La Crosse Technology V16 User manual

SET UP GUIDE
MODEL NUMBER V16 (C74443)
Wi-Fi MULTI-DAY
FORECAST STATION

Table of Contents
BASICS
Initial Setup
Station Settings
Buttons
LCD Display Brightness
Auto-Dim Settings
Low Battery Indicators
02
06
07
08
08
16
TEMP. AND HUMIDITY
Viewing Current
Conditions
Accessing Indoor/Outdoor
Readings
Viewing TH Records
Temp. & Humidity Alerts
09-13
09
12
13
APPENDIX
Specifications
Cautions/Statements
FCC Statement
Canada Statement
Warranty
Recycling & Disposal
22
22-24
24
24
25
25
LA CROSSE VIEW
Connecting to the App
Connecting Your Station
Adding Your Sensor to
the App
Manually Add Sensor to
the App
03
04
05
05
FORECAST
Viewing Your Forecast Data
Viewing Extended Forecasts
Standalone Forecast Icons
Enhanced Forecast Data
Relative Pressure
13
14
15
15
16
BONUS STATION
Station Settings
Accessing Indoor/Outdoor
Readings
Viewing Temperature and
Humidity Data
Buttons
17
17
18
18
SENSORS
Placement & Mounting
Add-On Sensors
Adding Extra Sensors
19
19-21
19
SUPPORT
We’re Here to Help
Factory Reset
Stay in Touch
25
25
25

02
Initial Setup
Power Up
Note: It may take up to 10 minutes for the sensor data to appear on your stations’ screens.
BASICS
Weather Station: Insert the 5V Power Adapter into an outlet, and then plug it into the Power Jack
on the bottom of the station. Next, remove the Insulation Tab from the Station’s Battery Compartment.
About 30 seconds after powering the station on, it will automatically enter the Settings Menu.
See page 6for more details.
Thermo-Hygro Sensor: Install 2 fresh “AA” batteries according to polarity and replace battery cover.
The blue LED light will flash when transmitting.
Bonus Station: Install 2 fresh “AAA” batteries according to polarity and replace battery cover.
Thermo-Hygro Sensor
(LTV-TH2i)
Back of Weather
Station (V16) Power Jack
Back of Bonus Station
(LTV-D2)

03
Connecting to the App
LA CROSSE VIEW
Download the La Crosse View App
Visit the App Store or Google Play Store to download the free
La Crosse View app onto your mobile device.
Stay connected to your home anytime, anywhere with the
La Crosse View app.
Monitor your home environment and set custom alerts to
notify you when conditions change.
Connecting your station is optional and the display will
function as a standalone unit without the Wi-Fi connection.
However, we recommend connecting during the initial
setup, as it will save you time and allows access to some
advanced features right away.
Launch the App
Connecting Your Station to the App
Open the La Crosse View app. Follow the on-screen setup instructions
to create an account, add new devices, and connect your station to
your Wi-Fi network.
Stay Connected to Your Home
Anytime, Anywhere.
Now that you’ve created your La Crosse View account, it’s time to add your station into your account
and connect it to your home router using the La Crosse View app.
NOTE: For the steps listed on the next page, you’ll need your Wi-Fi network name (SSID) and password.
Make sure your mobile device is connected to the same Wi-Fi network.

04
Adding & Connecting Your Station to Wi-Fi
LA CROSSE VIEW
Checking Your Station’s Wi-Fi Status
Press the SET button on the top of the station to view your Wi-Fi Status.
Having Trouble Connecting to Wi-Fi?
The app should guide you through the best method for your Wi-Fi network and router. However, if
you have trouble connecting, please go to: bit.ly/wifi_questions or scan the QR code. This will explain
additional connectivity options, including connecting by WPS or contacting our technical support
team for further assistance.
ALL OK CONNECTED: Your station is connected to
your Wi-Fi network and its data should be available
on the station and in the app.
SEE APP TO CONNECT: Check the app for notifications.
NO WEATHER SERVICE: Your Internet weather and time
services are not connecting. These should resolve on their
own, please be patient.
LOST WIFI: Check your router and network connections.
The La Crosse View app is required to connect the station to your Wi-Fi network. Download, install,
and log into your La Crosse View account first.
New User Initial Setup: When first setting up your
station, the app will lead you through a series of
instructions to help get your station added into your
account and connected to your home Wi-Fi network.
Manually Add & Connect Display: After the initial walkthrough,
stations can be added and connected via the Devices tab in the
app’s main menu. Simply tap the Add Device or +button at the
bottom of the Devices page in the app.
1.
Follow the initial app instructions or manually add the display into your account.2.
Next, the app will prompt you to use your phone to scan the device ID barcode located on the back of
the station. Please note, adding a device to your account and connecting it to Wi-Fi are two dierent
steps. You can complete either step separately if you have any trouble.
When connected, the station will beep, and time and forecast information should populate on the
display. The indicator will also become solid.
3.
4.

Add Your Sensors to the App
LA CROSSE VIEW
05
123456-ABC
* This step is only required if you do not receive the Add Device notification within the app.
Prior to mounting/positioning your sensor, make sure your station is receiving sensor data.
Upon getting the station connected to your Wi-Fi network, the app will
explain how your connected sensor should be brought in. Within the
next 15 minutes, you should receive an Add Device notification in your
app. This is indicated by the Red Cloud and the numbers inside of it.
Tap this icon to begin adding your sensor into the app.
1.
Manually Add Your Sensor to the App*
3.
4.
2.
Open your La Crosse View app. On the Main Menu, scroll to
ADD/EDIT and select DEVICES.
Scan the Barcode on your Sensor or type in the Device ID
manually.
Confirm the sensor image and Device ID and add a Device
Name and Location Name. Select DONE.
On the Devices page, select the ADD DEVICE or PLUS (+) button.
100%
Add Device SaveCancel
12:34
2
Please wait up to 15 minutes
for your additional devices
to connect to your account.
If you do not receive device
notifications, go to the Main Menu
and select Add/Edit Devices to
add your devices separately.
Check the notification icon when
your devices are ready to add.
123456-ABC
Back of Sensor

Station Settings
BASICS
About 30 seconds after powering the station on, it will automatically enter the Settings Menu.
Use the steps below to navigate the menu and get your station working the way you’d like.
06
Settings Menu Order
• Greeting/HELLO
• Language (English/Spanish/French/German)
• Beep ON/OFF
• 12/24 Hour Time Format
• Hour | Minute | Year | Month | Date
• Calendar Order Month/Date or Date/Month
• Temperature Units (Fahrenheit/Celsius)
• Pressure Units (InHg/hPa)
• Pressure Number Setting
The default pressure reading is 29.91 INHg (1013 hPa).
The station will acclimate on it’s own if the pressure
number is not set. Learn more on page 16
• THANK YOU
Important: Settings such as language and units of measure must
be set manually within the station’s Settings Menu. These are not
controlled by the La Crosse View app.
The language selected will aect menu instructions as well as
weekday and month readouts.
Weekday will set automatically after year, month, and date
settings are adjusted.
When in 24 hour time format, seconds will show in place of
AM/PM markings.
If you’re connected to Wi-Fi, the time/date will automatically
update from the Internet. See pages 3-4 for more info.
Navigating the Settings Menu
To manually set language, time/date, and other
settings, hold the SET button to enter the
Settings Menu.
1.
Use the +/- buttons on the top of the station to
adjust the values.
2.
Press the SET button to confirm your selection
and move to the next setting.
3.
You may exit the Settings Menu at any time
by pressing the LIGHT button on the top of
the station.
4.

Buttons
BASICS
07 * Your display must be connected to Wi-Fi to receive Daily/Hourly forecast information.
Front of Station Back of Station
1. LIGHT: Press to adjust backlight or exit menus. Hold to enter Auto-Dim settings.
2. ALERTS: Hold to enter the alerts setting. Use +/- buttons to turn alerts on/o.
3. TEMP: Press to view high/low records, heat index, and dew point. While viewing, hold the MINUS
(-) button to reset the history reading. Hold to search for Outdoor Sensor.
4. SET: Press to view Wi-Fi status. Hold to enter the Settings Menu.
5. PLUS/MINUS (+/-): Use to adjust values.
6. IN/OUT: Press to switch between Indoor/Outdoor Temperature & Humidity display or autoscroll.
7. FORECAST REFRESH*: Press to refresh Forecast Readings.
8. EXTRA SENSOR ( ): Press to view ID numbers. While viewing, hold the MINUS (-)button to delete
the sensor. Hold to add sensors.
9. EXTENDED FORECAST ( )*: Press to change Forecast Times.
Hold to select Percent or Amount of Precipitation reading.
10. WIFI: Press during initial setup for Wi-Fi Connection.
Hold to re-enter Configuration Mode and clear previous Wi-Fi settings.

08
LCD Display Brightness
The Auto-Dim Icon ( ) will appear on the LCD when the Auto-Dim feature is activated.
BASICS
Please Note: Only the hour can be set.
Auto-Dim Settings
Program your display to automatically
dim during preselected times.
Adjusting the LCD Display Brightness
Press the LIGHT button to adjust the backlight
intensity. There are 4 brightness levels, plus an
o option.
1. Hold the LIGHT button to enter
the Auto-Dim Settings Menu.
2. Press the +/- buttons to turn the
Auto-Dim feature on or o.
Press LIGHT to confirm.
3. Press the +/- buttons to adjust the
starting hour. Press LIGHT to confirm.
4. Press the +/- buttons to adjust the
stopping hour. Press LIGHT to
confirm and exit.

Viewing Current Conditions
TEMPERATURE & HUMIDITY
09
Your indoor/outdoor temperature & humidity readings
share the same section on the LCD.
Press the IN/OUT button on the top of the station to
switch between Indoor & Outdoor readings, or select
the Auto-Scroll option to alternate between readings.
Accessing Indoor/Outdoor Readings
Indoor Data Example
Indicated by house icon in top left
Outdoor Data Example
Indicated by tree icon in top right
Programming the Auto-Scroll Option
Press the IN/OUT button until AUTOSCROLL
TEMP DATA appears on the LCD.
To deactivate the Auto-Scroll option, press the
IN/OUT button until the Auto-Scroll Icon ( )
disappears. The station will stay on your
current selection.
The Auto-Scroll Icon ( ) located in the bottom
left corner will appear when active.

Viewing Current Conditions
TEMPERATURE & HUMIDITY
10
1. INDOOR ICON ( )
5. OUTDOOR ICON ( )
2. TEMPERATURE ALERT ICONS
6. AUTO-SCROLL ICON ( )
3. INDOOR OR OUTDOOR TEMPERATURE
7. LOW BATTERY INDICATOR ( )
9. SENSOR RECEPTION INDICATOR ( )
4. INDOOR OR OUTDOOR HUMIDITY
8. HUMIDITY ALERT ICONS
Indicates you are viewing indoor temperature
and humidity
Indicates you are viewing outdoor temperature
and humidity
Indicates an active high ( ) or low ( )
temperature alert
Icon will appear when auto-scroll is active
Current indoor or outdoor temperature
(based on setting)
Indicates the batteries in the thermo-hygro
sensor should be replaced soon
Indicates if the station is receiving data from the thermo-hygro sensor
Current indoor or outdoor humidity
(based on setting)
Indicates an active high ( ) or low ( )
humidity alert
Current Conditions Section Close-Up

11
Viewing Current Conditions
TEMPERATURE & HUMIDITY
Resetting Individual Records
Records Viewing Order
Press the TEMP. button to view the
individual values you’d like to reset.
Next, hold the MINUS (-) button until
dashes appear on the LCD. This reading
is now reset to your current temperature
or humidity value.
•Outdoor High Temperature
•Outdoor Low Temperature
•Outdoor High Humidity
•Outdoor Low Humidity
•Indoor High Temperature
•Indoor Low Temperature
•Indoor High Humidity
•Indoor Low Humidity
•Heat Index
•Dew Point
Press and release the TEMP. button to toggle through
indoor/outdoor temperature and humidity records with
time and date stamps.
Viewing Records
Outdoor Low Temperature Record Example Heat Index Example

12
Customizable Alerts
TEMPERATURE & HUMIDITY
1.
2.
3.
Hold the ALERTS button to enter the
Alert Settings Menu.
Use the +/- buttons to activate/deactivate
individual alerts, or press the ALERTS
button to skip to the next alert option.
Once activated, use the +/- buttons to
adjust the alert value. Press the ALERTS
button to confirm and move forward.
Setting Custom Alerts
Outdoor High Humidity Alert LCD Example
Alerts Setting Order
Outdoor High Temperature •Outdoor Low Temperature •Outdoor High Humidity •Outdoor Low Humidity
Indoor High Temperature •Indoor Low Temperature •Indoor High Humidity •Indoor Low Humidity
Activating/Deactivating Alerts
1.
2.
Hold the ALERTS button to enter alert settings.
Use the +/- buttons to activate/deactivate alerts.
Active alerts are indicated by the and / icons in
the Current Conditions section on the screen.
Note: The default setting for
alerts is OFF.
Alerts Sounds
•When an alert value is reached, the station will
beep 5 times each minute until the value moves
out of the alert range.
•Press any button to stop the alert sound.
•If the alert sounds and you do not see a flashing
alert icon, press the IN/OUT button to view the
other reading.
•Alerts set on the station are separate from
those created within the app.

13
Viewing Your Forecast Data
* Your display must be connected to Wi-Fi to receive AccuWeather forecast data.
** When connected, your station will display 6 additional forecast icons.
*** Refreshing the forecast may result in the same readings if they are current.
FORECAST
You can view up to 6 days of forecasts and 12 hours of forecast data. The default display will
show your current and following 2 days of forecasts, detailing weather conditions, chance of
precipitation, and high/low temperature predictions.
1. INTERNET ICON ( )
5. FORECAST ICONS
2. CHANCE OF PRECIPITATION
6. FORECAST REFRESH ICON ( )
3. DAILY FORECASTED HIGH TEMPERATURE
7. EXTENDED FORECAST SECTION
4. DAILY FORECASTED LOW TEMPERATURE
Indicates the station is connected and receiving
AccuWeather forecasts*
Predicted weather conditions to happen within
the next 12 hours**
Percent chance of precipitation*
Hold the EXTENDED FORECAST ( ) button
to view amount of precipitation*
Press the FORECAST REFRESH button to
refresh the 3-day forecast. The icon will cycle
for 30 seconds***
Forecasted daily high temperature*
Forecast icons and daily forecasted highs and lows for the next 2 days
Press the EXTENDED FORECAST ( ) button to view additional 3-day & 12-hour forecast information
Forecasted daily low temperature*

FORECAST
14
Viewing Your Forecast Data
Extended Forecast Examples
Forecast When not Connected Day/Night Forecast
When not connected to Wi-Fi, you’ll see current
temperature and humidity, as well as daily high/low
temperature and humidity records from your sensor.
Forecast icons will only appear in the circular area.
When clear or partly clear conditions are predicted,
the sun icon will show during daylight hours and
the moon icon will show during nighttime hours.*
The times the sun and moon icons appear are
pre-programmed and cannot be adjusted.
Forecast data for upcoming 4-6 days Forecast data for next, 2nd, and 3rd hours Forecast data for upcoming 4th, 5th, and 6th hours
Sun Icon (7:00am to 6:59pm) Moon Icon (7:00pm to 6:59am)
Press and release the EXTENDED FORECAST ( )
button to toggle through your next 3 days and next
12 hours of forecasts.
Viewing Extended Forecast
* The station must be connected Wi-Fi to activate
the day/night forecast feature.

15
Viewing Your Forecast Data
Please Note: The Forecast Icons may not represent your current weather. They are a future prediction of
the weather to come over the next 12 hours.
When connected to Wi-Fi, the station will receive additional weather icons, chance of precipitation values,
and future forecast information. These enhanced Internet features are powered by AccuWeather.
Additional forecast scenes include:
Tip: The icon will appear in the top left corner of the forecast section when your display is
connected and receiving AccuWeather forecasts.
When using as a standalone station, the display will use changes in barometric pressure to predict your
weather to come in the next 12 hours. These will be represented by the following 6 forecast scenes:
Forecast Icons
Secondary Forecast Icons | The following icons appear in the extended forecast section:
Sunny Rain SnowClouds Light
Snow
IcePartly
Sunny
T-Storms WindLight
Rain
Wintry
Mix
Fog
Sunny
Light Rain
Rain
Wind
Partly Sunny
Light Snow
T-Storms
Ice
Clouds
Wintry Mix
Snow
Fog
FORECAST

16
Relative Pressure
Low Battery Indicators
Note: The default pressure reading is 29.91 InHg (1013 hPa). The station will acclimate on its own if the pressure number is not set.
•Your Relative Pressure reading will come
from your station’s internal barometer.
•Please allow up to 10 days for automatic
calibration, or program your local pressure
value in the Settings Menu.
•The dark blue arrows located above the values
represent Pressure Tendency.
•If a green low battery indicator appears in the forecast/
circular section, replace batteries in the TH sensor.
You’ll only see this icon if you’re not connected to Wi-Fi.
•If a dark blue low battery indicator appears in the extra
sensor section, replace batteries in the extra sensor.
•If a light blue battery indicator appears in the outdoor
temperature section, replace batteries in the TH sensor.
•If a white low battery indicator appears next to the time
display, replace the coin cell battery in the station.
•Select your desired unit of measurement (InHg or hPa) in the Settings Menu.
You can also set a specific pressure number setting if desired.
Pressure Tendency Arrows
BASICS
FORECAST

Bonus Station Settings
BONUS STATION
When the station is first powered on, it will begin searching for the included
Thermo-Hygro Sensor, which should connect within the first 10 minutes.
Search for Outdoor Sensor
• If the signal is lost, the station will display the last data recorded for 10 minutes. After 10 minutes, the station
will display dashes “--”. After 30 minutes, the station will automatically start searching for the sensor.
• Hold the +/SEARCH button to manually search for the outdoor sensor. The Reception Icon will
animate while searching and be solid when signal is received.
Navigating the Settings Menu
Front of Station
Hold the SET/IN-OUT button to enter the
Settings Menu.
1.
Use the +/SEARCH button to adjust the
values.
2.
Press the SET/IN-OUT button to confirm
your selection & move to the next setting.
3.
17
Settings Menu Order
12/24 Hour Time Format • Hour • Minutes • Temperature Units (Fahrenheit/Celsius)
Your indoor/outdoor temperature and humidity
readings share the same section on the LCD.
Press the SET/IN-OUT button to view either
Indoor or Outdoor Readings.
Accessing Indoor/Outdoor Readings

Viewing Temperature & Humidity Data
BONUS STATION
18
Station Buttons
SET/IN-OUT
Press to view indoor or outdoor readings.
Hold to enter settings menu.
+/SEARCH
Hold to search for sensor. While in the settings
menu, press and/or hold to increase values.
1. INDOOR ICON ( )
2. OUTDOOR ICON ( )
3. SENSOR RECEPTION INDICATOR ( )
4. SENSOR LOW BATTERY INDICATOR ( )
10.STATION LOW BATTERY INDICATOR ( )
5. INDOOR OR OUTDOOR TEMPERATURE
7. INDOOR OR OUTDOOR HUMIDITY
6. TEMPERATURE TREND INDICATORS
8. HUMIDITY TREND INDICATORS
9. TIME DISPLAY
Indicates you are viewing indoor readings
Indicates you are viewing outdoor readings
Indicates if the station is receiving data from
the sensor
Indicates batteries in the sensor should be
replaced soon
Indicates batteries in the station should
be replaced soon
Current indoor or outdoor temperature
(based on setting)
Current indoor or outdoor humidity
(based on setting)
Represents changes in temp. over the past hour
Represents changes in humidity over the past hour
Current time in 12 or 24-hour format

19
SENSORS
• Insert one mounting screw through the hole at the top of the sensor,
or hang it from the back using a nail.
• Mount the sensor in an open shaded location with protection from
direct weather elements and sunlight. Under an eave on a north-
facing wall is often a great choice.
• The maximum wireless transmission range to the station is up to
400 feet (121 meters) in open air, not including walls or floors.
• Be sure your sensor is mounted vertically, to allow moisture to drain
out properly.
Sensor Placement & Mounting
Add-On Sensors
Whether you choose to connect to the La Crosse View app or not,
this station can display data for up to 4 extra sensors.
This data will appear in the dark blue section on the LCD
and in your La Crosse View app if connected.
Note: When first powering up, or after a factory reset, extra sensors should automatically connect to your station.
Viewing Add-On Sensor Data
If you have multiple add-on sensors connected,
press & release the EXTRA SENSOR ( ) button to
toggle through the data you’d like displayed on the
LCD. The Auto Scroll Icon ( ) will appear if activated.
This setting will also include relative pressure data
in the cycle.
Adding Sensors to Your Station
3. Your sensor should connect within the next 3
minutes, briefly displaying its ID and type on the
LCD. The Sensor Reception Indicator will show
solid on the screen when a sensor is connected.
1. Hold the EXTRA SENSOR ( ) button until the
Sensor Reception Indicator ( ) starts to animate.
2. Install batteries into your sensor. If the sensor
has a TX button, press it to force a transmission
signal. This button is usually located in or near
the sensor’s battery compartment. The LED light
on the sensor will flash once.
Water Leak
Sensor Example
