Kvaser U100 User manual

Kvaser U100 User’s Guide
Copyright 2020-2021 Kvaser AB, Mölndal, Sweden
https://www.kvaser.com
Printed Tuesday 16th February, 2021
We believe that the information contained herein was accurate in all respects at the time of printing.
Kvaser AB cannot, however, assume any responsibility for errors or omissions in this text. Also note
that the information in this document is subject to change without notice and should not be construed
as a commitment by Kvaser AB.

Kvaser U100 User’s Guide 2 (22)
(This page is intentionally left blank.)
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 3 (22)
Contents
1 About this manual 4
2 Introduction 5
2.1 Welcome to Kvaser U100 . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Major features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.3 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4 Additional software and documentation . . . . . . . . . . . . . . . . 6
3 Kvaser U100 hardware 7
3.1 Hardware installation . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2 USB connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.3 CAN channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.4 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.5 LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.6 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Appendices 9
4.1 Definitions of LED states and colors . . . . . . . . . . . . . . . . . . 9
4.2 Definitions of Information types and States . . . . . . . . . . . . . . 11
4.3 Interface mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.4 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.5 USB connector options . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.6 CAN connector options . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.7 CAN bus termination . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.8 Updating the firmware . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5 Safety Instructions 16
5.1 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.2 Usage Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6 Disposal and Recycling Information 17
7 Legal Acknowledgements 19
7.1 EU Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . . 19
7.2 FCC Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . 20
7.3 Patents, Copyrights and Trademarks . . . . . . . . . . . . . . . . . . 21
8 Document Revision History 22
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 4 (22)
1 About this manual
This manual is intended for Kvaser U100 users. This document contains a
description of the hardware’s properties and general instructions for connecting the
device to a computer.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 5 (22)
2 Introduction
This section will describe the functions and features of the Kvaser U100.
2.1 Welcome to Kvaser U100
Figure 1: Kvaser U100 with D-SUB CAN connector
Kvaser U100 is a small, yet powerful, CAN to USB interface. It provides real-time
transmission and reception of standard and extended CAN messages on the bus
with a high timestamp precision, and is compatible with applications that use
Kvaser’s CANlib.
This guide applies to Kvaser U100 devices listed in Table 1.
Device Product Number
Kvaser U100 73-30130-01173-1
Table 1: Kvaser U100 devices, with Product numbers.
2.2 Major features
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 6 (22)
•USB CAN interface.
•Powered through the USB connector.
•Supports CAN FD, up to 8 Mbit/s (with correct physical layer implementation).
•Supports both 11-bit (CAN 2.0A) and 29-bit (CAN 2.0B active) identifiers.
•Lightweight robust housing made of glass fibre reinforced polyamide
overmolded with TPE.
•Intuitive LED UI.
•Reinforced galvanic isolation, design validated with 5000 VAC rms applied for
60 s.
•Industrial grade temperature range, −40 ◦C to +85 ◦C.
•20 000 msg/s, each timestamped with a resolution of 100 µs.
•Fully compatible with applications written for other Kvaser CAN hardware
with Kvaser CANlib.
•Support for SocketCAN.
•Fully compatible with J1939, CANopen, NMEA 2000 R
and DeviceNet.
•IP67 rating.
•A selection of different cables/connectors for the CAN connection.
2.3 Interface
Kvaser U100 provides a CAN bus interface through a standard USB interface.
2.4 Additional software and documentation
The Kvaser CANlib SDK includes everything you need in order to develop software
applications interacting with Kvaser CAN hardware. The SDK contains full
documentation and many sample programs, written in C, C++, C#, Delphi, Python
and Visual Basic. Kvaser CAN hardware is built around the same common
software API. Applications developed using one device type will run without
modification on other device types.
The latest versions of documentation, software and drivers can be downloaded for
free at www.kvaser.com/download.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 7 (22)
3 Kvaser U100 hardware
In this section you can read more about the CAN channels, power supply and LED
indicators.
3.1 Hardware installation
The Kvaser U100 may be inserted in any free USB socket on the host computer.
You do not need to switch the power off before inserting or removing the device.
For the Kvaser U100 to communicate with the host computer, a compatible version
of the Kvaser driver and firmware must be installed.
The driver is installed by running the file kvaser_drivers_setup.exe . For
instructions on how to update the firmware, see Section 4.8, Updating the
firmware, on Page 15. The latest version of the driver and firmware can be
downloaded from www.kvaser.com/download.
The firmware is downloaded and installed directly on the Kvaser U100 and the
driver is installed on the host computer. After the driver has been installed on the
host computer, the firmware may then be downloaded and installed on the Kvaser
U100.
Device Firmware Windows driver Linux driver
Kvaser U100 v3.22.578 v5.34 (kcany) v5.34 (mhydra)
Table 2: Kvaser U100 devices and requirements on minimal version of firmware and
drivers.
3.2 USB connection
The Kvaser U100 is connected to a PC using USB. See Section 4.5, USB
connector options, on Page 13 for more information.
Connect the device to your computer using any high quality USB 2.0 certified
cable. The maximum USB cable length is 5 m (∼16 ft). If you need a longer cable,
you can use USB hubs or USB extension cables with a built-in hub. By chaining up
to 5 hubs, you can achieve an effective cable length of up to 25 m (∼82 ft).
As USB cables become longer they are more sensitive to EMI,
because they make a longer antenna that can pick up more
noise. These issues can be mitigated by using higher quality
cables with better shielding. Thicker cables tend to be better than
thin ones, and braided shielding tends to be more reliable than
only foil. Furthermore, longer cables may introduce signal
degradation and timing issues that, if necessary, can be mitigated
using shorter cable segments combined with hubs that amplify
the signal and handle delays on a per-cable basis.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 8 (22)
3.3 CAN channels
The Kvaser U100 has one CAN Hi-Speed channel. See Section 4.6, CAN
connector options, on Page 14 for more information.
3.4 Power supply
The Kvaser U100 is powered through the USB connector.
3.5 LED Indicators
The Kvaser U100 has one Tx LED Bar and one Rx LED Bar as shown in Figure 2
on Page 9, Figure 3 on Page 10. Their functions are described in Section 4.2,
Definitions of Information types and States, on Page 11.
3.6 Troubleshooting
Use “Kvaser Device Guide” in the Control Panel to verify that the computer can
communicate with the Kvaser U100. If the firmware version shown is all zeros,
there are communication problems. If the LED Bar or the status indication is not
flashing or does not light up at all, check the power supply.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 9 (22)
4 Appendices
In this section you will find technical information about the Kvaser U100 and its
connectors.
4.1 Definitions of LED states and colors
The Kvaser U100 has one Tx LED Bar and one Rx LED Bar. Each LED Bar has a
status area, the Tx LED Bar has a status area towards the USB end of the bar, and
the Rx LED bar has a status area towards the CAN end of the bar. This is shown in
Figure 2.
Figure 2: The Tx and Rx LED bars on the Kvaser U100 includes status areas.
The Tx LED bar lit area grows from the USB end of the LED bar towards the CAN
end of the bar as CAN Tx traffic is increased. Likewise, the Rx LED bar lit area
grows from the CAN end of the LED bar towards the USB end of the bar as the
message rate of the received traffic is increased, see Figure 3 on Page 10. In this
example the unit is transmitting data, which shows a yellow Tx status area. No
CAN traffic is received and as such the Rx status area is green.
The total size of the LED bars are indicating the current bus load, e.g. Figure 3 on
Page 10 shows only receiving CAN messages at 50% bus load. Figure 4 on
Page 10 shows two different bus load conditions. The image on the left shows the
unit transmitting and receiving data corresponding to 50% bus load in each
direction for a total of 100% bus load. The image on the right shows the unit
transmitting data corresponding to 100% bus load.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 10 (22)
Figure 3: The Tx LED bar lights up from the USB side to the CAN side of the unit,
while the Rx LED bar lights up from the CAN side to the USB side of the unit.
Figure 4: The total size of the LED Bars is proportional to the bus load. Both
images indicate a bus load of 100%.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 11 (22)
4.2 Definitions of Information types and States
A Kvaser U100 device has two traffic LED bars where part of each LED bar is also
used as a status area. Different colors are used for different types of information
and different blink patterns define the current state, see Table 3 and Table 4.
Color Information type
Yellow Traffic
Green Power
Red Error
White Alert
Blue System
Table 3: Different types of information.
State Definition
Off The indicator is off and no light is emitted.
Slow Blink The indicator is repeatedly turned on and off. The on and off phases are equal in
time.
Fast Blink The indicator is repeatedly turned on and off but with a higher frequency than Slow
Blink. The on and off times are still equal.
On The indicator is constantly emitting light.
Dynamic The indicator is moving and/or increasing/decreasing in size.
Table 4: Definitions of the indicator states.
4.3 Interface mode
The device is in interface mode when connected to the PC via USB. If the status
area is presenting a steady green light, the device is in interface mode and is
working correctly. When connected to the computer for the first time, the status
area will Fast Blink with blue light until the Kvaser Driver is installed and the device
has automatically received a USB configuration. Table 5 summarises the
information shown in interface mode.
Description Status area LED bar
Power is on On (Green) -
CAN overrun On (Red) -
CAN channel is error passive Fast Blink (Red) -
Firmware update Slow Blink (Blue) -
Waiting for USB configuration Fast Blink (Blue) -
Error frame On (Red) On (Red)
CAN channel traffic On (Yellow) Dynamic (Yellow)
Locate hardware Slow Blink (White) Slow Blink (White)
Table 5: LED inidications in interface mode.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 12 (22)
4.4 Technical data
In Table 6 on Page 12 below you will find the Kvaser U100’s technical
specifications.
CAN Channels 1
CAN Transceivers ADM3055E (Compliant with ISO 11898-2)
CAN Controller Built into the processor.
Galvanic isolation Yes, reinforced. Design validated with 5000 VAC rms applied for 60 s.
CAN Bit Rate 10 kbit/s to 1 Mbit/s
CAN FD Bit Rate Up to 8 Mbit/s (with correct physical layer implementation).
Time stamp resolution 100 µs
Max message rate 20 000 msg/s per channel
Error Frame Detection Yes
Error Frame Generation No
Silent mode No
Kvaser MagiSync No
PC interface USB 2.0
Power consumption Typical 250 mA
Hardware configuration Done by software (Plug & Play)
Software requirements Windows (7 or later), Linux
Dimensions 38 x 128 x 26 mm for body
Cable length USB 1.0 m, CAN 0.3 m
Weight 167 g with default connectors
Operating temperature −40 ◦C to +85 ◦C
Storage temperature −40 ◦C to +85 ◦C
Relative humidity 0 % to 85 % (non-condensing)
IP Rating IP67
Table 6: Technical Specifications
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 13 (22)
4.5 USB connector options
This section describes the PC connector options available for Kvaser U100.
4.5.1 USB-A connector (Default)
The default option for the Kvaser U100 is a standard USB type “A” connector.
Figure 5: A standard USB type “A” connector.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 14 (22)
4.6 CAN connector options
This section describes the CAN connector options available for Kvaser U100.
4.6.1 9-pin D-SUB connector (Default)
The default option for the Kvaser U100 is the 9-pin D-SUB connector (see
Figure 7) which has the pinout described in Table 7.
Figure 6: 9-pin D-SUB CAN connector.
Figure 7: The D-SUB 9 connector pinout.
D-SUB pin Function
1 Not connected
2 CAN_L
3 GND
4 Not connected
5 Shield
6 Not connected
7 CAN_H
8 Not connected
9 Not connected
Table 7: Configuration of the 9-pin D-SUB
4.7 CAN bus termination
Every CAN bus must be terminated with a 120 Ohm resistor at each end of the
bus. The Kvaser U100 does not contain any CAN bus termination, because their
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 15 (22)
inclusion could cause severe disturbance in a system which is already correctly
terminated.
For laboratory or testing use, the exact value of the termination resistors is not
always critical. Sometimes a single terminator is sufficient. For production, proper
termination is essential. If you see error frames on the bus, you should check the
termination.
To save yourself a lot of trouble, always terminate the CAN
bus properly.
4.8 Updating the firmware
For the Kvaser U100 to communicate with the host computer, compatible versions
of the Kvaser CANlib (including driver) and firmware must be installed.
The latest versions of firmware and drivers can be downloaded for free at
www.kvaser.com/download.
Connect the Kvaser U100 to your PC with the USB cable and start the update.exe
application. A window opens showing the Firmware Update Instructions, read and
follow those carefully.
To check the current firmware version, open “Kvaser Device Guide” which can be
found in the Control Panel. Select “Kvaser U100” in the tree view to the left, and
click on the channel. The firmware revision information now appears in the right
half of the window.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 16 (22)
5 Safety Instructions
5.1 Intended Use
Kvaser CAN Interfaces are used to connect computer systems to CAN and LIN
networks. The Kvaser U100 is inteded for connection to a computer via the USB
interface.
5.2 Usage Warning
WARNING FOR ALL USERS
WARNING! - YOUR USE OF THIS DEVICE MUST BE DONE WITH CAUTION AND A FULL
UNDERSTANDING OF THE RISKS!
THIS WARNING IS PRESENTED TO INFORM YOU THAT THE OPERATION OF THIS DEVICE
MAY BE DANGEROUS. YOUR ACTIONS CAN INFLUENCE THE BEHAVIOR OF A CAN-BASED
DISTRIBUTED EMBEDDED SYSTEM, AND DEPENDING ON THE APPLICATION, THE
CONSEQUENCES OF YOUR IMPROPER ACTIONS COULD CAUSE SERIOUS OPERATIONAL
MALFUNCTION, LOSS OF INFORMATION, DAMAGE TO EQUIPMENT, AND PHYSICAL
INJURY TO YOURSELF AND OTHERS. A POTENTIALLY HAZARDOUS OPERATING
CONDITION IS PRESENT WHEN THE FOLLOWING TWO CONDITIONS ARE
CONCURRENTLY TRUE: THE PRODUCT IS PHYSICALLY INTERCONNECTED TO A REAL
DISTRIBUTED EMBEDDED SYSTEM; AND THE FUNCTIONS AND OPERATIONS OF THE
REAL DISTRIBUTED EMBEDDED SYSTEM ARE CONTROLLABLE OR INFLUENCED BY THE
USE OF THE CAN NETWORK. A POTENTIALLY HAZARDOUS OPERATING CONDITION MAY
RESULT FROM THE ACTIVITY OR NON-ACTIVITY OF SOME DISTRIBUTED EMBEDDED
SYSTEM FUNCTIONS AND OPERATIONS, WHICH MAY RESULT IN SERIOUS PHYSICAL
HARM OR DEATH OR CAUSE DAMAGE TO EQUIPMENT, DEVICES, OR THE SURROUNDING
ENVIRONMENT.
WITH THIS DEVICE, YOU MAY POTENTIALLY:
•CAUSE A CHANGE IN THE OPERATION OF THE SYSTEM, MODULE, DEVICE,
CIRCUIT, OR OUTPUT.
•TURN ON OR ACTIVATE A MODULE, DEVICE, CIRCUIT, OUTPUT, OR FUNCTION.
•TURN OFF OR DEACTIVATE A MODULE, DEVICE, CIRCUIT, OUTPUT, OR
FUNCTION.
•INHIBIT, TURN OFF, OR DEACTIVATE NORMAL OPERATION.
•MODIFY THE BEHAVIOR OF A DISTRIBUTED PRODUCT.
•ACTIVATE AN UNINTENDED OPERATION.
•PLACE THE SYSTEM, MODULE, DEVICE, CIRCUIT, OR OUTPUT INTO AN
UNINTENDED MODE.
ONLY THOSE PERSONS WHO:
(A) ARE PROPERLY TRAINED AND QUALIFIED WITH RESPECT TO THE USE OF THE
DEVICE,
(B) UNDERSTAND THE WARNINGS ABOVE, AND
(C) UNDERSTAND HOW THIS DEVICE INTERACTS WITH AND IMPACTS THE FUNCTION
AND SAFETY OF OTHER PRODUCTS IN A DISTRIBUTED SYSTEM AND THE APPLICATION
FOR WHICH THIS DEVICE WILL BE APPLIED, MAY USE THE DEVICE.
PLEASE NOTE THAT YOU CAN INTEGRATE THIS PRODUCT AS A SUBSYSTEM INTO
HIGHER-LEVEL SYSTEMS. IN CASE YOU DO SO, KVASER AB HEREBY DECLARES THAT
KVASER AB’S WARRANTY SHALL BE LIMITED TO THE CORRECTION OF DEFECTS, AND
KVASER AB HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY OVER AND ABOVE THE
REFUNDING OF THE PRICE PAID FOR THIS DEVICE, SINCE KVASER AB DOES NOT HAVE
ANY INFLUENCE ON THE IMPLEMENTATIONS OF THE HIGHER-LEVEL SYSTEM, WHICH
MAY BE DEFECTIVE.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 17 (22)
6 Disposal and Recycling Information
When this product reaches its end of life, please dispose of it
according to your local environmental laws and guidelines.
For information about Kvaser’s recycling programs, visit:
https://www.kvaser.com/en/kvaser/recycling-policy.html
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 18 (22)
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 19 (22)
7 Legal Acknowledgements
7.1 EU Regulatory Compliance
Company Name:
Postal address:
Postcode:
City:
Telephone number:
E-mail address:
Product:
EU Declaration of Conformity (DoC)
We
Kvaser AB
Aminogatan 25
431 53
M¨olndal
[phone]
[e-mail]
declare that the DoC is issued under our sole responsibility and belongs to the following product:
Kvaser U100
Object of the declaration (identification of apparatus allowing traceability):
Product: Kvaser U100
Type: 73-30130-01173-1
The object of the declaration described above is in conformity with the relevant Union harmonisation
legislation:
Electromagnetic Compatibility (EMC) Directive 2014/30/EU (Art. 6)
RoHS recast Directive 2011/65/EU (Art. 4.1)
The following harmonised standards and technical specifications have been applied
(title, date of standard/specification):
EN 55032 (2012) EN 55035 (2017)
EN 61000-6-3 (2007 + A1:2011) EN 50581 (2012)
Signed for and on behalf of:
M¨olndal
Place of issue
2020-05-05
Date of issue Claes Haglund, Supply Chain and Quality director
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100 User’s Guide 20 (22)
7.2 FCC Regulatory Compliance
Federal Communications Commission (FCC) Compliance Information Statement
IDENTIFICATION OBJECT:
Product: Kvaser U100
Type: 73-30130-01173-1
APPLICABLE COMPLIANCE STATEMENTS:
CFR Title 47 Part 15 §15.107, §15.109
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
RESPONSIBLE PARTY (IN USA) NAME:
Kvaser Inc.
23881 Via Fabricante, Suite 503
Mission Viejo, CA 92691
Internet contact: [email protected]
Kvaser AB, Mölndal, Sweden — www.kvaser.com
