Lanta Quasar Sapphire Twinkle User guide

Owner Handbook
Quasar Sapphire Twinkle™
450mW Blue Laser Net

© Lanta Lighting™ 2011. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Quasar Sapphire Twinkle™
For your Safety
• Follow all instructions to maintain Manufacturer Warranty and for your own safety.
• There are no user replacement parts inside the product. Do not open the product for
any reason. This will invalidate your Manufacturer Warranty and may impair the safety
features of the product.
• Do not expose this product to moisture, rain or other fluids.
• Do not use this product near water or other fluids.
• Do not use if the product if you suspect it has been damaged in any way, including
being dropped, is malfunctioning, or has been exposed to liquids or moisture. The unit
must be repaired by an authorised service centre only. Manufacturer Warranty is void
if unit is opened or adapted in any way. Operator safety may be compromised if this
product is not operated and maintained in accordance with the details contained in
this Owner Handbook.
• This appliance must be earthed. Do not remove the earth connection in the plug or
any other location - it is essential for user safety.
• Be aware that products are mains powered and may be capable of producing high
voltages from its outputs and has mains voltages inside the cabinet.
Product Installation, Use & Maintenance
• Keep this Owner Handbook safe for future reference.
• Clean the product with a clean and dry, non-abrasive cloth. Do not use solvents or
liquids to clean the product.
• To prevent overheating, do not obstruct any ventilation opening, fan cover or vent. Do
not install near any sources of heat such as radiators, heaters, other heat producing
items such as amplifiers, power units etc.
• Power connection to the product is via a UK 240 Volt AC three-pin mains plug. Do not
remove or adapt this plug. If necessary, only replace the plug top fuse with one of the
same type, size and value.
• The mains lead must not be crushed or damaged. If any damage occurs, disconnect
from the mains immediately. Replace the damaged cable, or if the mains lead is
captive, return the product to an authorised repair centre for cable replacement.
Do not attempt to repair the cable - it must be discarded and destroyed.
• To maintain the Manufacturer Warranty, only attach authorised accessories and
external devices. This includes cables, connectors and other electrical and/or
mechanical devices.
• Unplug the product from the mains during lightning storms or periods of mains
fluctuations. If the product is going to be unused for long periods, unplug from
the mains.

© Lanta Lighting™ 2011. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Quasar Sapphire Twinkle™
Product Quality & Compliance
Products from Lanta Lighting meet all required safety standards in force at the time of
manufacture and are fully compliant with them.
Unpacking & Inspection
• Inspect the packaging before opening. If the packaging appears to have sustained
significant damage, please take extra care before using the product. If you are in any
doubt, consult a suitably qualified professional.
• If you suspect the product has been damaged, do not use it. Return it to your original
supplier without delay.
• Keep all packaging in a safe place for storage or transport in future.
Manufacturer Warranty
• This Manufacturer Warranty is valid in the UK only.
• Lanta Lighting warrants that this product is free from workmanship defects and material
failure during normal use and operation for a period of 12 months from first use or from
original date of sale (whichever is the earliest) providing all of the terms indicated in the
warranty section have been fully complied with.
• Expressly excluded is our liability for any directly connected or indirectly connected
item or items or any consequential loss associated with the failure of the product
howsoever caused.
• If the product has been opened, modified, tampered with, incorrectly connected,
used inappropriately or in conflict with the instructions herein, or the product model
or serial number has been damaged, removed, tampered with, obliterated or made
partly unreadable by any person or persons, the Manufacturer Warranty is irrevocably
null and void.
• No extension, adaption, alteration or modification to the terms of this Manufacturer
Warranty will be permitted, unless expressly authorised in writing (excluding
email and fax) by a Director of Lanta Lighting. Warranty is transferrable during the
Warranty period.
For Further Information about Lanta Lighting
Our website can be found at www.lantalighting.com and is available for the benefit
of customers worldwide. Please consult for information, advice and support on this and
other high quality products from Lanta.

© Lanta Lighting™ 2011. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Quasar Sapphire Twinkle™
About Lanta Lighting™
Based in the UK, Lanta are committed to providing high quality products at cost-effective
prices to the professional lighting market. Since the first product was launched in 2006,
Lanta has established a reputation for reliability, common sense design and customer
support that has become the envy of others. All Lanta products are specifically designed
for UK operation and are optimized for 240VAC 50Hz UK mains power.
The Lanta Lighting range includes:-
Professional Lighting
Focussing on the use of LED technology, Lanta offer distinctive lighting effects for install
and mobile applications. From washes to floods, spots to projectors, LED technology now
outperforms traditional lights while at the same time requiring significantly lower power
and generating far less unwanted heat.
Performance Lasers
Recent advances have reduced the costs of Lasers, made them more portable and
brought improved performance and reliability. With step and animation lasers in multi
and single colour formats for mobile DJs and static installs, Lanta promise Lasers that
won’t burn a hole in your pocket.
Atmospheric Effects
When you need special atmospherics effects, Lanta have everything from bubble
machines to fake flame, hazers and foggers. There’s also a range of fluids and
consumables specially designed to get the best from the range.
Control Gear
Lightweight and portable, Lanta Control Gear is robust enough to survive life on the road
and smart enough to control DMX kit whatever the venue.
Visit us at www.lantalighting.com for more details.

© Lanta Lighting™ 2011. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Quasar Sapphire Twinkle™
Features of the Lanta Quasar Sapphire Twinkle™
Laser Power 450mW Blue Diode
Deflection Angle ±45°
DMX Control 6 Channel DMX control
Control Connectors 3 Pin Female XLR socket
3 pin Male XLR socket
Power Requirement 240V AC 50/60Hz
Dimensions (W x D x H) 153mm x 201mm x 86mm
Weight 1.3Kg
I
0
OFF ON
ON DIP
12 3 4 5 6 7 8 9 10
Rear Panel

© Lanta Lighting™ 2011. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Quasar Sapphire Twinkle™
1. AUTO Mode
To use the Auto mode – a selection of exciting and vibrant blue colour effects, push
Dipswitch 1 & 10 into the up position
2. DMX Mode
It is possible to operate the Lanta Quasar Sapphire Twinkle™ from a remote location by
using either a DMX controller or a PC or laptop with a DMX interface. Lanta products
use a 3 pin XLR style connector and usually have an input and output DMX connector.
This allows multiple lighting products to be “daisy-chained” together to build a display
controlled by just one cable back to the DMX controller.
Choosing DMX Control Mode
Ensure that Dip Switch 10 is set to the “down” position to activate DMX Control Mode.
Setting the DMX Addresses
Dip Switches 1-9 on the Rear Panel set the DMX Address of the unit. The unit uses binary
format, allowing values from 1 to 511 to be set. Dip Switch 1 represents “1”; Dip Switch
2 represents “2”; Dip Switch 3 represents “4”; Dip Switch 4 represents “8”; Dip Switch 5
represents “16”; Dip Switch 6 represents “32”; Dip Switch 7 represents “64”; Dip Switch 8
represents “128” and Dip Switch 9 represents “256”.
Ch1 Ch2 Ch3 Ch4 Ch5 Ch6
Master
Dimming
Rotate Speed Not Used Strobe Dots, Lines &
Star Effects
0-64 Off Left Slowest Slowest
65-129 Sound
Mode
130-191 Auto
Mode
192-255 Control
Mode Right Fastest Fastest

© Lanta Lighting™ 2011. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Quasar Sapphire Twinkle™
3. SOUND Mode
The unit responds to sounds picked up by the in-built mic. Each sound steps the Effect
to the next in the sequence. To select Sound Activated Mode Dip Switch 10 needs to be
pushed to the up position.
4. MASTER /SLAVE Mode
This is a great way of making two or more Lanta Quasar Sapphire Twinkle™ units do the
same things at the same time, without the need for a DMX controller. The Lanta Quasar
Sapphire Twinkle™ has a DMX controller of its own, built inside and when a second
Lanta Quasar Sapphire Twinkle™ (set as SLAVE) is connected to a Lanta Quasar Sapphire
Twinkle™ (set as MASTER) the SLAVE will follow all of the activity of the MASTER.
It is possible to run 9 units on a master/ slave function, 1 unit as the master, 8 units as the
slaves. To set the first slave unit must push Dipswitch 2 & 10 into the “ON” position. To set a
second unit on slave you must push Dipswitch 3 & 10 into the “ON” position. Continue this
process until you reach the maximum allowance of 8 units ( 9 & 10 in the “ON” position)
