LAMBORGHINI URUS User manual

LAMBORGHINI
URUS
INSTALLATION MANUAL
For:

• cable loom
• Electronics
• Bridge plug
• Installation manual
• side cutter
• small screwdriver
• ratch with 13‘ nut
Package contents
Requested Tools
2
To be able to take the benefits of all technical advantages of your newly purchased additional
electronics, please consider the following advices. Do not use the additional electronics before
you have read and understood the „Important infromation“. The installation confirms the buyer
has read, understood and accepted the „Important information“.
Important!
In order to ensure maximum performance, at least 98 RON must be fueled.
Hinweis / Note

3
5 min
1. Wait 5 minutes after locking!!!
2. Do not open any doors during this time.
3. During this time all sensors of the vehicle switch off.
4. After the 5 minutes you can begin with the installation.
Notes to be observed during the installation!
When installing the wiring harness and the
electronics, pay attention to the following:
• Do not mount near moving parts
• Protect from vibration and water
• Do not attach the electronics to hot parts.
Preparation for installation
LOCK
1. Switch off your vehicle!
2. Open the hood.
3. Lock all doors and close your vehicle.
Do not perform the installation when the ignition is on!

PREPARATION
4
Preparation
• Loosen the both clips to remove the engine cover.

Preparation
• Loosen the both hose clamps to remove the air filter box.
5
PREPARATION

PREPARATION
* Colors correspond to the marking on the wiring harness
B
C
A
A: Manifold air pressure 1*
B: Manifold air pressure 2*
C: Camshaft sensor *
+: Power supply*
6
+

7
INSTALLATION
A
A. Manifold air pressure sensor 1
• The manifold air pressure sensor 1 is located lower.

INSTALLATION
A. Manifold air pressure sensor 1
• Disconnect the 3-pin plug-in connection at the manifold air pressure sensor 1
and insert the supplied cable loom which is marked with (A) in between.
8
A

9
B
INSTALLATION
B. Manifold air pressure sensor 2
• Disconnect the 3-pin plug-in connection at the manifold air pressure sensor 2
and insert the supplied cable loom which is marked with (B) in between.

INSTALLATION
C
C. Camshaft sensor
• The camshaft sensor is located on the front of cylinder bank.
• Disconnect the 3-pin plug-in connection at the camshaft sensor and insert the
supplied cable loom which is marked with (C) in between.
10

11
INSTALLATION
+. Power Supply
• Connect the red wire to the power supply.
+

• Check again if all connections are seated correctly and reassemble the parts of the vehicle, if
necessary, in the reverse order.
• You can now close the engine hood and start the vehicle.
END
INSTALLATION
Function of the bridge plug
With the bridge plug, you can return your vehicle to the serie state without removing the cable
loom. The bridge plug only fits into one position. Before using the bridge plug, please refer to
„Prepararion for installation“ on page 3.
12

Error description Solution tips
"The vehicle does not start" • Repeat the installation step by step and check the proper
fit of the connectors.
• If the problem persists -> Instead of the electronics, insert
the supplied bridge plug and restart the vehicle.
• If the error persists, contact your sales representative
"The vehicle jerky or stutters while driving" • Repeat the installation step by step and check the proper
fit of the connectors.
• If the error persists, contact your sales representative
The vehicle jumps into the emergency running mode "
(Motor control lamp or incandescent lamp is lit)
• Repeat the installation step by step and check the proper
fit
• If the error persists, contact your sales representative
"No additional benefit" • For the petrol engine: Please pay attention to fuel: For a
maximum performance, at least 98 RON must be fueled.
• If the error persists, contact your sales representative
13
FAQ

Notes
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
14

Notes
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
———————————————————————————————
15

V1.0
