KYE Systems Corp. Genius SP-HF850X User manual

SP-HF850X
Service Guide SP-HF850X
Version : 1.0 Page 1 of 15
SERVICE GUIDE
KYE SYSTEMS CORP.

Service Guide SP-HF850X
Version : 1.0 Page 2 of 15
Version : 1.0
Revision History
Version Date Change
1.0 04/15/2008

Service Guide SP-HF850X
Version : 1.0 Page 3 of 15
Table of Contents
Revision History …………………………………………………………………….2
Table of Contents ……………………………………………………………………3
Getting Started ………………………………………………………………………4
Conventions Used in this Guide ……………………………………….4
Safety Precautions ……………………………………………………..4
Chapter 1. How to Handle Defective Returns……………………………………..5
1.1 Overview …………………………………………………………..5
1.2 Problems …………………………………………………………...6
1.2.1 One or more channels no sound ………………..…7
1.2.2 Power LED (indicator) no light………………....…8
1.2.3 Volume no function...…………………….………..8
Chapter 2. Specifications …………………………………………………………9
Chapter 3. Block Diagram ……………………………………………………….11
Chapter 4. Exploded View ……………………………………………………….12
Chapter 5. Part List ………………………………………………………………15
Chapter 6. Schematic Diagram …………………………………………………..17
Chapter 7. Important Notes ………………………………………………………19
7.1 Packing Requirement for Sending the PCB Assembly by Post …..19
7.2 Short of Spare Parts while Repairing a Speaker System …………19

Service Guide SP-HF850X
Version : 1.0 Page 4 of 15
Getting Started
Conventions Used in this Guide
Pay Special Attention : Instructions that are important to remember and
may prevent mistakes .
Caution : Information that, if not followed, may result in damage to the
product .
Safety Precautions
The following precautions should be observed in handling the speaker
Described in this guide :
Place the speakers on a flat, level and stable surface.
Do not place the speakers in environments subject to mist, smoke,
vibration, excessive dust, salty or greasy air, or other corrosive gases
and fumes.
Do not drop or jolt the speakers.
Do not allow anything to drop into the subwoofer case through its
ventilator, as it could result in fatal electric shock or fire .
Place the unit far enough from other equipments for good heat
dissipation .
Disconnect the AC power cord from the AC outlet before performing
any maintenance on the speakers .
Do not perform any maintenance with wet hand .
Prevent foreign substances, such as water, other liquids or chemicals ,
From entering the speakers while performing maintenance procedures
on the speakers .

Service Guide SP-HF850X
Version : 1.0 Page 5 of 15
Chapter 1. How to Handle Defective Returns
1.1 Overview
Receiving Defective speaker form customers
Analyzing possible
malfunction causes
Deciding & proceeding the
rectification methods
Replace necessary
defective
p
arts
Return the speakers with proper
re
p
acka
g
in
g
to customers
Verifying problems
proceeding
necessar
y
tests
Proceeding tests to
verify if the speaker is
functionin
g
normall
y
Function OK
Function NG
Function OKFunction NG

Service Guide SP-HF850X
Version : 1.0 Page 6 of 15
1.2 Problems
Item Problem Description
1.2.1 One or more channels no sound
1.2.2 Power LED (indicator) no light
1.2.3 Volume no function

Service Guide SP-HF850X
Version : 1.0 Page 7 of 15
Attention
1.2.1 One or more channels no sound
Problem
Solutions
Please follow the numbered sequence marked within parenthesis given in individual
Flow chat, in that this is the best-recommended sequence to rectify the problems.
One or more channels no sound
Broken or short circuit
Defective U1,U2,K1,K3
Speaker cable dis-connect or
speaker damaged
Check solder points on
PCB
Check and Replace
defective U1,U2,K1,
K3
Re-connect speaker cable or
replace defective speaker(s)
Analyzer and
Identify the Causes

Service Guide SP-HF850X
Version : 1.0 Page 8 of 15
1.2.2 Power LED (indicator) no light
Problem
Solutions
1.2.3 Volume no function
Problem
Solutions
Power LED (indicator) no light
Power switch or LED defective
Defective K1,F2,R21
LED
Ac cord of transformer
disconnected or defective
Re-solder or replace
defective component(s)
Analyzer and
Identify the Causes
Volume no function
Broken or short circuit Defective U2,K2,K3,C13,C14
Check solder points on PCB
Analyzer and
Identify the Causes
Check and Replace defective
components

Service Guide SP-HF850X
Version : 1.0 Page 9 of 15
Chapter 2. Specifications
NO. Description Unit Specifications
1 Out Power at THD 10% W >
>
>
10
2 Sensitivity mV 440 ±60
3 Freq. Response (Ref:-3dB) Hz 50Hz ~ 20KHz
4 Separation dB 40
BdoitarN/S5 65
6 Hum & Noise (Vol.: max) mV < 3

Service Guide SP-HF850X
Version : 1.0 Page 10 of 15
Chapter 3. Block Diagram
AUDIO IN
Volume
Increase Power
Amplifier
R.CH Speaker
AC IN
L.CH Speaker
Volume
Decrease
Power
Conditioner

Service Guide SP-HF850X
Version : 1.0 Page 11 of 15
Chapter 4. Exploded View
Host

Service Guide SP-HF850X
Version : 1.0 Page 12 of 15
Satellite

Service Guide SP-HF850X
Version : 1.0 Page 13 of 15
Chapter 5. Part List
NO. Qty UNIT
1 1 PC
2 1 PC
3 1 PC
4 1 PC
5 1 PC
6 1 PC
7 1 PC
8 1 PC
PCBA,
,
,
SP-HF850X
IC SJ9843
SP-HF850X/BODY-230V-EU
CARTON, SP-HF850X
GLFT BOX,SP-HF850X/230V-EU(NO PMOP)
412000200209
462212313009
462112313009
PartNo.
101123130109
Transformer 230V/18V/1.3A(EU)
LOUD SPEAKER 3.5”4Ω10W
RUBBER PAD, SP-HF850X
20140350100003
420200140109
311231301009
403000290209

Service Guide SP-HF850X
Version : 1.0 Page 14 of 15
Chapter 6. Schematic Diagram

Service Guide SP-HF850X
Version : 1.0 Page 15 of 15
Chapter 7. Important Notes
7.1 Packing Requirement for Sending the PCB Assembly by Post
PCB assembly is a kind of sophisticated electronic circuit board. Well
packing will be required when sending them by post.
* Some sophisticated IC components are mounted on the PCB assembly,
hence it is necessary to pack each PCB assembly with a separate static
protecting bag, in order to avoid static electricity.
* Reliable external packing is also very important when sending PCB
assembly by post, in that it would avoid unnecessarily lost or damage.
7.2 Short of Spare Parts while Repairing a Speaker System
If you are short of spare parts when you have some speaker systems waiting
to be repaired, it would be recommended to take the necessary parts form
one speaker system, so that you may have the as many speaker systems.
