Labtech LBI-150E User manual

- 1 -
Operating Manual Number : LBI-500EE
Edited : December 1999
Revised : January 2016
July 2017
May 2018
Low Temperature BOD Incubator
Model LBI-150E / LBI-250E / LBI-500E / LBI-1000E

- 2 -
Thank you very much for purchasing DAIHAN LABTECH CO., LTD. products.
In order to use the product correctly and most appropriately, please carefully read and fully
understand instructions in this manual and keep it in a convenient location for further
reference.
In order to protect the human life and property, please pay attention to the following signs /
symbols.
Warning
This mark is to alert that user may have loss of life or injury if all
precautions described in this manual are not taken properly.
Caution
This mark is to indicate that if all precautions described in this manual and
operation procedures are not taken properly, it may result in malfunction of
the equipment.
Note
This mark is to indicate precautions which must be taken properly for safe
usage or important functional matters.
Explosive
This mark is to indicate the possibility of explosion by volatile material or
explosive chemical
●This equipment must be used in accordance with the specifications to prevent fire or damage to the
equipment.
●Do not touch high-voltage connections such as power supply terminals, etc. to avoid electric shock.
●DAIHAN LABTECH CO., LTD. is not responsible if this equipment is repaired, modified or disassembled
by 3rd party.
●Changing the parameter value randomly may cause malfunction of the unit.
WARNING
CAUTION
WARNING

- 3 -
●If the power cable or terminal is damaged, stop using it and contact a service center.
-There is a risk of electric shock, or injury.
●Do not bend the power cable excessively or press it with heavy objects to prevent damage.
-There is a risk of electric shock, or injury.
●Do not touch the circuit breaker or power source with wet hands.
-There is a risk of electric shock, or fire
●Please be sure to ground for safety.
- If not, there is a risk of electric shock in case of malfunction or short circuit
●Be sure to check the rated voltage when installing
- 220/230 V ~, 50 or 60 Hz, single phase.
- If the voltage or rating does not match, it may cause fire or electric shock, and if used in
combination with other equipment, it may cause abnormal heat generation and fire.
●The figures, diagrams and numeric values used in this manual are only for the purpose of
illustration.
●DAIHAN LABTECH CO., LTD. is not responsible for any damage or injury that is caused as a result
of using this equipment, equipment failure of indirect damage.
●No portion of this document may be reprinted, copied, stored, and retrieved through any
electronic, optical or other means without prior written approval from DAIHAN LABTECH CO.,
LTD.
●Your equipment are 220/230V~, 50 or 60 Hz, SINGLE PHASE.
●To reduce the risk of electric shock, do not open the body and no user serviceable parts inside.
●Do not put flammable, volatile or explosive materials inside of the chamber.
CAUTION
WARNING

- 4 -
1. Tables of contents
1. Tables of contents ·······························································································4
2. Product overview ································································································5
3. Product specifications ·························································································6
4. Part and functions ·······························································································7
5. Installation ···········································································································9
6. Operating ········································································································10
7. Maintenance and repair of products ······························································12
8. Cause and trouble shooting ··········································································· 13

- 5 -
2. Product overview
●Microprocessor PID Control
Provides precise temperature control from 10℃ to 60℃, timer, alarm, Auto-tuning
●Silent Fan Motor
Provides automatic defrost function and achieves excellent temperature uniformity and quiet
operation
●Safety and Convenience
Over temperature and current protection capability ensure user safety
●This equipment equipped with a compressor which allows general incubation as well as low
temperature incubation experiments.
●This equipment is made with high quality stainless steel and the fan installed inside circulates
the air forcibly to provide stable temperature inside.
●This equipment alerts the user with visual and audible alarms when the temperature inside
deviates from set temperature range,
●An over temperature protector protects the sample from injury from high temperature.

- 6 -
3. Product Specifications
Model
LBI-150E
LBI-250E
LBI-500E
LBI-1000E
Dimensions
Inner
500*500*600
500*500*1000
700*700*1000
1400*600*1000
(W x D x H mm)
Outer
660*845*1325
660*840*1755
860*955*1795
1560*940*1780
Capacity
150ℓ
250ℓ
490ℓ
840ℓ
Temperature
Range 10℃ ~ 60℃
Set Accuracy ± 0.1℃
Uniformity ± 0.5 ℃ at 20℃
Controller
Microprocessor PID Multi-Function Controller
Display
4 Digits LED Display
Timer
99hr 59 min / Continuous
Material
Inner
Stainless Steel(SUS304)
Outer
Epoxy Powder coated Steel
Door
Inner
Tempered Safety Glass
Outer
Silicone Packing Magnetic Door
Shelves
Adjustable 3 or 5 Shelves
Circulation Fan
2EA
2EA
4EA
6EA
Compressor
1/4HP
1/4HP
1/3HP
1/2HP
Safety
Over Temp. Protector, Over Current & Leakage Breaker
Electric Supply
220/230 V~, 50 or 60 Hz

- 7 -
4. Parts and Functions
4.1. Main Controller
① Display
Indicates temperature, time, parameters
② Temperature indicating lamp(TEMP)
Illuminates when the temperature is indicated on the display
③ Timer indicating lamp(TIME)
Illuminates when the timer is indicated on the display
④ Operation and Auto-Tuning indicating lamp(START & AT)
Illuminates when the equipment is in operation
Flickers when the Auto-Tuning is in operation
⑤ Heater operation indicating lamp(OUTPUT)
Illuminates the heater is in operation
⑥ Timer display lamp(TIMER)
Illuminates when timer is operating
⑦ START/STOP button(START/STOP)
Button to start/stop the equipment
⑧ Setting entering button(MODE)
Enters to the temperature and time setting and parameter setting
⑨ Shift button for a leftward movement(◀, LEFT SHIFT)
Leftward movement of set value
⑩ Set value change button(▲, INC)
Change set value
⑪ Display mode change and Auto-Tuning button(CH/AT)
Changes temperature and time display
Starts Auto-tuning. If you press the CH/AT button for 5 seconds or more
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪

- 8 -
4.2. Power and safety device
①Over Temp
Over temperature protection device
- It is a dial type temperature controller. It automatically cuts the heater output off when there is
over temperature due to equipment malfunction.
- Set this 10~20% higher than the set temperature.
- Over temperature protection device is analog type; therefore, it will not accurately match the
displaying temperature.
②Power switch
Power on/off switch
③Circuit Breaker
Device to supply power and to cut off an overcurrent
①
②
③

- 9 -
5. Installation
●Caution during installation
- Do not install in an inclined or uneven ground.
- Install the equipment horizontally and approximately 15cm away from the wall.
- Establish minimum spacing required for inspection and repairs.
- Do not leave flammable or volatile materials near the equipment such as gasoline.
- Do not put anything on top of the equipment.
- Ambient temperature 5℃to 40℃, Optimum temperature 18℃to 25℃
- Allowance of supplying voltage change: lower than 10%
* Wrong power supply (over/less voltage) may cause serious damage to compressor and freezer.
The damage from wrong power supply is not covered under warranty.
If the power supply is unstable, please install AVR (Automatic Voltage Regulator) separately.
- For electric safety, the unit should be earthed.
If the power socket is fitted with earth cord, please check the outlet for earth before use.
* Do not earth to a gas pipe, a telephone line or lightning conductor.
●When not used for a long time.
- Unplug the power cord from the outlet when the equipment is not used for long hours and to
keep it in safe from moisture.
●When transporting
- Do not lay the equipment on its sides when moving
If the equipment is moved to a long distant location, it may cause a malfunction.
●Do not dismantle/remodel
- Do not dismantle, repair, or remodel unless you are an authorized repair technician.
There is danger of fire, electric shock, and injury due to abnormal operation.
●Transport & storage condition
- Temperature: 0℃to 70℃
- Humidity: 0% to 90%
- Pressure: 700hPa to 1060hPa
WARNING
CAUTION

- 10 -
6. Operating
6.1 Getting Started
1) The main voltage must correspond to the voltage given on the name-plate
2) Open the front door and remove packing materials.
3) Install shelves in the chamber.
4) Connect tubing to the drain.
Put the other end of the tubing to sink-hole which is lower than the valve.
5) Turn the circuit breaker on.
6) Turn the power switch on.
6.2 Over Temperature Protection
User must set the over temperature protection before operation.
Set this 10~20% higher than the set temperature.
6.3 How to set temperature
1) If you press the MODE button once, "TEMP" will be indicated on the display.
2) Press MODE button once again. Set temperature will be indicated on the display, waiting for
input.
4) Press LEFT SHIFT(◀) button to move to digit you want change value.
5) Press INC(▲) button to change value
6.4 How to set time
1) Press MODE button after temperature set finished. "TIME" will be indicated on the display.
2) Press MODE button once again.
3) The first digit of the LED display blink and prompt user input. (00:00)
4) Press LEFT SHIFT(◀) button to move to digit you want change value.
5) Press INC(▲) button to change value from 0 to 9.
6) Set four digits of time value you want to operate.
7) You can set timer up to 99 hours 59 min maximum.
If you do not want timer function, set the value 00:00.
8) After setting is done, press the MODE button
6.5 Operating
1) Temperature is controlled when the START/STOP button is pressed
2) If you press the START/STOP button during operation, the equipment stops

- 11 -
6.6 Operating characteristic of timer
1) Timer does not operate until the chamber temperature reaches to set values.
2) "Timer" indication lamp flickers until the equipment reaches to set values. After reaching the
set values, "Timer" indication lamp illuminates and the timer starts to count down.
3) After set time, "Timer" indicating lamp turns off and operation stops.
6.7 Auto-tuning
1) Auto-tuning function automatically sets optimal P.ID. values that can reach to set temperature
quickly and accurately according to the equipment`s installation environment.
2) Auto-tuning can be done during operation
3) Auto-tuning starts if you press the CH/AT button for 5 seconds or more

- 12 -
7. Maintenance and repair of products
7.1. Maintenance
This maintenance manual provides you with important check points to maintain your equipment.
Regular checking according to the maintenance manual can prevent malfunction and increase the
lifetime of the machine
●Ventilation on mechanical compartment
The ventilation in the mechanical compartment is very important to dissipate the heat of the heat
exchanger in the equipment. Always be careful not to block the air inlet or outlet of the vents in
the mechanical compartment.
●Cooling condenser
Cooling condenser's heat exchanger always comes in contact with the outside air by the fan, so there
is a lot of dust stack up. In this case, the cooling efficiency may be reduced and the compressor may
be overloaded or the lifetime of the compressor may be shortened. The heat exchanger should be
cleaned every 3 months using a vacuum cleaner and an air compressor.
●Noise
The operating noise of the equipment is an important parameter to determine the performance
of the compressor. If the sound of equipment operating suddenly becomes loud or irregular,
please check with our service team.
7.2. Maintenance of electric compartment
●Be careful not to let water enter the electric compartments. If water enters, there is a risk of short-
circuit.
●If the electric wiring of this unit is arbitrarily changed or operated, even if in the warranty period,
you cannot get free of charge service. Please be sure to obtain service from an authorized service
engineer.
●When using for a long time, dust or foreign matters may adhere to electric parts, which may cause
malfunction. Please remove dust once a year.
●It is advised to keep the internal temperature of the electric compartment below 60 degrees. If the
ambient temperature is too high, it may cause malfunction.
7.3. Internal maintenance
●Moisture entering the unit may be accumulated when using for a long time. If water is stored for a
long time, it may cause corrosion and contamination. Please clean it regularly.
7.4. How to refill and check refrigerant
●The refrigeration piping of the appliance is completely sealed, so it is not necessary to refill the
refrigerant. If you want to check or supplement the product, please contact the place of purchase.

- 13 -
8. Cause and trouble shooting
Trouble
Check Point
Trouble shooting
When the power light is not on
Check the power cord
Connect the power cord
properly
Circuit breaker short-circuit
check
Switch on the circuit breaker
When temperature control is not
possible
Check the condition of the
controller
Calibrating regulator settings
Over temperature protection
check
Set higher than set
temperature
If the problem persists even after the inspection, please contact the place of purchase or customer
service center of the head office.

- 14 -
APPENDIX Ⅰ
Consumables List
NO
PART CODE
NAME
SPECIFICATION
UNIT
Q’ty
1
LBI-E001
HEATER
LBI-150E(M)
750W
EA
1
LBI-250E(M)
1KW
EA
1
LBI-500E(M)
750W
EA
2
LBI-1000E(M)
750W
EA
3
2
3
4
5
6
7
8
9
10
