LANGER EMV-Technik PA 3010 set User manual
User Manual
- Translation of the original -
PA 3010 set
Preamplier 10 MHz up to 10 GHz
Copyright © August 2021
LANGER EMV-Technik GmbH 2021.09.24 PA 3010 Bedienungsanleitung A5_DE_ENG_PS
PA 3010 set
- 2 / 12 -
Content
1 Declaration of Conformity....................................................................3
2 General Information..............................................................................4
2.1 Storage of the User Manual .................................................................... 4
2.2 Reading and Understanding the User Manual ........................................ 4
2.3 Local Safety and Accident Prevention Regulations ................................. 4
2.4 Images and Graphics .............................................................................. 4
2.3 Limitations of Liability .............................................................................. 4
2.4 Errors and Omissions .............................................................................. 4
2.5 Copyright ................................................................................................. 4
3 Scope of Delivery..................................................................................5
4 Technical Parameters...........................................................................6
4.1 Connections and Dimensions .................................................................. 6
4.2 Measurements and Characteristics ......................................................... 7
5 Safety .....................................................................................................9
5.1 Intended Use ........................................................................................... 9
5.2 Reasonably Foreseeable Improper Use .................................................. 9
5.3 Staff Requirements .................................................................................. 9
5.4 Safety Instructions ................................................................................... 9
6 Application ..........................................................................................10
6.1 Application Notes ................................................................................... 10
6.2 General Measurement Set-up ............................................................... 10
7 Information on Recycling and Disposal ...........................................11
8 Customer Service ...............................................................................12
9 Warranty ..............................................................................................12
PA 3010 set
- 3 / 12 -
1 Declaration of Conformity
Manufacturer:
Langer EMV-Technik GmbH
Nöthnitzer Hang 31
01728 Bannewitz
Germany
Langer EMV-Technik GmbH herewith declares, that the product
PA 3010 set, Preamplier 10 MHz up to 10 GHz
with PA 3010
agrees with the regulations of EC guidelines:
- Low Voltage Directive 2014/35/EU
- EMC Directive 2014/30/EU
- Restriction of certain Hazardous Substances 2011/65/EU / EU 2015/863
For the implementation of the requirements from the above mentioned directives, the following
applicable standards were used:
- DIN EN 61010-1:2020-03 Safety requirements for electrical equipment for measurement,
control, and laboratory use - Part 1
- DIN EN 61000-6-1:2019-11 EMC - Immunity
- DIN EN 61000-6-3:2011-09 EMC - Emission
Name of the person authorized to compile the technical le:
Gunter Langer
Bannewitz, 12.01.2021
_________________
(Signature)
G. Langer, Managing Director
PA 3010 set
- 4 / 12 -
2 General Information
2.1 Storage of the User Manual
This user manual enables the safe and efcient use of the PA 3010 set. It must be kept close at hand
and accessible to the user.
2.2 Reading and Understanding the User Manual
Read the user manual carefully, observe the safety information and follow the instructions given in
this manual before putting the device into service.
2.3 Local Safety and Accident Prevention Regulations
The local accident prevention and general safety regulations also apply to ensure that the PA 3010 set
is used for its intended purpose.
2.4 Images and Graphics
Figures have been included in this user manual to assist the reader‘s understanding but may differ
from the device‘s actual design.
2.3 Limitations of Liability
The Langer EMV-Technik GmbH can assume no liability for personal injury or damage to material,
if
- the instructions in this user manual were not followed,
- the PA 3010 set was operated by staff not qualied in the eld of EMC and who are not t to work
under the inuence of disturbance voltages and electric and magnetic elds,
- the PA 3010 set was not used as intended,
- the PA 3010 set was subjected to unauthorized modications or technical changes,
- spare parts or accessories were used, that were not authorized by Langer EMV-Technik GmbH.
2.4 Errors and Omissions
The information in this user manual has been checked very carefully and found to be correct to
the best of our knowledge; however, Langer EMV-Technik GmbH can assume no responsibility for
spelling, typographical or proofreading errors.
2.5 Copyright
The content of this user manual is protected by copyright and may only be used in connection with
the PA 3010 set. This user manual may not be used for other purposes without the prior consent of
Langer EMV-Technik GmbH.
PA 3010 set
- 5 / 12 -
Item Name of article Type Qty.
01 Preamplier 10 MHz to 10 GHz PA 3010 1
02 Power supply unit NT FRI EU or NT FRI US 1
03 System case Case A5 1
04 Quick guide 1
05 User manual 1
The scope of delivery may deviate depending on the respective order.
Figure 1 - System case of PA 3010 set
3 Scope of Delivery
PA 3010 set
- 6 / 12 -
PA3010preamplier(25°C,12V,170mA)
Frequency range 10 MHz - 10 GHz
Gain typ. 30 dB
-1 dB compression point (output) typ. 18 dBm at 5 GHz
Noise gure typ. 2.5 dB at 5 GHz
Supply voltage 12 V DC
Impedance 50 Ω
Current consumption 170 mA
Max. input power (destruction threshold) 17 dBm
Max. DC component at RF input/output 9 V
Amplitude atness ± 3 dB
Housing dimensions (height x width x depth) (50 x 38 x 14) mm
Weight 60 g
Connector - input SMA, female, jack
Connector - output SMA, male, plug
Ambient temperature (in operation) (0 - 40) °C
4.1 Connections and Dimensions
Figure 2a - Designation of connections Figure 2b - Dimensions of PA 3010 preamplier
4 Technical Parameters
PA 3010 set
- 7 / 12 -
4.2 Measurements and Characteristics
Average of 26 measurements (T=25°C, I =170 mA, U =12 V)
Freq[GHz]
(Frequency)
S21[dB]
(Gain)
S11[dB]
(Voltage standing
wave ratio)
S22[dB]
(Voltage standing
wave ratio)
NF[dB]
(Noise gure)
OP1dB
(-1 dB compression
point)
0.01 29 -3 (6.3) -8 (2.2) 8.4 -
0.1 30 -16 (1.4) -18 (1.3) 4.0 -
1 30 -15 (1.4) -20 (1.2) 3.1 19
2 29 -13 (1.6) -12 (1.7) 2.7 17
3 30 -17 (1.3) -13 (1.6) 2.1 18
4 30 -13 (1.6) -11 (1.8) 2.1 18
5 30 -9 (2.2) -10 (1.9) 2.2 18
631 -13 (1.5) -13 (1.6) 2.4 17
731 -16 (1.4) -13 (1.6) 2.5 17
8 30 -11 (1.8) -19 (1.3) 2.8 17
9 30 -13 (1.6) -12 (1.6) 3.2 16
10 27 -14 (1.5) -7 (2.6) 3.7 14
11 24 -10 (1.9) -13 (1.6) 6.2 14
Figure 3 - PA 3010 frequency range
Gain
Upper limit
Lower limit
Matches:
Input
Output
PA 3010 set
- 8 / 12 -
Figure 4 - PA 3010 -1 dB compression point
Figure 5 - PA 3010 noise gure
PA 3010 set
- 9 / 12 -
5 Safety
5.1 Intended Use
The PA 3010 is used to amplify (weak) measurement signals from connected near-eld probes in the
frequency range from 10 MHz to 10 GHz.
A near-eld probe is connected to the SMA input of the preamplier via a suitable coaxial cable with
SMA connector (male). The PA 3010 is connected to either a spectrum analyzer or an oscilloscope
via the SMA output (male).
The PA 3010 is powered by the provided power supply.
5.2 Reasonably Foreseeable Improper Use
Improper use of the PA 3010 set may put the user at risk, damage the product and/or the technical
equipment connected to the product.
Examples of improper use:
• Safety devices are bypassed or rendered ineffective.
• The PA 3010 preamplier or any connected devices are used in a defective state.
• The PA 3010 set is used outside the specied range of technical parameters.
• The eld of application is changed by modications to the design.
Claims due to the improper use of the PA 3010 set are excluded!
5.3 Staff Requirements
Only persons who are trained and qualied in the eld of electromagnetic compatibility (EMC) may
operate the PA 3010 set.
The PA 3010 set must not be operated by persons whose reactions are impaired by, for example,
alcohol, medication or drugs.
5.4 Safety Instructions
When using a product from Langer EMV-Technik GmbH, please observe the following safety
instructions to protect yourself against electric shock or the risk of injury:
• The operating and safety instructions for all devices included in the set-up must be observed.
• Before operating the product, externally inspect all equipment used in the set-up for damage.
• Damaged or defective devices must be replaced.
• All devices are to be connected or disconnected only when the source of interference is switched off.
• The product may only be operated under supervision.
• To avoid excessive heating of the preamplier, it must not be covered.
PA 3010 set
- 10 / 12 -
6 Application
6.1 Application Notes
When the PA 3010 is supplied with voltage, the LED lights up red continuously.
During normal operation, the PA 3010 heats up. This does not represent a malfunction. The housing
reaches a temperature approx. 15 °C above room temperature.
For reproducible measurement results, it is recommended to let the preamplier preheat for approx.
20 minutes.
To avoid damage to the PA 3010 preamplier, coaxial cables must be discharged shortly before
they are connected to the preamplier (due to its funtion, the input of the PA 3010 preamplier is not
secured against ESD). For this we recommend to establish a low impedance connection between
the inner and outer conductor of the coaxial cable.
6.2 General Measurement Set-up
The PA 3010 is connected via the SMA output (male) to either the 50 Ω connector of a spectrum
analyzer or an oscilloscope.
A near-eld probe is connected to the SMA input (female) of the preamplier via a coaxial cable with
the SMA male connector (plug).
The provided power supply unit is connected to the DC 12 V (power supply) connection.
Figure 6 - Measurement set-up with PA 3010, spectrum analyzer, near-eld probe and DUT
PA 3010 set
- 11 / 12 -
7 Information on Recycling and Disposal
In accordance with the WEEE Directive 2012/19/EU (Waste of Electrical and
Electronic Equipment), the following must be observed:
At the end of its service life, this product should be taken to a suitable disposal
facility for recycling and disposal. Do not dispose of with household waste.
PA 3010 set
- 12 / 12 -
8 Customer Service
Please contact us if you have any questions, comments or suggestions.
Contact us at:
Langer EMV-Technik GmbH
Rosentitzer Straße 73
01728 Bannewitz
Germany
Internet: https://www.langer-emv.com
E-mail: sales@langer-emv.de
You can reach us: Monday - Friday 8:00 am to 4:00 pm (CET)
Phone: +49 (0) 351-430093-0
Fax: +49 (0) 351-430093-22
9 Warranty
Langer EMV-Technik GmbH will remedy any fault due to defective material or defective manufacture
during the statutory warranty period either by repair or by delivery of spare parts.
This warranty is only granted on condition that:
- the information and instructions in the user manual have been observed.
The warranty will be forfeited if:
- an unauthorized repair is performed on the product,
- the product is modied,
- the product is not used for its intended purpose,
- the product is opened.
This document may not be copied, reproduced or electronically processed, either in its entirety or in part, without the
prior written permission of Langer EMV-Technik GmbH. The management of Langer EMV-Technik GmbH assumes
no liability for damage that may arise from using this printed information.
