La Castellana GIANGI CC User manual

1
-GIANGI SC
-GIANGI CC
-LADY
-MARISOL
-MINIFLAM
-SCINTILLA
-SCINTILLA 12 KW
-STELLA
-QUEEN
-SCIROCCO
-TERMOIDRO

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 2

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 3
Service guide and maintenance

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 4
Dear Ladies and Gentlemen,
We wish to thank you for choosing an La Castellana s.r.l. product. We
are sure to provide you a truly effective appliance.
Please read the following instructions in order to appreciate, properly
use and maintain this product, as well as to provide for its maintenance.
Our customer care is at your disposal for any occurrence.
Our best regards
LA CASTELLANA S.R.L.
La Castellana s.r.l. sas takes no responsibility for any errors or
omissions of any kind in the manual translation and reminds
customers that guarantee is to be considered valid only if
followed by proper installation and operation.
For any problems occurring it will prevail and it must be
considered the italian language user's manual.
WARNING:
La Castellana s.r.l. reserves the right to effect minor changes to stove parts. Please be
informed that these may not be identified in this instruction manual. Any aesthetic
alteration regarding our index is due to normal adjustments related to seasonal
collections.

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 5
Contents
:
•Safety guidance page 6
•Specifications:
•Giangi CC page 7
•Giangi SC page 8
•Lady page 9
•Marisol page 10
•Miniflam page 11
•Queen page 12
•Stella page 13
•Scintilla page 14
•Scintilla 12 KW page 15
•Scirocco page 16
•Termoidro page 17
•Selecting a location page 18
•Electrical wiring page 18
•Installations (pipe, vent, air-inlet) page 18
•Pipe layouts page 19
•Chimney calculation table page 20
•Installing pellet stove vents page 21
•Installing an air intake combustion chamber page 22
•Hydraulic connection page 23
•Water filling page 24
•Kind of installation page 25
•Use of fuel page 26
•How to start the air/water stove (due pi board) pages 27-28
•Use of remote control (due pi board) page 29
•Use of automatic ignition (due pi board) select language pages 29-31
•Alarm detector (due pi board) page 32
•Cleaning and maintenance page 33
•Electronic boards connection:
•Giangi, Lady, Marisol, Scintilla, Stella, Lady, Queen page 34
•Scirocco, Miniflam, Termoidro page 35

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 6
SAFETY GUIDANCE
WARNING!!! Caution is never enough: before
installing please
read and follow these important rules:
•Installation of this appliance must conform to local codes, applicable state and law
requirements for smokes in chimney flues. Please remember to ask a specialist to
periodically check the engine in order to ensure an appropriate chimney draft, before and
after combustion. It’s important to let the chimney flue aspire smoke naturally; therefore, it
must be adapted to height and number of curves along the pipe.
•A thorough cleaning of stove and system must be performed at least once a year by the
authorized service center, or warranty will be considered lapsed.
•As the stove needs air consumption for combustion, the stove must be placed near a vent,
besides the one directed to the combustion room.
•Regarding the weight of the stove, before installation make sure that the chosen area is able
to sustain its burden.
•If the floor is made of flammable material like parquet or moquette for instance, place a plate
under it as a ground for the stove (Let the plate extend at least 25/30 cm. beyond the edges
of the stove).
•For your own safety keep at least a 30 cm. distance between hot surrounding panels and
any flammable covering material, such as beaded walls, wallpaper and so on, or else it is
recommended using non-conducting material commercially available.
•Absence of chimney draft (or else obstruction or closure of air inlet grate, or grate itself)
may alter the proper functioning of the stove which, while in automatic ignition, may cause
an excessive pellet dosage in the grate because of the retarded ignition of fire. Immoderate
presence of smoke into combustion room may provoke a violent blaze due to auto ignition of
fumes. It is recommended, in this case, not to open the door of the combustion chamber
•Please avoid using any flammable liquid for fire ignition. .
•Do not touch the glass while stove is on and please be careful before handling it.
•Please don’t leave children alone near the stove when turned on; all its hot sections may
cause severe burns.
•To solve minor problems, do not try to perform any other intervention on this stove except
those recommended in this service guide and remember to disconnect the power source
before doing anything. Even if protected, keep fingers away from propeller and stove auger
(cochlea pipe) when these are working; they could be suddenly crushed or sheared. If you
need to remove a stuck foreign object, please remember to disconnect power source before
and be sure of not being involved in accidents because stove may burn automatically, if so
preset.
•Always check and verify that the combustion chamber’s door is kept perfectly and
hermetically closed during ignition and stove burning.
•Pellet’s automatic ignition is the most delicate phase. In order to execute it without any
problem always keep stove and grate clean.

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 7
SPECIFICATIONS:
GIANGI CC AIR STOVE
Tank Capacity
18 Kg
Efficiency
89 %
Maximum power
8 Kw
Maximum range
20 h
Pellet consumption
Kg/h 0,4 – 1,4
Heatable volume
180 cubic meters
Weight of steel type
Kg. 60
Size of flue release
Ø 80 mm
Size of air inlet
Ø 35 mm
Power consumption
Watt 40 / 250
Remote control frequency
Infrared
Remote control battery
12 V
Protection of general power
Fuses
Protection of circuit board
Fuses
Dimensions
44,5x46,5x79
EQUIPMENT
•Ambient probe
•Power adjustment: 5 stages of automatic modulation
•Power adjustment: 5 stages of automatic ventilation
•Eko-tek system (particulate matters destroyer)
•Weekly thermostat
•Remote control (optional)
•Self-cleaning glass
•Ash pan

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 8
SPECIFICATIONS:
GIANGI SC AIR STOVE
Tank Capacity
18 Kg
Efficiency
89 %
Maximum power
5,5 Kw
Maximum range
20 h
Pellet consumption
Kg/h 0,4 – 0,97
Heatable volume
140 cubic meters
Size of flue release
Ø 80 mm
Weight of steel type
Kg. 60
Size of air inlet
Ø 35 mm
Power consumption
Watt 40 / 250
Remote control frequency
Infrared
Remote control battery
12 V
Protection of general power
Fuses
Protection of circuit board
Fuses
Dimensions
44,5x46,5x79
EQUIPMENT
•Ambient probe
•Power adjustment: 5 stages of automatic modulation
•Power adjustment: 5 stages of automatic ventilation
•Eko-tek system (particulate matters destroyer)
•Self-cleaning glass
•Remote control (optional)
•Ash pan
•External thermostat

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 9
SPECIFICATIONS:
LADY AIR STOVE
Tank Capacity
22 Kg
Efficiency
91 %
Maximum power
10 Kw
Maximum range
25 h
Pellet consumption
Kg/h 0,6 – 1,8
Heatable volume
280 cubic meters
Weight of ceramic type
Kg. 120
Size of flue release
Ø 80 mm
Size of air inlet
Ø 35 mm
Power consumption
Watt 40 / 250
Remote control frequency
Infrared
Remote control battery
12 V
Protection of general power
Fuses
Protection of circuit board
Fuses
Dimensions
48,5x52,5x102
EQUIPMENT
•Ambient probe
•Weekly thermostat
•Remote control
•Power adjustment: 5 stages of automatic modulation
•Power adjustment: 5 stages of automatic ventilation
•Self-cleaning glass
•Ash pan
•Eko-tek system (particulate matter destroyer)

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 10
SPECIFICATIONS:
MARISOL AIR STOVE
Tank capacity
42 Kg
Efficiency
80 %
Max/min power
9/3 Kw
Maximum range
45 h
Pellet consumption
Kg/h 0,7 – 1,8
Heatable volume
230 cubic meters
Weight of steel type
Kg. 145
Carbon monoxide Max./Min.
0,04/0,02%
Size off lue release
Ø 80 mm
Size of air inlet
Ø 50 mm
Power consumption
Watt 130 / 320
Remote control frequency
Infrared
Remote control battery
12 V
Protection of general power
Fuses
Protection of circuit board
Fuses
Dimensions
103x35x102
EQUIPMENT
•Ambient probe
•Weekly thermostat
•Remote control
•Power adjustment: 5 stages of automatic modulation
•Power adjustment: 5 stages of automatic ventilation
•Self-cleaning glass
•Ash pan
•Eko-tek system (particulate matters destroyer)

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 11
SPECIFICATIONS:
MINIFLAM AIR STOVE
Tank capacity
33 Kg
Efficiency
85 %
Max/min power
7/2,5 Kw
Maximum range
42 h
Pellet consumption
Kg/h 0,6 – 1,5
Heatable volume
196 cubic meters
Weight of steel type
Kg. 125
Carbon monoxide Max./Min.
0,04/0,02%
Size of flue release
Ø 80 mm
Size of air inlet
Ø 50 mm
Power consumption
Watt 130 / 320
Remote control frequency
Infrared
Remote control battery
12 V
Protection of general power
Fuses
Protection of circuit board
Fuses
Dimensions
107x28x86
EQUIPMENT
•Ambient probe
•Weekly thermostat
•Remote control
•Power adjustment: 5 stages of automatic modulation
•Power adjustment: 5 stages of automatic ventilation
•Self-cleaning glass
•Ash pan
•Eko-tek system (particulate matters destroyer)

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 12
SPECIFICATIONS:
QUEEN AIR STOVE
Tank capacity
22 Kg
Efficiency
91 %
Max./min. power
12/3 Kw
Maximum range
18 h
Pellet consumption
Kg/h 0,6 – 2,2
Heatable volume
330 cubic meters
Weight
Kg. 190
Size off lue release
Ø 80 mm
Size of air inlet
Ø 35 mm
Power consumption
Watt 40 / 250
Remote control frequency
Infrared
Remote control battery
12 V
Protection of general power
Fuses
Protection of circuit board
Fuses
Dimensions
77x57x102
EQUIPMENT
•Ambient probe
•Weekly thermostat
•Remote control
•Power adjustment: 5 stages of automatic modulation
•Power adjustment: 5 stages of automatic ventilation
•Self-cleaning glass
•Ash pan
•Eko-tek system (particulate matters destroyer)

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 13
SPECIFICATIONS:
STELLA AIR STOVE
Tank capacity
22 Kg
Efficiency
91 %
Maximum power
8 Kw
Maximum range
26 h
Pellet consumption
Kg/h 0,6 – 1,4
Heatable volume
224 cubic meters
Weight of steel type
Kg. 90
Size of flue release
Ø 80 mm
Size of air inlet
Ø 35 mm
Power consumption
Watt 40 / 250
Remote control frequency
Infrared
Remote control battery
12 V
Protection of general power
Fuses
Protection of circuit board
Fuses
Dimensions
48,5x52x99
EQUIPMENT
•Ambient probe
•Weekly thermostat
•Power adjustment: 5 stages of automatic modulation
•Power adjustment: 5 stages of automatic ventilation
•Self-cleaning glass
•Ash pan
•Eko-tek system (particulate matters destroyer)
•Remote control (optional)

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 14
SPECIFICATION:
SCINTILLA AIR STOVE
Tank capacity
22 Kg
Efficiency
91 %
Maximum power
10 Kw
Maximum range
25 h
Pellet consumption
Kg/h 0,6 – 1,8
Heatable volume
280 cubic meters
Weight of steel type
Kg. 90
Weight of ceramic type
Kg.100
Size of flue release
Ø 80 mm
Size of air inlet
Ø 35 mm
Power consumption
Watt 40 / 250
Remote control frequency
Infrared
Remote control battery
12 V
Protection of general power
Fuses
Protection of circuit board
Fuses
Dimensions
48,5x52x99
EQUIPMENT
•Ambient probe
•Weekly thermostat
•Remote control
•Power adjustment: 5 stages of automatic modulation
•Power adjustment: 5 stages of automatic ventilation
•Self-cleaning glass
•Ash pan
•Eko-tek system (particulate matters destroyer)

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 15
SPECIFICATION:
SCINTILLA 12 KW AIR STOVE
Tank capacity
22 Kg
Efficiency
91%
Maximum power
12 Kw
Maximum range
18 h
Pellet consumption
Kg/h 0,6 – 2,2
Heatable volume
330 cubic meters
Weight of ceramic type
Kg.100
Size of flue release
Ø 80 mm
Size of air inlet
Ø 35 mm
Power consumption
Watt 40 / 250
Remote control frequency
Infrared
Remote control battery
12 V
Protection of general power
Fuses
Protection of circuit board
Fuses
Dimensions
48,5x52x99
EQUIPMENT
•Ambient probe
•Weekly thermostat
•Remote control
•Power adjustment: 5 stages of automatic modulation
•Power adjustment: 5 stages of automatic ventilation
•Self-cleaning glass
•Ash pan
•Eko-tek system (particulate matters destroyer)

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 16
SPECIFICATIONS:
SCIROCCO AIR STOVE
Tank capacity
32 Kg
Efficiency
80 %
Maximum power
12 Kw
Maximum range
25 h
Pellet consumption
Kg/h 0,8 – 2,5
Heatable volume
330 cubic meters
Weight of steel type
Kg. 140
Weight of ceramic type
Kg. 180
Size of flue release
Ø 80 mm
Size of air inlet
Ø 35 mm
Power consumption
Watt 130 / 320
Remote control frequency
Infrared
Remote control battery
12 V
Protection of general power
Fuses
Protection of circuit board
Fuses
Dimensions
56,5x56x119,5
EQUIPMENT
•Ambient probe
•Weekly thermostat
•Remote control
•Power adjustment: 5 stages of automatic modulation
•Power adjustment: 5 stages of automatic ventilation
•Self-cleaning glass
•Ash pan
•N. 2 hot air outlets
•Air duct kit

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 17
SPECIFICATIONS:
TERMOIDRO BOILER STOVE
Tank capacity
32 Kg
Efficiency
83 %
Maximum power
16 Kw
Maximum range
25 h
Pellet consumption
Kg/h 1,1 – 3,2
Heatable volume for water distribution
310 cubic meters
Weight of steel type
Kg. 150
Weight of ceramic type
Kg. 190
Size of flue release
Ø 120 mm
Size of air inlet
Ø 35 mm.
Power consumption
Watt 130 / 320
Remote control frequency
Infrared
Remote control battery
12 V
Protection of general power
Fuses
Protectipon of circuit board
Fuses
Dimensions
56,5x56x119,5
EQUIPMENT
•Ambient probe
•Water temperature probe
•Weekly thermostat
•Remote control
•Modulating pellet power
•Ash pan
•Self-cleaning glass
•Safety valve
•Vent valve
•Expansion tank (8 liters capacity)
•Hydraulic pump
•Electronic hydrometer set on pressure max./min.

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 18
SELECTING A LOCATION
AIR STOVES
When positioning the stove select the most central point in the desired location in
order to easily and uniformly heat and obtain a sure optimal profit.
Once you have chosen the right location, near a chimney flue, place a floor protector
under the stove (optional) if the floor is made of flammable material such as parquet or
moquette.
TERMOIDRO ( boiler stove)
A boiler stove requires a wide space, as it may get hot due to stove’s warmth, while all
the rest of the house will be heated through radiators or floor’s heating plant. For the
rest the same principles of normal pellet stoves are valid.
ELECTRICAL WIRING
1. Electrical wiring of the stove needs a grounded electrical outlet. Before plugging
please ensure the efficiency of outlet.
2. While installing please make sure not to let the cable system contact the stove’s
hot parts. To avoid the danger of short circuits, ensure the cable is not crushed by
the stove.
Note: The stove’s plant is protected by two fuses plugged into the main switch
placed behind the stove.
Always remember to remove voltage from the stove before maintenance and/or
inspection!!
INSTALLATIONS
Installing the stove to the chimney flue is an important operation which may
compromise the proper functioning of the stove, so it should be always supervised by
a qualified person. We strongly recommend avoiding any operation without complete
knowledge of all necessary instructions.
Precisely calculate the diameter of the flue apart from the diameter of the stove’s
outlet: the right functioning of a pellet stove depends on the efficiency of the chimney
flue.
Before installation please ensure that the internal section and chimney flue’s
height are adequately measured to obtain a proper draft and that this is not
obstructed or incorrectly connected. Regulation of chimney flue for pellet
stoves follows the same rule for flues for fireplaces and wood stoves, so they
have been produced to make use of natural aspiration. Please remember: they
need an aspiration of 10 Pascal, when hot.
Reductions in diameter on the area of pipes connecting to chimney flue are not allowed:
in order
to obtain a good burning it is better not to install horizontal segments because they’re subject to
be filled with ash from the subsequent reduction of the section provided. Also it is wise to avoid
excessive use of curves (max.2): they should be fixed permanently to get maximum security and
lower pressure drop.

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 19
Important:
Installation of a pellet stove must be performed by a technician
qualified pursuant to CE 46/90.
MAKE SURE that the diameter of the flue release is not reduced for
any reason while performing the installation of the chimney flue.
PIPE LAYOUTS
Combustion air
taken fron outside
Combustion air
taken from outside
Combustion air
taken from outside
Combustion air
taken from
outside

Manuale d’istruzione Sez.7 All. 9 Rev. 3 del 25.07.2013 20
CHIMNEY CALCULATION TABLE
Attention: The table is used for new installations and provides maximum parameters to direct
installers to a correct evaluation of the diameter of the flue which, if not included in those cases
mentioned above, must be adequately adapted and calculated and, in case of formerly existent
furnaces, it must be performed a proper cleaning, to obtain the best draft.
Pipe
Types
Height and
Horizontal Section
Stove Power
8 - 10 KW Stove Power 12- 14 KW Stove Power 18 KW
Pic. 1 From H 200 = 0,5÷1,5 80 120 120
To H 600 = 1,5÷3,0 100 140 140
Pic. 1 From H 600 = 0,5÷1,5 100 120 140
To H 1200 = 1,5÷3,0 120 140 160
Pic. 1 From H 1200 = 0,5÷1,5 120 140 160
To H 1800 = 1,5÷3,0 140 160 180
Pic. 2 From H 200 = 0,5÷1,5 80 80 120
To H 600 = 1,5÷3,0 80 100 120
Pic. 2 From H 600 = 0,5÷1,5 80 100 120
To H 1200 = 1,5÷3,0 100 120 140
Pic. 2 From H 1200 = 0,5÷1,5 80 100 120
To H 1800 = 1,5÷3,0 100 120 140
Pic. 3 From H 200 = 0,5÷1,5 80 120 120
To H 600 = 1,5÷3,0 100 140 140
Pic. 3 From H 600 = 0,5÷1,5 100 120 140
To H 1200 = 1,5÷3,0 120 140 160
Pic. 3 From H 1200 = 0,5÷1,5 120 140 160
To H 1800 = 1,5÷3,0 140 160 180
Pic. 4 From H 200 = 0,5÷1,5 80 120 120
To H 600 = 1,5÷3,0 100 140 140
Pic. 4 From H 600 = 0,5÷1,5 100 120 140
To H 1200 = 1,5÷3,0 120 140 160
Pic. 4 From H 1200 = 0,5÷1,5 120 140 160
To H 1800 = 1,5÷3,0 140 160 180
