KV2 Audio VHD5000 User manual

User Guide
VHD5000 GUI
Touchscreen Control,
Web Control
This User Guide shows how to Control the VHD5 system using
the VHD5000 amplier Touchscreen control system, and/or Web
control using a web browser.

Contents
VHD5000 GUI · Contents
VHD5000 GUI
Introduction 2
Touchscreen Control System 3
Amplier Settings 4 - 9
Flybar 10
Diagnostics 11
Generator 12
Ethernet 13
Basic controls · Keyboard window 14
Bottom menu 15 - 17
K-NET 18 - 22
VHD5000 GUI · Web Control 23
Remote Control System 24 - 26
Settings 27 - 32
Preset 33
Diagnostics 34
Network 35
Keyboard 36
Ethernet 37
Device Setup 38 - 39
K-NET 40 - 41
Notes 42 - 44

VHD5000 GUI · Introduction
This page has a side menu (A) and a bottom menu (B).
To navigate in the application you can use the touch screen or the encoder. Turn the encoder left or right to focus,
(C) - focused button) and then press the encoder to select the button (D) - selected button) or to produce a specic
action depending on the button type, (which will be explained below).
VHD5000 Introduction
On the front panel of the VHD5000 amplier is a 3.7"Color Transreective LCD touch display, a standby button
and a rotary encoder with a push-button function for controlling the system. After powering on, the VHD5000 will
display the KV2 logo until it has completed booting up.
Once the amp has booted, it will then change to the system overview screen. (Pic 1)
Pic 1
Pic 2
B
D
2
VHD5000 GUI · Introduction
A
C

VHD5000 GUI · Touchscreen Control System
Touchscreen Control System
Use the side menu to switch between the four main tabs.
Pic 3: LIST - System settings overview Pic 4: SET - Amplier settings, ybar control
Pic 5: DIA - diagnostics, signal generator, software version Pic 6: NET - network connection
(A) Home
(B) "AMP" - device setup
(C) PRESET - presets management
(D) K-NET - remote control of ampliers and group management
The bottom menu of the overview page contains four button options (see page 17):
Pic 7
A B C D
3
VHD5000 GUI · Touchscreen Control Systems

VHD5000 GUI · Amplier Settings
Amplier Settings
Setting
The LIST tab provides a view of the whole amplier setup. Each amplier channel has a box with its settings.
On Pic 8 you can see the system default values. Pic 9 shows a custom user setting. Muted channels are
shown with a red line through the band, and the text is grayed out.
wSUB-INT/EXT = Internal or external sub input, LD EQ = long distance equalizer for HF band.
When cardioid SUB mode is set, there is only one row for the SUBS - SUB CARDIOID
This screen also shows all of the other system settings; PHASE, GAIN, INPUT IMPEDANCE, SYSTEM DELAY, etc.
The SIGNAL METER (Pic 3) shows input level from -21 to +9dB with a 1sec peak as well as the SIGnal and LIMiter
indicators. The SIGNAL METER is included in the LIST, SETting and DIAgnostic tabs.
In the SETting tab (Pic 11) you can manage the amplier settings.
INPUT, LOW, MID, HI, SUB A, SUB B (or one button for SUB CARDIOID) and FILL buttons represent individual channels.
Press the channel button to open a window showing the advanced settings (except the MID channel which can only
be muted. This is because the MID band is treated as the baseline for the system and the other bands are gained
against the MIDS). Press and hold the channel button to mute or unmute each channel. A Red cross-hatch indicates
that the channel is muted (Pic 12). The LOW and HI bands have A and B channels which can be muted in the advanced
settings window. The MUTE button opens a window where you can mute output channels or unmute all channels.
The RESET button opens a window where you can conrm if you want to reset amplier settings to default. The Button
for controlling the FLYBAR is enabled when the VHD5.0 speaker multi-cable & ybar POWER UNIT is connected.
Pic 8 Pic 9
Pic 11 Pic 12
Pic 10
4
VHD5000 GUI · Amplier Settings

VHD5000 GUI · Amplier Settings
Input
Press the INPUT button to open the advanced settings window (Pic 13)
Press X, or touch anywhere outside the window (gray zone) to close the window.
Specication table
UNMUTE/MUTE
LEVEL: -20, -19, -18, -17, -16, -15, -14, -13, -12, -11, -10, -9, -8.5,
-8, -7.5, -7, -6.5, -6, -5.5, -5, -4.5, -4, -3.5, -3, -2.5, -2, -1.5, -1, -0.5,
0, 0.5, 1, 1.5, 2, 2.5, 3 dB
PHASE: 0°, 180°
IMPEDANCE: 120Ω, 10kΩ
FULL RANGE: ON/OFF
SUB INPUT: INTERNAL, EXTERNAL
CARDIOID: ON/OFF
INSERT: ON/OFF
enabled if SUB INPUT: INTERNAL DELAY - TIME: 0 - 379ms,
0.05ms step;
DISTANCE: 0 - 130m, cca 0.02m step
Buttons description:
UNMUTE/MUTE
Press to toggle
Enabled button
Toggle buttons:
Disabled button
Focused button
When using the encoder to navigate in the interface,
the focused button is highlighted in a white box. Use
the touch screen, or press encoder to select function.
Selected button
(See Specications Table above for step
values).
When the eld is selected, you can rotate
encoder to change its value. Rotate clockwise
to increase, and counter-clockwise to decrease
value.
Pic 13
PHASE button
Press to toggle
Pic 14 Pic 15
Pic 16 Pic 17
Pic 18
Pic 19
Pic 20
Pic 21
Pic 22
5
VHD5000 GUI · Amplier Settings

VHD5000 GUI · Amplier Settings
Delay Setting
Pic 23: Delay (TIME DISTANCE box) can be set in meters or milliseconds.
Pic 24: Touch box or use encoder to focus on the rst number.
Pic 25: Focus on specic range using encoder.
Pic 26: Press encoder to select range.
Pic 27: Rotate encoder to set value. This will change the value in 0.05ms steps which is approximately 0.02m.
For that reason, when setting meters, it adds or subtracts approximately 0.02, 0.1, 1, 10, or 100 meters depending
on the selected range.
Pic 28: When the maximum allowable delay is reached, MAX will appear at the top of the display
6
VHD5000 GUI · Amplier Settings

VHD5000 GUI · Amplier Settings
Hi
UNMUTE/MUTE
LEVEL: -6, -5, -4, -3, -2, -1, 0, 1, 2, 3, 4 dB
A: UNMUTE/MUTE
B: UNMUTE/MUTE
HF RECOVERY: ON/OFF
GAIN: -60, -57, -54, -51, -48, -45, -42, -39, -36, -34, -32, -30,
-28, -26, -24, -22, -20, -18, -16, -14, -12, -11, -10, -9, -8, -7, -6,
-5, -4, -3, -2, -1, 0 dB
If HF RECOVERY is enabled:
HI-PASS FILTER: 7.2, 3.3, 2.2, 1.5kHz
GAIN
LONG DISTANCE EQ: ON/OFF
This setting increases gain to increase long throw
characteristics of HF in larger venues.
UNMUTE/MUTE
LEVEL: -6, -4, -2, -1, 0, 1, 2, 3, 4, 5, 6 dB
A: UNMUTE/MUTE
B: UNMUTE/MUTE
LOW MID MODULE COUNT: 1, 2, 3 VHD8.10
You can individually mute the A or B channels when
a VHD5000S is connected. Otherwise these two buttons are
disabled.
LOW MID MODULES COUNT
This function is used to tell the controller how many
VHD8.10 are connected to the system.
A drop down list is displayed where you can select how
many VHD8.10 cabinets are being deployed in the system
using the touch screen or with the push button function of
the encoder.
Low
Pic 29
Pic 30
Pic 30
7
VHD5000 GUI · Amplier Settings

VHD5000 GUI · Amplier Settings
Sub A, B
Sub Cardioid
Fill
UNMUTE/MUTE
LEVEL: -20, -18, -16, -14, -12, -10, -8, -6, -4, -2, -1, 0, 1, 2, 3, 4, 5,
6, 7, 8, 9, 10 dB
PHASE: 0°, 180°
DELAY - TIME: 0 - 109.2ms, 0.05ms step;
DISTANCE: 0 - 37.46m, cca 0.02m steps
FULLRANGE label is visible when LOW FULLRANGE
is selected to ON
UNMUTE/MUTE
LEVEL: -20, -18, -16, -14, -12, -10, -8, -6, -4, -2, -1, 0, 1, 2, 3, 4, 5,
6, 7, 8, 9, 10 dB
PHASE: 0°, 180°
PREQUENCY: 35, 40, 45, 50, 55, 60, 65, 70, 75 Hz
DELAY - TIME: 0 -102.1ms, 0.05ms step;
DISTANCE: 0 - 35.2m, cca 0.02m steps
Set sub channels mode in input window
UNMUTE/MUTE
LEVEL: -54, -51, -48, -45, -42, -39, -36, -33, -30, -28, -26, -24,
-22, -20, -18, -16, -14, -12, -10, -8, -6, -5, -4, -3, -2, -1, 0, 1, 2, 3,
4, 5, 6 dB
PHASE: 0°, 180°
HI-PASS FILTER: 800Hz, 400Hz, 100Hz,
OFF DELAY - TIME: 0 - 379ms, 0.05ms step;
DISTANCE: 0 - 130m, cca 0.02m step
Pic 31
Pic 32
Pic 33
8
VHD5000 GUI · Amplier Settings

VHD5000 GUI · Amplier Settings
Mute
Reset Conguration
INPUT
unmute
LEVEL: 0dB
IMPEDANCE: 10kΩ
FULL RANGE: OFF
SUB INPUT: INTERNAL
CARDIOID: OFF
INSERT: OFF
DELAY: 0ms/m
LOW A/B
unmute
LEVEL: 0dB
A: unmute
B: unmute
Low Mid Modules Count: 3 VHD8.10
MID
unmute
MUTE ALL
mutes LOW A, LOW B, MID, HI A, HI B, SUB A, SUB B,
CARDIOID and FILL
UNMUTE ALL
unmutes INPUT, LOW, LOW A, LOW B, MID, HI, HI A, HI B, SUB
A, SUB B, CARDIOID, FILL
HI
unmute
LEVEL: 0dB
A: unmute
B: unmute
HF RECOVERY: OFF
GAIN: -60dB
HI-PASS FILTER:
EQ: OFF
SUB A/B
unmute
LEVEL: 0dB
PHASE: 0°
DELAY: 0ms/m
CARDIOID
unmute
LEVEL: 0dB
PHASE: 0°
PREQUENCY: 60Hz
DELAY: 0ms/m
FILL
unmute
LEVEL: 0dB
PHASE: 0°
HI-PASS FILTER: OFF
DELAY: 0ms/m
Default values
Pic 34
Pic 35: Conrm to reset amplier to default values.
9
VHD5000 GUI · Amplier Settings
WARNING! RESET CONFIGURATION WILL UNMUTE ALL CHANNELS AT 0DB. THIS COULD CAUSE SERIOUS
HEARING OR SYSTEM DAMAGE IF THERE IS PROGRAM MATERIAL PASSING THROUGH THE SYSTEM.

VHD5000 GUI · Flybar
Flybar
Pic 36: The FLYBAR button is disabled when VHD5.0
SIGNAL & POWER UNIT is not connected
to the system.
Pic 37: ANGLE: When the ybar is connected
to a VHD5.0 SIGNAL & POWER UNIT, this display
shows the currently measured angle for TILT with
accuracy to 1°, N/A if ybar is not connected.
Push and Hold arrow to move TILT or AUX (for
Downll). When the ybar is in motion, it is signaled
by the rotating wheel. If the ybar cannot be moved
(cable unplugged, short circuit, motor stuck),
the OVERLOAD label is displayed.
10
VHD5000 GUI · Flybar

VHD5000 GUI · Diagnostics
The Diagnostic page has a top menu
to select from these tabs:
(A) AMPS - amplier and speaker status
(B) GEN - signal generator
(C) VER - software versions
AMPS
Shows current status. There are rows for channels HI 1, HI 2, MID (VHD5000) LOW A and LOW B (VHD8.10).
AMPLIFIER STATUS
The rst three columns show:
MAIN VOLTAGE
(one sensor for HI 1, HI 2 and MID): ideal 200-250V, working 160-270V, undervoltage less than 200V LOW A LOW B
TEMPERATURE
(one sensor for HI 1, HI 2): 280°C over temperature shutdown
MID
LOW A
LOW B
ERROR STATUS
OK
FAIL
SPEAKER STATUS
OK
NOT CON - not connected
SHORT - shorted
LOW SIG - low signal
All status cells for channels LOW A and LOW B can indicate:
N/A - VHD8.10 not connected
OFF - no voltage detected on VHD8.10
Pic 38
A B C
11
VHD5000 GUI · Diagnostics

VHD5000 GUI · Generator
GEN - signal generator
Turn SIGNAL GENERATOR ON to generate signal. Choose SINE WAVE or PINK NOISE
Adjust LEVEL of generated signal from -127 to 0dB
You can set the FREQUENCY of sine from 20Hz to 20000Hz (1Hz step)
SIGNAL GENERATOR can only be turned on when system is in EDIT mode.
VER - software versions
Pic 39 Pic 40
Pic 41
12
VHD5000 GUIT · Generator

VHD5000 GUI · Ethernet
Side menu - NETwork - connection
Ethernet
Set ETHERNET conguration by pressing DHCP/STATIC button (pic 42 - A).
Pic 43
In STATIC mode (Pic 42): set the IP and MASK. When you
change it, a validity indicator appears (Pic 43).
Red frame indicates invalid change, green frame (IP)
indicates acceptable change. When your changes are
marked green, the OK button (C) is enabled. Press it to apply
changes. Reset (B) IP address and mask to the current setting.
DHCP mode: The IP address is set automatically from DHCP
server, push the RENEW ADDRESS button (D) to refresh
connection.
DHCP Status:
"Discovering server",
"Server found" / "No DHCP server found"
"Address accepted" / "Address refused"
Check DHCP Server Address, IP Address and Subnet Mask.
ETHERNET CONNECTED: YES/NO MAC ADDRESS
Speed / Mode - "Half Duplex", "Full
Set RS485 TERMINATOR ON/OFF.
Pic 42
Pic 44
Pic 45
A B C
D
13
VHD5000 GUIT · Ethernet

VHD5000 GUI · Basic controls
Basic controls
WEB
This text (pic 46 - A) informs you whether a password is required to access this amplier via web control.
You can use SET PASSWORD to protect access via web control.
Once set, you can CHANGE the password or DISABLE it. (Pic 47)
Keyboard window (Pic 48 and Pic 49).
Label describes you are going to SET PASSWORD (Pic B).
Text eld - maximum 5 chars enabled (C).
Double arrow - backspace - removes last character (E).
ABC and 123 button changes charset (D).
SET button sets the password (F).
Use letters, numbers, and !, @, #, $, %, ^, &, *, ?, (, ), /, ', ., -, _
Pic 46 Pic 47
Keyboard window
Pic 49
Pic 48
A
B
C
D
E
F
14
VHD5000 GUI · Basic controls

VHD5000 GUI · Bottom menu
Bottom menu
Pic 50 (A) - HOME button
When a VHD5000 is controlled from the GUI the home button shows this icon and is disabled
(Pic 51). When a second VHD5000 is controlled from the rst amplier GUI this icon is displayed
(Pic 52). Pressing this button returns control to the local amplier.
Pic 50
(E) DATE TIME - button shows current date and time,
opens window Pic 55.
SET NAME - button opens window to rename
amplier
Pic 53
(B) - Device SETUP button - shows the name of currently controlled amplier
(D - "LEFT") and the name of group (C - "VOCAL")
Pushing the amplier (LEFT) button, opens window for the device setup Pic 54.
To set date and time, select a eld and change
with the encoder and conrm with SET NEW TIME
button.
Pic 51
Pic 54 Pic 55
A B
Pic 52
C
D
E
15
VHD5000 GUI · Bottom menu

VHD5000 GUI · Bottom menu
Bottom menu
Pic 58: Use the STANDBY HW button on the VHD5000 front
panel to turn DISPLAY OFF or to go into STANDBY
Pic 56: PASSWORD MANAGER - opens
window Pic 57
DISPLAY OFF/ LOCK - turn o display or LOCK device
when password is set.
STANDBY - go standby
Pic 57: You can SET PASSWORD which will need
to be entered to access amplier when it is in
STANDBY mode or if its DISPLAY is OFF. Once set,
you can CHANGE the password or DISABLE it.
Pic 59: When amplier is locked with password, after
turning on display or turning on display or turning
on from standby you need to enter this password.
OFF
ON
DISPLAY OFF
STANDBY
16
VHD5000 GUI · Bottom menu

VHD5000 GUI · Bottom menu
Bottom menu - PRESET
The PRESET button shows the name of last loaded preset (example "RESET"). This button opens a window for preset
management (Pic 61). There is a box (A) representing the settings of selected preset in list (B). Until you create your
custom presets, there is only the default preset, called RESET, which cannot be overwritten or deleted.
The last loaded preset is marked with CURRENT label, and then when you edit amplier settings (so settings are
dierent to the current preset ), the label displays EDITED.
For example here is list of custom presets: #5, #1, ABC, #3, DEF and #2. There is list of presets you can scroll using
scrollbar (C) arrows . Each new preset is added to the end of the list.
You can manage presets using bottom menu buttons:
LOAD selected preset. Enabled when current settings are dierent from selected preset settings.
SAVE rewrites selected preset with current settings. Enabled when current settings are dierent from selected preset
settings, default RESET cannot be rewritten.
NEW creates a preset with current settings. Set its name in keyboard window. Enabled when current settings are
dierent from the currently selected preset.
DEL - delete selected preset.
Pic 60 Pic 61
Pic 62 Pic 63
A B
C
17
VHD5000 GUI · Bottom menu

VHD5000 GUI · K-NET
K-NET interconnection VHD5000/VHD5000
There are various options for how to interconnect VHD5 systems. It is recommended to use an Ethernet connection,
however you can also our proprietary K-Net connection, using conventional XLR microphone cables, or a combination
of XLR and ethernet, (Although at the time of publishing, K-NET still in Beta).
Connecting two VHD5 systems needs crossover Ethernet cable or preferably a network switch or router.
Use STATIC IP mode, (See chapter Ethernet) and set proper IP addresses on both devices.
When using the K-Net XLR network, termination must be set correctly.
Set TERMINATOR: ON for OPEN END DEVICEs and OFF for NOT OPEN DEVICEs).
(See chapter Ethernet)
This is an example:
device A device B
ip: 192.168.0.1 ip: 192.168.0.2
mask: 255.255.255.0 mask: 255.255.255.0
Pic 64
Pic 65
18
VHD5000 GUI · K-NET
