KYORITSU 5000 User manual

MODEL 5000/5001
KEWLEAKLOGGER
LeakLoggerforMeasuring&Recordingleakagecurrent
INSTRUCTIONMANUAL
KYORITSUELECTRICALINSTRUMENTS
WORKS,LTD.

Contents
1.Safetywarnings ...............................................................................1
2.Features ...............................................................................3
3.Instrumentlayout...............................................................................4
3-1)Panel ...............................................................................4
3-2)Menuconfiguration...................................................................5
3-3)LCD ..........................................................................................7
3-4)Displayedmessage..................................................................8
4.Recordingprocedures......................................................................9
Step1:Preparation.........................................................................10
Step2:Confirmationandchangeofsetvalue................................11
Step3:Preparationbeforearecording ..........................................12
Step4:Startofrecording................................................................14
Step5:Stopofrecording................................................................15
5.Recordingmodesandconditions...................................................16
Continuousrecordingmode ..........................................................16
Eventrecordingmode ...................................................................19
Maxvaluerecordingmode .............................................................21
Capturerecordingmode.................................................................23
6.Recordingmodes ........................................................................25
7.Othersettings(Setting2) .................................................................30
8.DatatransfertoPC ........................................................................35
9.Batteryreplacement ........................................................................37
10.Specification ..................................................................................38

―
1
―
1.SafetyWarnings
Thisinstrumenthasbeendesigned,manufacturedandtestedaccording
toIEC61010:SafetyrequirementsforElectronicMeasuringapparatus,
anddelivered inthe bestcondition afterpassed theinspection. This
instruction manual contains warnings and safety rules which must be
observedby the userto ensure safeoperation of theinstrumentand
retainitinsafecondition.Therefore, read throughtheseoperating
instructionsbeforeusingtheinstrument.
WARNING
¡Readthrough andunderstand the instructionscontained inthis
manualbeforestartingtousetheinstrument.
¡Saveandkeepthe manualathandtoenable quick reference
whenevernecessary.
¡Besuretousetheinstrumentonlyinitsintendedapplications.
¡Besuretounderstandandfollowallsafetyinstructionscontained
inthemanual.
Besuretoobservetheaboveinstructions.Failuretofollowtheabove
instructionsmay cause injury,instrument damage and/or damage to
equipmentundertest.
Thesymbolindicatedontheinstrumentmeansthattheusermust
refertorelatedpartsinthemanualforsafeoperationoftheinstrument.
Besuretocarefullyreadtheinstructionsfollowingeachsymbolin
themanual.
DANGER isreserved for conditions and actionsthat arelikely to
causeseriousorfatalinjury.
WARNING isreserved for conditions and actionsthat cancause
seriousorfatalinjury.
CAUTION is reserved for conditions and actions that can cause a
minorinjuryorinstrumentdamage.

DANGER
¡Nevermakemeasurementonthecircuitinwhich voltage over
AC300Vexists.
¡Donotattempttomakemeasurementinthepresenceofflammable
gasses.
Otherwise,the use of the instrumentmay causesparking, which
canleadtoanexplosion.
¡Transformerjawtipsaredesignednottoshortthecircuitundertest.
Ifequipment undertest hasexposed conductiveparts, however,
extraprecautionshouldbetakentominimizethepossibilityof
shorting.
¡Never attempt to use the instrument if its surface or your handis
wet.
¡Donotexceedthe maximumallowableinputofany measuring
range.
¡NeveropentheBatterycoverduringameasurement.
¡Verifyproper operationon a knownsource beforeuse ortaking
actionasaresultoftheindicationofthedevice.
WARNING
¡Never attempt to make measurement if any abnormal conditions,
suchas brokencase andexposed metalparts arefound on the
instrument.
¡Donotinstallsubstitutepartsormakeanymodificationtothe
instrument.
Forrepairorre-calibration,returntheinstrumenttoyourlocalKEW
distributorfromwhereitwaspurchased.
¡Donottrytoreplacethebatteriesifthesurfaceoftheinstrumentis
wet.
¡Makesuretoremovetheinputclamps,andpoweroffthe
instrumentwhenopeningtheBatterycoverforbatteryreplacement.
CAUTION
¡Do not expose the instrument to the direct sun, high temperature
andhumidityordewfall.
¡Besuretopowerofftheinstrumentafteruse.Whentheinstrument
willnotbeinuseforalongperiod,placeitinstorageafterremoving
thebatteries.
¡Usea cloth dipped in wateror neutraldetergent for cleaningthe
instrument.
Donotuseabrasivesorsolvents.
―
2
―

―
3
―
2.Features
¡Thisinstrument isaleak loggerfor measuringandrecording
leakagecurrent.
¡Capableofrecordingleakagecurrentfrom1to3chwithleakage
clampsensor.(Leakclampsensors:M-8141/8142/8143are
available.)
¡Canmeasureandrecordmax.AC1000mA(50/60Hz)withRMS.
¡LED current indicator flashes when the preset current value is
exceeded.(Event/Max.value/Capturerecordingmode)
¡Canstore60,000datawhenusing1ch,andwhenusingall3ch,
can store 20,000 data at each channel. (Continuous recording
mode)
¡Datawill not belost at batteryreplacement or atlower battery
voltageasitisstoredinnonvolatilememory.
¡CanperformrecordingforlongtimewithPower-savefunction.
¡CantransfertherecordeddatatoPCviaUSBcable.
¡Protectedthroughoutbydouble(reinforced)insulation"F".
¡Thisinstrument provides 4recording modes. Canbe used for
anykinds ofinsulation controls since the usercan selectany
desirablerecordingmodeasusage.Readthroughthe
instructionmanualandunderstandthefeaturesofeach
recordingmodetoselecttheappropriaterecordingmode.

―
4
―
3.Instrumentlayout
3-1)Panel
¡Operationofbutton
¡LCD ・・・ P. 7
¡LEDcurrentindicator ・・・ P.18
¡USB ・・・ P.35
Button
Atrecording/measurementmode:
Atmenumode:
ShifttoMenumode SelectMenu,
Settingchange,Enter
Startandstoprecording
Back,Cancel
Switchchannels SwitchMenuitem,
Increasenumber
Switchranges SwitchMenuitem,
Decreasenumber

―
5
―
3-2)Menuconfiguration

―
6
―

―
7
―
3-1)LCD
100mA 1000mA
Mark Details
Selectedchannelnumber
(Themeasuredvalueatthischannelisdisplayed.)
Auto-power-offisdisabled.
(Instrumentwon'tbeoffautomatically.)
Timerfunctionisactivated.
(Stand-bytillthepresettime.)
Recording
Batterymark
Recordingmode
Displayedwhenviewingtherecordeddata.
Displayedwhenviewingtherecordedmax.
andmin.value.
One-timesystemisactivated.
(Recordingstopswhenmemorybecomesfull.)
Scalefunctionisactivated.
("Measuredresult"x"Scalevalue"isdisplayed.)
Rangehold(Notdisplayedatauto-ranging.)
Menuguide(▲/▼buttoncanbeoperated.)
Measurementrange(100.0mA/1000mA)

―
8
―
3-4)Displayedmessage
Message Meaning
Sensorisnotconnected.
Over-range
Menu:Setting1(SET.1)
Vieworchangetherecordingmode/condition.
Menu:Setting2(SET.2)
VieworchangetheLocationinformationand
auto-power-offfunction.
Menu:Status1(STS.1)
Viewtherecordedquantityandthemax.value
ateachchannel.
Menu:Status2(STS.2)
Viewthenumberofrecordeddataand
RECALL.
Menu:End
Continuousrecordingmode(LOGging)
Eventrecordingmode(detect)
Max.valuerecordingmode(Max)
Capturerecordingmode(CAPture)
PCdataintransit
Warningofmemoryclear

―
9
―
4.Recordingprocedures
Followingexplainstheflowofoperation:through preparationtothestop
ofrecording.
P. 10
Selecttheappropriatesensor,andconnectittothe
instrument.
P. 11
Confirmtherecordingmode.
P. 12
Installtheinstrumentanddosetupsforeach
channel.
P. 14
Startrecording.
P. 15
Stoprecording.
*Therecordeddatacanbeviewedeitherbythefollowingtwomethods.
(1)OnaPC:Referto"8.DatatransfertoPC"inthismanual.(P.35)
(2) Ontheinstrument:Referto(2)Confirmationofrecordeddata (status1)
and (3)Confirmationofrecordeddata(status2) describedinthe
suppliedQuickmanual.
*Pressthe buttonatleast1sec.topowerofftheinstrument.
Step1:Preparation
Step2:Confirmationandchangeofsetvalue
Step3:Preparationbeforearecording
Step4:Startofrecording
Step5:Stopofrecording
▼
▼
▼
▼

―
10
―
Step1:Preparation
1.Connect the clamp sensor to the
instrumentfirmlywithcarefulattentionto
theorientationoftheconnector.
2.Press the button at least 1 sec. to
poweronthe instrument. Releasethe
button when all indications are
displayedontheLCD.
3.TimeisdisplayedontheLCDfor1sec.
If incorrect time is displayed each time
whentheinstrumentispoweredon,
batteryfortheclockmaybeexhausted.
Inthiscase,sendbacktheinstrumentto
yourlocalKEWdistributorfromwhereit
waspurchased.
4.Canmakemeasurementrightafter
poweringontheinstrument.When
(non-connect)is displayed ontheLCD,
a sensor is not connected to the
appropriatechannel; orthe connection
isincorrect.

―
11
―
Step2:Confirmationandchangeofsetvalue
Confirm the mark indicating the
selectedrecordingmode.
Referto"5.Recordingmodesand
conditions"inthis manual tochange
the recording mode or condition
(Recordinginterval/Presetcurrent
value).
Recording
mode Details Referto:
Intermittentmeasured valueis recorded
continuouslyatthepresetinterval.
(15-kind:1sec.to60min.)
P.16
Whenthepresetcurrentvalueisexceeded,
(hereinafter,thiseventisreferredas
currentdetection)threepreviousRMS
value,theRMSvaluewhendetecting it,
andfoursubsequentRMSvalues,8datain
total(0.8sec.)arerecorded.
P.19
Themax.RMSvalueisrecordedatevery
10sec.priortoandsubsequenttothe
currentdetection. It endswhena value
dropsto50%orlessofthepresetcurrent
value;orwhen10min.hasbeenelapsed.
P.21
Tentotwelvewaveforms(for200mS)are
recordedpriortoandsubsequenttothe
currentdetection. P.23
Continuous
recording
Eventrecording
Max.value
Recording
Capture
recording

―
12
―
1.Clamp onthe measuredobject andfix
theClampsensor.
2.Instrumentshallbefirmlyfixedsoasnot
tocomeoffeasily.
1)Hangtheinstrumentonhook:
Canfixtheinstrumentwithahookor
screw by using the hooking hole on
thetopoftheinstrument.
2)Fixtheinstrumentwithmagnetonits
back.Canfixtheinstrumentto
metallicplatewiththemagnetonits
backside.
3.Pressthe buttontoswitchthe
displayofmeasuredvalueamong
Channel(1)and(3).
㩷
㩷
㩷
㩷
㩷
㩷
Step3:Preparationbeforearecording

―
13
―
㩷
㩷
㩷
4.Pressthe buttontoswitchthe
measurementrangesateachchannel.
TheRangeholdfunctionisactivated
whenthe markisdisplayedonthe
LCD.
Note
¡Atcontinuousrecordingmode:
Itswitchesinthesequencebelow.
Auto-ranging→1000mA→100.0mA→
Auto-ranging
¡AtEvent/ Max. value/Capturerecording
mode:
It switches between 1000mA and
100.0mA.
Rangecannotbeswitchedduringa
recording.Selecttheappropriaterange
beforearecording.
5.When only the leftmost segment of the
Battery mark is flashing on the LCD, it
meansbatteryvoltageislow.
Replacethebatterieswithnewones.
WhennothingisdisplayedontheLCD,
thebatteriesareexhausted.Replace
thebatterieswithnewones.

―
14
―
Step4:Startofrecording
Followtheproceduresstatedbelowandstartrecording.
Besuretocheckeachsettingbefore startingarecordingsincethe
settingscannotbechangedduringarecording.
1.Pressdownthe buttonforawhile.
¡Atcontinuous recordingmode orafter
changingtherecordingmode;"CLr"
flashes while the button is being
presseddown.Afewsecondslater,the
measuredvalueandthe"REC"mark
aredisplayedontheLCD.Thena
recordingstarts.
(Thedata,whichhadbeen recorded,
willbeclearedatthistime.Sothe
importantdatamust be transferredto
PCinadvance.)
¡AtEvent/Maxvalue/Capturerecording
modeortherecordingmodeisnot
changed,the "REC"mark flashesand
themeasuredvalueandthe"REC"
markaredisplayedontheLCD.Thena
recordingstarts.
(Attheserecordingmodes,recorded
datawillnotbeclearedwhencontinuous
recordingisperformed.The recorded
datawillbe deletedwhenchanging a
recordingmodeorsensor connecting
channel.Sotheimportantdatamustbe
transferredtoPCinadvance.)
㩷
㩷
㩷
㩷

―
15
―
Followingoperationsareavailableduringarecording.
*Displaythemeasuredvalueateachchannel button
*Recordingstate:Displaythemax.recordedvalue
→Referto(2) Confirmationofrecordeddata(status1) described
inthesuppliedQuickmanual.
*Recordingstate:DisplayRECALL
→Referto(3) Confirmationofrecordeddata(status2) described
inthesuppliedQuickmanual.
*ConfirmthesettingvalueatSetting1"SEt.1" andSetting2"SEt.2".
FollowingoperationsareNOTavailableduringarecording.
*Powerofftheinstrument.
*Switchmeasurementranges.
*ChangethesettingvalueatSetting1"SEt.1" andSetting2"SEt.2".
*CommunicationwithPC
Stoptherecordingoncetodoaboveoperations.
TherecordingendsautomaticallywhenOne-timesystemhasbeensetto
"ON"at"Step2:Confirmationandchangeofthesetvalue".
1.Pressthe buttonatleast1sec.to
stoptherecording.
2.Recordingstops,and the "REC"mark
disappears.Thenthe instrumentgoes
backintomeasurementstate.
Nowrecordingiscomplete.
*Pressthe buttonatleast1sec.topowerofftheinstrument.
Step5:Stopofrecording

―
16
―
5.Recordingmodesandconditions
Continuousrecordingmode:Recordingintervalof1min.
Max.numberofrecordeddata
Usingall3channels Using2channels Usingonly1channel
20,000data 40,000data 60,000data
Max.recordingduration
1sec. 5:33:20 1min. 13days/ 21:20:00
2sec. 11:06:40 2min. 27days/ 18:40:00
5sec. 1day/ 3:46:40 5min. 69days/ 10:40:00
10sec. 2days/ 7:33:20 10min. 138days/ 21:20:00
15sec. 3days/ 11:20:00 15min. 208days/ 8:00:00
20sec. 4days/ 15:06:40 20min. 277days/ 18:40:00
30sec. 6days/ 22:40:00 30min. 416days/ 16:00:00
60min. 833days/ 8:00:00
Note)*Max.recodingdurationislimitedbythebatterylife.
*Max.recordingdurationislengthenedby1.5timeswhenusing2
channels,andtripledwhenusing1channelonly.
1.Powerontheinstrument,andpressthe
button.Thentheinstrumentgoesinto
Menumode.
㩷
EachbuttonactsasfollowsatMenumode.
→:Select,Change,Enter
→:Return,Cancel
→:Switch,Increasesetvalue
→:Switch,Decreasesetvalue
Settingprocedure
Recording
interval
Usingall3channels
Recording
interval
Usingall3channels

―
17
―
2.Pressthe buttonwhen"SEt.1"is
displayedontheLCD.
3.Theselectedrecordingmodeisdisplayed.
When (Continuousrecording mode)
is displayed on the LCD, press the
buttontoproceedtothenextsetting.
Incasethat , or is
displayedontheLCD,pressthe
button.
Thentheindication ontheLCD flashes.
Press the or button to
changeitto .Pressthe
button.
4.Therecordingintervalisdisplayed.
Canbeselectedfrom;1,2,5,10,15,20,30sec.,
1,2,5,10,15,20,30,60min
¡Pressthe buttonandproceedto
thenextstepwhennotchangingthe
setting.
¡Tochangethesetting, press the
button.
Thenthe indicationon the LCDflashes.
Pressthe or buttontoset
thevalueto the desiredone.Then press
the buttontoconfirmit.
㩷
㩷
㩷
㩷
㩷
㩷
㩷

―
18
―
㩷
㩷
㩷
㩷
5.StateofOne-timesystemisdisplayed.
on:Recordingstopswhenmemorybecomes
full.
off:Overwritetheolddata,andstorethe
latestdata.
¡Pressthe buttonandproceedto
thenextstepwhennotchangingthe
setting.
¡Tochangethesetting, press the
button.
Thenthe indicationon the LCDflashes.
Pressthe or buttontoset
thevalueto the desiredone.Then press
the buttontoconfirmit.
6.NowSetting1iscomplete;"End"is
displayedontheLCD.Pressthe
buttontoreturntothescreenonwhich
"SEt.1"isdisplayed.
7.Pressthe buttontogettheinstrument
readyforameasurement.
LEDcurrentindicator
*Atthe Event/Max. value/Capture recording modes, when the preset
currentvalueis exceeded,thecorresponding LED foreachchannel
flashes.The LED flashes each time when the preset currentvalue is
exceededduringameasurement.TheLEDkeepflashingoncethe
eventthatexceedsthepresetcurrentvalueoccursduring arecording.
Pressthe buttononcetorestoretheflashingLED.
Whenthebuttonispressed,theinstrumentgoesintoMenumode.Then
pressthe button.LEDflasheswhenthepresetcurrentvalue
isexceededagain.Pressthe buttontoreturntothemeasurement
screen;aftertheindicationsdisappearedbecauseofPower-save
function.Inthiscase,theLEDisturnedofftemporary.Pressthe
buttonand buttonagaintoturnofftheLEDcompletely.
This manual suits for next models
1
Table of contents
