Land Pride FDR1648 Series User manual

49
Grooming Mowers
Specifications & Capacities
Designs, specifications, features and information are subject to change without notice.
Grooming Mowers
FDR16 Series (Rear Discharge)
FDR1648 FDR1660 FDR1672
Maximum HP - Engine 30 HP
Cutting Width 48” 60" 72"
Overall Width 50 5/8” 62 1/2” 74 5/8”
Height 35 1/8” 35 1/8” 35 1/8”
Length 57” 64” 69”
Weight 486# 577# 619#
Cutting Height (1/2” increments) 3/4” - 5 1/4”
Deck Material Thickness 3/16”
Blade Tip Speed 16,203 FPM 18,195 FPM 18,130 FPM
Blade Construction -3 ea. 1/4” x 2 1/2” x 16 7/8”
Heat Treated Alloy Steel 1/4” x 2 1/2” x 21” Heat Treated Alloy Steel 1/4” x 2 1/2” x 25” Heat Treated Alloy Steel
Blade Options Standard Blades: Medium Lift
Optional Blades: Low Lift, High Lift & Mulching
Blade Overlap 1 1/4”
Blade Spindles 1 3/8” dia., Cast Iron Greasable Hubs
Discharge Rear
Hitch Category l
Lower Hitch Floating Clevis with Plated Pins
Top Link Floating Clevis
Castered Gauge Wheels 3 1/4” x 10” Solid Rubber
Caster Wheel Spindle 1” Diameter with Nylon Bushing
Drive Train 540 RPM PTO
Cast Iron Housing Gearbox With Beveled Gears, 1:2.83 Ratio
Spring Loaded Single V-Belt
Gearbox Oil Capacity & Type 2.5 Pints of 80-90W EP Gear Lube
Driveline Heavy-Duty w/quick coupler, ASAE Cat 2
Front Roller Optional
Quick Hitch Compatible No Yes Yes
310-366S continued on next page 4/12/11

50
Grooming Mowers
Specifications & Capacities
Designs, specifications, features and information are subject to change without notice.
26965
310-366S ends 4/12/11
