Lanbe AS-3100L Series User manual

1/ 11
KVM User Manual
KVM SWITCHES PACKING LIST
Type Name Num/Unit Note
AS-3100L
Series Products KVM Control Platform
1 15 inches LCD screen, keyboard and mouse control platform integrated
KVM switch with multiple ports
(4/8/16ports).
AS-7100L
Series Products KVM Control Platform 1
17 inches LCD screen, keyboard and
mouse control platform integrated
KVM switch with multiple ports
(4/8/16ports).
AS-9100L
Series Products KVM Control Platform
1 19 inches LCD screen, keyboard and mouse control platform integrated
KVM switch with multiple ports
(4/8/16ports).
Cable
KVM Connecting Cable 1/4/8/16 PS/2 Connecting and USB Connecting
AC Power Power Cable 1 AC power connecting cable
KVM Control
User Manual User Manual 1/2 LCD Manual and KVM Manual
Please check the lists carefully and contact with your dealer if you have some problems.
Please read the manual carefully before installation.
Assembling & Disassembling
The device can be assembled and disassembled as following.

2/ 11

3/ 11
OVERVIEW
KVM control platform is one witch integrate a multiple ports KVM switch into 1U height. It
controls multiple computers with one platform (keyboard, mouse and monitor).
A KVM switch can control 4/8/16 PC by direct connection and it can control 256 PC at most by 3
level cascade connection.
It is easy and quick to install. Just connect the wire to the correct port without software
configuration. So there is no difficulty in installation and incompatibility.
KVM switch provides two methods to control the computers connected to it:
1. By keyboard combine key.
2. By OSD operation.
In addition, it provides powerful automatic scanning function to scan and monitor all computers

4/ 11
connected to it.
Using KVM control platform is a best choice to save time and money. By using one KVM platform
to manage all the computers connected to it, user can save money for keyboard, mouse and monitor
for each computer and their space.
PRODUCT TYPE
Type OSD
Function Note
AS-3100L No 15 inches LCD screen, keyboard and mouse. And Body parts can be easily demolished
AS-3104\ 08\16RDL Yes 15 inches LCD screen, keyboard, mouse and 4\8\16 ports PS/2 KVM. And Body parts can be easily demolished
AS-3104\ 08\16UDL Yes 15 inches LCD screen, keyboard, mouse and 4\8\16 ports USB KVM. And Body parts can be easily demolished
AS-7100L No 17 inches LCD screen, keyboard and mouse. And Body parts can be easily demolished
AS-7104\ 08\16RDL Yes 17 inches LCD screen, keyboard, mouse and 4\8\16 ports PS/2 KVM. And Body parts can be easily demolished
AS-7104\ 08\16UDL Yes 17 inches LCD screen, keyboard, mouse and 4\8\16 ports USB KVM. And Body parts can be easily demolished
AS-9100L No 19 inches LCD screen, keyboard and mouse. And Body parts can be easily demolished
AS-9104\ 08\16RDL Yes 19 inches LCD screen, keyboard, mouse and 4\8\16 ports PS/2 KVM .And Body parts can be easily demolished
AS-9104\ 8\16UDL Yes 19 inches LCD screen, keyboard, mouse and 4\8\16 ports USB KVM .And Body parts can be easily demolished
FEATURES
Control Platform
Control platform with LCD, keyboard, mouse and multiple ports KVM switch.
1U height, suitable for 19’’standard cabinet installation and metal structure.
15/17/19’’LCD screen with high brightness, high clear and high resolution.
Control platform can be totally pulled out from the cabinet and the LCD screen can be turned
on to 120 degrees.
Ultra thin keyboard with keypad.
Mouse touch board with two function button.
Front panel with lock to prevent damage by accident.
Built-in power.
Automatic power on/off. When pulling control platform out from cabinet, the power turns off
automatically. When pushing it into the cabinet, the power turns on automatically.
An easy to use OSD menu.

5/ 11
Switch
One control platform can control 4/ 8/16 computers by direct connection.
One control platform can control 256 computers by 3 level cascade connection.
Be compatible with PS/2, USB standard interface.
Support VGA, SVGA, XGA video input.
Accord with DDC, DDC2, DDC2B standard and VESAstandard.
Support maximum resolution of 1920 * 1440
Support multiple operating systems: WIN95/98/98SE/ME/200/XP、WIN NT、UNIX、LINUX.
FRONT VIEW
1. Front panel
2. Handle
3. LCD screen
4. Keyboard
5. Mouse touch board
6. Rear hang ear channel
7. Guide
8. Front hang ear
9. LCD OSD control key
1
2
3
4
5
6
7
8
9
REAR VIEW
AS-3104UDL/AS-7104UDL/AS-9104UDL
AS-3108UDL/AS-7108UDL/AS-9108UDL

6/ 11
AS-3116UDL/AS-7116UDL/AS-9116UDL
①②
①AC 100~230V power socket
②PC connecting port
AS-3104UDL/AS-7104UDL/AS-9104UDL
AS-3108UDL/AS-7108UDL/AS-9108UDL
AS-3116UDL/AS-7116UDL/AS-9116UDL
①DC 9V 1000mA power socket
②PC connecting port
KVM CONTROL PLATFORM CONNECTING WIRE
Cable Type Applicable Type KVM Port PC or Server Port
USB Connecting
Cable
AS-3104/08/16UDL
Series Products
VGA port
(Keyboard, mouse
and monitor)
VGA、Keyboard、Mouse
(Standard USB Interface)
PS/2 Connecting
Cable
AS-3104/08/16RDL
Series Products
VGA Port
(Keyboard mouse
And monitor)
VGA、Keyboard、Mouse
(Standard PS/2 Interface)

7/ 11
USB Connecting 1.8m Cable
PS/2 Connecting 1.8m Cable
USB and PS/2 Connecting 1.8m Cable
KVM CONTROL PLATFORM POWER WIRE
Wire Type Note Voltage Range Machine Type
AC Power Wire 3 Plugs of National Standard 100~230V All

8/ 11
AC Power Wire
DIMENSION
CONNECTION OF KVM SIGNALWIRE
1. PS/2 connecting wire
Connect the end with 3 sockets to the KVM control platform, and the other to the
computer.
2. USB connecting wire

9/ 11
Connect the end with HD15 to the USB KVM control platform, and the other to the
computer.
OPERATIO
Before Use
zMake sure all the devices safely grounded.
zMake sure the KVM wire and power wire connected correctly.
During Use
zPull the KVM control platform out from cabinet totally, the guide locks automatically and the
power turns on.
zRelease front lock. As shown below:

10 / 11
zThen open the front panel and the LCD can be turn on to 120 degrees. As shown below:
UNLOCK
AUTO LOCK
zPress LCD power key (red), the LCD is on.
After Use
zPress LCD power key, the LCD is power off.
zClose LCD panel and lock the front panel.
zRelease guide lock.
zPush the control panel into the cabinet totally, and then it is power off.
Hot Plug
The KVM control platform supports hot plug. It can be connected and disconnected without power
off. Please follow the steps:
Hot plug PC connecting port:
When hot plugging PC port:

11 / 11
1. The connecting wire must be plugged into the port from which it is pulled out.
2. Plug the mouse before the keyboard.
Note: The KVM control platform must be power on before PC.
Power On/Off and Reboot
If user needs to cut off the power of KVM control platform, please follow the steps before power on
again.
1. Cut off the power supply of all computers.
Note:
1) The power wire of computer with keyboard power on function must be pulled out. Otherwise, the
KVM still receives the power signal from computer.
2) If the control unit uses the external power, please pull out external power.
2. After about 10 seconds, power on the KVM control platform.
3. After the KVM switch starts, power on the computers.
INTERFACE SELECTION
There are two ways to select: Hot key and OSD menu.
HOTKEY
The hotkey let the user control the connected computers by keyboard. Please check AUTO
SWITCH user manual.
