Lanoptik CE210T User manual

HDMI Microscope
User’s Manual
www.lanoptik.com
CE210T

Content
www.lanoptik.com
CHAPTER 1 NOTES AND SAFETY REQUIREMENTS
1.1 CAUTIONS AND NOTES
CHAPTER 2 PACKING LIST
CHAPTER 3 FUNCTION INTRODUCTION OF EACH PART
CHAPTER 4 INSTALLATION GUIDE
CHAPTER 5 INSTRUCTIONS
5.1 INTRODUCTION OF VARIOUS FUNCTIONS
5.1.1 Photography
CHAPTER 6 DISCLAIMER
- 1 -
- 1 -
- 2 -
- 3 -
- 4 -
4.1 NAME AND FUNCTION FOR EACH PART OF THE CAMERA - 4 -
- 5 -
- 5 -
- 5 -
5.1.2 Record - 5 -
- 8 -
3.1 NAME AND FUNCTION FOR EACH PART OF THE CAMERA - 3 -
3.2 ACCESSORY - 4 -
5.1.3 Playback - 5 -
5.1.4 Frozen - 6 -
5.1.5 Menu Setup - 6 -
5.1.6 Exposure Setup - 6 -
5.1.7 White Balance Adjustment - 6 -
5.1.8 Crosshair mark - 7 -

To avoid danger or damage incurred to the lens, do not touch the lens or sensor directly with your
fingers.
Chapter 1 Notes and Safety Requirements
1.1 Cautions and Notes
User's Manual | CE210T HDMI Microscope
To avoid failure or electric shock hazard and so on, do not disassemble or modify the internal
structure of the device.
Do not plug in or unplug the Power connection port when hands are wet.
Do not use alcohol and other organic solvents to clean.
If the lens or sensor is dirty or damp, you should better use dry and non-linen fabric or professional
lens tissue to wipe them. To avoid scratches on the surface, do not touch the lens with your fingers.
Wipe the lens or sensor lightly.
The products are not specifically designed for an outdoor use. Do not expose it to outdoor
environment without any protection. Excessive temperature and humidity will damage the lens.
Please avoid using the product under the following environment: high temperature or high humidity
environment, places with direct sunlight, dirt or vibration and places near heat source.
Please use and store in the following environment:
Operating temperature ： 0℃~ 40℃
Storage temperature ： -20℃~ 60℃
Operating Humidity ： 30~60%RH
Storage Humidity ： 10~80%RH
If any foreign matter, water or liquid enter into the device by accident, disconnect the Power line
immediately. Please send it to the maintenance center and do not use the hair dryer to dry it by
yourself.
To prevent microscope from being tripped over or dropped, please put away the device’s connect
cable in use or standby.
To avoid electric shock by accident, please power off microscope before you move your computer or
laptop.
The cleanliness of the device lens will directly affect clarity degree of contents from the computer
screen during preview. Problems like various circles or spots on the screen may mostly be incurred
by dirt on the lens. When cleaning, please use professional lens tissue or other professional detergent
to clear the dirt on the lens.
Registered trademark and copyright: Copyright ownership of this produc belongs to Lanoptik
Technologies Ltd. Without written authorization of this company, any organizations or individuals
shall not photocopy, print, or translation to another language to any part of this document.
www.lanoptik.com
- 1 -

Chapter 2 Packing List
User's Manual | CE210T HDMI Microscope
www.lanoptik.com
- 2 -
Adapter
HDMI Microscope
Screwdriver
USB cable
Screw
HDMI cable
Quick installation guide Wired controller

User's Manual | CE210T HDMI Microscope
Chapter 3 Function Introduction of Each Part
3.1 Name and Function for Each Part of Microscope
Left button: Menu/return/frozen (hot key) function. “Menu” function will be activated in the mode of
photographing, playing back and recording. In the mode of photographing and recording, long press (2
seconds) will trigger “frozen” function. After entering the menu, “return” function will be on.
Bottom button: Zoom out/downward/video fast forward function. “Reduction” function is on in the mode
of photographing and recording. “Downward” function is on after entering the menu or in the mode of
playing back. Video playing will be changed into “fast rewind” function in the mode of playing back.
Top button: Zoom in/upward/speed retreat function. “Magnification” function will be activated in the
mode of photographing and recording.“Upward” function be activated after entering the menu or during
browsing. Video playing will be changed into “fast rewind” function in the mode of playing back.
Middle button: Record/camera/play back function. “Recording” function is for the mode of recording.
“photographing” function is for the mode of photographing. In the mode of playing back, the recording
file carries the function of “playing back”.
Right button: Mode/sure/crosshair (hot key) function. Mode includes “camera”, “play back” and “record”.
Without entering the menu, “Mode switch” function will be activated and can be switched successively
among three modes, namely photographing, playing back and recording. “Confirm” function will be on
after entering the menu. Long press in the mode of photographing and recording activates the mode of
“cross line” shortcut key.
1. HDMI port : Connect to the display with HDMI to realize signal transmission.
2. USB port : Connect to the adapter with USB to supply power for HDMI microscope.
3. Push-button : 5 buttons can match to each other to achieve different functions.
4. Camera Switch : Put the switch to right: turn on the camera; put the switch to left: turn off the camera.
5. Focus knob : Rotate the knob to implement the focus function; Rotate clockwise: back focal length decreases and
object distance increases; Rotate anticlockwise: back focal length increases and object distance
decreases.
6. TF card slot : The location of TF card, photos and videos will be stored in TF card.
7. LED light : The coaxial light and the diffuse reflection coexist, and the two effect lights are respectively
controllable; the coaxial light lamp adopts a circular distribution of 13 light beads at a small angle;
the diffuse reflection light is distributed by 18 high brightness light beads, and the brightness is
uniform.
8. Bottom plate : Aluminium alloy bottom plate.
9. Mobile Knob : loosen the knob anticlockwise and the stand will be adjusted in any degree; tighten the knob
clockwise and the current position of the electronic eyepiece can be fixed.
10. Stand : Can rotate by 360 degree.
11. Adjustment knob
of the coaxial light
: Rotate Clockwise: turn on the coaxial light/strengthen coaxial lightness; rotate counterclockwise:
REDUCE the coaxial lightness/turn off the coaxial light.
12. Adjustment knob
of the diffuse light
: Rotate Clockwise: turn on the diffuse reflected light/strengthen the diffuse reflected lightness;
rotate counterclockwise: weaken the diffuse reflected lightness/turn off the diffuse reflected light.
www.lanoptik.com
- 3 -

User's Manual | CE210T HDMI Microscope
www.lanoptik.com
- 4 -
3.2 Accessory
The HDMI microscope can be powered by connecting to the adapter.
USB Cable
Connecting the electron microscope to the display can realize signal
HDMI Cable
Chapter 4 Installation Guide
4.1 Name and Function for Each Part of Microscope
PC connection: Use the USB cable to connect microscope and computer.
4.1.1 Connection Methods:
HDMI connection:
1) As shown in Figure 1, use the HDMI cable to connect microscope and monitor, and use the screws
to lock the microscope and HDMI cable.
2) As shown in Figure 2, use the USB plug to power the microscope.
4.1.2 Start to use:
1) Turn on the camera; 2) Adjust the camera position; 3) Adjust the focal length

Chapter 5 Instructions
5.1 Introduction of Various Functions
The machine contains altogether 5 press buttons. For press button instruction, please refer to chapter
4-1. Besides, the machine can also connect a wired controller with 5 press buttons via a connection
device.
Short press refers to press time 0.2s~1s. Long press refers to press time more than 2s or above.
(Without special reference, press below all means short press).
For 10 seconds without operation, the system will automatically hide the icon on the screen desk for
users to watch the video more conveniently .The icon on the desk can be awakened by pressing the left
button and the other 4 buttons will execute the command of the current press button while been
awakened. (Users can press arbitrary button to awake the desk icon).
The maximum magnification ratio of the zoom in function button: x4. Zoom out function button can
only be available when being zoomed in first.
The highest resolution pixel of photography is 1920x1080.
Shutdown save parameter: Each time the camera eyepiece is started, the current parameter is the
parameter of the last shutdown. When you initialize the parameter, you can restore the factory settings
by using the"Restore defaults" in the menu.
User's Manual | CE210T HDMI Microscope
www.lanoptik.com
- 5 -
5.1.1 Photography
The top right corner icon displays for photography mode. Please ensure the TF card insertion, press
“middle button” for picture shooting. Pictures will be automatically saved into the Photo file under TF card
file Microscope. File name format: "Photo_00001.jpg" ， "Photo_00002.jpg", …
5.1.2 Record
The icon on the top right corner of the screen displays for recording mode to record sound and video
files.Please ensure the TF card insertion, press“middle button”for recording and press“middle button”again
to exit recording. Records will be automatically saved into the Video file under TF card file Microscope. File
name format "Video_0001.mov" ， "Video_0002. mov "…
Note: The maximum capacity of recording file is 4G. When 4G capacity is reached, a new recording file will be started.
5.1.3 Playback
“Photo_xxxx.JPG” on the top right corner means the picture is an photo.
“Video_xxx.MOV” on the top right corner means the picture is a video. Press “Middle button” to play/pause
recording. Press “Top Button” or “Bottom button” can fast forward or fast backward during playing.
pressing "Right button" exit playing.
The top right corner icon displays for Playback mode. Flip over for observation by pressing “Top Button”or
“Bottom button”. Pressing button “Left button” can enter the file attributes interface, which includes three
operation functions such as delete, protect and slide show.

User's Manual | CE210T HDMI Microscope
www.lanoptik.com
- 6 -
5.1.4 Frozen
Under the mode of camera or recording, long press “left button” and the right side of the desk will display
the icon , which is the frozen screen. You can long press “the left button” or short press any button to
defrost the screen and the icon disappears. Each button's function is performed after unfreeze.
5.1.5 Menu Setup
Pressing “Left Button” to enter the menu bar interface. Through button “Top Button” and “Bottom Button” to
move the cursor up and down for selecting the required function. Press “Right Button” to enter into setup.
After setup, press “Left Button” to exit menu bar.
Note: common functions are set up on the menu bar, namely exposure compensation, white balancing, 3 sequence, image
quality, HDR, resolution ,sharpness, shooting ways, color, quick preview, button press sound, auto power off, language,
frequency, image rotation, frozen and date/time.
5.1.6 Exposure Setup
Under the mode of camera or recording, press the “left button” to enter the menu bar. Press the “top button”
or the “bottom button” to select the menu bar “Exposure EV” and then press the “right button” to enter the
exposure setup interface.
Then the screen shows the icon . (Note: font flashes: stands for the cursor is located in current position.
Red font: stands for the status of been selected. )
Press the “top button” or “bottom button” to move the cursor. Press the “right button” to select the current
status and the font color will turn red. Press the “left button” to exit the exposure setup interface.
The cursor points to A, the real-time automatic exposure function will be started by pressing the “right
button” and the color of the letter A will turn red.
The cursor points to S, the single real-time automatic exposure function will be started by pressing the “right
button” and the color of the letter S will turn red.
The cursor points to M, the manual exposure can be started by pressing the “right button” and the color of
the letter M will turn red and a flashing red number 0 will also appear on the right side. Press the “top button”
or “bottom button” to change the current number value (the valid adjustment range is -10~+10 and the
default value is 0). Press the “right button” to save the number value and the number value will be covered
simultaneously.
5.1.7 White Balance Adjustment
Under the mode of camera or recording, press the “left button” to enter the menu bar. Press the “top button”
or the “bottom button” to select the menu bar “white balance WB” and then press the “right button” to enter
the interface of the white balance setup.
Now the screen will display the icon . (Note: font flashes: stands for the cursor is located in current
position. Red font: stands for the status of been selected. )
Press the “top button” or the “bottom button” to move the cursor. Press the “right button” to select the
current status and the font color will turn red. Press the “left button” to exit the White balance setup
interface

User's Manual | CE210T HDMI Microscope
www.lanoptik.com
- 7 -
The cursor points to A, the real-time automatic white balance function will be started by pressing the “right
button” and the color of the letter A will turn red.
The cursor points to S, the single automatic white balance function will be started by pressing the “right
button” and the color of the letter S will turn red.
The cursor points to M, the manual white balance can be started by pressing the “right button” and the color
of the letter M will turn red and a group of value (R128, G128, B128) will also appear on the right side. The
flashing red number is the value currently been selected. Press the “top button” or “bottom button” to change
the current number value (the valid adjustment range is 1-255). Press the “right button” to switch the value R,
G and B consequently.
Whichever value letter (R/G/B) is selected, as long as the “left button” is pressed, RGB current number value
will be saved and altogether RGB and the number value will be covered.
Note: From automatic white balance to manual white balance: the value of manual white balance is the white balance under
the current background. From single automatic white balance to manual white balance: the value of manual white balance is
the previous single automatic white balance.
5.1.8 Crosshair Mark
Under the mode of camera or recording, long press the “right button” to recall the crosshair mark and then
long press the “right button” to cancel the crosshair mark. The default cross line invoked by shortcut key is
the first kind. If either of the other two shortcut keys of the cross line is needed, other cross lines will be
firstly invoked via menu and current cross line is controlled by shortcut key. There are three kinds of
crosshair marks (“crosshair mark” menu can be found in the menu bar):
Cross (default)
Grid
Concentric Circles

Please do not use wet hands to plug and unplug the power supply of the equipment.
Please be sure to use a regular brand power socket, and make sure the grounding is well grounded to
prevent electric shock.
Please be sure to make regular safety checks on sockets and plugs to avoid potential electrical
safety hazards caused by aging and short circuit.
Please be sure not to use the product in a humid or hot environment to ensure the safety of the
product.
Please be sure to loosen bundle cords of the power cable before using, to avoid electromagnetic
induction and heating, thus increasing the heat dissipation speed.
Please be sure not to use the product equipment or socket or other places in high or easy to fall, so
as to avoid damage.
Before opening the socket power supply, please be sure to turn off the load power switch of the
product equipment.
The company reserves the rights to improve product, upgrade technology and change parameters
without prior notice.
1. In order to protect the legitimate rights and interests of users, please carefully read the
instructions, disclaimers and safety instructions provided with this product before using it. The company
reserves the right to update the above documents. Please operate the product
according to the instructions and safety instructions.
2. Once you begin to use the product, you shall be deemed to have read, understood,
recognized and accepted all terms and contents of the product's instructions, disclaimers and
safety instructions. Users undertake to be responsible for their actions and all consequences.
User undertakes to use the product only for legitimate purposes and agrees to these terms and
any relevant policies or guidelines that the company may establish.
3. In the process of using this product, please strictly abide by and execute the requirements
including but not limited to the instructions and safety instructions. All personal injuries,
accidents, property losses, legal disputes and other adverse events that cause conflicts of
interest caused by violation of the safety instructions or irresistible factors shall be borne by
users themselves, and the company shall not assume any responsibility.
4. Safety instructions:
Chapter 7 Disclaimer
User's Manual | CE210T HDMI Microscope
www.lanoptik.com
- 8 -

LANOPTIK TECHNOLOGIES LTD
No. 72 Hongjing Street, Lejia Road, Baiyun District, Guangzhou, China. 510400
Phone: [phone] | Fax: [phone]
Website: http://www.lanoptik.com | Email: [e-mail]
Specifications are subject to change without any obligation on the part of the manufacturer.
