FS-6525MFP
MONOCHROME MULTIFUNCTIONAL FOR A4/A3 FORMAT
This multifunctional device offers all
the benefits of a professional document
management solution for workgroups and
small offices. Advanced functionality, easy
to operate, and a range of paper-handling
options, all in a well-designed compact
package. Cost-efficient and eco-friendly
offices will appreciate KYOCERA’s unique
ECOSYS technology which increases op e-
rating life, reduces environmental impact,
cuts printing costs and ensures reliability.
Up to 25/12 pages A4/A3 per minute
Time to first copy: 7.8 seconds or less
Professional print, copy, colour scan and fax functionality
Paper capacity up to 1,600 sheets and a range of paper-handling options
Easy to install and operate
Easy to use full colour touch panel with wizard-style navigation
Low noise emissions, 0.9W low power in sleep-mode
Compact, 360° all-round stylish design to match any office
Long-life components provide unprecedented efficiency and reliability
HyPAS™ solution platform enables powerful customisations
WANT A PROFESSIONAL,
USER-FRIENDLY MULTIFUNCTIONAL
YOU CAN RELY ON?
The reverse automatic
document processor
scans double-sided
documents for easy
filing and forwarding.
Customisable, colour
touch panel offers
fast, easy access
to frequently used
functions.

Your KYOCERA Business Partner:
ECOSYS stands for ECOlogy,
ECOnomy and SYStem printing.
With their long-life components, ECOSYS devices
are designed to maximise durability and mini-
mise the total cost of ownership with regard to
maintenance, administration and consumables.
The cartridge-free system means that only the
toner has to be replaced regularly. The modular
design concept allows you to add workflow-
enhancing functions as required. Integrated
system software provides long-term cross-
network compatibility. KYOCERA’s long-life com-
ponents cost you and the environment less.
0412DSE6525MFP_EMC
PRESCRIBE IIe
With the KYOCERA page design and control language PRESCRIBE II, even complex graphics, logos and forms (multipart forms) can be created
independently on the system and saved and updated in the printer. Consequently, integration into print files no longer applies. They are only
accessed as required and therefore relieve the load on the network.
KYOCERA NetViewer
KYOCERA NetViewer enables complete monitoring and control of all ECOSYS printers and digital KYOCERA multifunction units from any
Windows
©
PC and thus provides ideal network administration. It also supports the standardised SNMP protocol.
Command Center RX
The ‘Command Center RX’ enables to control and manage various settings by accessing the device via Web browser. E.g. automatically
updating of screens, customizing user screens, viewing department & restriction settings.
HyPAS™ – Hybrid Platform for Advanced Solutions
KYOCERA’s powerful software development platform enables users to customise the functionality and operations of the multifunctional device to
their individual requirements.
KYOCERA Document Solutions Europe B.V. – Branch Office Germany – Otto-Hahn-Straße 12 – 40670 Meerbusch – Germany
Tel [phone] – Fax [phone]
www.kyoceradocumentsolutions.eu – [email protected].com
KYOCERA Document Solutions Inc. – 2-28, 1-Chome – Tamatsukuri – Chuo-Ku
Osaka 540-8585 – Japan – www.kyoceradocumentsolutions.com
* KYOCERA does not warrant that any specifications mentioned will be error-free. Specifications are subject to change without
notice. Information is correct at time of going to press. All other brand and product names may be registered trademarks or
trademarks of their respective holders and are hereby acknowledged. **Depending on the country.
FS-6525MFP
MONOCHROME MULTIFUNCTIONAL FOR A4/A3 FORMAT
General
Technology: KYOCERA ECOSYS, Mono Laser, HyPAS™
solution platform
Engine speed: Up to 25/12 pages A4/A3 per minute
Resolution: 600 x 600 dpi (print), 600 x 600 dpi (scan/copy)
Warm-up time: Approx. 20 seconds or less
Time to first print: Approx. 8 seconds or less
Time to first copy: Approx. 9.2 seconds or less (DP), 7.8 seconds
or less (Platen Cover)
CPU: PowerPC 464 / 800 MHz
Memory: Standard 1GB, max. 2GB
Standard interface: USB 2.0 (Hi-Speed), USB Host 2.0, Fast
Ethernet 10/100/1000Base-TX, slot for optional print server,
slot for optional CompactFlash®-Card
Integrated accounting: 100 department codes
Dimensions with document processor (WxD xH): 590 x 590 x 694 mm
Weight with document processor: Approx. 52.2 kg including
toner container
Power source: AC 220 ~240 V, 50/60 Hz
Power consumption
Printing: 530 W
Ready mode: 114 W
Sleep-mode: 0.9 W
Noise (sound pressure level: ISO 7779/ISO 9296)
Copying/Printing: 46.8 dB(A)
Stand-by: 27.1 dB(A)
Safety standards: TÜV/GS, CE
This unit is manufactured according to ISO 9001 quality
standard and ISO 14001 environmental standard.
Paper handling
All paper capacities quoted are based on a paper thick-
ness of max. 0.11 mm. Please use paper recommended by
KYOCERA under normal environmental conditions.
Input capacity: 100-sheet multi-purpose tray, 45–256 g/m2
(52–163 g/m2for larger than A4/Letter size), A3, A4, A5, A6,
B5, Letter, Legal, Folio, envelopes, Custom
(98 x 148 to 297 x 432 mm)
500-sheet universal paper cassette, 60–163 g/m2, A3, A4, A5,
B5, Letter, Legal, Folio, max. input capacity with options: 1,600
sheets
Duplex unit: Duplex as standard supports 60–163 g/m2
Reversing document processor: 50-sheet, Simplex scan
45–160 g/m2, Duplex scan 50–120 g/m2, A3, A4, A5, B5,
Letter, Legal, Custom (140 x 182 to 297 x 432 mm)
Output capacity:
Max. 300 sheets; 250 sheets face-down
(Main Tray) plus 50 sheets (Job Separator Tray)
Print functions
Controller language: PRESCRIBE IIe
Emulations: PCL 6 (5e/XL), KPDL 3 (PostScript 3 compatible),
PDF Direct Print, XPS Direct Print
Operating systems: All current Windows operating systems,
MAC OS X Version 10.4 or higher, Unix, Linux as well as other
operating systems on request
Fonts/barcodes: 93 outline fonts (PCL 6, KPDL3) + 8 (Windows
Vista), 1 Bitmap font, 45 types of one-dimensional barcodes,
1 type of two-
dimensional barcode (PDF417)
Features: encrypted PDF Direct Print, IPP printing, e-mail
printing, WSD print, secure printing via SSL, IPsec, SNMPv3,
Private Print
Copy functions
Max. original size: A3/Ledger
Continuous copying: 1–999
Zoom range: 25–400% in 1% steps
Preset magnification ratios: 5 Reductions / 5 Enlargements
Exposure mode: Auto, manual: 7 steps
Image adjustments: Text, Photo, Text + Photo, Graphic/Map,
Copy/Printout
Features: Scan-once-copy-many, electronic sort, 2in1, 4in1,
job reserve, priority print, program, auto duplex copy, split
copy, continuous scan, auto cassette change (PF-470 or PF-471
is required), copy density control, Prevent Bleed-Through
Scan functions
Functionality: Scan-to-Email, Scan-to-FTP, Scan-to-SMB, Scan to
USB Host, Network TWAIN , WIA, WSD scan
Scan speed: 40 ipm (300 dpi, A4, b/w), 20 ipm (300 dpi, A4 colour)
Scan resolution: 600, 400, 300, 200 dpi (256 greyscales per colour)
Max. scan size: A3, Ledger
Original recognition: Text, photo, text + photo, optimised
for OCR
File types: TIFF, PDF, PDF/A, JPEG, XPS
Compression method: MMR /JPEG
Features: Colour scan, integrated address book, Active Directory
support, encrypted data transfer, multi send (e-mail, fax, SMB/FTP
folder, print) at once
Fax functions (optional)
Compatibility: ITU-T Super G3
Modem speed: Max. 33.6 kbps
Transmission speed: Less than 3 sec
Scanning speed: 2.0 seconds (Quick Scanning, Bitmap)
Address book: 200 entries
Scanning density
Normal: 8 dot/mm x 3.85 line/mm
Fine: 8 dot/mm x 7.7 line/mm
Superfine: 8 dot/mm x 15.4 line/mm
Ultrafine: 16 dot/mm x 15.4 line/mm
Halftone: 256 grey scales
Maximum original size: A3, Ledger
Compression method: JBIG, MMR, MR, MH
Memory reception: 700 sheets or more
Features: Network fax, duplex transmission and reception,
encrypted transmission and reception, polling transmission
and reception, broadcast
Consumables
Average continuous toner yield in accordance with
ISO/IEC 19752
TK-475 Toner Kit: Microfine toner black for 15,000 pages A4
Capacity of starter toner is 3,000 pages A4
Options
Fax System (U)
Paper handling
PF-470 Paper feeder: Max. 500 sheets; 60–163 g/m2; A3, A4,
A5, B5, Letter, Legal, Custom (98 x 148 to 297 x 432 mm)
PF-471 Paper feeder: Max. 1,000 sheets; 60–163 g/m2; A3, A4,
A5, B5, Letter, Legal, Custom (98 x 148 to 297 x 432 mm)
DF-470* Document finisher + AK-470: Max. 500 sheets A4,
60–163 g/m2; A3, A4, A5, B5, Letter, Legal, Custom (98x148
to 297x432 mm), 3 positions stapling up to 50 sheets A4 or
25 sheets A3
*Bridge unit AK-470 is required for the use of DF-470
Memory upgrade
MDDR2-1024: 1,024 MB
CF*-Card: CF-4 (4 GB) for printing forms, fonts, logos, macro storage
and for HyPAS™ applications
USB Flash Memory: Supports direct printing and scanning of
PDF, XPS, TIFF, JPEG files via USB Host interface
UG-33: ThinPrint support
USB IC Card Reader + Card Authentication Kit (B): Support for
various authentication keys available
Optional interface
IB-50:
Gigabit-Ethernet board 10BaseT/100BaseTX/1000BaseT
CB-470 Cabinet: Wooden desk with storage capacity, inclu-
ding castors (wheels)
CB-471 Base Unit: Wooden base for height increase (to be used
only with PF-470 or PF-471)
CB-472 Cabinet: Metal desk with storage capacity, including
castors (wheels)
CB-473 Base Unit: Metal base for height increase (to be used
only with PF-470 or PF-471)
Warranty
1-year warranty as standard.** KYOCERA guarantees the drum
and developer for 3
years or 300,000 pages (whichever
occurs sooner), provided
each device is used and cleaned in
accordance with the service instructions.
Up to 5-year on-site warranty extensions
available for product and options.
Product depicted includes optional extras.
