La Crosse Technology V22-WRTH User manual

Page | 1Professional Remote Monitoring Station
PROFESSIONAL
Remote Monitoring Weather Station
Welcome!
--------------
Congratulations on your new Professional Weather Station and welcome to
the La Crosse Technology family! This product was designed with you in mind
by our hometown team of weather enthusiasts based in La Crosse, Wisconsin.
Instructional Manual
Model: V22-WRTH
DC: 101017
www.lacrossetechnology.com/V22-WRTH

Page | 2Professional Remote Monitoring Station
Table of Contents
Temperature | Humidity Trend Arrows
Daily HI | LO Temperatures
Feels Like Temperature
Seasonal Changes in Foliage
Backlight Brightness
Low Battery Icons
Sensor ID | Sensor Search
Delete Your Sensor ID
Factory Reset V22-WRTH
Detailed Sensor Setup and Mounting
Bonus Station Setup
Help Us, Help You
Let’s Be Social
Specifications
Care and Maintenance
Warranty and Support
FCC Statement
Canada Statement
3
3
3
4
4
5
6
7
8
9
10
10
11
12
12
12
13
14
14
14
15
15
15
16
16
16
17
17
18
18
21
22
22
23
24
24
25
25
Step 1: Power Up
Step 2: Station Options
Step 3: Mounting Basics
Option 1: Connect with La Crosse View
Wi-Fi Network Requirements
La Crosse View
La Crosse View Enhancements
New Data Stream Technology
Simple Status Messages
Connect Additional Sensors to Your
La Crosse View™ App
Option 2: Standalone Station
Settings Menu
Your Station’s Features:
Standalone or Connected
Wind Speed Readings
Wind Speed History
Reset Wind Speed History
Rainfall Readings
Reset Rainfall Readings
HI | LO Temperature/Humidity Records
Reset HI | LO Temperature/Humidity

Page | 3Professional Remote Monitoring Station
Insert the batteries (in any order):
Note: Batteries are not included.
• 2-C batteries into Wind speed sensor
• 2-AA batteries into Thermo-hygro sensor
• 2-AA batteries into Rain sensor
• 5 volt power cord (required) into V22-WRTH station
*3-AA batteries for optional backup of your time and date
• 2-AAA batteries into LTV-D1 bonus station
*Battery operation only, station will not update sensor or Wi-Fi data. Power cord is required.
STEP 1. Power Up
STEP 2: Station Options
OPTION 1
CONNECT WITH LA CROSSE VIEW™ APP
The easiest and fastest way to setup your station!
• Enjoy all of the standalone station features along with the enhanced feature set from your
La Crosse View™ app! Continue with these instructions on page 4.
OPTION 2
OPERATE AS A STANDALONE STATION
Full Weather Station Features
• Monitor your backyard temperature, humidity, wind speed, and rainfall information
on the easy-to-read LCD display. Continue with these instructions on page 9.
• You always have the option of connecting to the La Crosse View™ app at a later time if you choose.
STEP 3: Mounting Basics
At this time, all of your sensor information should be displayed on your station.
Here are a few quick tips for mounting your sensors:
THERMO-HYGRO
Keep out of direct sunlight & ensure the sensor is well-ventilated.
• We recommend mounting under a deck or eave facing north.
WIND SPEED
Ensure the sensor is mounted vertically – an unobstructed rooftop is ideal.
• Your wind sensor should be the tallest object in the area to avoid any obstructions.
RAIN
Mount in an open area, preferably o the ground on a level platform.
• Clean out the bucket regularly to avoid debris; this can aect readings.
For detailed sensor setup and mounting instructions, see page 18.

Page | 4Professional Remote Monitoring Station
Option 1: Connect with La Crosse View™
DOWNLOAD
• Visit the App Store or Google Play Store to download the free La Crosse View™ app on your mobile device.
CHECK YOUR NETWORK
• Confirm that your mobile device is connected to a 2.4GHz (802.11 b/g/n) Wi-Fi band before trying to connect
your station to the La Crosse View app. The station itself cannot accept 5GHz Wi-Fi bands that most
dual-band routers oer. Dual band routers also have a 2.4GHz channel.
MAKE SURE YOUR STATION IS READY TO CONNECT.
• When connecting to the app, ensure the Wi-Fi Indicator icon is blinking.
• Solid: Indicates that you are connected to Wi-Fi.
• Slow Flash: Searching for connection
• Not displayed: Not Connected
• If your Wi-Fi icon is not displayed, hold the + & - buttons together until the icon begins to flash.
• For detailed information about all of this station’s icons, see page 11.
LAUNCH
• Open the app on your iOS or Android device.
FOLLOW INSTRUCTIONS
• The La Crosse View™ app will walk you through creating an account and connecting your station to the
Internet. Once connected, your time, date, and local forecast information will update instantly on your
weather station’s screen. For online help: http://www.lacrossetechnology.com/lacrosseviewsupport
Wi-Fi Network Requirements
In order for your station to connect to your Wi-Fi, it will need to meet the following requirements:
• Confirm that your mobile device is connected to a 2.4GHz (802.11 b/g/n) Wi-Fi band before trying to connect
your station to the La Crosse View app. The station itself cannot accept 5GHz Wi-Fi bands that most
dual-band routers oer
• Weather station power cord use is required for Wi-Fi connection.
iOS Requirements: Mobile device with iOS 9.0 (or higher) with cellular or Wi-Fi service
Android Requirements: Mobile device with Android OS 5.0 (or higher) with cellular or Wi-Fi service
Tips:
• Do not use public Wi-Fi networks.
• Your weather station and mobile device must be within 10 feet of each other during setup.
• If you change your Wi-Fi network, simply go into the La Crosse View™ app, select your station, and then
choose “Select Wi-Fi” from the app menu. Here, you will just need to enter your new Wi-Fi network’s login
information.
• Hold the PLUS and MINUS buttons together for 3 seconds to have your station search for your Wi-Fi.
• If you have connection issues, Hold the RAIN and LIGHT buttons together for 5 seconds to complete a
factory restart.

Page | 5Professional Remote Monitoring Station
ON-THE-GO HOME MONITORING
• Check Current Indoor & Outdoor Readings, View History Charts, and Set Custom Mobile Alerts.
FRIENDS & FAMILY SHARED ACCOUNTS
• No Need to Share Logins or Passwords! Invite Friends & Family to Download the App & Monitor Your
Home’s Data.
BEST IN CLASS APP EXPERIENCE
• Use Your Own Photos and Receive Free Push Notifications on the New, Easy-to-Navigate App
NEW DATA STREAM TECHNOLOGY
• Add your own personal messages or NWS data feeds from your La Crosse View™ app, that will show on
your station.
ADD OTHER SENSORS TO YOUR LA CROSSE VIEW™APP
• You can add additional Temperature & Humidity, Wind Speed, Rain, or Multi-Sensors to your La Crosse View™
app, easily expanding your coverage to all areas of your home.
• Your weather station will act as a Wi-Fi gateway, allowing these additional sensors to pass through the station
and show their data on your La Crosse View™ app.
• Add-on sensor data will, however, not be shown directly on your weather station.
• For more help connecting additional sensors, see page 9.
Note: If switching to a new Wi-Fi network, your station may take up to 3 minutes to reacquire all sensor
information.
Note: In the event of a power outage, or your station being unplugged temporarily, your station should
automatically reconnect to your existing Wi-Fi network, once power is reestablished.
Note: Weather station power cord use is required. Battery operation only will not update sensor or Wi-Fi data.
Connecting You to Your Home Anytime, Anywhere.

Page | 6Professional Remote Monitoring Station
NWS (National Weather Service) Daily HI | LO temperature
Note: When not using the app, the daily HI | LO will come
from your outdoor TH sensor.
NWS Chance of Precipitation
The letters NWS will show in the forecast area
NWS Additional Forecast Icons
Standard Icons:
Sunny • Partly Sunny • Clouds • Rain • T-Storm • Snow
Additional Icons:
Windy • Light Rain • Severe T-Storm • Light Snow
Wintry Mix • Blizzard • Fog • Ice
NWS Wind Direction
The words “NWS Wind Direction” will show, and the blue
circle will change to indicate wind direction.
La Crosse View™ Enhancements
NWS
WIND
DIRECTION
FORE CASTNWS
MPH
WIND SPEED
IN
1 HOUR
NWS FORECAST
LO
HI
FEELS LIKE
RAIN
OUTDOOR
INDOOR
TOP
SPEED
1 HR
Standard Forecast Icons:
FORECAST FORECAST FORECAST FORECAST FORECAST FORECAST
Sunny Partly Sunny Clouds Rain T-Storm Snow
FORECASTNWS FORECASTNWS FORECASTNWS FORECASTNWS
FORECASTNWS FORECASTNWS
NWS Additional Forecast Icons:
Note: Snow icon will show when the outdoor temperature is 32°F or lower and the forecast is Rain or T-Storm.
When your station is connected to the NWS, you will see the six icons above (with precipitation added) as well
as the additional eight icons here:
Windy Light Rain Severe T-Storm Light Snow Wintry Mix Blizzard
Fog Ice
FORECASTNWSFORECASTNWS

Page | 7Professional Remote Monitoring Station
New Data Stream Technology
NWS
WIND
DIRECTION
FORE CASTNWS
MPH
WIND SPEED
IN
1 HOUR
NWS FORECAST
LO
HI
FEELS LIKE
RAIN
OUTDOOR
INDOOR
TOP
SPEED
1 HR
Use the Data Stream Menu in the La Crosse View™ app to select up to 4 items to stream on your station.
1. Open the La Crosse View™ app and select your station.
2. Scroll down to the Data Stream section and press the blue icon.
3. Follow the app’s instructions to add the “Data Stream” you’d like displayed on your station
Allow a few minutes for all the data to update on your station.
Data Stream Items:
National Weather Service (NWS)
• Selectable Forecast on Your Display
(Wind, Snow, & Sky Conditions, probability of Thunderstorms, Hail or Tornados)
Personal Message
• Enter Up to 20 Characters for Special Events or Reminders
Note: Allow up to 10 minutes for new Data Stream selections to appear on your station.

Page | 8Professional Remote Monitoring Station
NWS
WIND
DIRECTION
FORE CASTNWS
MPH
WIND SPEED
IN
1 HOUR
NWS FORECAST
LO
HI
FEELS LIKE
RAIN
OUTDOOR
INDOOR
TOP
SPEED
1 HR
NWS
WIND
DIRECTION
FORE CASTNWS
MPH
WIND SPEED
IN
1 HOUR
NWS FORECAST
LO
HI
FEELS LIKE
RAIN
OUTDOOR
INDOOR
TOP
SPEED
1 HR
FORE CAST
MPH
WIND SPEED
IN
1 HOUR
LO
HI
FEELS LIKE
RAIN
OUTDOOR
INDOOR
TOP
SPEED
1 HR
“NO CONNECT APP SERVER”
• The Wi-Fi router connection is working.
• Check your connection to the La Crosse View app.
• Is there an update to install?
“NO NIST SERVER”
• This indicates an error on the NIST server.
• Your time will be maintained by your weather station
until the NIST updates resume.
• The NIST will resolve this.
• Very rare to have this error.
“NO NWS SERVER”
• This indicates an error on the NWS server.
• NWS Expanded Forecast, Wind Direction, and
selected data streams will not update or show.
• The NWS will resolve this.
• Very rare to have this error.
Simple Status Messages
Your station has built-in status messages for your
convenience. Press and release the SET button to view.
Note: Only one relevant status message will display.
NWS
WIND
DIRECTION
FORE CASTNWS
MPH
WIND SPEED
IN
1 HOUR
NWS FORECAST
LO
HI
FEELS LIKE
RAIN
OUTDOOR
INDOOR
TOP
SPEED
1 HR
“ALL OK CONNECTED”
• Your station is connected, there are no problems.
FORE CAST
MPH
WIND SPEED
IN
1 HOUR
LO
HI
FEELS LIKE
RAIN
OUTDOOR
INDOOR
TOP
SPEED
1 HR
“LOST Wi-Fi”
• Check your power cord connection.
(power cord required to connect)
• When trying to reestablish your station’s Wi-Fi
connection, be sure your mobile device is on
the same 2.4GHz network you want your station
to use.
• Check your network connection.
• Hold the + and - buttons together for 3 seconds to
search for Wi-Fi.

Page | 9Professional Remote Monitoring Station
Connect Additional Sensors to Your La Crosse View™ App
Add Sensors:
Open your La Crosse View™app to add sensors.
1. From Main Menu - select “Devices” under “Add/Edit”
2. On Edit Devices page - select “ADD DEVICE”
3. Scan Device ID - Scan the bar code on your sensor or choose “ADD MANUALLY” to type in the number on
the bar code. Select “CONTINUE”.
4. On Confirm Device page - Confirm the sensor image and select “YES”
5. On Enter Device and Location Name page - enter Device Name and select a location or enter a Location
Name for your sensor. Select “DONE”.
Repeat steps 1-5 for any additional sensors you wish to add.
Note: Additional sensors may be purchased and added to your La Crosse View™ app at any time. Compatible
additional sensors start with the letters “LTV-”. Always check your product page for available sensors:
www.lacrossetechnology.com/V22-WRTH
DID YOU KNOW?
You can expand your system’s coverage with additional sensors (sold separately). These add-on sensors will use
your weather station as a gateway to the La Crosse View app, where their data can be viewed and tracked 24/7
from anywhere.
Note: The number of sensors or stations you can add will be limited by the memory of your mobile device.
Expand your coverage:
• Your baby’s room
• Your wine cellar
• Your basement
• Your attic
• Your garage
Just add a sensor and use your La Crosse View™app to monitor its data anywhere on-the-go.
For support and guidance of your La Crosse View™ app, please visit:
www.lacrossetechnology.com/lacrosseviewsupport

Page | 10Professional Remote Monitoring Station
When operating as a standalone station, you can manually adjust your stations settings
Note: When using the La Crosse View™ app, time and date will be set automatically.
Settings Menu
1. Hold the SET button for 3 seconds to enter settings menu.
2. Press and release the + or - buttons to adjust the flashing values. Hold to adjust quickly.
3. Press and release the SET button to confirm and move to the next item.
Note: Press and release the LIGHT button any time to exit settings.
Settings menu order:
1. BEEP ON | OFF
2. 12/24 hour format
3. Hour
4. Minutes
5. Year
6. Month
7. Date
8. Temperature Fahrenheit | Celsius
Note: SEE APP TO CONNECT will show as a reminder to connect to La Crosse View™ (optional).
• Press the LIGHT button to exit Settings Menu.
Option 2: Standalone Station
BEEP ON | OFF 12 | 24 Hour Time
Hour Minutes
Year Month
Date Temp °F | °C
Connection Prompt

Page | 11Professional Remote Monitoring Station
Your Station’s Features - Standalone or Connected
NWS Forecast Information:
Precipitation, HI | LO, Wind Direction, etc.
Weather Forecast Icons
Low Battery Icons
Inches or Millimeters of Rain
Wind Speed Icon
Miles or Kilometers - Wind Speed
Wi-Fi Connection Icon
Sensor Reception Icon
Trend Arrows
Fahrenheit or Celsius - Temperature
Percentage
Relative Humidity Icon
Temperature Icon
Connected stations oer the ability to display custom
data, controlled with the La Crosse View™app
Standalone stations can only display
time and date information as shown here

Page | 12Professional Remote Monitoring Station
Wind Speed Readings
Wind Speed:
• Reflects highest current wind speed
Top Speed:
• Reflects highest wind speed in the past 60 minutes.
Wind Cup animation:
• The wind cups spinning speed will vary with actual wind speed.
• When wind speed is higher, the cups spin faster.
Blue Circle:
• The blue circle will remain solid when operating as a standalone station.
• When station is synced to the La Crosse View™ App, the circle will forecast
NWS Wind Direction.
Wind Speed History
Simply press and release the WIND button to cycle through the Wind
History (other readings will disappear temporarily).
One Hour:
• Past 60 minute period
(default Top Speed record, always shown)
24 hour:
• Past 24 hour period, from last record
7 Days:
• Past 7-day period, from last record
Current Month:
• Defined by Calendar Month (i.e. January 1 - January 31)
• Press and release the PLUS button to view previous months.
Year:
• Defined by Calendar Year (i.e. January 1 - December 31 )
MPH
WIND SPEED
TOP
SPEED
1 HR
Standalone Station
Station with La Crosse View App
NWS
WIND
DIRECTION
MPH
WIND SPEED
TOP
SPEED
1 HR
MPH
WIND SPEED
TOP
SPEED
MPH
WIND SPEED
TOP
SPEED
MPH
WIND SPEED
TOP
SPEED
MPH
WIND SPEED
TOP
SPEED
1. Press and release the WIND button to view each wind speed reading.
2. Hold the MINUS button for five seconds to reset the individual value.
3. Wind speed history reading will reset to current speed, time and date.
4. Press and release the LIGHT button, or wait 20 seconds to return to a
full, normal display.
Reset Wind Speed History

Page | 13Professional Remote Monitoring Station
Rainfall Readings
Simply press and release the RAIN button to cycle through the exact rain history you’d like displayed
(other readings will disappear temporarily). Your station will stay on your selection.
Press and release the LIGHT button, or wait 20 seconds to return to a full, normal display.
NOW:
• Rain readings from the start of a rain event until no rain has accumulated for 30 minutes.
• After a 30 minute period of no rainfall, this number will reset to zero.
1 Hour:
• Rainfall in the past 60 minutes (last twelve 5 minute samples).
• Example: current time is 6:49, 1HOUR is the accumulated rain between 5:50 to 6:49.
24 Hours:
• Rainfall for the past 24 hours. Updates at each full hour. This is a running total.
7 Days:
• Rainfall from the last 7 consecutive 24 hour rainfall readings.
• Updates each day at 12am midnight. Not subject to your calendar, but be sure you have your
time set correctly.
Month:
• Current Month: First day to current day. Current month will show.
• Press and release the PLUS button to view previous months.
1 Year:
• Current month plus past 11 months total. Current year will show.
Total:
• Total rainfall since station was powered on or reset.
Note: As time passes without rain, the 1 hour, 24 hour, and 7 day rain totals will count down to zero.
IN
NOW
RAIN
IN
1 HOUR
RAIN
IN
24 HOURS
RAIN
IN
7 DAYS
RAIN 1 MONTH
RAIN
IN
1 YEAR
RAIN
IN
TOTAL
RAIN

Page | 14Professional Remote Monitoring Station
Reset Rainfall Readings
1. Press the RAIN button to view individual rain readings.
2. Hold the MINUS button for five seconds to reset the individual value.
3. Rainfall reading will reset to 0.00
4. Press and release the LIGHT button, or wait 20 seconds to return to a full, normal display.
HI | LO Temperature/Humidity Records
Press and release the TEMP button to view your HI
and LO records with time and date of occurrence.
A new HI or LO record will replace the existing record.
Viewing order:
• Outdoor HI Temp with Time/Date
• Outdoor LO Temp with Time/Date
• Outdoor HI Humidity with Time/Date
• Outdoor LO Humidity with Time/Date
• Indoor HI Temp with Time/Date
• Indoor LO Temp with Time/Date
• Indoor HI Humidity with Time/Date
• Indoor LO Humidity with Time/Date
• Feels Like HI Temp with Time/Date
• Feels Like LO Temp with Time/Date
• Outdoor Dew Point
OUTDOOR OUTDOOR
OUTDOOR OUTDOOR
INDOOR
INDOOR
INDOOR
INDOOR
FEELS LIKE
FEELS LIKE
OUTDOOR
Reset HI | LO Temperature/Humidity Records
1. Press the TEMP button to view individual readings.
2. Hold the MINUS button for five seconds to reset the individual value.
3. HI | LO reading will reset to current temperature, humidity, and current time/date.

Page | 15Professional Remote Monitoring Station
Feels Like Temperature
Your “Feels Like” temperature is a combination of outdoor temperature, humidity and wind speed.
• When outdoor temperature is higher than 80˚F, Heat Index will show as the Feels Like Temperature.
• When outdoor temperature is lower than 50˚F, Wind Chill will show as the Feels Like Temperature.
• When outdoor temperature is between 50˚F and 80˚F, will show Current Outdoor Temperature as the
Feels Like Temperature.
Note: When you have a high humidity reading, but the temperature is not over 80°F the Feels Like
temperature will remain the same as the current outdoor temperature.
UP ARROW: For this to show, the temperature will have to rise by 2°F (1°C), or the humidity go up by
3%RH or more within the current hour.
RIGHT ARROW: Temperature/ Humidity is steady
DOWN ARROW: For this to show, the temperature will have to fall by 2°F (1°C), or the humidity drop by
3%RH or more within the current hour.
Temperature | Humidity Trend Arrows
Your temperature and humidity trend arrows update every 15 minutes. The trend reflects changes over the past
one hour period.
Daily HI | LO Temperatures
• When your station is connected to the La Crosse View™ app, you will see NWS FORECAST over the HI | LO
temperatures.
• This indicates the daily HI | LO values displayed are from the National Weather Service.
• When you operate your station as a standalone unit, the daily HI | LO readings come directly from your
outdoor sensor.
• The daily HI | LO temperatures cannot be reset.
Note: When connected and receiving NWS forecast
information, your daily HI and LO temperature readings
will oftentimes not match those recorded from your
sensor, and therefore will dier from the records in
your La Crosse View™ app.
NWS FORECAST
LO
HI
FEELS LIKE

Page | 16Professional Remote Monitoring Station
The tree foliage will change seasonally on your weather station. The dates are programmed into your
weather station for an automatic foliage change.
Seasonal Changes in Foliage
March 20th – June 20th
Spring
Autumn
Summer
Winter
June 21st – Sept. 20th
Sept. 21st – Dec 20th
Dec 21st – Mar 19th
• Battery icon by Outdoor Temperature: replace batteries in your Thermo-Hygro sensor.
• Battery icon by Wind: replace batteries in your Wind sensor.
• Battery icon by Rain: replace batteries in your rain sensor.
• Battery icon by Indoor Temperature: replace batteries in your station.
Low Battery Icons
NWS
WIND
DIRECTION
FORE CASTNWS
MPH
WIND SPEED
IN
1 HOUR
NWS FORECAST
LO
HI
FEELS LIKE
RAIN
OUTDOOR
INDOOR
TOP
SPEED
1 HR
Backlight Brightness (5 levels)
Your station has 5 levels of brightness for the backlight:
• When operating with the power cord press and release the LIGHT button to adjust the backlight:
Intensity Levels: 0% | 3% | 20% | 50% | 100%
• When operating on battery power only, press the LIGHT button to activate the backlight for
10 seconds at 100%.

Page | 17Professional Remote Monitoring Station
Sensor ID | Sensor Search
Each of your sensors has an individual ID number, located on its bar code.
This sensor ID is visible on your station by pressing the SENSOR button.
View ID numbers:
• Press and release the SENSOR button to view individual station and sensor ID numbers. All other information
will disappear temporarily.
Search for all sensors:
• While viewing sensor ID, hold the SENSOR button for 3 seconds to search for all sensors.
• The station will search for all sensor ID numbers on the station.
• The sensor reception icon will flash for each sensor while searching.
• The sensor reception icon will be solid when sensor signal is acquired.
• Allow up to 3 minutes to receive sensor signal.
MPH
WIND SPEED
TOP
SPEED
1 HR
Delete Your Sensor ID
OUTDOOR
In the rare event you need to replace your sensor, you will first need to delete the old sensor ID from your
station and remove batteries from your old sensor.
1. Remove batteries from your old sensor.
2. Press and release the SENSOR button to view your sensor ID number.
3. While viewing your sensor ID, hold the MINUS button for 5 seconds to delete your old sensor ID. Dashes
will show for the ID number.
4. Your station will search for a new sensor.
5. Install batteries in your new sensor and allow up to three minutes for your new sensor readings and ID to
appear on your station.
Note: When replacing your Thermo-hygro sensor, press the TX button (under the battery cover) to send a signal
immediately. The Rain and Wind sensors do not have a TX button.
TX F/C
View Sensor ID Number Deleted Sensor ID Number

Page | 18Professional Remote Monitoring Station
Factory Reset V22-WRTH
A factory restart of your station will remove all sensor ID numbers and Wi-Fi settings and return it to its default
settings and “out of the box” condition. This may resolve connection issues with your sensors or Wi-Fi.
1. Hold the RAIN and LIGHT button together for 5 seconds.
2. Your station will reset and search for all sensors.
3. Allow up to 3 minutes to reacquire all sensors.
4. You will need to reconnect to your La Crosse View™app by following the steps on page 4.
Detailed Sensor Set Up and Mounting
LTV-W1 Wind Speed Sensor
1. Turn the battery cover of your wind sensor left.
2. Install fresh “C” batteries.
3. Carefully align and turn battery cover right to tighten.
4. There is a blue LED light on the sensor that will flash when transmitting.
Mounting:
• Position in an open area that will have the least amount of interference with wind speed.
• Mount your sensor vertically with the wind cups on top.
• The maximum wireless transmission range to the station is up to 400 feet (121 meters) in open air, not
including walls or trees.
1. Use screws through the bottom of the mounting bracket to attach.
2. Insert bottom of pole into mounting bracket. Tighten knob to secure
3. Insert the included mounting pole into your sensor.
4. Tighten screws.
Alternatively:
1. Insert your own mounting pole (up to 1.179”) into the sensor.
2. Tighten screws
Twist
Left Side Mount
Option
LED
Light
Wind Cups
Battery
Cover
Mounting
pole
Mounting
Bracket
Knob
C C
Screws

Page | 19Professional Remote Monitoring Station
LTV-R2 Rain Sensor:
1. Flip open both locking tabs on your rain sensor and lift o the funnel portion.
2. Pull up on the battery cover and remove.
3. Install 2-AA batteries according to polarity.
4. Reposition the battery cover over the battery compartment, and firmly push down to lock it back into place
5. Remove cardboard and any tape around the rocker before use. These were used to protect the sensor from
unwanted movement during shipping.
6. Place the funnel portion back over the sensor and re-secure the locking tabs.
Mounting:
1. Mount in an open area, on a stationary level platform for a more accurate rain count.
Note: Avoid placing the bottom of the rain sensor in a depression that would not allow proper water drainage.
2. Insert the mounting screws through the holes in the bottom of your rain sensor. Do not over tighten.
3. Mount your rain sensor at least 3 feet and optimally 6 feet in the air and in direct line of sight to your station.
4. Your rain sensor should be accessible to allow for periodic cleaning of debris or insects.
5. The maximum wireless transmission range to your station is up to 400 feet (121 meters) in open air,
not including walls or floors.
AA
+
-
AA
+
-
Top (Funnel)
Battery Cover
Locking Tabs Remove piece under
rocker of rain sensor
Rocker

Page | 20Professional Remote Monitoring Station
LTV-TH2 Thermo-Hygro Sensor
1. Install 2-AA batteries according to polarity and replace battery cover.
Mounting:
1. Use the hole at the top to hang your sensor from the back using a nail. Or, insert one mounting screw through
the front of your sensor.
2. Mount your sensor on a north-facing wall or in any shaded area. Under an eave or deck rail is preferred.
3. The maximum wireless transmission range to the weather station is up to 400 feet (121 meters) in open air,
not including walls or floors.
4. Be sure your sensor is mounted vertically, to allow moisture to drain out properly.
Note: Watch sensor mounting video: http://bit.ly/TH_SensorMounting
LED Light
AA
+
-
AA
+
-
Battery Cover
Hole for
mounting
TX F/C
∙ Press TX to send a signal
∙ Press F/C to select Fahrenheit
or Celsius display on sensor.
V22-WRTH
1. Insert the power cord into a wall outlet, then into your station.
Optional: Insert 3 AA batteries into your station to maintain time/date in the event of a power outage.
Mounting:
1. Place your station near an outlet. Power cord is required for operation.
2. Use the mounting holes on the back to place your station on a wall.
3. Use the pull down stand on the back of your station to place on a desk or counter.
4. Your station should remain in good Wi-Fi range of your wireless router to use all the remote monitoring
options using the La Crosse View™app.
For more information on manually setting you weather station see page 10.
Power
Cord
AA
AA
+
-
AA
+
-
+
-Optional
