Lamtec LT3 User manual

www.lamtec.de
Sensors and Systems for Combustion Engineering
User Manual
Lambda Transmitter LT3
Lambda Probe LS2

2
Table of Contents
Table of Contents
1 Important Information about the Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Validity of these Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Information on Using this Operating Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 General Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Classification of the Safety Instructions and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Proper Use - Conditions of Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.3 Permissible Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.4 Safety Equipment/Safety Measures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Product Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1 Design and Accessory LS2 Lambda Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 Display and Operational Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2 Menu Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2.1 Password Entry Menu Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2.2 Information Menu Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.2.3 Calibration Menu Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.2.4 Settings Menu Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.3 Status Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.4 Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.4.1 Main Menu - Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.4.2 Main Menu - Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.4.3 Main Menu - Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.1 Probe Testing and Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.1.1 Checking/Calibrating the Air Voltage (Offset) . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.1.2 Checking/Calibrating the O2 Electrode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.1.3 Reading the Measured Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.1.4 Enter the Password for the Access Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.1.5 Activate/deactivate Maintenance Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.1.6 Response of the Internal Resistance Regulation. . . . . . . . . . . . . . . . . . . . . . . . 24
5.1.7 Premature Cold Start Termination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.1.8 Calibrating the Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5.1.8.1 Offset Calibration perform to 21 % O2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.1.8.2 O2 Calibrating in the Operating Point with Reference Measurement. . . . . . . . . 29
5.1.9 Checking/Calibrating with Test Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.1.10 Checking/Calibrating with Reference Measurement . . . . . . . . . . . . . . . . . . . . . 33
5.1.11 Consumables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.1.12 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.1.12.1 Maintenance Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.1.12.2 Filter Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.1.12.3 Analogue Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.1.12.4 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.1.12.5 Limit Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6 Correcting Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
6.1 Faults and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

3
Table of Contents
6.1.1 Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
6.1.2 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6.1.3 Call of the Fault History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
7 Decommissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.1 Protection Against Emissions from Gas Carrying Channels . . . . . . . . . . . . . . . . . . . . . 42
8 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
8.1 Analogue Outputs via LSB Module Current, alternative Voltage, LSB address 19 . . . . 43
8.1.1 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
8.1.2 Factory Setting of Analogue Outputs via LSB Module. . . . . . . . . . . . . . . . . . . . 44
8.1.3 Conversion of the Output Range via the User Interface . . . . . . . . . . . . . . . . . . 45
8.2 Digital Outputs via LSB Module, LSB Address 03 and 51 . . . . . . . . . . . . . . . . . . . . . . . 46
8.2.1 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
8.2.2 Factory Setting of the Digital Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8.2.3 Diagnosis of the Digital Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8.3 Digital Inputs via the LSB Module, LSB Address 11 and 55 . . . . . . . . . . . . . . . . . . . . . 48
8.3.1 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.3.2 Factory Settings of the Digital Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.3.3 Diagnosis of the Digital Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.4 LSB Module for Calculating Combustion Efficiency. . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
8.4.1 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
9 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
9.1 Storage Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
10 Disposal Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
10.1 Environmental Protection, Waste Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
11 Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
11.1 Wet/Dry Measurement Deviations, Conversion Table . . . . . . . . . . . . . . . . . . . . . . . . . . 54
11.2 EU Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

4
1 Important Information about the Manual
1 Important Information about the Manual
1.1 Validity of these Instructions
This manual describe the Lambda Transmitter LT3 with all required components. The informa-
tion in this document applies to the software version V1.09.0.0. If you utilise a different version,
this can lead to other effects to your device than those described in this manual.
NOTICE
LT3 Lambda Transmitter cannot be used for LAMTEC CO/O2 Control.
1.2 Information on Using this Operating Manual
NOTICE
Before starting work, you absolutely must read these instructions!
Carefully observe all warning notes!
They contain important data and information, the compliance with which will ensure the func-
tion of the device and, in turn, reliable measurement results.
The device described here corresponds with the standard configuration.
Particular attention must be paid to information and warnings. These are indicated by re-
spective pictograms. They serve to safeguard your personal safety and help you to avoid op-
erating errors.
This manual for end users contains the information required to operate and maintain the sys-
tem.

5
2 General Safety Instructions
2 General Safety Instructions
2.1 Classification of the Safety Instructions and Warnings
The following symbols are used in this document to draw the user's attention to important safe-
ty information. They are located at points where the information is required. It is essential that
the safety information is observed and followed, and that applies particularly to the warnings.
DANGER!
This draws the user's attention to imminent danger. If it is not avoided, it will result in death or
very serious injury. The plant including its surroundings could be damaged.
WARNING!
This draws the user's attention to the possibility of imminent danger. If it is not avoided, it may
result in death or very serious injury. The plant including its surroundings could be damaged.
CAUTION!
This draws the user's attention to the possibility of imminent danger. If it is not avoided, it may
result in minor injuries. The plant including its surroundings could be damaged.
NOTICE
This draws the user's attention to important additional information about the system or system
components and offers further tips.
The safety information described above is incorporated into the instructions.
Thus, the operator is requested to:
1 Comply with the accident prevention regulations whenever work is being carried out.
2 Do everything possible within his control to prevent personal injury and damage to prop-
erty.

6
2 General Safety Instructions
2.2 Proper Use - Conditions of Use
Operation
The LT3 Lambda Transmitter is an all-purpose O2 measuring device based on microprocessor
for direct measurement of the O2 concentration under super-stoichiometric range (λ > 1) used
together with Lambda Probe LS2
Operation
The Lambda Transmitter is an electronic data interpreting device which is used in conjunction
with the Lambda Probe LS2for the continuous measurement of the O2 concentration in non-
combustible gases in the superstoichiometric area.
Prerequisites
It is assumed that plant planning, mounting, installation, commissioning, maintenance, and
service work will be carried out by sufficiently trained personnel and that this work will be
checked by responsible skilled personnel. It must be particularly noted that
• the operation complies with the technical data and specifications regarding permissible
use, mounting, connection, and environment and operating conditions (refer to the con-
tract documents, the device user information, rating plates, etc.).
• work will be carried out in accordance with the local, plant-specific circumstances and with
regard to the operational risks and directives.
• all the measures required to preserve the value, e.g. for transportation and storage as well
as maintenance and service, are maintained.
Intended use
The product described here has left the factory in a flawless, safe and checked condition and
it must be maintained exclusively in the manner that is described by the manufacturer. Equally,
the proper transportation, correct storage and setup as well as the careful operation and main-
tenance, are critical for the flawless and safe operation of the device. Sufficiently qualified per-
sonnel must be used to install and operate this product. They must be familiar with the security
advice and warnings specified here and ensure they can be implemented flawlessly. Unqual-
ified persons working on the device or the warning information provided here or on the device
not being observed could result in serious personal injury and / or damage to property. The
device is being used as intended if the device is being used solely for the application specified
in the technical description. Auxiliary devices or those from other manufacturers must be rec-
ommended or authorised by LAMTEC. Provided the safety information and operating direc-
tives specified in this manual are observed, this device should not present any risks in terms
of damage to property or the health of personnel.

7
2 General Safety Instructions
2.3 Permissible Users
Qualified personnel
The person responsible for safety absolutely must guarantee that
• only qualified personnel perform work on the system parts.
Due to their training, education, experience, or instruction and due to their knowledge of
pertinent standards, provisions, accident prevention regulations, and system conditions,
qualified personnel are authorized to perform these tasks by the person responsible for
the safety of people and the system. It is decisive that this personnel must be able to rec-
ognise and prevent risks on time.
Experts are considered to be people according to DIN VDE 0105 or IEC 364 or directly
comparable standards like DIN 0832.
• These persons must have access to the provided operating manual and any pertinent or-
der-related documentation during all work and observe these documents within the scope
of preventing risks and damage.
User groups
For the handling of the Lambda Transmitter LT3, three user groups are required:
• Service technicians of LAMTEC or its OEM customers and/or trained customer personnel:
– Qualified technicians/engineers  have very good knowledge of the device.
– SERVICE access level - password-protected
• Operators, customer fitters, technicians for instrumentation and control technology, elec-
tricians, and electronic engineers  have introductory knowledge of the device.
– CUSTOMER access level - password-protected
• Operating personnel with basic knowledge
– OPERATION access level - no password

8
2 General Safety Instructions
2.4 Safety Equipment/Safety Measures
Hazards from electrical equipment
The LT3 Lambda Transmitter and the Lambda Probe LS2 is equipment for use in industrial
electrical power installations. Always switch off the power when working on mains connections
or mains voltage. If shrouding (for electrical safety) has been removed, reattach it before
switching on the power supply again. Damage to health or equipment may result from improp-
er use or improper handling.
NOTICE
To avoid damage, always observe the respective security notices.
Preventive measures for improving operating safety
If the LT3 is used in conjunction with control and monitoring technology, the operator must en-
sure that any breakdown or failure of the LT3 device does not cause inadmissible damage or
dangerous operating states. To avoid faults which could cause direct or indirect personal or
material damage, the operator must ensure that:
• the responsible maintenance personnel can be reached at any time and as quickly as pos-
sible
• the maintenance personnel are trained to correctly respond to faults with the LT3 Lambda
Transmitter and the associated malfunctions
• in the case of doubt, the faulty equipment can be switched off immediately
• A switch-off does not lead to direct follow-up problems.
Avoiding consequential damages
To avoid consequential damages in the event of failure, which could cause direct or indirect
personal or material damage, the owner must ensure that qualified personnel can assess the
faults and initiate appropriate measures to tackle them.
Protect against gas leakage from the gas-bearing channel
The Lambda Probe LS2 is fitted directly to the gas-bearing channel via the probe installation
fitting (PIF). If the Lambda Probe LS2 or the installation fitting (PIF) are removed there is a
chance that hot and/or noxious gases, which could be hazardous to health, could egress
through the open orifice in the flue - this is particularly like where the gases in the flue are at
positive pressure. A risk assessment should be carried out and precautions taken to eliminate
any hazardous situation occurring. For prevention, suitable protective measures must be tak-
en in advance.
WARNING!
Discharge of hot, corrosive gases !
In the event of high pressure and temperatures higher than 200 °C (392 °F) in the gas duct,
gas escapes when the LS2 Lambda Probe or the probe installation fitting (PIF) is removed.
Switch OFF the application before opening.
Wear protective clothing and a protective mask.
Affix appropriate warnings near by.
Close aperture immediately after finishing work.
Decommissioning/recommissioning
The Lambda Transmitter LT3 Lambda Probe LS2 are a high-quality,
electronic measuring system. It therefore requires careful handling in all situations - decom-
missioning, transport, and storage.

9
2 General Safety Instructions
NOTICE
Do not switch off the Lambda Transmitter LT3 as long as the LS2 Lambda Probe is mounted.
Not even if the associated plant has been brought to a standstill. Residual gases will cause
corrosion and could damage the probe.
Do not store the device outside without any protection!
Always store in a dry location and, if possible, keep in the original packaging.
When uninstalling, protect the ends of cables and the connectors from corrosion and soil-
ing. Corroded connectors can cause malfunctions.
If possible, always transport in the original packaging.

10
3 Product Description
3 Product Description
3.1 Design and Accessory LS2 Lambda Probe
The Lambda Probe LS2 provide the in situ (direct in the flue gas) measurement of O2 concen-
tration in exhaust gases in the super-stoichiometric range (>1).
Fig. 3-1 Lambda Probe LS2 standard design
Alternatively:
Fig. 3-2 Lambda Probe LS2 in HT design
1 Lambda Probe LS2 in standard housing up to 300 °C (572 °F)
Default cable length is 2 m (6.5 ft), FEP, with connecting plug
2 Probe installation fitting (PIF)
3 Gas Extraction Device (GED)
1 Lambda Probe LS2-HT with flue gas bypass tube, temperature up to 1200 °C
(2192 °F) depending on material,
– 750 °C (1382 °F) Stainless steel
– 950 °C (1742 °F) Inconel
– 1200 °C (2192 °F) Kanthal
Temperature at probe heat max.100 °C (212 °F)
Default cable length is 2 m (6.5 ft), FEP, with connecting plug
2 Flue gas bypass tube

11
3 Product Description
Fig. 3-3 Lambda ProbeLS2-HT for manual purging (for application in high dusty environments)
1 Lambda Probe LS2-HT up to 300 °C (572 °F)
Temperature at probe heat max.100 °C (212 °F)
Default cable length is 2 m (6.5 ft), FEP, with connecting plug
2 High dust reception flange with pneumatic connections

12
4 Display and Operational Controls
4 Display and Operational Controls
To display and operate LT3, the user interface is integrated into the front door of LT3 (included
in the standard).
Functions:
• Reading of the O2 measured values
• Password entry
• Information  regarding the probe, fuel, warnings, faults, software version,
CRC, and serial number
• Calibration of measurement
• Settings  maintenance, filter time, analogue output, probe replacement, display,
limit values, and digital outputs
Fig. 4-1 LT3 user interface
Fig. 4-2 Housing with user interface

13
4 Display and Operational Controls
4.1 Operation
Using the arrow keys you can navigate within the menus.
The keys and mov their selection to the right or the left hand.
ENTER ENTER takes you to menu entries or to the edit mode in the case of selected pa-
rameters or values.
With the keys and the currently selected value can be changed accordingly Hold
down the respective key and the value will count automatically up or down.
BACK BACK leaves the window, menu, or edit mode.
4.2 Menu Structure
4.2.1 Password Entry Menu Structure
No access level necessary
Access level ’Customer’
Access level ’Service’

14
4 Display and Operational Controls
4.2.2 Information Menu Structure
4.2.3 Calibration Menu Structure
Enter the password for access level 1 (see chapter 5.1.4 Enter the Password for the Access
Level).

15
4 Display and Operational Controls
4.2.4 Settings Menu Structure
Enter the password for access level 1 (see chapter 5.1.4 Enter the Password for the Access
Level).

16
4 Display and Operational Controls
4.3 Status Line
The status line contains information about LT3, including the device family.
Fig. 4-3 UI300-LT-V2 front view status line
1. Status line
Description status line:
Active fault/warning
Operating mode OK
Heat-up (cold start)
Status of limit values 1-4*
Active limit value not triggered
Non-active limit value (off)
Active limit value undershot/exceeded
Active maintenance mode
Without access level
Access level 1 - Customer
Access level 2 - Service
Window number
*If a limit value is exceeded the display shows an upward or downward arrow.

17
4 Display and Operational Controls
4.4 Main Menu
The display shows the O2 value, resolution 0,1 %
Press ENTER to access the main menu.
Meaning of the symbols:
Password entry
Information regarding the probe and fuel, warnings and faults,
software version, CRC, and serial number
Calibration of measurement
Settings (maintenance, filter time, analogue output, probe replacement, display,
limit values and digital outputs)
Basic display Main menu

18
4 Display and Operational Controls
4.4.1 Main Menu - Information
Meaning of the symbols:
Measured values and probe data
Fault/warning history
Software version of LT3 and display
CRC checksums
Serial number
Manual reset of the limit values if they are set to manual reset
4.4.2 Main Menu - Calibration
Enter the password for access level 1 (see chapter 5.1.4 Enter the Password for the Access
Level).
Meaning of the Symbols Required Access Level
Offset calibration to 21 % O2 (calibration in air) none
O2 calibration 1 (customer) or higher
Fuel change over 1 (customer) or higher

19
4 Display and Operational Controls
4.4.3 Main Menu - Settings
Enter the password for access level 1 (see chapter 5.1.4 Enter the Password for the Access
Level).
Meaning of the Symbols Required Access Level
Maintenance mode none
Filter time of the measurement values none
Analogue outputs 1 (customer) or higher
Trigger probe replacement 1 (customer) or higher
Display parameters none
Limit values 1 (customer) or higher
