Lacava ZOOM EX42-D1 User manual

LACAVA ZOOM
deck-mount hand dryer
EX42-D2
• Replacement parts:
•#EX42-BX - replacement operang box
•
• #EX22 - electronic faucet
• #EX23 - electronic soap dispenser
Spout Dimensions:
Material:
Finishes:
Cutout Size:
Component Parts Included:
Ø 1 3/8”
Recommended Items:
•
and standards
Codes + Standards:
ADA
Features:
Specifications:
Installa�on:
Meets and exceeds applicable naonal codes
compliant when installed to specific
requirements of this regulaon
Matching fixtures (sold separately)
LACAVA reserves the right to revise anydimension or informaon on this sheet without noce. Dimensions are nominal and may vary within an industryaccepted tolerance of 1/4”.
Drawings provided herein are meant to give the user an idea of the product and are not made to scale. Location of plumbingis meant for reference, your specific application may
vary.
Revised: 02/15/2023
LACAVA | CHICAGO, IL, USA | 773.637.9600 | [email protected] | LACAVA.COM
• #EX42-SENR replacement sensor
Power Supply:
•Power supply:
• Voltage: 120V AC
• Frequency: 50/60 Hz
• Power: 1100W max.
• Sensing distance: 4” approx. (10 - 12 cm)
Designed to automacally shut off aer 60 seconds
of connuous operaon
Complements the Zoom electronic faucets
HEPA-filter removes 99.99% of parcles as small
as 0.3 µm, including dust, mold spores and most bacteria
from airflow
Easy installaon; easy maintenance
spout, power supply cable, installaon hardware,
operang box and flexible air hose
touch- free safety from
spreading undesirable pathogens
commercial grade automated fixture
•
•
•
•
•
•
•#EX42-FL - replacement filter
32
Ø 1 1/4"
Max 1 3/8"
35
6 3/4"
171
5 1/2"
141
3 1/2"
82 Ø 1 1/8"
29
1 7/8"
48
8"
203
10 3/4"
275
Max 48"
1220
Max 21"
533
deck- mount 1-hole, touch-free
H: 5 1/2” SPOUT: 6 3/4”
solid brass construcon for durability
AC
CR - polished chrome
21 - brushed staineless steel
PN - polished nickel
NI - brushed nickel
BG - brushed gold
44 - matte black
TN - titanium

LACAVA®
6630 West Wrightwood Ave. Chicago, IL 60707 tel [phone] fax [phone] [e-mail] www.lacava.com
Owner’s Manual
Zoom Hand Dryer
Item #EX42-D1, EX42-D2
Features:
-Deck-mount single hole hand-dryer
-Easy installation; easy maintenance
-Electronic touch-free (infrared sensor) operation promotes germ free environment
-Brass or stainless steel construction for commercial grade durability
-Includes spout, flexible supply hose, operating box, and installation hardware
-Easy electric plug-in power supply
-HEPA-filter removes 99.99% of particles as small as 0.3 µm, including dust, mold spores and most bacteria from airflow
-Sensing distance range: 4” approx. (10 - 12 cm)
-It can be installed to meet ADA compliance
-Automatic protection stops fixture after 60 seconds of continuous operation
-Power supply: 120V AC, Frequency: 50/60 Hz, Power: 1100W max.
-UL certified
-Meets and exceeds applicable national codes and standards

LACAVA 2
Product Specifications/Especificaciones de Producto
Note:
Drawings provided herein are meant to give the user an idea of the product and are not made to scale. The sizes in
inches are rounded up to the nearest 1/16.
Nota:
Los planos proporcionados en este documento tienen el propósito de dar al usuario una idea del producto y no
están hechos a escala. Los tamaños de pulgadas se redondean al más cercano 1 / 16.
4"
100
32
Ø 1 1/4"
Max 1 3/8"
35
6 3/4"
171
5 1/2"
141
3 1/2"
82 Ø 1 1/8"
29
1 7/8"
48
10 1/4"
260
Max 48"
1220
Max 21"
533
10 3/4"
275
3 3/4"
95
10"
255
FILTER
2”
50
5"
128
30
o
3 3/4"
95
6 3/4"
172
35
Ø 1 3/8"
Max 1 1/4"
30
EX42-D1 EX42-D2
7"
178
5"
127
8"
203
Ø 1 1/8"
29

LACAVA3
Parts Breakdown/Desglosamiento de Partes
Note:
Please reference this sheet and the corresponding part number when requesting parts.
Nota:
Por favor referirse a esta pagina y la parte correspondiente cuando ordene partes.
1
2
3
4
5
6
7
8
9
10
11
12
13

LACAVA
Installation Instructions/Instrucciones de Instalación
Warnings:
-Do not install the fixture facing a mirror-like surfaces or other electronic systems
operated by an infra-red sensor
-Space for installation so that the user hands should not interfere with the sensor
detection area while operating a nearby faucet or other objects
-The control box must be accessible after installation
1) A dedicated 120 V AC, 15A GFCI minimum outlet must be provided, properly grounded
and no more than 4 ft. from the installation of the dryer assembly.
2) If no GFCI outlet is provided, contact a licensed electrician to assure proper electrical
connections in accordance with local building codes.
3) Troubleshooting and internal maintenance must be performed by a qualified service
personnel.
IMPORTANT:
Min 10”
255
Installation Diagram
Mount and install components according to the diagram
Min 4”
100
Min 6”
152
Min 6”
152
FILTER
optional
soap
dispenser optional
faucet hand dryer
4
Max 48”
1220
Max 21”
533

LACAVA
Installation Instructions/Instrucciones de Instalación
Max 1 3/4”
45
1. Install spout body into mounting hole and install
washer and lock nut from underneath the mounting
surface (avoid damaging mounting surface by over-
tightening).
5
2. Mount the hand dryer operating box within 21” of the spout
location, and connect it to the spout with flexible hose.
For best performance, keep the connecting hose straight if
possible, free of unnecessary turns and twists.
For ADA compliant installation, refer to ADA requirements.
a. Mark the location of mouting screws, and install
the mounting bracket, using the provided or suitable
hardware.
b. Hook the back of the hand dryer box onto the mounting
bracket and secure the bottom of the hand dryer box
to the wall.
c. Feed the sensor cable through the flexible hose, making
sure the cable is not kinked, screw the hose onto the tail
of the spout.
d. Connect the sensor cable to the hand dryer box
via a metal 3-pin aviation plug and hand-tighten the base.
e. Make sure to place the sensor cable in the slot on the
hose coupling sleeve, and tighten the hose clamp.
Do not pinch the senser cable.
3. Plug power cord to wall socket.
1.
2b.
2a.
2d.
!
2e.
3.
2c.

LACAVA 6
How to Use
Place hands in the sensor field
2”-4” below the spout’s tip
Warm air blows until hands are removed
or for 60 seconds of continuous operation
and then shuts down
Remove hands from sensing field
for 3 seconds to repeat the cycle
Maintenance
WARNING
DO NOT operate the hand dryer without the HEPA filter. Operating the hand dryer without the
LACAVA provided HEPA filter will void the product warranty. The H Class HEPA filter removes 99.99%
of particles as small as 0.3 µm, including dust, mold spores and most bacteria from the airflow.
It also ensures that the air flowing through the blower motor is clean and dust free. Running the
hand dryer without the filter may cause dust and small particles to be sucked into the blower, which
may shorten the service life of the motor.
A clogged-up filter reduces the air flow volume and puts unnecessary stress on the blower motor.
For relatively clean and dry environments, the HEPA filter should be replaced at least every 12 months.
For moist or dusty environments, we recommend shorter replacement intervals, e.g. every 3 - 6 months.
FILTER REPLACEMENT
1. Unplug the power cord.
2. Pull out the HEPA filter tray. The tray is click-locked into place with small plastic tabs on the
body of the tray. It might be tight when you try to pull it out. Pry it out gently with flathead
screwdriver wiggling it slightly side-to-side and up-and-down. Do not use brute force.
3. Remove the tray lid, replace the filter, put the lid back on, and insert the tray back into the
hand dryer body. There will be a distinctive “CLICK”when the tray is locked into place.
4. Plug in the power cord, and the hand dryer is back in service again.
tray cover
tray
CLICK!

Cleaning and Care
For best results, please care for this product in accordance with the following instructions:
- Only use warm water and a mild detergent (i.e. dishwashing soap) for cleaning.
- If another cleaner is used, check the label to make sure that it is safe for use on the material being cleaned and
always test in an inconspicuous area first.
- Make sure to wipe any excess cleaners off with a damp sponge or cloth and then rinse with water.
- Dry the surface with a soft cloth until dry after each use.
- Never use abrasive materials or cleaners that contain ammonia, bleach or acid, since they can cause damage
to the finished surface.
We would like to thank you for your purchase and are confident that you will be able to enjoy our products for
many years to come!
Para mejores resultados, por favor cuide des este producto de acuerdo con las siguientes instrucciones:
- Sólo utilice agua tibia y un detergente suave (es decir, el jabón para lavar la vajilla) para la limpieza.
- Si se utiliza otro limpiador, revise la etiqueta para asegurarse de que es seguro para el uso del material para su
limpieza y siempre prueba en un área discreta primero.
- Asegúrese de limpiar cualquier exceso de productor de limpieza con una esponja o un trapo húmedo y luego
enjuague con agua.
- Seque la superficie con un paño suave hasta que se seque después de cada uso.
- Nunca use materiales abrasivos o productos de limpieza que contienen amoníaco, lejía o ácido, ya que pueden
causar daños a la superficie acabada.
¡Nos gustaría darle las gracias por su compra y estamos seguros que usted podrá disfrutar de nuestros productos
por muchos años!
Cuidado y Limpieza
LACAVA
7
CLEANING THE SENSOR WINDOW
Periodically clean the sensor window by wiping the nozzle of the air outlet spout with a clean damp
cloth. If necessary, use a little bit of mild soap.
DO NOT use abrasive material, such as steel wool, scotch scrub pads, etc.
The spout is for airflow, not for water. NEVER rinse it with water or pour water into the spout.
sensor
spout
