Lanzar VIBE226 User manual

Viberant Owner’s Manual- 1
12
3
765
Congratulations on your purchase of a Lanzar Viberant amplifier. You have purchased a quality product designed
and engineered to give you many years of uncompromised musical service. VIBE amplifiers are designed with
the latest technology available, which provides headroom for even the most demanding peaks and dynamic ranges
found on modern CD's and recordings.
TABLE OF CONTENTS
System Wiring
6. 2 channel stereo
7. 2 channel bridged mode
8. 2 channel tri-mode
9. 2 channel triamp system
10. 4 channel stereo
11. 4 channel bridged mode
12. 4 channel tri-mode
13. Precautions
14.Troubleshooting
15.Notes
1. INPUT LEVEL CONTROLS
Enables the matching of input levels to the output levels from
head unit (or other signal source).
2. CROSSOVER MODE SELECTOR
Determines the mode of built-in crossover:
low pass (permits only low frequency signals to pass to speakers),
high pass (permits only high frequency signals to pass to speakers),
or flat.
3. BASS BOOST CONTROL
With a bass boost switch engaged, the bass level is increased
approx 18dB.
4. REMOTE BASS BOOST
Plug in the remote bass boost control wire in here
5. POWER & PROTECTION INDICATORS
Provide instant information on status of amplifier, including
short-circuit and thermal overload alerts.
6. HIGH PASS FILTER (HPF)
When Crossover Mode Selector is in High Pass Mode, this control
limits the frequencies which will be distributed to the speakers
to those below the value to which this is set within the range 80-
2.5KHz.
7. LOW PASS FILTER (LPF)
When Crossover Mode Selector is in Low Pass Mode, this control
limits the frequencies which will be distributed to the speakers
to those below the value to which this is set within the range 35-
400Hz.
Table of Contents
Feature and Controls
1. VIBE 226/236/246/256/266/276/286
2. VIBE 416/426/436
3. Installation
4. Specifications
Features and Control
s
Viberant Owner’s Manual
VIBE 226/236/246/256/266/276/28
6
4

Viberant Owner’s Manual- 3
1. REMOTE BASS BOOST
Plug in the remote bass boost control wire in here
2. INPUT LEVEL CONTROLS
Enables the matching of input levels to the output levels from
head unit (or other signal source).
3. CROSSOVER MODE SELECTOR
Determines the mode of built-in crossover:
low pass (permits only low frequency signals to pass to speakers),
high pass (permits only high frequency signals to pass to speakers),
or flat.
4. BASS BOOST CONTROL
With a bass boost switch engaged, the bass level is increased
approx 18dB.
5. POWER & PROTECTION INDICATORS
Provide instant information on status of amplifier, including
short-circuit and thermal overload alerts.
6. HIGH PASS FILTER (HPF)
When Crossover Mode Selector is in High Pass Mode, this control
limits the frequencies which will be distributed to the speakers
to those below the value to which this is set within the range 80-
2.5KHz.
7. LOW PASS FILTER (LPF)
When Crossover Mode Selector is in Low Pass Mode, this control
limits the frequencies which will be distributed to the speakers
to those below the value to which this is set within the range 35-
400 Hz.
1. Find a suitable location in the vehicle to mount the amplifier.
2. Make sure there is sufficient air flow around the intended mounting location.
3. Bolt the amplifier to the mounting surface.
4. Connect the power ground terminal to the nearest point on the chassis of the car. Keep this ground wire less than one meter (39")
in length. Use 8 gauge wire.
5. Connect the remote terminal to the remote output of the head unit using 14 gauge wire.
6. Connect an empty fuse holder within 300mm (12") of the battery and run 8 gauge of larger high quality cable from this fuse to the
amplifier location.
7. Make sure there is no fuse in this fuse holder. Then make the connection to the "BATT" connection on the amplifier.
8. If multiple amplifiers are being used, use cables (each with its own fuse at the battery) or a #0 or #2 cable from the fuse holder at
the battery to a distribution block at or near the amplifier's location.
9. Connect all line inputs and outputs using high-quality RCA-RCA cables.
10. Insert fuse(s) at the battery fuse holder(s).
11. Recheck all connections before powering up.
12. Set all level controls to their least sensitive positions and set all crossover controls, switches, etc. to the desired frequency or
position.
13. Once the system is powered up, set the volume control on the head unit to about the 2 o'clock position, and then set all the
amplifiers' level controls for maximum output level.
14. Further fine tuning of the various controls may be necessary to obtain the desired results.
Viberant Owner’s Manual2 -
Features and Controls Installatio
n
VIBE 416/426/436
5 234762 3 476
1

Viberant Owner’s Manual4 -
Specifications
Viberant Owner’s Manual- 5
Specification
s
2 channel
amplifier
VIBE 266
2 x 150W
2 x 1000W
1 x 2000W
2 x 230W
2 ohm
0.04%
15Hz-35KHz, -1dB
250mV-5000mV
22 Kohm
>90dB
>65dB
35Hz-400Hz
80Hz-2.50KHz
+18dB
11.06"x2.24"x17"
20Ax2
VIBE 226
2 x 50W
2 x 400W
1 x 800W
2 x 80W
2 ohm
0.04%
15Hz-35KHz, -1dB
250mV-5000mV
22 Kohm
>90dB
>65dB
35Hz-400Hz
80Hz-2.50KHz
+18dB
11.06"x2.24"x9.25"
15A
MODEL
RMS at 4 Ohms
MAX at 4 Ohms
At 4 Ohms Bridged
RMS at 2 Ohms
Min. Speaker Impedance
T.H.D.
Frequency Response
Input Sensitivity
Input Impedance
S/N Ratio
Channel Separation
Crossover Filters
Low Pass
High Pass
Bass Boost
Dimensions (WxHxL)
Fuse(s)
2 channel
amplifier 2 channel amplifier 2 channel amplifier 2 channel amplifier
VIBE 276 VIBE 286 VIBE 416 VIBE426 VIBE436
2 x 200W 2 x 300W 4 x 35W 4 x 50W 4 x 75W
2 x 1200W 2 x 2000W 4 x 250W 4 x 400W 4 x 500W
1 x 2400W 1 x 4000W 2 x 500W 2 x 800W 2 x 1000W
2 x 300W 2 x 450W 4 x 55W 4 x 80W 4 x 120W
2 ohm 2 ohm 2 ohm 2 ohm 2 ohm
0.04% 0.04% 0.04% 0.04% 0.04%
15Hz-35KHz, -1dB 15Hz-35KHz, -1dB 15Hz-35KHz, -1dB 15Hz-35KHz, -1dB 15Hz-35KHz, -1dB
250mV-5000mV 250mV-5000mV 250mV-5000mV 250mV-5000mV 250mV-5000mV
22 Kohm 22 Kohm 22 Kohm 22 Kohm 22Kohm
>90dB >90dB >90dB >90dB >90dB
>65dB >65dB >65dB >65dB >65dB
35Hz-400Hz 35Hz-400Hz 35Hz-400Hz 35Hz-400Hz 35Hz-400Hz
80Hz-2.50KHz 80Hz-2.50KHz 80Hz-2.50KHz 80Hz-2.50KHz 80Hz-2.50KHz
+18dB +18dB +18dB +18dB +18dB
11.06"x2.24"x19" 11.06"x2.24"x21" 11.06"x2.24"x12" 11.06"x2.24"x15" 11.06"x2.24"x17"
25Ax2 35Ax2 20A 30A 20Ax2
2 channel
amplifier 4 channel amplifier 4 channel amplifier 4 channel amplifier
2 channel
amplifier
VIBE 236
2 x 75W
2 x 500W
1 x 1000W
2 x 100W
2 ohm
0.04%
15Hz-35KHz, -1dB
250mV-5000mV
22 Kohm
>90dB
>65dB
35Hz-400Hz
80Hz-2.50KHz
+18dB
11.06"x2.24"x12"
20A
VIBE 246
2 x 100W
2 x 600W
1 x 1200W
2 x 130W
2 ohm
0.04%
15Hz-35KHz, -1dB
250mV-5000mV
22 Kohm
>90dB
>65dB
35Hz-400Hz
80Hz-2.50KHz
+18dB
11.06"x2.24"x13.5"
30A
VIBE 256
2 x 125W
2 x 800W
1 x 1600W
2 x 200W
2 ohm
0.04%
15Hz-35KHz, -1dB
250mV-5000mV
22 Kohm
>90dB
>65dB
35Hz-400Hz
80Hz-2.50KHz
+18dB
11.06"x2.24"x15"
30A

Viberant Owner’s Manual- 7
VIBE 226/236/246/256/266/276/286VIBE 226/236/246/256/266/276/286
head unit
To a second amplifier
Y Adaptors
head unit
L/R Audio
Outputs
FRONT
REAR
2 CHANNEL STEREO CONFIGURATION
FRONT
REAR
2 CHANNEL BRIDGED MODE CONFIGURATIO
N
To Remote Output
From Head Unit
To Battery
SPEAKER
IMPEDANCE
4 OHMS!
Viberant Owner’s Manual6 -
System Wiring System Wirin
g
LEFT speaker RIGHT speaker
To Remote Output
From Head Unit
To Battery
SPEAKER
IMPEDANCE
4 OHMS!
speaker

Viberant Owner’s Manual- 9
TO REMOTE OUT
PUT
FROM HEAD UN
IT
TO BATTERY
RL
TWEETER
SPEAKER IMPEDANCE
2-4 OHMS
TO REMOTE OUT
PUT
FROM HEAD UN
IT
TO BATTERY
RL
FULL
SPEAKER IMPEDANCE
2-4 OHMS
VIBE 226/236/246/256/266/276/286
2 CHANNEL TRI-MODE CONFIGURATION
FRONT
REAR
TRIAMP SYSTEM USING THREE 2 CHANNEL AMPLIFIER
S
Master Amp Front (Woofers) Master Amp Rear
Slave Amp #1 Front (Mids) Slave Amp #1 Rear
Slave Amp #2 Front (Tweeters) Slave Amp #2 Rear
Switch in
High Pass Position
Switch in
Full Position
Switch in
Low Pass Position
FROM HEAD UNIT
TO OUTPUT
YADAPTOR
TO REMOTE OUT
PUT
FROM HEAD UN
IT
TO BATTERY
RL
WOOFERS
SPEAKER IMPEDANCE
2-4 OHMS
head unit
VIBE 226/236/246/256/266/276/286
Viberant Owner’s Manual8 -
System Wiring System Wirin
g
To Remote Output
From Head Unit
To Battery
LEFT
speaker
Speaker
SPEAKER
IMPEDANCE
4-8 OHMS!
RIGHT
speaker

Viberant Owner’s Manual10-
System Wiring
Viberant Owner’s Manual-11
System Wirin
g
To Remote Output
From Head Unit
To Battery
To Remote Output
From Head Unit
To Battery
CH4
CH1
CH2
CH3
FRONT
REAR
4 CHANNEL BRIDGED MODE CONFIGURATIO
N
VIBE 416/426/436
head unit
SPEAKER
IMPEDANCE
4 - 8 OHMS
L
R
4 CHANNEL STEREO CONFIGURATION VIBE 416/426/436
FRONT
REAR
head unit
YADAPTOR
YADAPTOR
SPEAKER
IMPEDANCE
2-
4 OHMS
RIGHT speakerLEFT speaker

Viberant Owner’s Manual12-
System Wiring
Viberant Owner’s Manual-13
Precaution
s
VIBE 416/426/436
4 CHANNEL TRI-MODE CONFIGURATION
FRONT
REAR
To Remote Output
From Head Unit
To Battery
SPEAKER
IMPEDANCE
4 - 8 OHMS
YADAPTOR YADAPTOR
TO OUTPUTFROM HEAD UNIT
CH1/2
L
R
R
L
CH3/4
• Before you drill or cut any holes, investigate your car's layout very carefully. Take care when your work near the gas tank, fuel lines, hydraulic
lines and electrical wiring.
• Do not operate the amplifier when it is unmounted. Attach all audio system components securely within the automobile to prevent damage,
especially in an accident.
• Do not mount this amplifier so that the wire connection, or likely to be damaged by nearby objects. Be sure to select a location inside your
vehicle which has adequate ventilation.
• Before making or breaking power connections in your system, disconnect the vehicle battery. Confirm that your head unit or other equipment
is turned off while connecting the input jacks and speaker terminals.
• If you need to replace the power fuse, only replace it with a fuse indentical to that supplied with the system. Using a fuse of a different
type or rating may result in damage to your system which isn't covered by the manufacturer's warranty.
Amplifier Will Not Power Up.
• Check for good ground connection.
• Check that remote DC terminal has at least 12V DC.
• Check that there is battery power on the "+" terminal.
• Check all fuses.
• Check that Protection LED is not lit. If it is lit, shut off amplifier briefly and then repower it.

Viberant Owner’s Manual-15
Note
s
Viberant Owner’s Manual14-
Troubleshooting
STOP
YES! NO!
2-channel Amplifier
(Operating in Stereo)
4 ohm
4 ohm
Two 4-ohm speakers, wired in stereo,
will present a 4-ohm load to each
channel of the amplifier. Most two-
channel amplifiers will work well in this
configuration.
Two 4-ohm speakers, wired in parallel
to a bridged two-channel amplifier.
will present a 2-ohm mono load to the
amplifier. MOST TWO-CHANNEL
AMPLIFIERS DO NOT SUPPORT 2-OHM
MONO OPERATION! AMPLIFIER DAMAGE
COULD RESULT!
sound around, Inc.
1600 63rd street. brooklyn. ny 11204
4 ohm
4 ohm
2-channel Amplifier
(Operating in
Bridged Mono)
STOP
YES! NO!
Four 4-ohm speakers, wired in stereo,
will present a 4-ohm load to each
channel of the amplifier. Most four-
channel amplifiers will work well in this
configuration.
Four 4-ohm speakers, wired in parallel
to a bridged four-channel amplifier,
will present a 4-ohm mono load to the
amplifier. MOST FOUR-CHANNEL
AMPLIFIERS DO NOT SUPPORT 2-OHM
MONO OPERATION! AMPLIFIER DAMAGE
COULD RESULT!
4-channel Amplifier
(Operating in
Bridged Mono)
4 ohm
4 ohm
4 ohm
4 ohm
4-channel Amplifier
(Operating in Stereo)
4 ohm
4 ohm
4 ohm
4 ohm
High Hiss Or Engine Noise (Alternator Whine) In Speakers.
• Disconnect all RCA inputs to the amplifier(s)-if hiss/noise disappears, then plug in the component driving the amplifier and unplug its
inputs. If hiss/noise disappears, go on until the faulty/noisy component is found.
• It is best to set the amplifier's input level as low as possible. The best subjective S/N ratio is obtainable this way. Try to drive as high a
signal level from the head unit as possible.
Protection Led Comes On When The Amplifier Is Powered Up
• Check for shorts on speaker leads.
• Check that the volume control on the head unit is turned down low.
• Remove speaker leads, and reset the amplifier. If the Protection LED still comes on, then the amplifier is faulty.
Amplifier(S) Gets Very Hot
• Check that the minimum speaker impedance for that model is correct.
• Check for speaker shorts.
• Check that there is good airflow around the amplifier. In some appliciations, an external cooling fan may be required.
Distorted Sound
• Check that the level control(s) is set to match the signal level of the head unit.
• Check that all crossover frequencies have been properly set.
• Check for shorts on the speaker leads.
High Squeal Noise From Speakers
• This is almost always caused by a poorly-grounded RCA patch cord.
