carefully introduce the rinse aid as far as
the maximum (110 ml) reference notch of the
 lling space - avoid spilling it. If this happens,
clean the spill immediately with a dry cloth.
3. Press the lid down until you hear a click
to close it.
NEVER pour the rinse aid directly into the
tub.
ADJUSTING THE DOSAGE
OF RINSE AID
If you are not completely satis ed with the
drying results, you can adjust the quantity of
rinse aid used.

8
Technical passporT english
dishwasher
ÂSwitch the dishwasher on using the ON/
OFF button.
ÂSwitch it off using the ON/OFF button.
ÂPress button P three times - a beep will be
heard.
ÂSwitch it on using the ON/OFF button.
ÂThe current selection level number and
rinse aid indicator light  ash.
ÂPress button P to select the level of rinse
aid quantity to be supplied.
ÂSwitch it off using the ON/OFF button
Setting is complete! If the rinse aid level is
set to ZERO (ECO), no rinse aid will be supplied.
The LOW RINSE AID indicator light will not
be lit if you run out of rinse aid. A maximum of
4 levels can be set according to the dishwasher
model.The factory setting is for a medium level.
ÂIf you see bluish streaks on the dishes, set
a low number (1-2).
ÂIf there are drops of water or limescale
marks on the dishes, set a high number (3-4)
DETERGENT
Only use detergent which has been
speci cally designed for dishwashers.
DO NOT USE washing up liquid.
Using excessive detergent may result in
foam residues remaining in the machine after
the cycle has ended.
To achieve the best washing and drying
results, the combined use of detergent, rinse
aid liquid and re ned salt is required.
We recommend using detergents that do
not contain phosphates or chlorine, as these
products are harmful to the environment.
FILLING THE DETERGENT DISPENSER
Good washing results also depend on
the correct amount of detergent being used.
Exceeding the stated amount does not result
in a more effective wash and increases
environmental pollution.
The amount can be adjusted to the soil
level. In the case of normally soiled items, use
approximately either 35g (powder detergent)
or 35ml (liquid detergent) and additional tea
spoon of detergent directly inside the tub. If
tablets are used, one tablet will be enough.
If the crockery is only lightly soiled or if it has
been rinsed with water before being placed in
the dishwasher, reduce the amount of detergent
used accordingly (minimum 25 g/ml) e.g. skip
the powder/gel putted inside the tub.
For good washing results also follow the
instructions shown on the detergent box.
For further questions please ask the
detergent producers.
To open the detergent dispenser use the
opening device A.
Introduce the detergent into the drydispenser
B only.
Place the amount of detergent for pre-
washing directly inside the tub.
ÂWhen measuring out the detergent refer
to the (see PROGRAMS TABLE) to add the
proper quantity. Compartment B comprises a
level showing the maximum quantity of liquid
or powder detergent that can be added to each
cycle.
ÂRemove detergent residues from the
edges of the dispenser and close the cover until
it clicks.
ÂClose the lid of the detergent dispenser by
pulling it up until the closing device is secured
in place.
The detergent dispenser automatically opens
up at the right time according to the program.
If all-in-one detergents are used, we
recommend using the TABLET button, because
it adjusts the program so that the best washing
and drying results are always achieved.

9
english Technical passporT
dishwasher
PROGRAMS TABLE
Program
Drying phase
Available options *)
Detergent
container Duration of
wash program
(h:min) **)
Water con-
sumption
(litres/cycle)
Energy con-
sumption
(kWh/cycle)
Tub B
1. Eco 50°    3:40 9,0 1,05
2. Auto-Normal
-   1:25-3:00 7,0-14,0 0,9-1,40
3. Intensive 65° -2:50 16,0 1,60
4. Daily 50° -1:30 13,0 1,15
5. Silent 50° -3:30 15,0 1,15
6. Rapid 30' 50° - - 0:30 9,0 0,55
7. Cristal 45° -1:40 11,5 1,20
8. Pre-Wash - - - 0:12 4,5 0,01
9. Sanitizing 65° -1:40 10,0 1,30
10. Self- Clean 65° - - - 0:50 8,0 0,85
ECO program data is measured under laboratory conditions according to European Standard EN 50242.
*) Not all options can be used simultaneously.
**) The duration of the program shown on the display or in the booklet is an estimate calculated on standard conditions. The actual time may
vary depending on many factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and
type of load,load balancing, additional selected options and sensor calibration.The sensor calibration can increase program duration up to 20 min.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
Instructions on wash cycle selection.
ECO
Normally soiled crockery. Standard program, the most
ef cient in terms of its combined energy and water
consumption.
AUTO-NORMAL
Automatic program for normally soiled pans and dishes.
INTENSIVE
Program recommended for heavily soiled crockery,
especially suitable for pans and saucepans (not to be used
for delicate items).
DAILY
Normally soiled crockery. Everyday cycle, that ensures
optimal cleaning performance in shorter time.
SILENT
Suitable for night-time operation of the appliance.
Optimum performance ensured.
RAPID 30’
Program to be used for lightly-soiled dishes with no dried
food residues. Ideal for 2 place settings.
CRISTAL
Cycle for delicate items, which are more sensitive to high
temperatures, for example glasses and cups.
PRE-WASH
Crockery to be washed later. No detergent to be used with
this program.
SANITIZING
Normally or heavily soiled crockery, with additional
antibacterial wash.
SELF-CLEAN
Cycle to be used to perform maintenance of the dishwasher.
It cleans the interior of the appliance using hot water.
Notes:
Optimum performance levels when using the “Rapid”
programs can be achieved by observing the maximum



10
Technical passporT english
dishwasher
OPTIONS AND FUNCTIONS
OPTIONS can be selected directlybypressing
the corresponding button (see CONTROL
PANEL).
If an option is not compatible with the

     
times and beeps will sound.The option will
not be enabled.
MULTIZONE
If there are not many dishes to be washed, a
half loading may be used in order to save water,
electricity and detergent.
Select the program and then press the
MULTIZONE button: the indicator over the
button lights up and the symbol of the chosen
rack will appear on the display. By default the
appliance washes dishes in all racks.
To wash only the speci c rack, press this
button repeatedly:
-shown on the display (only lower rack)
- shown on the display (only upper
rack)
- shown on the display (only cutlery rack)
- shown on the display (option is OFF
and the appliance will wash dishes in all racks).
Remember to load the upper or lower rack
       
accordingly.
TABLET (TAB)
This setting allows you to optimize the
performance of the program according to
the type of detergent used. Press the TABLET
button (the indicator light will light up ) if you
use combined detergents in tablet form (rinse
aid, salt and detergent in 1 dose).
      
option should be off.
DELAY
The start time of the program may be delayed
for a period of time between 1 and 12 hours.
1. Press the DELAY button: the corresponding
symbol appears on the display; each time you
press the button, the time (1 h, 2h, etc. up to
max. 12h) from the start of the selected wash
cycle will be increased.
2. Select the wash program and close the
door: the timer will begin counting down;
3. Once this time has elapsed, the indicator
light switches off and the wash cycle begins.
To adjust the delay time and select a shorter
period of time, press the DELAY button. To
cancel it, press the button repeatedly until the
selected delayed start indicator light switches
off.
The wash program will start automatically
as soon as the door is shut.
The Delay function cannot be set once a
wash cycle has been started.
LOADING THE RACKS
TIPS
Before loading the baskets, remove all food
residues from the crockery and empty the
glasses. You do not need to rinse beforehand
under running water.
Arrange the crockery so that it is held in place
 rmly and does not tip over; and arrange the
containers with the openings facing downwards
and the concave/convex parts placed obliquely,

11
english Technical passporT
dishwasher
UPPER RACK
Load delicate and light dishes: glasses,
cups, saucers, low salad bowls. The upper rack
has tip-up supports which can be used in a
vertical position when arranging tea/ dessert
saucers or in a lower position to load bowls
and food containers.
(loading
example for
the upper
rack)
ADJUSTING THE HEIGHT OF THE
UPPER RACK
The height of the upper rack can be
adjusted: high position to place bulky crockery
in the lower basket and low position to make
the most of the tip-up supports by creating
more space upwards and avoid collision with
the items loaded into lower rack.
The upper rack is equipped with a Upper
Rack height adjuster (see  gure), without
pressing the levers, lift it up by simply holding
the rack sides, as soon as the rack is stable
in its upper position. To restore to the lower
FOLDABLE FLAPS WITH ADJUSTABLE
POSITION
The foldable  aps can be positioned at three
different heights to optimize the arrangement
of crockery inside the rack.
Wine glasses can be placed safely in the
foldable  aps by inserting the stem of each
glass into the corresponding slots.
For optimum drying results incline foldable
 aps more.
To change the inclination, pull up the
foldable  ap, slide it slightly and position it as
you wish.
Use foldable  ap as a plastic boxes holder
to avoid relocation of light items by the water
jets in the wash cycle.
position, press the levers A at the sides of the
rack and move the basket downwards.
We strongly recommend that you do not
adjust the height of the rack when it is loaded.
NEVER raise or lower the basket on one side
only.
thus allowing the water to reach every surface
and  ow freely.
Warning: lids, handles, trays and frying pans
do not prevent the sprayer arms from rotating.
Place any small items in the cutlery basket.
Very soiled dishes and pans should be placed
in the lower basket because in this sector the
water sprays are stronger and allow a higher
washing performance.
After loading the appliance, make sure that
the sprayer arms can rotate freely.

12
Technical passporT english
dishwasher
LOWER RACK
For pots, lids, plates, salad bowls, cutlery etc.
Large plates and lids should ideally be placed
at the sides, to avoid interferences with the
spray arm.
(loading example for the lower basket)
The lower rack has tip-up supports which can
be used in a vertical position when arranging
plates or in a horizontal position (lower) to
load pans and salad bowls easily.
CUTLERY BASKET
The third rack was designed to house the
cutlery.
Arrange the cutlery as shown in the  gure.
DAILY USE
1. CHECK WATER CONNECTION
Check that the dishwasher is connected
to the water supply and that the top is open.
2. SWITCH ON THE DISHWASHER
Open the door and press the ON/OFF
button.
3. LOAD THE RACKS
(see LOADING THE RACKS)
4. FILLING THE DETERGENT
DISPENSER
(see PROGRAMS TABLE).
5. CHOOSE THE PROGRAM AND
CUSTOMISE THE CYCLE
Select the most appropriate program in
accordance with the type of crockery and its
soiling level PROGRAMS DESCRIPTION by
pressing the P button.
Select the desired options (see LOADING
THE RACKS).
6. START
Start the wash cycle by closing the door.
When the program starts you hear a beep.
7. END OF WASH CYCLE
The end of the wash cycle is indicated by
beeps and the flashing of the indicator light
of the selected program. Open the door and
A separate arrangement of the cutlery makes
collection easier after washing and improves
washing and drying performance.
Knives and other utensils with sharp edges
must be positioned with the blades facing
downwards.
The geometry of the rack makes it possible
to place such small items as coffee cups in the
area in the middle.

13
english Technical passporT
dishwasher
MODIFYING A RUNNING PROGRAM
If a wrong program was selected, it is
possible to change it, provided that it has only
just begun: open the door (be ware of HOT
steam!), press and hold the ON/OFF button,
the machine will switch off.
Switch the machine back on using the ON/
OFF button and select the new wash cycle and
any desired options; start the cycle by closing
the door.
ADDING EXTRA CROCKERY
Without switching off the machine, open
the door (be ware of HOT steam!) and place
the crockery inside the dishwasher.
Close the door and the cycle will begin from
the point at which it was interrupted.
ACCIDENTAL INTERRUPTIONS
If the door is opened during the wash cycle,
or if there is a power cut, the cycle stops. It
starts again from the point at which it was
interrupted once the door has been closed or
the electricity supply is restored.
TIPS
UNSUITABLE CROCKERY
ÂWooden crockery and cutlery.
ÂDelicate decorated glasses, artistic
handicraft and antique crockery. Their
decorations are not resistant.
ÂParts in synthetic material which do not
withstand high temperatures.
ÂCopper and tin crockery.
ÂCrockery soiled with ash,wax,lubricating
grease or ink.
The colours of glass decorations and
aluminium/silver pieces can change and fade
during the washing process.
Some types of glass (e.g. crystal objects) can
become opaque after a number of wash cycles
too.
DAMAGE TO GLASS AND CROCKERY
ÂOnly use glasses and porcelain
guaranteed bythe manufacturerasdishwasher
safe.
ÂUse a delicate detergent suitable for
crockery to avoid white strips on the glass
use.
ÂCollect glasses and cutlery from the
dishwasher as soon as the wash cycle is over.
HYGIENE
To avoid odour and sediment which can
be accumulated in the dishwasher please run
a high temperature program at least one a
month. Use a tea spoon of detergent and run
it without the loading to clean your appliance.
CARE AND MAINTENANCE
ATTENTION: Always unplug the appliance
when cleaning it and when performing
maintenance work.
Do not use  ammable liquids to clean the
machine.
switch off the appliance by pressing the ON/
OFF button.
Wait for a few minutes before removing
the crockery - to avoid burns.
Unload the racks, beginning with the
lower one.
The machine will switch off automatically

in order to minimise electricity consumption.
If the crockery is only lightly soiled or if it
has been rinsed with water before being

of detergent used accordingly.

14
Technical passporT english
dishwasher
If the inlet hose has a transparent coating,
periodically check if the colour intensi es
locally. If yes, the hose may have a leak and
should be replaced.
For water stop hoses: check the small safety
valve inspection window (see arrow). If it is red,
the water stop function was triggered, and the
hose must be replaced by a new one.
For unscrewing this hose, press the release
button while unscrewing the hose.
CLEANING THE WATER INLET HOSE
If the water hoses are new or have not been
used for an extended period of time, let the
water run to make sure it is clear and free of
impurities before performing the necessary
connections. If this precaution is not taken, the
water inlet could become blocked and damage
the dishwasher.
CLEANING THE FILTERA SSEMBLY
Regularly clean the  lter assembly so that
the  lters do not clog and that the waste water
 ows away correctly.
The  lter assembly consists of three  lters
which remove food residues from the washing
water and then recirculate the water. They
must be cleaned if you wish to achieve the
best results in every wash.
After several washes, check the  lter
assembly and if necessary clean it thoroughly
under running water, using a non-metallic
brush and following the instructions below:
1. Turn the cylindrical  lter A in an anti-
clockwise direction and pull it out.
PREVENTING UNPLEASANT ODOURS
Always keep the door of the appliance ajar
in order to avoid moisture from forming and
being trapped inside the machine.
Clean the seals around the door and detergent
dispensers regularly using a damp sponge. This
will avoid food becoming trapped in the seals,
which is the main cause behind the formation
of unpleasant odours.
CHEKING THE WATER SUPPLY HOSE
Check the inlet hose regularly for brittleness
and cracks. If damaged, replace it by a new hose
available through our After-Sales Service or
your specialist dealer.
Depending on the hose type:
CLEANING THE DISHWASHER
Any marks on the inside of the appliance
may be removed using a cloth dampened with
water and a little vinegar.
The external surfaces of the machine and
the control panel can be cleaned using a non-
abrasive cloth which has been dampened with
water. Do not use solvents or abrasive products.

15
english Technical passporT
dishwasher
2. Remove the cup  lter B by exerting a
slight pressure on the side  aps.
3. Slide out the stainless-steel plate  lter C.
4. Inspect the trap and remove any food
residues.NEVER REMOVE the wash-cycle pump
protection (black detail).
After cleaning the  lters, re-place the  lter
assembly and  x it in position correctly; this
is essential for maintaining the ef cient
operation of the dishwasher.
The dishwasher must not be used without


CLEANING THE SPRAY ARMS
On occasions, food residue may become
encrusted onto the spray arms and block the
holes used to spray the water. It is therefore
recommended that you check the arms from
time to time and clean them with a small non-
metallic brush.
To remove the upper spray arm, turn the
plastic locking ring in an anticlockwise
direction. The upper spray arm should be
replaced so that the side with the greater
number of holes is facing upwards.
The lower spray arm can be removed
by pressing on the side tabs and pulling it
upwards.
LEAVING THE MACHINE UNUSED FOR
EXTENDED PERIODS
Disconnect the appliance from the electricity
supply and shut off the water tap.
Leave the door of the appliance ajar.
When you return, run a program when the
dishwasher is empty.

16
Technical passporT english
dishwasher
TROUBLESHOOTING
Your dishwasher may not work properly.
Before contacting the Service Centre check if the problem can be solved by going through the following list.
PROBLEMS POSSIBLE CAUSES SOLUTIONS
The dishwasher
won't start or does
not respond to com-
mands.
The appliance has not been plugged in
properly. Insert the plug into the socket.
Power outage. The dishwasher starts automatically when the power returns.
The dishwasher door is not closed. Vigorously push the door until you hear the “click".
It does not respond to commands. Switch off the appliance by pressing the ON/OFF button, switch it back
on after approximately one minute and reset the program.
The door doesn't
lock.
Racks are not  t to the end. Verify that racks are fi t to the end.
The door is not lock. Vigorously push the door until you hear the “clack" sound.
The dishwasher
won't drain.
The wash cycle has not  nished yet. Wait until the wash cycle fi nishes.
The drain hose is bent. Check that the drain hose is not bent (see Installation Guide).
The sink drain pipe is blocked. Clean the sink drain pipe.
The  lter is clogged up with food residues Clean the  lter (see CLEANING THE FILTER ASSEMBLY).
The dishwasher
makes excessive
noise.
The dishes are rattling against each. Arrange the crockery correctly (see LOADING THE RACKS).
An excessive amount of foam has been pro-
duced.
The detergent has not been measured out correctly or it is not suitable
for use in dishwashers (see FILLING THE DETERGENT DISPENSER).
Reset dishwasher by pressing the DRAIN button (see OPTIONS AND
FUNCTIONS) and run new program without detergent.
The dishes have not
been dried.
The selected program hasn't any drying
phase.
Verify on the programs table if the selected program has the drying
phase.
The rinse aid has run out or the resolution
is not adequate.
Add the rinse aid or adjust the dosage levels higher (see FILLING THE
RINSE AID DISPENSER).
The dishes are made of non-stick or plastic. It is normal the presence of drops of water (see TIPS).
The dishes are not
clean.
The crockery has not been arranged properly. Arrange the crockery correctly (see LOADING THE RACKS).
The spray arms cannot rotate freely, being
hindered by the dishes. Arrange the crockery correctly (see LOADING THE RACKS).
The wash cycle is too gentle and/or
detergent ef ciency is low. Select an appropriate wash cycle (see PROGRAMS TABLE).
An excessive amount of foam has been pro-
duced.(see AFTER-SALES SERVICE)
The detergent has not been measured out correctly or it is not suitable
for use in dishwashers (see FILLING THE DETERGENT DISPENSER).
Reset dishwasher by pressing the DRAIN button (see OPTIONS AND
FUNCTIONS) and run new program without detergent.
The cap on the rinse aid compartment has
not been shut correctly. Make sure the cap of the rinse aid dispenser is closed.
The  lter is soiled or clogged. Clean the  lter assembly (see CARE AND MAINTENANCE).
There is no salt. Fill the salt reservoir (see FILLING THE SALT RESERVOIR).
The dishwasher does
not  ll the water.
No water in the water supply or the tap is
closed. Make sure there is water in the water supply or the tap running.
The inlet hose is bent. Make sure the drain hose is not bent (see INSTALLATION) reprogram
the dishwasher and reboot.
The sieve in the water inlet hose is clogged;
it is necessary to clean it
After having carried out the veri cation and cleaning, turn off and turn
on the dishwasher and restart a new program.
The dishes and
glasses show calcina
tion or a whitish
fi lm.
The salt level is too low. Fill the salt reservoir (see FILLING THE SALT RESERVOIR).
The adjustment of the water hardness is not
adequate. Increase the values (see Water Hardness Table).
The cap of the salt reservoir is not properly
closed. Check to have properly closed the salt reservoir cap.
The rinse aid is used up or the dosage is
insuf  cient. Add the rinse aid or adjust the dosage levels higher.
The dishes and
glasses are blue
streaked or have a
bluish tinge.
The rinse aid dosage is excessive. Adjust the dosage rates below.

17
english Technical passporT
dishwasher
INSTALLATION
ATTENTION: If the appliance must be moved
at any time, keep it in an upright position; if
absolutely necessary, it may be tilted onto its back.
CONNECTING THE WATER SUPPLY
Adaptation of the water supply for
installation should only be performed by a
quali ed technician.
The water inlet and outlet hoses may be
positioned towards the right or the left in
order to achieve the best possible installation.
Make sure the dishwasher does not bend or
squash the hoses.
CONNECTING THE WATER INLET HOSE
ÂRun the water until it is perfectly clear.
ÂScrew the inlet hose tightly into position
and turn on the tap.
If the inlet hose is not long enough, contact a
specialist store or an authorised technician.
The water pressure must be within the values
indicated in the Technical Data table - otherwise
the dishwasher may be function properly.
Make sure the hose is not bent or compressed.
SPECIFICATIONS FOR THE CONNECTION
OF THE WATER SUPPLY HOSE:
WATER SUPPLY cold or hot (max. 60°C)
WATER INTAKE 3/4"gas
POWER OF WATER
PRESSURE
0,05 ÷ 1MPa (0.5 ÷ 10 bar)
7,25 - 145 psi
CONNECTING THE WATER OUTLET HOSE
Connect the outlet hose to a drain duct with
a minimum diameter of 2 cm A
Before connecting the water outlet hose to
the sink drain, remove the plastic plug B.
ANTI-FLOODING PROTECTION
Anti- ooding protection. To ensure  oods
do not occur, the dishwasher:
Âis provided with a special system which
blocks the water supply in the event of
anomalies or leaks from inside the appliance.
Some models are also equipped with the
supplementary safety device New Aqua Stop,
which guarantees anti- ooding protection
even in the event of a supply hose rupture.
Under no circumstances should the water
inlet hose be cut as it contains live electrical
parts.
ELECTRICAL CONNECTION
WARNING: Under no circumstances
should the water inlet hose be cut as it
contains live electrical parts.
Before inserting the plug into the electrical
socket, make sure that:
ÂThe socket is earth and complies
with current regulations;
ÂThe socket can withstand the maximum
load of the appliance as shown on the data
plate located on the inside of the door (see
PRODUCT DESCRIPTION).
ÂThe power supply voltage falls within
the values indicated on the data plate on the
inside of the door.
The outlet hose connection must be at a
height ranging from 40 to 80 cm from the
 oor or surface where the dishwasher rests.

18
Technical passporT english
dishwasher
ÂThe socket is compatible with the plug
of the appliance.
If this is not the case, ask an authorised
technician to replace the plug (see AFTER-
SALES SERVICE). Do not use extension cables
or multiple sockets. Once the appliance has
been installed,the power supply cable and the
electrical socket should be easily accessible.
The cable should not be bent or compressed.
If the power supply cable is damaged,
have it replaced by the manufacturer or its
authorised Technical Assistance Service in
order to prevent all potential hazards.
The Company shall not be held responsible
for any incidents, if these regulations are not
observed.
POSITIONING AND LEVELLING
1. Position the dishwasher on a level
sturdy  oor. If the  oor is uneven, the front
feet of the appliance may be adjusted until it
reaches a horizontal position. If the appliance
is levelled correctly, it will be more stable and
much less likely to move or cause vibrations
and noise while it is operating.
2. Before recessing the dishwasher, stick
the adhesive transparent strip under the
wooden shelf in order to protect it from any
condensation which may form.
3. Place the dishwasher so that its sides or
back panel are in contact with the adjacent
cabinets or the wall. This appliance can also
be recessed under a single worktop.
4. To adjust the height of the rear foot,
turn the red hexagonal bushing on the lower
central part at the front of the dishwasher
using a hexagonal spanner with an opening
of 8 mm. Turn the spanner in a clockwise
direction to increase the height and in an
anticlockwise direction to decrease it.
AFTER-SALES SERVICE
CONTACTING AFTER-SALES SERVICE
When you contact the After-Sales Service,
you must provide the codes shown on the
rating plate attached to the left or right side
inside the door of the dishwasher.
The phone number is listed in the warranty
booklet or on the Kuppersberg website:
http://www.kuppersberg.ru.
TECHNICAL DATASHEET
The technical data containing the energy
consumption data can be downloaded from
the Kuppersberg website:
http://www.kuppersberg.ru.

STANDBY CONSUMPTION:
WIDTH 595 mm
HEIGHT 820 mm
DEPTH 580 mm
CAPACITY 14 standard place-settings
STANDBY CONSUMPTION: Left-on mode - 5 W
Off mode - 

19
english Technical passporT
dishwasher

20
Technical passporT english
dishwasher
