INPUT :120 Volt, AC Solenoid
MODEL #: 091-9-090
AUTO DRAIN ACHP
AN AUTOMATIC MOISTURE DRAIN
FOR THE 091-9HP AIR COMPRESSOR
INSTRUCTION MANUAL

170 Cherry Avenue
West Sayville, NY 11796
www.kussmaul.com
Ph: 800-346-0857
Fax: [phone]
[email protected]
2
INTRODUCTION
ITEMQUANTITYPARTNUMBER
1
2
3
4
5
6
7
8
9
10
A2231-1-C108
F5044-02-DH-Z310
216P-2
PLB112-4
219-P-2
219-P-4
PL1/4-NIU
1202P4-4
CMMQ20B
11
12
13
2205P-4
209R4-2
NN4-035
PVC-1/4
The Auto Drain ACHP system consists of a 120 volt normally open solenoid, a filter and
assorted fittings. Designed to work with the 120 volt Model 091-9HP Auto Pump, the solenoid
bleeds the filter bowl when the pump is not running. As soon as the pressure switch turns
on the compressor, the solenoid is energized and the bleed is closed. A check valve that
is supplied with the Auto Drain kit must be installed as shown to seal off the vehicles air
pressure when the bleed valve opens.
AUTO DRAIN COMPONENTS
1
1
1
2
1
1
1
2
1
1
1
1
1
DESCRIPTION
SolenoidValve,120VoltA.C.,normallyopen
Filter with metal bowl
Nipple,1/8NPT
Nipple,1/4NPTClose
Plug,1/8NPT
Plug,1/4NPT
Elbow, 1/8 NPT, male - 1/4 tube
StreetElbow,1/4NPT
BallCheck Valve, 1/4 NPT male-1/4 NPT male
Cross, Brass, 1/4 NPT
Reducingbushing,brass,1/4x1/8NPT
1/4Tubing,24inches
Sleeving, 1/4" PVC, 11 inches

3
170 Cherry Avenue
West Sayville, NY 11796
www.kussmaul.com
Ph: 800-346-0857
Fax: [phone]
[email protected]
091-9-090 AUTO DRAINACHP INSTALLED ON 091-9HPAUTO PUMP

170 Cherry Avenue
West Sayville, NY 11796
www.kussmaul.com
Ph: 800-346-0857
Fax: [phone]
[email protected]
4
TO MOTOR
AUTO DRAIN SOLENOID
POWER CORD
INSTALLATION WIRING DIAGRAM
PRESSURE
SWITCH
AUTO DRAIN WIRING INSTALLATION
1. Install the black sleeving over the solenoid wires
2.Connect the AUTODRAINsolenoidwirestooutputterminalsofpressure switch. These are the
same terminals that supply power to the AUTO PUMP motor
3. TheAUTODRAINisnowproperlyconnected. TestbybleedingsystempressuretostartAUTO
PUMP and note that when pump shuts down, air and moisture will bleed out of drain tube.
4. Position drain tube to direct moisture to exterior of vehicle.

5
170 Cherry Avenue
West Sayville, NY 11796
www.kussmaul.com
Ph: 800-346-0857
Fax: [phone]
[email protected]
All products of Kussmaul Electronics Company Inc. are warranted to be free of
defects of material or workmanship. Liability is limited to repairing or replacing
at our factory, without charge, any material or defects which become apparent in
normal use within 3 years from the date the equipment was shipped. Equipment
is to be returned, shipping charges prepaid and will be returned, after repair,
shipping charges paid.
Kussmaul Electronics Company, Inc. shall have no liability for damages of any
kind to associated equipment arising from the installation and/or use of the Kuss-
maul Electronics Company, Inc. products. The purchaser, by the acceptance of
the equipment, assumes all liability for any damages which may result from its
installation, use or misuse, by the purchaser, his or its employees or others.
WARRANTY POLICY
DATE INSTALLED _______________________________________________________
INSTALLED BY _________________________________________________________
VEHICLE IDENTIFICATION _______________________________________________
VEHICLE OWNER _______________________________________________________
INSTALLATION RECORD
