L.R. Baggs ALIGN SERIES User manual

ALIGN SERIES
DELAY
USER’S GUIDE

INTRODUCTION
The Align Delay brings a classic eect to acoustic
musicians by optimizing the signal for high-delity
instruments. By expanding the range of your sonic
prole while underlining your primary acoustic sound,
the Delay augments both rhythm and melody for a
larger dimensional sound and feel. We’ve combined the
most desirable qualities of both analog and digital
circuitry to create the best possible sound with the
convenient features of a modern platform.
GETTING STARTED
1. Power the Delay with a 9V power supply or a
9V battery.
2. Plug your instrument into the input to activate the
Delay (upper right hand side) and a cable into
the ¼” output (upper left hand side).
3. Plug the ¼” cable into your amp, PA, or next pedal in
the signal chain and experiment with the Delay.
TOP FEATURES
A. TONE
This is a simple control to help you alter the tone of the
delay itself. It will not aect the tone of your instrument,
only the tone of the delay. Turn the control clockwise for
clear, digital-like repeats or counterclockwise for warm,
analog-like repeats.

B. DIVISION
This control sets the delay to a dotted eighth note of
whatever the tempo is set to. Best used with the tap.
C. INSTRUMENT INPUT
The ¼” input is an unbalanced (mono), all-discrete
input. Plugging into the input will activate the Delay,
therefore, unplugging will turn the system o.
C
A
D
G
I
J
H
F
E
B

D. TIME
This control sets the time between the original signal
and the repeated signal. The max time is about one
second. This control will override the tap when used.
E. TAP
This control allows you to manually set the delay tempo.
Tap multiple times at the desired delay tempo. This
control will override the time control when used.
F. ENGAGE
Press the footswitch to engage the eects. When the
light is on, all of the controls on the Delay are engaged.
When the light is o, the whole pedal is true bypassed.
G. REPEATS
This control determines the total number of repeats.
Turn clockwise to increase the number of repeats.
H. ¼” OUT
The ¼” output is an unbalanced, line level output. You
can plug into any amp or device that has a ¼” input.
We recommend running into any other LR Baggs Align
pedals, DI’s, or the Synapse Personal PA System.
I. DELAY
The delay control blends an aected delay signal with
an unaected instrument signal. When turned fully
counterclockwise, no delay will aect the signal. Turn
clockwise to add delay.

SIDE FEATURES
A. DC INPUT
The DC power input is designed for a standard 2mm
plug commonly used with eects pedals and “oorbox”
products. Most power supplies or multi-power devices
designed for musical products may be used. 9VDC
recommended with a 12VDC maximum. Plugging in a
power supply will activate the Delay.
J. TAP TEMPO INPUT
This jack allows for the connection of an external tap
tempo footswitch or time control device to be used with
the pedal.
A

SPECIFICATIONS
1/4” INPUT
Input Impedance: 2.2 Megohms
Preamp Gain: +0dB
Input Level: -25dBv to +4.0dBv (0.056Vrms to 1.591Vrms)
LINE OUTPUT
Output Level: +5.8dBv (1.945Vrms) Un-Balanced
Output Impedance: 220 Ohms
DELAY
Max Delay Time: 1.0 Second
POWER
DC Power Consumption: 450mW Max at 9V
DC Current Draw: 48mA
Voltage Range: 7.5VDC – 12VDC
Power Supply: 9VDC with 100mA minimum
*IMPORTANT: polarity Pos (+) on outside, Gnd (-) on center
9V Battery Life: 11 hours
Signal to Noise: 90dB, Unweighted
PHYSICAL CHARACTERISTICS
0.85 Lbs, 5” Length x 3.25” Width x 2” Depth
These specications may change without notice.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.

PRODUCT REGISTRATION
Register the Align Delay online at:
lrbaggs.com/register
PRODUCT REGISTRATION
& WARRANTY INFORMATION
LIMITED WARRANTY
L.R. Baggs warrants to the using purchaser that this
product shall be free of defects in workmanship and
materials under normal and proper use for a period of
one year. If you experience problems with the Align
Delay, please contact your dealer.
To learn more about this product, please visit:
lrbaggs.com/align
