Kusina 600 Series Instructions for use

Instruction and Maintenance
Manual
GRILL
GAS
.
“Professionally with Professionals”

DESCRIPTION
The instructions in this manual contain important information on the safe mounting, usage, cleaning
and maintenance of the device. Thus, keep the manual at a place easily accessible by the person who
will use the machine, and the technician.
Mounting, conversions for different gas groups or electrical inlet, and maintenance works of the
device should be performed by a specialist authorized in this subject and in accordance with the
instructions of the manufacturer company.
Gas and electrical connections of the device should be arranged according to the tables and electrical
diagram given in this manual.
Manufacturer Company accepts no responsibility for the final damages incurred in humans or
properties that are caused by any procedure not conforming to the instruction manual, or maintenance
or technical interventions that are not performed by authorized people.
TYPES
G I100-110-200-210-220G - 00 serie counter top gas grill
G L200G - 00 serie counter top gas grill
G7I100-110-200-210-220G -700 serie gas grill
G7I100-110-200-210-220G-S -700 serie counter top gas grill
G7L100-200G -700 serie gas lavastone grill
G9I100-110-200-210-220G -900 serie gas grill
G9L100-200 -900 serie gas lavastone grill
MOUNTING INSTRUCTION
PLACEMENT
Installation and adjustment of the device should be carried out by technical staff of the Authorized
Service.
Place the device beneath a filtered exhaust hood in order to eliminate smell and fume that may be
emitted during cooking.
Place the device at a place min. 10cm away from the side or back wall to prevent excessive
temperature rises.
Device should be placed on a flat surface by suitably balancing on the four adjustable legs. (Figure
A)
Remove the protective nylon on the device. Clean the adhesive particles left on the device with a
suitable cleaner.
Never leave flammable material near the device.
Gas Connection
Device should be connected in accordance with the national and local gas standards of the relevant
country.
Gas inlets of the device are indicated with a label “GAS” on device body.
Connection to the gas installation should be made with flex pipe and ball valve. Fix the said ball
valve to a place that is away from heat and easily accessible in case of a danger.
After gas inlet connection is completed, check for possible gas leakages.
Feed the device with the gas and pressure as specified on device information plate and adjusted. If
the gas type to which the device was adjusted for is not suitable to the gas type at the mounted place,
follow the instructions written below.

ATTENTION: All adjust ents and odifications to be perfor ed on the gas
installation and connection of the device should be perfor ed by authorized people.
Gas pressure ay never exceed 21 bar for Natural gas and 30 bar for LPG.
ADJUSTMENT ACCORDING TO DIFFERENT GAS TYPES
If the device is connected to gas installation, close main gas inlet valve.
 Replacement of burner nozzles (Figure B)
1. Dissemble front panel of the grill. Unscrew the nozzle at the burner inlet using a suitable
wrench (1).
2. Replace nozzle (2) with a nozzle suitable for the gas type to be used
3. Replace the flame nozzles of pilot burner (4) with a nozzle suitable for the gas type. For this
purpose, it is enough to dismantle coupling (3) and pull the gas pipe down
OPERATOR INSTRUCTIONS AND ATTENTION POINTS
Before cooking with the grill, operate it with no load for a while. Thus, the protection oil on it will
disappear and it will become ready to use.
When you do not cook, keep the adjustment button on half flame “ ” or pilot position. It will
provide a more economical usage for you.
 Clean the grill platina using suitable scraper every day. In this way, you prevent the accumulation of
burned and carbonized foods, and accordingly any decrease in the cooking efficiency.
Clean the oil drawer inside the cabinet after each use.
If you will not use the grill for a long time, cover the grill platina with suitable liquid oil and keep
away from moisture.
Do not operate the grill with its back funnel mouldings removed or closed.
Never leave any uncovered food in the cabinet section of the devices.
START-UP
Turn the main gas valve to open position.
Turn the grill gas button (5) to lighter position “ ” by pushing it gently. In this position, ignite
( ) the pilot burner with lighter.
After the pilot is ignited, keep the button pressed for a few seconds (min. 10) to heat the safety
thermocouple end.
Later, you can adjust it to the desired position by turning to high flame “ ” or low flame “ ”
marks indicated on button.
If the device is operated for the first time, keep the button pressed at pilot burner flame position for a
while before ignition to discharge the air in the gas installation.
TURNING OFF
Turn the gas button to lighter position “ ”. In this position, only pilot burn occurs. Turn to
position “0” to turn off completely.

MAINTENANCE
Never perform maintenance without closing the main gas valve of the device.
Before it cools down completely, wipe the device with a cloth immersed in warm soapy water.
Do not use cleaning substances and tools that may cause scratches on device surface.
If required, use chemical cleaners.
Do not clean the device with pressurized water or vapour.
If the device will not be used for a long time, coat the surfaces with a thin layer of Vaseline.
ATTENTION: Any part replace ent that ay affect safety ust be carried out by the
authorized people. During aintenance and repair, keep the ain gas valve closed and
keep away fire. Always perfor leakage check after repair or part replace ent; use foa
or gas detector for this ai . In case of any dangerous condition with the device, notify to the
authorized service. Do not allow unauthorized people to interfere in the device.
DANGEROUS: Never allow leakage check to be perfor ed with fla e.
