La Crosse Technology 308-1425B User manual

Model: 308-1425B www.lacrossetechnology.com/support pg. 1
Model: 308-1425B
Instruction Manual
DC: 083017
WIRELESS COLOR FORECAST STATION
Table of Contents
INITIAL SETUP..................................................................................................................... 3
LCD FEATURES................................................................................................................... 4
BUTTONS ............................................................................................................................. 4
▼ (Down) Button......................................................................................................... 4
TIME SET Button ....................................................................................................... 4
SNOOZE/LIGHT (HI-LOW-OFF) Button.............................................................. 5
HEAT/DEW/SENSOR SEARCH button............................................................... 5
▲ (UP) Button .............................................................................................................. 5
ALERT Button ............................................................................................................. 5
ALARM Button............................................................................................................ 5
SET TIME, DATE, ETC. ...................................................................................................... 6
BACKLIGHT (HI/LO/OFF) ..................................................................................................7
MOON PHASE......................................................................................................................7
TX141TH-Bv2
Sensor

Model: 308-1425B www.lacrossetechnology.com/support pg. 2
ANIMATED COLOR FORECAST ICONS......................................................................7
FORECAST TENDENCY INDICATORS........................................................................ 8
24 HOUR PRESSURE HISTORY GRAPH.................................................................... 8
TEMPERATURE ALERTS.................................................................................................. 8
ARM/DISARM TEMPERATURE ALERTS...................................................................... 9
TEMPERATURE ALERT SOUNDS................................................................................. 9
SEARCH FOR OUTDOOR SENSOR ............................................................................ 9
MAX/MIN TEMPERATURES ...........................................................................................10
HEAT INDEX/DEW POINT ..............................................................................................10
TEMPERATURE TREND ICONS....................................................................................10
MANUAL WWVB RADIO-CONTROLLED TIME SEARCH ..................................... 11
TIME ALARM........................................................................................................................ 11
DEACTIVATE TIME ALARM............................................................................................. 11
SNOOZE................................................................................................................................ 11
POSITION THE FORECAST STATION........................................................................12
POSITION OUTDOOR SENSOR ..................................................................................12
SPECIFICATIONS ..............................................................................................................12
LOW BATTERY ICON .......................................................................................................13
CARE AND MAINTENANCE ..........................................................................................13
WARRANTY AND SUPPORT INFORMATION .......................................................... 14
FCC STATEMENT..............................................................................................................14

Model: 308-1425B www.lacrossetechnology.com/support pg. 3
INITIAL SETUP
Step 1:
Insert 2 new AA batteries (not included)
into the TX141TH-Bv2 sensor. Observe
the correct polarity.
Step 2:
Insert the 5.0 volt AC adapter (included) into the forecast station.
Step 3:
(Optional) Insert 3 AAA batteries (not included) into the forecast
station.
Step 4:
After 5 minutes, place the sensor outside in a shaded location.
Maximum transmission range is 300 ft. (91 meters).
Note:
If the outdoor temperature area shows dashes after 3 minutes, hold
the HEAT/DEW button on the weather station to search for the sensor.
Press the TX button on the sensor to send a signal.
TX
Button
AC Adapter

Model: 308-1425B www.lacrossetechnology.com/support pg. 4
LCD FEATURES
BUTTONS
▼ (Down) Button
Setting-
•Press to decrease values during setting.
•Hold 2 seconds to quickly adjust values.
Default Time Display-
•Press to display minimum temperature/humidity.
•Hold 2 seconds to clear minimum temperature/humidity memory.
Temperature Alert-
•Press to disarm alerts
TIME SET Button
Default Time Display-
•Press to start or stop a WWVB time signal search
•Hold for 3 seconds to set time/calendar, etc.
WWVB
Time
Calendar +
Alarm
Color
Animated
Forecast +
Tendency
Outdoor
Humidity with
Trend
Indoor
Temperature
with Trend
Indoor/Outdoor
Temperature
Alerts + Indoor
Humidity with
Trend
Outdoor
Temperature
with Trend
24 Hour
Pressure
History Graph
with Trend
Moon Phase

Model: 308-1425B www.lacrossetechnology.com/support pg. 5
SNOOZE/LIGHT (HI-LOW-OFF) Button
Default Time Display-
•Press to change the LCD backlight brightness. HI/LOW/OFF
•Press to activate backlight for 10 seconds (without adaptor).
Time Alarm-
•Press to activate the snooze function when alarming
HEAT/DEW/SENSOR SEARCH button
Default Time Display-
•Press once to view Heat Index.
•Press twice to view Dew Point.
•Hold to search for Outdoor sensor.
▲ (UP) Button
Setting-
•Press to increase the values during setting.
•Hold 2 seconds to quickly adjust values.
Default Time Display-
•Press to view maximum temperature/humidity.
•Hold 2 seconds to clear maximum temperature/humidity memory.
Temperature Alert-
•Press to arm alerts
ALERT Button
Default Time Display-
•Press to toggle between Outdoor High Alert, Outdoor Low Alert,
Indoor High Alert and Indoor Low Alert.
•Hold to enter Alert setting
ALARM Button
Default Time Display-
•Press once to show alarm time
•Hold for 2 seconds enter alarm setting mode
Alarm Mode-
•Press to activate or deactivate time alarm.

Model: 308-1425B www.lacrossetechnology.com/support pg. 6
SET TIME, DATE, ETC.
1. Hold the
TIME
SET
button to enter time set mode.
2. Press the ▲ or ▼ button to adjust values.
3. Press the
TIME SET
button to confirm adjustments and move to the
next item.
Settings order:
1. WWVB Reception
2. Time Zone
3. DST Indicator,
4. 12/24 Hour Time Format
5. Hour
6. Minutes,
7. Ye a r
8. Month
9. Date
10. Fahrenheit/Celsius
WWVB Time On/Off Time Zone
DST ON/OFF 12/24 Time Format
Hours Minutes
Year Month
Date Fahrenheit/Celsius
Press the
TIME
SET
button to exit or wait 20 seconds.

Model: 308-1425B www.lacrossetechnology.com/support pg. 7
BACKLIGHT (HI/LO/OFF)
When using A/C power (for constant light):
•Press the HI/LOW/OFF button to adjust the backlight.
When using battery power only:
•Press the HI/LOW/OFF button for 10 second backlight.
MOON PHASE
The Moon phase is based on the lunar calendar.
ANIMATED COLOR FORECAST ICONS
Animated forecast icons use changing atmospheric pressure to predict
weather conditions for the next 12-hours with 70-75% accuracy.
INTELLIGENT WEATHER FORECAST
This station learns; please allow 7-10 days for barometric calibration. This
will ensure an accurate personal forecast for your location.
The forecast station samples the barometric pressure every twelve
minutes.
These samples are averaged hourly and daily then stored in
nonvolatile memory.
The three hour pressure icon change is based off of the last four
average hourly readings.
The icons forecast the weather in terms of getting better or worse and not
necessarily sunny or rainy as each icon indicates.

Model: 308-1425B www.lacrossetechnology.com/support pg. 8
FORECAST TENDENCY INDICATORS
Working with the forecast icons, the tendency indicators let you know if the
weather is improving, steady or worsening.
Rising Pressure
Weather is Expected
to Improve
Steady Pressure
Weather is Expected
to Stay the Same
Falling Pressure
Weather is Expected
to Worsen
24 HOUR PRESSURE HISTORY GRAPH
•The bar chart indicates the air pressure history
trend over the last 24 hours.
•The columns represent the pressure change
(”InHg” or “hPa”) readings at specific times.
•The “0” is equal to the current pressure and
each bar represents how past pressure was
compared
to the current pressure.
•Read the graph from left to right. If the bars are rising, it means that the
weather is getting better due to the increase of air pressure.
•If the bars go down, it means the air pressure has dropped and the
weather is expected to get worse from the present time.
TEMPERATURE ALERTS
The forecast station offers individual, programmable high and low
temperature alerts.
Hold the
ALERT
button for five seconds, until the forecast station beeps, to
select and set temperature alert values. Each alert value will flash
separately during alert set mode.

OUTDOOR HIGH
alert will flash. Press the ▼ or ▲ buttons to set the alert
value, and press the ALERT button to confirm. Then press the ALERT
button again switch to OUTDOOR LOW setting.

OUTDOOR LOW
alert will flash. Press the ▼ or ▲ buttons to set the alert
value, and press the ALERT button to confirm. Then press the ALERT
button again switch to INDOOR HIGH setting.

Model: 308-1425B www.lacrossetechnology.com/support pg. 9

INDOOR HIGH
alert will flash. Press the ▼ or ▲ buttons to set the alert
value, and press the ALERT button to confirm. Then press the ALERT
button again switch to INDOOR LOW setting.

INDOOR LOW
alert will flash. Press the ▼ or ▲ buttons to choose the
value, and press the ALERT button to confirm and exit.
Note:
After selecting temperature alert values use the next step to turn
individual alerts ON or OFF.
ARM/DISARM TEMPERATURE ALERTS
In normal time mode, press and release the
ALERT
button to toggle
between:
oOutdoor HI
oOutdoor Lo
oIndoor HI
oIndoor LO
Press the ▲ button to
arm
the selected alert.
The alert bell appears when each alarm is activated.
Press the ▼ button to
disarm
the selected alert.
OFF will show in the Alerts area if no alert is active.
TEMPERATURE ALERT SOUNDS
When temperature alert sounds, the corresponding alert bell will flash.
The alert beeps once every minute, until the temperature is out of alert
range.
Press any button to stop alert. The alert bell will still show.

Disarm Alert
: In normal mode, hold and release the ALERT button to
select the alert to disarm. With HI or LO alert selected, press the ▼ button
disarm alert.
SEARCH FOR OUTDOOR SENSOR
•Hold the HEAT/DEW button to search for the outdoor sensor.
•The strength signal icon will animate until the sensor signal is received
or for 3 minutes if no signal available.

Model: 308-1425B www.lacrossetechnology.com/support pg. 10
MAX/MIN TEMPERATURES
The Forecast station provides the daily minimum and maximum
temperatures each day starting at midnight (12:00 AM). The Forecast
station automatically resets the min/max temperatures at midnight (12:00
AM).
View MIN data:
Press and release the ▼ button to view the minimum
Indoor and Outdoor Temperatures.
Reset MIN data:
Hold the ▼ button for five seconds and the Indoor and
Outdoor Minimum Temperatures will be reset.
View MAX data:
Press and release the ▲button to view the maximum
Indoor and Outdoor Temperatures.
Reset MAX data:
Hold the ▲ button for five seconds and the Indoor and
all Outdoor Maximum Temperatures will be reset.
Note:
The temperature areas will show dashes briefly then return to
current temperatures.
HEAT INDEX/DEW POINT
The HEAT/DEW button toggles between Heat Index, Dew Point, and Mold
Risk. Each feature will display for 10 seconds then return to default display
if the button is not pressed again.
View Heat Index:
From a normal display, press the HEAT/DEW button
once and Heat Index will show in place of the outdoor temperature.
Note:
Heat index will be the same number as the temperature until the
outdoor temperature is above 80 °F (26.7°C).
View Dew Point Temperature:
From a normal display, press the
HEAT/DEW button twice and Dew Point will show place of the outdoor
temperature.
Note:
Dew Point is lower than the actual temperature.
TEMPERATURE TREND ICONS
The temperature (2°F/1°C) and humidity (3% RH) trend indicators update
every 30 minutes or less.
•
Temperature has risen in the past 3 hours.
•
Humidity has risen in the past 3 hours.

Model: 308-1425B www.lacrossetechnology.com/support pg. 11
•Temperature has not changed in the past 3 hours.
•Humidity has not changed in the past 3 hours.
•
Temperature has fallen in the past 3 hours.
•
Humidity has fallen in the past 3 hours.
MANUAL WWVB RADIO-CONTROLLED TIME SEARCH
•Hold the
TIME SET
button to start or stop a WWVB signal search.
•WWVB Icon will flash
For information about WWVB visit:
www.nist.gov/pml/div688/grp40/wwvb.cfm
TIME ALARM
Hold the
ALARM
button for 5 seconds to enter the alarm time set mode.
1. The alarm hour digit will flash in the time display.
2. Press and release the ▼ or ▲ buttons to select the hour.
3. Press and release the ALARM button to set the minutes. The minute
digits will flash.
4. Press and release the ▼ or ▲ buttons to select the minutes.
5. Confirm with the ALARM button and exit.
6. The bell icon will show indicating the alarm is active.
7. The bell icon will flash when the alarm is sounding.
DEACTIVATE TIME ALARM
1. Press and release the ALARM button once to show alarm
time.
2. Press and release the ALARM button to deactivate the Alarm.
3. The bell icon will disappear indicating the alarm is no longer
active.
SNOOZE
1. When the alarm sounds, press the SNOOZE/LIGHT button to trigger
snooze alarm for 10 minutes. The snooze icon
Zz
will flash by the
weekday when the snooze feature is active.
2. To stop alarm for one day, press ALARM button, while in snooze mode.
The bell icon will remain solid.
Note
: When the alarm sounds, it continues for 2 minutes and then
shuts off completely.

Model: 308-1425B www.lacrossetechnology.com/support pg. 12
POSITION THE FORECAST STATION
The forecast station has a wide base to sit on a desk or table.
•For best WWVB reception orientate the forecast station with the front
of the back facing Ft. Collins, Colorado.
•Choose a location 6 feet or more from electronics such as cordless
phones, gaming systems, televisions, microwaves, routers etc.
•Place within range of the outdoor sensor.
•The maximum transmitting range in open air is 300 feet (91 meters).
Obstacles such as walls, windows, stucco, concrete and large metal
objects can reduce the range.
POSITION OUTDOOR SENSOR
•Mount the outdoor sensor on a north-facing wall or in any well shaded
area. Under an eave or deck rail is preferred.
•The maximum transmitting range to the forecast station is over 300
feet (91 meters) in open air, not including walls.
SPECIFICATIONS
Indoor
:
Temperature Range: +32°F to +122°F (0°C to 50°C)
Humidity Range: 10%-99% (RH)
Interval: About every 30 seconds
Outdoor
:
Temperature Range: -40°F to 140°F (-40°C to 60°C)
Alkaline Batteries: -20°F to 140°F (-28.8°C to 60°C)
Lithium Batteries: -40°F to 140°F (-40°C to 60°C)
Note:
Temperatures below - 20°F (-28.8°C) require Lithium batteries in the
outdoor sensor.
Humidity Range: 10%-99% (RH)
Distance: Over 300 ft. (91 meters)
RF 433MHz (open air)
Interval: About every 50 seconds
Power:
Primary AC Power: AC6#: GPU280500150WA00
5.0 Volt 150mA adapter included
Optional: 3-AA, IEC, LR6 batteries (not included)

Model: 308-1425B www.lacrossetechnology.com/support pg. 13
TX141TH-Bv2 Sensor: 2-AA, IEC, LR6 batteries (not included)
Battery Life:
Battery life is over 24 months when using
reputable batteries.
Dimensions:
Forecast Station: 6.16” W x 9.65” H x 0.925” D
(156.5 x 245.1 x 23.5 mm)
TX141TH-Bv2 Sensor: 5.11” H x 1.57" W x 0.82" D
(129.8 x 40 x 20.8 mm)
LOW BATTERY ICON
•When displayed in Outdoor Temperature section, replace
batteries in the outdoor sensor.
•When displayed in Indoor Temperature section, replace
batteries in the forecast station.
CARE AND MAINTENANCE
•Do not mix old and new batteries.
•Do not mix Alkaline, Standard, Lithium, or Rechargeable Batteries.
•Always purchase the correct size and grade of battery suitable for the
intended use.
•Replace all batteries of a set at the same time.
•Clean the battery contacts and also those of the device prior to battery
installation.
•Ensure the batteries are installed correctly with regard to polarity (+and
-).
•Remove batteries from equipment when it is not to be used for an
extended period.
•Promptly remove expired batteries.
Low
Battery
Icon

Model: 308-1425B www.lacrossetechnology.com/support pg. 14
WARRANTY AND SUPPORT INFORMATION
La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on
this product relating to manufacturing defects in materials & workmanship.
Before returning a product, please contact our friendly customer support with questions or
visit our online help:
Phone: [phone]
Online Product Support and Registration:
www.lacrossetechnology.com/support
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy, and if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
This device must not be co-located or operating in conjunction with any other antenna or
transmitter.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user authority to operate
the equipment.
All rights reserved. This manual may not be reproduced in any form, even in part, or
duplicated or processed using electronic, mechanical or chemical process without the written
permission of the publisher. This booklet may contain errors or misprints. The information it
contains is regularly checked and corrections are included in subsequent editions. We
disclaim any responsibility for any technical error or printing error, or their consequences.
All trademarks and patents are recognized.
