Kyocera ECOSYS M2135dn User manual

ECOSYS M2135dn
ECOSYS M2635dn
ECOSYS M2635dw
ECOSYS M2735dw
ECOSYS M2040dn
ECOSYS M2540dn
ECOSYS M2540dw
ECOSYS M2640idw
PF-1100 SERVICE
MANUAL
Published in Febuary 2017
2S0SM063
Rev.3

CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BAT-
TERIES ACCORDING TO THE INSTRUCTIONS.
It may be illegal to dispose of this battery into the municipal waste stream. Check with your local solid waste
officials for details in your area for proper disposal.
ATTENTION
IL Y A UN RISQUE D’EXPLOSION SI LA BATTERIE EST REMPLACEE PAR UN MODELE DE TYPE
INCORRECT. METTRE AU REBUT LES BATTERIES UTILISEES SELON LES INSTRUCTIONS DONNEES.
Il peut être illégal de jeter les batteries dans des eaux d’égout municipales. Vérifiez avec les fonctionnaires
municipaux de votre région pour les détails concernant des déchets solides et une mise au rebut appropriée.
Notation of products in the manual
For the purpose of this service manual, products are identified by print speed.
Product name Manual classification KDJ KDA KDE KDAU
ECOSYS M2135dn
35 ppm
-LCD -
ADF
-
×○○ ×
ECOSYS M2635dn
FAX
××○○
ECOSYS M2635dw Wi-Fi ×○××
ECOSYS M2735dw TSI × × ○○
ECOSYS M2040dn
40 ppm
-LCD -
DADF
×○○ ○
ECOSYS M2540dn
FAX
××○○
ECOSYS M2540dw Wi-Fi ○○××
ECOSYS M2640idw TSI HyPAS ○○○ ○

Revision history
Revision Date Pages Revised contents
1 2 November 2016 CONTENTS Chenge: Page number
1-4, 1-5 Added: FAX functions
2-4 Added: Name of parts number 7
2-9 Correction: Description of "IMPORTANT"
3-2 Correction: Item name of 3-2/3-2(1)
Added: 4. Fuser pressure release motor
3-11 Correction: Description of the thermopile
4-3, 4-4
6-9, 6-10 Correction: Maintenance kits
4-36 to 38 Correction: Correction: Procedure of detaching and
rettaching the laser scanner unit
4-75 Deleted: Procedure of detaching the front cover
4-95 to 99 Added: Procedure of detaching the Wi-Fi PWB
6-68 Deleted: Destination code (22)
7-2 Correction: rear cover →cover
Deleted: (1-1)Step2 to 4
7-9, 7-10 Added: J4002 to J4018
7-15 to 83 Added: 7-2 Self diagnostic, 7-3 Image formation failure
7-4 Electric failure, 7-5 Mechanical failure
2 28 December 2016 1-5 Added: (Dual Scan / Simplex ADF)
3-11 Correction: Description of 7 (right →front)
4-101
6-37 Deleted: 5.(1) *:When using the SSFC card, ... Added: U222 Description of SSFC
6-10 Correction: Description of Toner Log
3 30 January 2017 6-40 Correction: Initial setting : DBL(Folio)
4-101
6-53, 6-54
6-63
9-12
Correction: Chart no.(7505000106→302NM94330)
4-100
6-53 to 55
6-58, 6-62
9-12
Correction: Chart no.(7505000107→302NM94340)
6-105 Added: U964 Contents (Description of transfer files)

This page is intentionally left blank.

Safety precautions
This booklet provides safety warnings and precautions for our service personnel to ensure the safety of
their customers, their machines as well as themselves during maintenance activities. Service personnel
are advised to read this booklet carefully to familiarize themselves with the warnings and precautions
described here before engaging in maintenance activities.

Safety warnings and precautions
Various symbols are used to protect our service personnel and customers from physical danger and
to prevent damage to their property. These symbols are described below:
DANGER: High risk of serious bodily injury or death may result from insufficient attention to or incorrect
compliance with warning messages using this symbol.
WARNING: Serious bodily injury or death may result from insufficient attention to or incorrect compliance
with warning messages using this symbol.
CAUTION: Bodily injury or damage to property may result from insufficient attention to or incorrect com-
pliance with warning messages using this symbol.
Symbols
The triangle ( ) symbol indicates a warning including danger and caution. The specific point of attention is
shown inside the symbol.
General warning. Warning of risk of electric shock.
Warning of high temperature.
indicates a prohibited action. The specific prohibition is shown inside the symbol.
General prohibited action. Disassembly prohibited.
indicates that action is required. The specific action required is shown inside the symbol.
General action required. Remove the power plug from the wall outlet.
Always ground the copier.

1. Installation Precautions
WARNING
• Do not use a power supply with a voltage other than that specified. Avoid multiple connections to
one outlet: they may cause fire or electric shock. When using an extension cable, always check that
it is adequate for the rated current. .....................................................................................................
• Connect the ground wire to a suitable grounding point. Not grounding the copier may cause fire or
electric shock. Connecting the earth wire to an object not approved for the purpose may cause
explosion or electric shock. Never connect the ground cable to any of the following: gas pipes, light-
ning rods, ground cables for telephone lines and water pipes or faucets not approved by the proper
authorities. ..........................................................................................................................................
CAUTION:
• Do not place the copier on an infirm or angled surface: the copier may tip over, causing injury. .........
• Do not install the copier in a humid or dusty place. This may cause fire or electric shock. .................
• Do not install the copier near a radiator, heater, other heat source or near flammable material. This
may cause fire. ...................................................................................................................................
• Allow sufficient space around the copier to allow the ventilation grills to keep the machine as cool
as possible. Insufficient ventilation may cause heat buildup and poor copying performance. ............
• Always handle the machine by the correct locations when moving it. .................................................
• Always use anti-toppling and locking devices on copiers so equipped. Failure to do this may cause
the copier to move unexpectedly or topple, leading to injury. ..............................................................
• Avoid inhaling toner or developer excessively. Protect the eyes. If toner or developer is accidentally
ingested, drink a lot of water to dilute it in the stomach and obtain medical attention immediately.
If it gets into the eyes, rinse immediately with copious amounts of water and obtain medical atten-
tion. .....................................................................................................................................................
• Advice customers that they must always follow the safety warnings and precautions in the copier’s
instruction handbook. .........................................................................................................................

2. Precautions for Maintenance
WARNING
• Always remove the power plug from the wall outlet before starting machine disassembly. ................
• Always follow the procedures for maintenance described in the service manual and other related
brochures. ..........................................................................................................................................
• Under no circumstances attempt to bypass or disable safety features including safety mechanisms
and protective circuits. ........................................................................................................................
• Always use parts having the correct specifications. ............................................................................
• Always use the thermostat or thermal fuse specified in the service manual or other related brochure
when replacing them. Using a piece of wire, for example, could lead to fire or other serious acci-
dent. ...................................................................................................................................................
• When the service manual or other serious brochure specifies a distance or gap for installation of a
part, always use the correct scale and measure carefully. ..................................................................
• Always check that the copier is correctly connected to an outlet with a ground connection. ...............
• Check that the power cable covering is free of damage. Check that the power plug is dust-free. If it
is dirty, clean it to remove the risk of fire or electric shock. .................................................................
• Never attempt to disassemble the optical unit in machines using lasers. Leaking laser light may
damage eyesight. ...............................................................................................................................
• Handle the charger sections with care. They are charged to high potentials and may cause electric
shock if handled improperly. ...............................................................................................................
CAUTION
• Wear safe clothing. If wearing loose clothing or accessories such as ties, make sure they are safely
secured so they will not be caught in rotating sections. ......................................................................
• Use utmost caution when working on a powered machine. Keep away from chains and belts. ..........
• Handle the fixing section with care to avoid burns as it can be extremely hot. ..................................
• Check that the fixing unit thermistor, heat and press rollers are clean. Dirt on them can cause
abnormally high temperatures. ...........................................................................................................

• Do not remove the ozone filter, if any, from the copier except for routine replacement. ......................
• Do not pull on the AC power cord or connector wires on high-voltage components when removing
them; always hold the plug itself. ........................................................................................................
• Do not route the power cable where it may be stood on or trapped. If necessary, protect it with a
cable cover or other appropriate item. ................................................................................................
• Treat the ends of the wire carefully when installing a new charger wire to avoid electric leaks. ..........
• Remove toner completely from electronic components. .....................................................................
• Run wire harnesses carefully so that wires will not be trapped or damaged. ......................................
• After maintenance, always check that all the parts, screws, connectors and wires that were
removed, have been refitted correctly. Special attention should be paid to any forgotten connector,
trapped wire and missing screws. .......................................................................................................
• Check that all the caution labels that should be present on the machine according to the instruction
handbook are clean and not peeling. Replace with new ones if necessary. .......................................
• Handle greases and solvents with care by following the instructions below: ......................................
· Use only a small amount of solvent at a time, being careful not to spill. Wipe spills off completely.
· Ventilate the room well while using grease or solvents.
· Allow applied solvents to evaporate completely before refitting the covers or turning the power
switch on.
· Always wash hands afterwards.
• Never dispose of toner or toner bottles in fire. Toner may cause sparks when exposed directly to
fire in a furnace, etc. ...........................................................................................................................
• Should smoke be seen coming from the copier, remove the power plug from the wall outlet immedi-
ately. ...................................................................................................................................................
3. Miscellaneous
WARNING
• Never attempt to heat the drum or expose it to any organic solvents such as alcohol, other than the
specified refiner; it may generate toxic gas. ........................................................................................
• Keep the machine away from flammable liquids, gases, and aerosols. A fire or an electric shock
might occur. ........................................................................................................................................

This page is intentionally left blank.

2S0/2S1/2S2/2S3/2S4/2S5/2SG/2SH/3RA-1
CONTENTS
1 Specifications
1-1 Specifications ...........................................................................................................................1-1
(1) Common function ................................................................................................................1-1
(2) Copy Functions....................................................................................................................1-3
(3) Printer Functions .................................................................................................................1-3
(4) Scanner Functions...............................................................................................................1-4
(5) FAX Functions.....................................................................................................................1-4
(6) Document Processor...........................................................................................................1-5
(7) Paper Feeder (PF-1100)(Option) ........................................................................................1-6
1-2 Part Names...............................................................................................................................1-7
(1) Machine Exterior..................................................................................................................1-7
(2) Connectors/Interior..............................................................................................................1-8
(3) With Optional Equipments Attached....................................................................................1-9
(4) Operation Panel (TSI)........................................................................................................1-10
(5) Operation Panel Keys (LCD).............................................................................................1-11
1-3 Overview of Optional Equipment............................................................................................1-13
(1) Expansion Memory............................................................................................................1-14
(2) PF-1100 "Paper Feeder" ...................................................................................................1-15
(3) Card Authentication Kit(B) "Card Authentication Kit".........................................................1-15
(4) UG-33 "ThinPrint Option" ..................................................................................................1-15
(5) SD/SDHC Memory Card....................................................................................................1-15
2 Installation
2-1 Environment .............................................................................................................................2-1
2-2 Installing the main unit..............................................................................................................2-2
(1) Unpacking and checking bundled items..............................................................................2-3
(1-1) Main unit.....................................................................................................................2-3
(1-2) Paper Feeder (Option) ...............................................................................................2-4
(2) Installing the optional equipment.........................................................................................2-5
(3) Connecting to other device..................................................................................................2-5
(4) Connecting to the cable.......................................................................................................2-6
(4-1) LAN Cable..................................................................................................................2-6
(4-2) USB cable ..................................................................................................................2-6
(5) Loading Paper.....................................................................................................................2-7
(6) Power-up.............................................................................................................................2-9
(7) Default (TSI model) ...........................................................................................................2-10
(7-1) Setting Date and Time..............................................................................................2-10
(7-2) Network Settings......................................................................................................2-11
(7-3) Altitude Adjustment Setting......................................................................................2-12
(7) Default (LCD model)..........................................................................................................2-13
(7-1) Setting Date and Time..............................................................................................2-13
(7-2) Network Settings......................................................................................................2-14
(7-3) Altitude Adjustment Setting......................................................................................2-16
(8) Installing Software.............................................................................................................2-17
(9) Output Maintenance Report (Executing Maintenance mode U000) (For Service)............2-18
(10) Clearing the counts (Executing Maintenance Mode U927) (For service)..........................2-18
(11) Terminating the maintenance mode (For service).............................................................2-18
(12) Installing the main unit is complete....................................................................................2-18

2S0/2S1/2S2/2S3/2S4/2S5/2SG/2SH/3RA-1
3 Machine Design
3-1 Cross-section view ...................................................................................................................3-1
(1) Main unit + Document processor + Paper feeder (option)...................................................3-1
3-2 The configuration of the electrical components........................................................................3-2
(1) Electric parts........................................................................................................................3-2
(1-1) Machine left side ........................................................................................................3-2
(1-2) Machine right side ......................................................................................................3-3
(1-3) Document processor ..................................................................................................3-4
(1-4) Paper feeder (option) .................................................................................................3-4
(2) Descriptions about the major PWBs....................................................................................3-5
(2-1) Main/Engine PWB......................................................................................................3-5
(2-2) High-voltage PWB......................................................................................................3-5
(2-3) Power source PWB....................................................................................................3-5
(2-4) Operation panel PWB (TSI)........................................................................................3-6
(2-5) Operation panel PWB (LCD)......................................................................................3-6
(3) Electric parts layout.............................................................................................................3-7
(3-1) PWBs .........................................................................................................................3-7
(3-2) Sensors and Switches..............................................................................................3-10
(3-3) Motors ......................................................................................................................3-13
(3-4) Others.......................................................................................................................3-15
3-3 Drive system...........................................................................................................................3-17
(1) Drive system for the paper conveying ...............................................................................3-17
(2) Each section drive .............................................................................................................3-18
(2-1) Primary paper feed drive..........................................................................................3-18
(2-2) Drum drive................................................................................................................3-18
(2-3) Developer drive........................................................................................................3-19
(2-4) Fuser unit drive.........................................................................................................3-19
3-4 Mechanical construction.........................................................................................................3-20
(1) Paper feed section.............................................................................................................3-20
(1-1) Cassette paper feed section.....................................................................................3-20
(1-2) MP tray paper feed section ......................................................................................3-22
(2) Optical section...................................................................................................................3-24
(2-1) Image scanner unit...................................................................................................3-24
(2-2) Laser scanner unit....................................................................................................3-26
(3) Developer section..............................................................................................................3-28
(3-1) Developer unit..........................................................................................................3-28
(4) Drum section .....................................................................................................................3-30
(4-1) Main charger unit......................................................................................................3-30
(4-2) Cleaning...................................................................................................................3-30
(5) Conveying/Transfer and Separation section .....................................................................3-32
(6) Fuser section.....................................................................................................................3-34
(7) Eject and feedshift section.................................................................................................3-36
(8) Duplex conveying section..................................................................................................3-38
(9) Document processor .........................................................................................................3-40
(10) Paper feeder (option).........................................................................................................3-42
4 Maintenance
4-1 Precautions for the maintenance..............................................................................................4-1
(1) Precautions..........................................................................................................................4-1
(2) Storage and handling of the drum.......................................................................................4-1
(3) Storage of the toner container.............................................................................................4-1

2S0/2S1/2S2/2S3/2S4/2S5/2SG/2SH/3RA-1
(4) Screening of the toner container .........................................................................................4-2
4-2 Maintenance parts....................................................................................................................4-3
(1) Maintenance kits..................................................................................................................4-3
(2) Executing the maintenance mode after replacing the maintenance kit............................4-3
(3) Maintenance parts list..........................................................................................................4-3
(4) Periodic maintenance Procedures.......................................................................................4-4
4-3 Maintenance parts replacement procedures ............................................................................4-5
(1) Cassette paper feed section................................................................................................4-5
(1-1) Detaching and reattaching the Paper feed roller........................................................4-5
(1-2) Detaching and reattaching the retard roller................................................................4-6
(1-3) Detaching and reattaching the MP paper feed pulley ................................................4-8
(2) Developer section..............................................................................................................4-10
(2-1) Detaching and reattaching the developer unit..........................................................4-10
(3) Drum section .....................................................................................................................4-11
(3-1) Detaching and reattaching the drum unit .................................................................4-11
(3-2) Detaching and reattaching the main charger unit.....................................................4-13
(4) Transfer section.................................................................................................................4-14
(4-1) Detaching and reattaching the transfer roller unit ....................................................4-14
(5) Fuser section.....................................................................................................................4-17
(5-1) Detaching and reattaching the fuser unit..................................................................4-17
4-4 Disassembly and Reassembly ...............................................................................................4-21
(1) Outer covers......................................................................................................................4-21
(1-1) Detaching and reattaching the left rear cover ..........................................................4-21
(1-2) Detaching and reattaching the ISU rear cover.........................................................4-21
(1-3) Detaching and reattaching the ISU left cover...........................................................4-22
(1-4) Detaching and reattaching the ISU right cover.........................................................4-22
(1-5) Detaching and reattaching the left cover..................................................................4-23
(1-6) Detaching and reattaching the right cover................................................................4-24
(1-7) Detaching and reattaching the front cover ...............................................................4-26
(1-8) Detaching and reattaching the rear cover ................................................................4-27
(2) Optical section...................................................................................................................4-28
(2-1) Detaching and reattaching the laser scanner unit (LSU)..........................................4-28
(2-2) Detaching and reattaching the image scanner unit (ISU).........................................4-39
(2-3) Detaching and reattaching the operation panel (TSI model)....................................4-45
(2-4) Detaching and reattaching the operation panel (LCD model) ..................................4-47
(2-5) Detaching and reattaching the ISU top frame..........................................................4-48
(2-6) Detaching and reattaching the scanner carriage assembly .....................................4-48
(3) Drive section......................................................................................................................4-49
(3-1) Detaching and reattaching the main motor ..............................................................4-49
(3-2) Detaching and reattaching the fuser pressure release drive unit.............................4-54
(3-3) Detaching and reattaching the MP solenoid (front side) ..........................................4-60
(3-4) Detaching reattaching the clutch..............................................................................4-64
(3-5) Detaching and reattaching the eject solenoid ..........................................................4-70
(4) Others................................................................................................................................4-83
(4-1) Detaching and reattaching the speaker....................................................................4-83
(4-2) Detaching and reattaching the eraser......................................................................4-89
(4-3) Replacing the language sheet (TSI model)..............................................................4-91
(4-4) Replacing the language sheet (LCD model) ............................................................4-92
(4-5) Fan motor attachment direction................................................................................4-93
(5) PWBs.................................................................................................................................4-94
(5-1) Detaching and reattaching the main/engine PWB....................................................4-94

2S0/2S1/2S2/2S3/2S4/2S5/2SG/2SH/3RA-1
(5-2) Detaching and reattaching the high voltage PWB..................................................4-102
(5-3) Detaching and reattaching the low voltage power source PWB.............................4-110
(5-4) Detaching and reattaching the FAX PWB..............................................................4-116
(5-5) Detaching and reattaching the Wi-Fi PWB.............................................................4-124
(5-6) Detaching and reattaching the USB PWB..............................................................4-126
(5-7) Detaching and reattaching the operation panel PWB (TSI model).........................4-138
(5-8) Detaching and reattaching the operation panel PWB (LCD model).......................4-141
(6) Detaching and reattaching the document processor.......................................................4-143
(6-1) Detaching and reattaching the DP pick up pulley,
DP paper feed roller and DP separation pad .........................................................4-143
(6-2) Detaching and reattaching the DP front cover .......................................................4-145
(6-3) Detaching and reattaching the DP rear cover........................................................4-146
(6-4) Detaching and reattaching the DP main motor ......................................................4-146
4-5 Maintenance parts replacement procedures (option)...........................................................4-148
(1) Paper feeder....................................................................................................................4-148
(1-1) Detaching and reattaching the PF main PWB........................................................4-148
(1-2) Detaching and reattaching PF conveying motor. ...................................................4-149
(1-3) Detaching and reattaching the PF clutch. ..............................................................4-152
5Firmware
5-1 Firmware update (TSI model)...................................................................................................5-1
5-2 Firmware update (LCD model) .................................................................................................5-6
6 Maintenance mode
6-1 Maintenance mode...................................................................................................................6-1
(1) Executing the maintenance mode.......................................................................................6-1
(2) Maintenance modes list ......................................................................................................6-2
(2-1) Content of the maintenance mode .............................................................................6-5
6-2 Service modes......................................................................................................................6-107
(1) TSI model........................................................................................................................6-107
(1-1) Executing the service mode...................................................................................6-107
(1-2) Descriptions of service modes ...............................................................................6-109
(2) LCD model.......................................................................................................................6-113
(2-1) Executing the service mode...................................................................................6-113
(2-2) Descriptions of service modes ...............................................................................6-115
7Troubleshooting
7-1 Conveying failures....................................................................................................................7-1
(1) Prior standard check items..................................................................................................7-1
(1-1) Paper jam due to the cover-open detection ...............................................................7-2
(1-2) Paper jam due to the wave or curl in the fuser section of the damp paper................7-2
(1-3) Paper jam due to the dog-ear, paper skew,
paper creases, fusing failure or the paper curl...........................................................7-2
(1-4) Paper jam caused by the conveying guide, paper entry guide or the feedshift guide 7-3
(1-5) Paper jam caused by incorrectly loaded paper in the cassette..................................7-3
(1-6) Paper jam due to the inferior paper............................................................................7-3
(1-7) Paper jam caused by the conveying rollers or the paper feed pulleys.......................7-4
(1-8) Paper jam due to the sensor ......................................................................................7-5
(1-9) Paper jam due to the setting / detection failure..........................................................7-5
(1-10) Paper jam due to the static electricity.........................................................................7-6

2S0/2S1/2S2/2S3/2S4/2S5/2SG/2SH/3RA-1
(1-11) Paper jam caused by installation in the environment
where paper inside the cassette is always moist. ......................................................7-6
(2) Paper jam indication............................................................................................................7-7
(3) Paper jam detection condition.............................................................................................7-8
(4) First check item .................................................................................................................7-12
7-2 Self diagnostic ........................................................................................................................7-15
(1) Self diagnostic function......................................................................................................7-15
(2) Self diagnostic codes.........................................................................................................7-15
(3) System Error (Fxxxx) Outline ............................................................................................7-32
7-3 Image formation failure...........................................................................................................7-37
(1) Poor image (due to DP and scanner reading)...................................................................7-38
(1-1) No image appears (entirely white)............................................................................7-39
(1-2) No image appears (entirely black)............................................................................7-41
(1-3) The entire image is faint...........................................................................................7-42
(1-4) The background is colored.......................................................................................7-44
(1-5) Vertical white streaks or bands appear....................................................................7-46
(1-6) Vertical white streaks or bands appear....................................................................7-47
(1-7) Horizontal black streaks appear...............................................................................7-49
(1-8) The image is partly dark or bright.............................................................................7-51
(1-9) Black dots appear in the image................................................................................7-53
(1-10) Characters are blurred .............................................................................................7-54
(1-11) Regular error images arise at the leading edge of the original and copy.................7-56
(1-12) The image is partly missing......................................................................................7-57
(1-13) The image is blurred.................................................................................................7-59
(1-14) Image center does not align with the original center................................................7-61
(1-15) Moire ........................................................................................................................7-62
(1-16) Skewed image..........................................................................................................7-63
(1-17) Abnormal image.......................................................................................................7-64
(2) Poor image (Image forming factor)....................................................................................7-65
(2-1) No image appears (entirely white)............................................................................7-66
(2-2) No image appears (entirely black)............................................................................7-67
(2-3) The entire image is faint...........................................................................................7-68
(2-4) It is foggy at the background image .........................................................................7-70
(2-5) Vertical white streaks or bands appear....................................................................7-71
(2-6) Vertical white streaks or bands appear....................................................................7-72
(2-7) There are horizontal bands in white or black............................................................7-73
(2-8) Uneven density vertically..........................................................................................7-74
(2-9) Uneven density horizontally .....................................................................................7-75
(2-10) Black dots appear in the image................................................................................7-76
(2-11) Offset occurs ............................................................................................................7-76
(2-12) The image is partly missing......................................................................................7-77
(2-13) The image is blurred.................................................................................................7-77
(2-14) Irregular horizontal white streaks appear in the image
Dots appear in the image .........................................................................................7-78
(2-15) Granular image (low solid image density)................................................................7-79
7-4 Electric failure.........................................................................................................................7-80
7-5 Mechanical failure...................................................................................................................7-83
7-6 Error codes.............................................................................................................................7-84
(1) Scan to SMB error code ....................................................................................................7-84
(2) Scan to FTP error code.....................................................................................................7-85
(3) Scan to E-mail error code..................................................................................................7-86

2S0/2S1/2S2/2S3/2S4/2S5/2SG/2SH/3RA-1
7-7 Error codes.............................................................................................................................7-88
(1) Error codes........................................................................................................................7-88
(2) Error codes........................................................................................................................7-89
(2-1) Error code table: U004XX Interrupted phase B........................................................7-92
(2-2) Error code table: U006XX Problems with the unit....................................................7-93
(2-3) Error code table: U008XX Page transmission error .................................................7-93
(2-4) Error code table: U009XX Page reception error.......................................................7-93
(2-5) Error code table: U010XX G3 transmission error.....................................................7-94
(2-6) U011XX G3 reception error......................................................................................7-96
(2-7) Error code table: U017XX V.34 transmission error..................................................7-97
(2-8) Error code table: U018XX V.34 reception error........................................................7-98
(2-9) Error code table: U023XX Page reception error.......................................................7-98
(2-10) Error code table: U044XX Encrypted transmission error .........................................7-98
8PWBs
8-1 Description for PWB .................................................................................................................8-1
(1) Main/Engine PWB ...............................................................................................................8-1
(2) High voltage PWB .............................................................................................................8-10
(3) Low voltage power supply PWB........................................................................................8-12
(4) Operation panel PWB (TSI)...............................................................................................8-14
(5) Operation panel PWB (LCD).............................................................................................8-19
(6) PF main PWB (option).......................................................................................................8-21
9 Appendixes
9-1 Appendixes...............................................................................................................................9-1
(1) Repetitive defects gauge.....................................................................................................9-1
(2) Firmware environment commands ......................................................................................9-2
(3) Chart of image adjustment procedures .............................................................................9-10
(4) Wiring diagram ..................................................................................................................9-13
(4-1) Standard...................................................................................................................9-13
(4-2) PF-1100 (Options)....................................................................................................9-17
Installation Guide
PF-1100 (250 sheets × 1 Paper Feeder)

2S0/2S1/2S2/2S3/2S4/2S5/2SG/2SH/3RA
1-1
1 Specifications
1-1 Specifications
(1) Common function
Item Description
40 ppm model M2640idw M2540dw M2540dn M2040dn
35 ppm model M2735dw M2635dw M2635dn M2135dn
Type Desktop
Printing Method Electrophotography by semiconductor laser
Paper Weight Cassette 60 to 163 g/m2
Multi Purpose
Tray
60 to 220 g/m², 209g/m² (Hagaki)
Paper Type Cassette Plain, Rough, Recycled, Preprinted, Bond, Color, Prepunched,
Letterhead, Thick, High Quality, Custom 1 to 8 (Duplex:
Same as Simplex)
Multi Purpose
Tray
Plain, Transparency (OHP film), Rough, Vellum, Labels, Recy-
cled, Preprinted, Cardstock, Coated, Color, Prepunched, Let-
terhead, Envelope,
Thick, High Quality, Custom 1 to 8
Paper Size Cassette A4, A5-R, A5, A6, B5, Letter, Legal, Folio, 216 × 340 mm,
Statement, Executive, Oficio II, 16K, B5(ISO),
Custom (105 x 148 to 216 x 356 mm)
Multi Purpose
Tray
A4, A5-R, A5, A6, B5, B6, Letter, Legal, Folio, 216 × 340 mm,
Statement-R,Executive, Oficio II, 16K, B5(ISO),
Envelope #10, Envelope #9, Envelope #6 3/4,
Envelope Monarch, Envelope DL, Envelope C5, Hagaki (Card-
stock), Oufukuhagaki (Return postcard), youkei 4, youkei 2,
Custom (70 x 148 to 216 x 356 mm)
Printable Area Print margin for top, bottom and both sides is 4.2 mm.
Warm-up Time
(23°C/ 73.4°F,
60%)
Power on 20secondsor
less 17 seconds or less
Sleep 10 seconds or less
Paper Capac-
ity
Cassette 300 Sheets (64 g/m2)*1
250 Sheets (80 g/m2) *1
Multi Purpose
Tray
120 sheets (A4/Letter or smaller) (64 g/m2)
100 sheets (A4/Letter or smaller) (80 g/m2)
Output Tray
Capacity
Inner tray 150 sheets (80 g/m²)
Image Write System Semiconductor laser and electrophotography (twin beams)
Scanning light source 3-color LED light source
Scanning method Flat-face scanning method with the CIS contact image sensor
Photoconductor OPC drum (diameter 30 mm)
Charging system Positive charge scorotron system

2S0/2S1/2S2/2S3/2S4/2S5/2SG/2SH/3RA
1-2
Developer system Magnetic mono-component developing system
Toner: magnetic toner
Toner feed system: leveled toner feed
Transfer system Transfer roller method
Separation system Curvature separation + discharger needle (grounded) : except
100 V model
Curvature separation + discharger needle (DC voltage
impressed) : 100 V model only
Cleaning system Counter blade
Charge erasing system Exposure by cleaning lamp (LED)
Fusing system Sliding belt + foam press roller system
Heat source: halogen heater
Abnormal temperature preventing device: 2 thermocat
Operation Panel 4.3inch TSI 5-line LCD
Memory 512 MB
Interface USB Interface Connector: 1 (Hi-Speed USB)
Network interface: 1
(10 BASE-T/100 BASE-TX/1000 BASE-T)
USB Port: 1 (Hi-Speed USB)
Fax Fax:1Fax:1Fax:1-
Wireless LAN WirelessLAN
support Only WirelessLAN support Only --
Operating
Environment
Temperature 10 to 32.5°C/50 to 90.5°F
Humidity 10 to 80%
Altitude 3,500 m/11,482 ft maximum
Brightness 1,500 lux maximum
Dimension (W × D × H) 16.42" × 16.23" × 17.21"417 × 412 × 437 mm (Metric Model)
18.71" × 16.23" × 17.21"475 × 412 × 437 mm (Inch Model)
Weight (without toner container) Approx. 41.9 lb/Approx. 19 kg
Space Required (W × D) (Using multi purpose tray) 14.77" × 28.47"375 × 723 mm
(Metric Model)
(Using multi purpose tray) 14.77" × 28.47"375 × 723 mm (Inch
Model)
Power Source AC100V,50/60Hz,9.7A
AC120 V, 60 Hz, 8.7A
AC220 to 240V, 50 Hz, 4.4 A
*1 Up to upper limit height line in the cassette.
Item Description
40 ppm model M2640idw M2540dw M2540dn M2040dn
35 ppm model M2735dw M2635dw M2635dn M2135dn

2S0/2S1/2S2/2S3/2S4/2S5/2SG/2SH/3RA
1-3
(2) Copy Functions
(3) Printer Functions
Item Description
40 ppm model 35 ppm model
Copy Speed A4/A5 40 sheets/min
Letter 42 sheets/min
Legal 34 sheets/min
B5 27 sheets/min
A5-R 19 sheets/min
A6 19 sheets/min
16K 22 sheets/min
A4/A5 35 sheets/min
Letter 37 sheets/min
Legal 30 sheets/min
B5 24 sheets/min
A5-R 17 sheets/min
A6 17 sheets/min
16K 20 sheets/min
First Copy Time
(A4, place on the platen, feed
from Cassette)
6.4 seconds or less 6.9 seconds or less
Zoom Level Manual mode: 25 to 400%, 1% increments
Auto mode:Preset Zoom
Continuous Copying 1 to 999 sheets
Resolution 600 × 600 dpi
Supported Original Types Sheet, Book, 3-dimensional objects (maximum original size:
Legal/Folio)
Original Feed System Fixed
Item Description
40 ppm model 35 ppm model
Printing Speed Same as Copying Speed.
First Print Time (A4, feed from
Cassette)
6.4 seconds or less 6.8 seconds or less
Resolution 300 dpi × 300 dpi, 600 dpi × 600 dpi, 1200 dpi equivalent ×
1200 dpi equivalent, 1800 dpi equivalent × 600 dpi
Operating System Windows XP, Windows Server 2003, Windows Vista, Windows
7, Windows 8, Windows 8.1, Windows 10, Windows Server
2008/R2, Windows Server 2012/R2, Mac OS X v10.5 or later
Interface USB Interface Connector: 1 (Hi-Speed USB)
Network interface: 1
(10 BASE-T/100 BASE-TX/1000 BASE-T)
Wireless LAN support Only
Page Description Language PRESCRIBE
Emulations PCL6(PCL-XL, PCL5c) KPDL3, (PostScript3 compatible),
PDF, XPS, OpenXPS

2S0/2S1/2S2/2S3/2S4/2S5/2SG/2SH/3RA-1
1-4
(4) Scanner Functions
(5) FAX Functions
FAX Function
Item Description
Resolution 300 × 300 dpi, 200 × 200 dpi, 200 × 100 dpi, 600 × 600 dpi*1,
400 × 400 dpi*1, 200 × 400 dpi*1
*1 One-sided scanning
File Format TIFF (MMR/JPEG compression), JPEG, PDF (MMR/JPEG
compression), High compressive PDF, XPS, OPEN XPS,
Encrypted PDF, PDF/A-1
Scanning Speed*2
*2 When using the document processor (except TWAIN and WIA scanning)
(A4 landscape, 300 dpi × 300 dpi, Image quality: Text/Photo
original)
1-sided B/W: 40 images/min, Color: 23 images/min
2-sided B/W: 32 images/min, Color: 16 images/min*3
*3 Simultaneous duplex scan: 40ppm model only
Interface Ethernet (10 BASE-T/100 BASE-TX/1000 BASE-T), USB
Transmission System SMBv3, SMTP, FTP, FTP over SSL, USB, TWAIN*4, WIA*5,
WSD
*4 Available Operating System: Windows XP/Windows Vista/Windows Server 2003/Windows Server 2008/
Windows Server 2008 R2/Windows 7/Windows 8/Windows 8.1/Windows 10/Windows Server 2012/Win-
dows Server 2012 R2
*5 Available Operating System: Windows Vista/Windows Server 2008/Windows Server 2008 R2/Windows 7/
Windows 8/
Windows 8.1/Windows Server 2012/Windows Server 2012 R2/Windows 10
Item Description
Compatibility G3
Communication Line Subscriber telephone line
Transmission Time Less than 3 seconds (33600 bps, JBIG, ITU-T A4-R #1 chart)
Transmission Speed 33600/31200/28800/26400/24000/21600/19200/16800/14400/
12000/9600/7200/4800/2400 bps
Coding Scheme JBIG/MMR/MR/MH
Error Correction ECM
Original Size Max. width: 8 1/2"/216 mm, Max. length: 14 1/32"/356 mm
Automatic Document Feed Max. 50 sheets (with document processor)
Resolution Scan:
200 × 100 dpi Normal (8 dot/mm × 3.85 line/mm)
200 × 200 dpi Fine (8 dot/mm × 7.7 line/mm)
200 × 400 dpi Super (Super Fine) (8 dot/mm × 15.4 line/mm)
400 × 400 dpi Ultra (Ultra Fine) (16 dot/mm × 15.4 line/mm)
Print: 600 dpi
Gradations 256 shades (Error diffusion)
One Touch Key 100 keys *1, 22 keys *2
Multi-Station Transmission Max. 100 destinations
