WS6205 Instruction Manual
Features:
 DCF Radio control time function
 Perpetual Calendar Up to Year 2099
 Day of week in 15 languages user selectable: English, German, French, Spanish, Italian, Dutch, Danish, Portuguese,
Norwegian, Swedish, Polish, Finnish, Czech, Hungarian, and Russian
 Time in optional 12/24 hour format.
 Daily Alarm Function
 Automatic snooze function
 Barometric pressure:
— Barometric pressure measurement ranges: 600 hPa/mb～1100 hPa/mb & 17.72 inHg～32.50 inHg
— Pressure alternatively in hPa/mb or inHg
 Humidity: Indoor & OUT measurable range: 20%RH ~ 95%RH
 Temperature:
— Indoor temperature measurement ranges: -9.9°C (13.9°F) ~ 50°C (122°F)
—OUT temperature measurement ranges: -40°C (-44°F) ~ 70°C (158°F)
— Temperature alternatively in °C or °F.
—OUT thermometer and frost alert
 Minimum/maximum display for air humidity and temperature
 Wireless OUT Sensor:
— Wall Mount or Table Stand
— One Wireless Thermo Sensor Included
— 433.92MHz RF transmitting frequency
— 60 meter transmission range in an open area
 The weather forecasting function
 Power Supply:
Weather Station:
Battery: 2 x LR6 AA
Wireless Remote Sensor:
Battery:2 x LR3 AAA
F.Y.I.:
The wireless remote sensor can work at -30°C to +70°C. Please choose the right battery according to the limit
temperature of the wireless sensor:
Alkaline zinc manganese battery can work at -20°C to +60°C
Polymer lithium ion rechargeable battery can work at -40°C to +70°C.

WS6205 Instruction Manual
Weather Station Appearance
Part A-Positive LCD
A1: OUT Temperature
A2: OUT Humidity
A3: OUT Temperature Alert
A4: Time/Calendar or Alarm time/ Day
A5: Barometric pressure
A6: Histogram shows the trend of 24 hours of atmospheric pressure
A7: Indoor Humidity
A8: Indoor comfort
A9: Indoor Temperature
A10: Weather Forecasting
A11: Outdoor comfort
Part B – Back button and power
B1: “ ” touch field
B2: “ ” button
B3: “ ” button
B4: “ ” button
B5: “ ” button
B6: “ ” button
B7: “ ” button
B8: “MEM” button
B9: Power adapter
B10: Battery compartment

WS6205 Instruction Manual
Part C –Wireless Remote Sensor:
C1: LCD display – Temperature
C2: LCD display – Humidity
C3: Transmit signal LED
C4: “°C/°F” button
C5: “TX” button
C6: “CHANNEL 1 or 2 or 3” switch
C7: Battery compartment

WS6205 Instruction Manual
Initial operation:
 Open Weather Station battery compartment cover
 Insert 2 x AA batteries observing polarity [ “+” and “ –“ marks]
 When you insert the batteries, all the icon on the LCD display will briefly light up for 3 seconds, and you will
hear a beep tone, and detect indoor temperature & humidity.
 Then insert 2 x AAA batteries in the outdoor sensor observing polarity [ “+” and “ –“ marks]. Be sure the
switch button is on channel 1.
 The Weather Station will now start to make a connection to the OUT sensor. This operation takes about 3
minutes and is displayed by a flashing reception RF antenna symbol in the “OUT” display area on the
receiver.
 After receiver has created a connection to the OUT sensor, it will then be enters the Radio control time
receive mode.
Reception of the Radio signal:
 The clock automatically starts the DCF signal search after 3 minutes of any restart or changing of new fresh
batteries. The radio mast icon starts to flash.
 At 1:00 /2:00 / 3:00 am, the clock automatically carries out the synchronization procedure with the DCF
signal to correct any deviations to the exact time. If this synchronization attempt is unsuccessful (the radio
mast icon disappears from the display), the system will automatically attempt another synchronization at the
next full one hour. This procedure is repeated automatically up to total 5 times.
 To start manual DCF signal reception, press and hold down the “+” button for two seconds. If no signals
received within 7 minutes, then the DCF signal search stops (the radio mast icon disappears) and start again
at the next full one hour.
 During RC reception，to stop searching radio signal, press the “+” button once.
F.Y.I.:
 A flashing radio mast icon indicates that the DCF signal reception has started
 A continuously displayed radio mast icon indicates that the DCF signal was received successfully
 We recommend a minimum distance of 2.5 meters to all sources of interference, such as televisions or
computer monitors
 Radio reception is weaker in rooms with concrete walls (e.g.: in cellars) and in offices. In such extreme
circumstances, place the system close to the window.

WS6205 Instruction Manual
 During the RCC receive mode, only the "+" button function, other button operation have no function, If you
want to carry out other functions of operation, please press "+" button to exit the RCC receiving mode.
Manual time setting:
 Press once “ ” button, can switch the display calendar or second
 Press and hold down the “ ” button more than 2 seconds to enter the time and general settings, first
set the temperature unit setting. Now use the “+” and “-” button to set the temperature of the unit, the unit of
temperature can be set to “°C” or “°F”
 Press “ ” to confirm your setting, switch to pressure unit setting. Now use the “+” and “-” button to
set the pressure of the unit, the unit of t pressure can be set to “hPa” or “inHg”
 Press “ ” to confirm your setting, switch to radio controlled clock(RCC) function setting, Now use “+”
and “-” buttons set the RCC receive function to activate(ON) or close(OFF)
 Press “ ” to confirm your setting, the Time zones start to flash, Now use “+” and “-” buttons set a
correct time zone (-12 to +12).
 Press “ ” to confirm your setting,, the 12/24 hour mode display starts to flash. Now use “+” and “-”
buttons to set the correct 12/24 hour mode.
 Press “ ” to confirm your setting, the Hour display starts to flash. Now use “+” and “-” buttons to set
the correct hour.
 Press “ ” to confirm your setting, the Minute displays starts to flash. Now use “+” and “-” buttons to
set the correct minute.
 Press “ ” button to confirm your setting, the Month and Date icon display starts to flash. Now use “+”
and “-” buttons to set the date display on Month/Date or Date/Month.
 Press “ ” button to confirm your setting, the Year display 2015 starts to flash. Now use “+” and “-”
buttons to set the correct year.
 Press “ ” button to confirm your setting, the Month display starts to flash. Now use “+” and “-”
buttons to set the correct month.
 Press “ ” button to confirm your setting, the Date display starts to flash. Now use “+” and “-” buttons
to set the correct date.
 Press “ ” button to confirm your setting, the language selection for the Weekday displays starts to
flash. Now use “+” and “-” buttons to select a language.

WS6205 Instruction Manual
Language MONDAY TUESDAY WEDNESDAY THURSDAY FRIDAY SATURDAY SUNDAY
ENGLISH MONDAY TUESDAY WEDNESDAY THURSDAY FRIDAY SATURDAY SUNDAY
ENG MON TUE WED THU FRI SAT SUN
GERMAN MONTAG DIENSTAG MITTWOCH DONNERSTAG FREITAG SAMSTAG SONNTAG
GER MON DIE MIT DON FRE SAM SON
FRENCH LUNDI MARDI MERCREDI JEUDI VENDREDI SAMEDI DIMANCHE
FRE LUN MAR MER JEU VEN SAM DIM
ITALIAN LUNEDI MARTEDÌ MERCOLEDÌ GIOVEDI VENERDÌ SABATO DOMENICA
ITA LUN MAR MER GIO VEN SAB DOM
SPANISH LUNES MARTES MIERCOLES JUEVES VIERNES SABADO DOMINGO
SPA LUN MAR MIE JUE VIE SAB DOM
PORTUGUESE SEGUNDA-FEIR
A TERÇA QUARTA-FEIRA QUINTA-FEIRA SEXTA-FEIRA SABADO DOMINGO
POR SEG TER QUA QUI SEX SAB DOM
DUTCH MAANDAG DINSDAG WOENSDAG DONDERDAG VRIJDAG ZATERDAG ZONDAG
DUT MAA DIN WOE DON VRI ZAT ZON
DANISH MANDAG TIRSDAG ONSDAG TORSDAG FREDAG LØRDAG SØNDAG
DAN MAN TIR ONS TOR FRE LOR SON
NORWEGIAN MANDAG TIRSDAG ONSDAG TORSDAG FREDAG LØRDAG SØNDAG
NOR MAN TIR ONS TOR FRE LOR SON
SWEDISH MÅNDAG TISDAG ONSDAG TORSDAG FREDAG LÖRDAG SÖNDAG
SWE MAN TIS ONS TOR FRE LOR SON
POLISH PONIEDZIAŁEK WTOREK ŚRODA CZWARTEK PIĄTEK SOBOTA NIEDZIELA
POL PON WTO SRO CZW PIA SOB NIE
FINNISH MAANANTAI TIISTAI KESKIVIIKKO TORSTAI PERJANTAI LAUANTAI SUNNUNTAI
FIN MAN TII KIS TOR PER LAU SUN
CZECH PONDĚLÍ ÚTERÝ STŘEDA ČTVRTEK PÁTEK SOBOTA NEDĚLE
CZE PON UTE STR CTV PAT SOB NED
HUNGARIAN HÉTFŐ KEDD SZERDA CSÜTÖRTÖK PÉNTEK SZOMBAT VASÁRNAP
HUN HET KED SZE CSU PEN SZO VAS
RUSSIAN PERIOD ПОНЕДЕЛЬНИК ВТОРНИК СРЕДА ЧЕТВЕРГ ПЯТНИЦА СУББОТА ВОСКРЕСЕНЬЕ
RUS ПОН BTO CPE ЧЕТ ПЯТ СУБ ВОС
 Press “ ” button to confirm your setting, the weather forecast displays starts to flash. Now use “+”
and “-” buttons to select a weather.

WS6205 Instruction Manual
 Press “ ” to confirm your setting and to end the setting procedures, enter the clock mode.
F.Y.I.:
 After 20 seconds without pressing any button, the clock switches automatically from Set Mode to Normal
Time Mode.
 There are 15 languages of Weekday: English, German, French, Spanish, Italian, Dutch, Danish, Portuguese,
Norwegian, Swedish, Polish, Finnish, Czech, Hungarian, and Russian
Setting the daily alarms:
 Press once “ ” button, can switch the display calendar or alarm time
 Press and hold down“ ” button more than 2 seconds to enter the alarm setting mode, first enter the
alarm 1 hour setting. Use the “+” and “-” buttons to set the required hour.
 Press “ ” button to confirm your setting, switch to the alarm 1 Minute setting. Use the“+” and “-”
buttons to set the required minute.
 Press “ ” button to confirm your setting, switch to the alarm 1 repeat setting. Use the “+” and “-”
buttons to set the alarm repeat in “M-F” (from Monday to Friday) or “S-S” (Saturday and Sunday) or “M-S”
(from Monday to Sunday) .
 Press “ ” button to confirm your setting, switch to the alarm 2 hour setting. Use the “+” and “-” buttons
to set the required hour.
 Press “ ” button to confirm your setting, switch to the alarm 2 minute setting. Use the“+” and “-” buttons
to set the required minute.
 Press “ ” button to confirm your setting, switch to the alarm 2 repeat setting. Use the“+” and “-” buttons
to set the alarm repeat in “M-F” (from Monday to Friday) or “S-S” (Saturday and Sunday) or “M-S” (from
Monday to Sunday).
 Press “ ” button to confirm your setting and to end the setting procedure.
F.Y.I.:
 After 20 seconds without pressing any button the clock switches automatically from setting mode to Normal
clock mode.
The alarm for opening and closing
 View the alarm clock time mode, press “ ” button can switch the display ALARM1 time or ALARM2 time,
in the alarm1 or alarm2 display mode, press the “+” button to turn individual alarms on or off.
 The alarm 1 or alarm 2 turn on, the “ ” or “ ”icon is displayed, the alarm 1 or alarm 2 function is open, The

WS6205 Instruction Manual
repeat of alarm icon at the same time is also displayed.
 The alarm 1 or alarm 2 turn off, the“ ” or “ ”icon disappears, the alarm 1 or alarm 2 function is close.
F.Y.I.:
 The alarm will sound for 2 minutes if you do not deactivate it by pressing any button. In this case the alarm
will be repeated automatically after 24 hours.
 Rising alarm sound (crescendo, duration: 2 minutes) changes the volume 4 times whilst the alarm signal is
heard.
Switching off the alarm signal
 Press any button except the “ ” button to stop the alarm signal. It is not necessary to
reactivate the alarm. It switches itself automatically to the alarm time which has already been set.
Snooze function:
 Touch the " " field or press the “ ” button the alarm signal sounds to get to
SNOOZE mode. The alarm signal sounds again after approx. 5 minutes.
°C/°F temperature display
 The temperature is displayed either in °C/°F. Briefly pressing the “+” button allows you to switch between the
individual modes.
Comfort display
 Indoor comfort level is calculated according to the humidity, a total of 3 levels.
Smiling face show
Humidity value 40%～70% <40% >70%
Displaying temperature/humidity/ barometric pressure and temperature/humidity
trend
 The current indoor temperature/humidity/barometric pressure and the temperature/humidity trend (indoors)
are shown in the LCD display.

WS6205 Instruction Manual
 After successfully connecting with the remote sensor, the weather station can display the remote
temperature/humidity and the temperature/humidity trend (OUT)
 You may see the following displays:
The temperature/humidity is rising.
The temperature/humidity is remaining constant.
The temperature/humidity is falling.
Remote sensor transmission:
 When the Weather Station successfully receives signals from the wireless sensor, the temperature and
humidity of the out sensor are displayed on the "OUT" column of the weather station.
 The weather station can connect up to 3 channel wireless sensor registration, the use of multiple wireless
sensor, the wireless sensor channel cannot choose the same channel at the same time (a total of 1, 2, 3
channel can choose,)
 Press the “-” key can switch the display of different channels of remote temperature and humidity. While
displaying a channel, hold the “-“ key to display each channel every 5 seconds automatically.
 If the weather station failed to receive transmission from remote sensor (“- -”display on the LCD), press and
hold “-” button for 3 seconds to receive transmission manually. the remote temperature will show an
animation of the RF antenna symbol，the Base Station will re receive the wireless signal of the remote
sensor.
F.Y.I.:
 when the wireless sensor set up different channels, the weather station "OUT SENSOR" also want to switch
to the same channel. When there is no wireless sensor signal transmission on the channel, "--" will be
displayed in the channel of the weather station
 When the wireless OUT sensor has no channel selection function, the sensor defaults to channel 1.
Maximum/Minimum Temperature/Relative Humidity
 To toggle indoor/ OUT maximum, minimum temperature and humidity data, press the “MEM” button:
Once to show the maximum temperature and humidity values.
Twice to sow the minimum temperature and humidity values
Three times to return to the current temperature and humidity levels
 To reset the maximum and minimum temperature and humidity, press and hold down the “MEM” button

WS6205 Instruction Manual
about 2 seconds. This will reset all minimum and maximum data recorded to the current displayed values.
F.Y.I.:
 If the temperature reading is below ranges, the LL.L will be displayed. If the temperature reading is above
ranges, the HH.H will be displayed.
OUT Remote Temperature alert setting
 Press and hold down the “ ” button for 2 seconds until the icon for the Temperature Alert” starts to flash
 The icon of Upper limit of the Temperature alarm starts to flash. Use the “+” and “-” buttons to set the
required maximum temperature. Press “ ” to confirm your setting.
 The icon of the Lower limit of the Temperature alarm starts to flash. Use the “+” and “-” buttons to set the
required minimum temperature. Press “ ” button to confirm your setting and to end the setting
procedure
F.Y.I.:
 Before entering the setup, you must select the remote channel, different channels can set different
temperature alarm range
Temperature and frost alert
 Press “ ” button to activate or deactivate the remote temperature alert, When the remote temperature
alarm is activated, the temperature alarm icon is displayed in the remote sensor bar
 When the remote channel temperature value exceeds the set temperature range, will activate the alarm, the
weather station will every minute continuous alarm 5 times, at the same time, temperature alarm in alarm
icon " " flashes, If the alarm activates the temperature that is currently displayed on the channel, its
temperature value and alarm upper limit icon “ "or lower limit icon" " also flashes
 When the temperature of remote SENSOR is –1°C to + 3°C or +30°F to + 37°F, the frost alarm will be
activated,
symbol " " flashing.
F.Y.I.:
 When the temperature is higher than the upper limit of the alarm temperature setting, the activation of the
